4. Carefully position the cabinet upright with the air vents at the
5. Place the UPS cabinet horizontally so that the left end of the
6. Place the EBM cabinet upside down so that the right end of the
7. Position two of the pedestals over the edge of each cabinet so
Powerware 5125 Two-in-One (2400–3000 VA) User's Guide
®
top (see Figure 7).
Continue to "Installing the UPS" on page 24.
Figure 7. Pedestals with One Cabinet
unit is accessible (see Figure 8).
Figure 8. Installing UPS Pedestals with Two Cabinets
unit is accessible (see Figure 9).
Figure 9. Installing EBM Pedestals
that the weight of the unit is evenly distributed. Secure the
pedestals with the screws provided in the accessory kit.
:
