CHAPTER 3 Installation Conditions
3.1
3.2
3.3
This chapter gives the external dimensions, installation conditions, surface
temperature conditions, cable connections, and switch settings of the hard disk
drives.
C141-E282
Dimensions
Mounting
Connections with Host System
3-1

Advertisement

   Related Manuals for Fujitsu C141-E282

   Summary of Contents for Fujitsu C141-E282

  • Page 1: Chapter 3 Installation Conditions

    CHAPTER 3 Installation Conditions Dimensions Mounting Connections with Host System This chapter gives the external dimensions, installation conditions, surface temperature conditions, cable connections, and switch settings of the hard disk drives. C141-E282...

  • Page 2

    Length of the connector pins Dimension from the outer edge of the user tap to the center of the connector pins Dimension from the outer edge of the user tap to the innermost edge of the connector pins Figure 3.1 Dimensions C141-E282...

  • Page 3

    3.2 Mounting 3.2 Mounting For information on mounting, see the "FUJITSU 2.5-INCH HDD INTEGRATION GUIDANCE (C141-E144)." (1) Orientation The disk drives can be mounted in any direction. (2) Frame The MR head bias of the HDD disk enclosure (DE) is zero. The mounting frame is connected to Signal Ground (SG).

  • Page 4

    Note) These dimensions are recommended values; if it is not possible to satisfy them, contact us. Side surface mounting Bottom surface mounting Frame of system Frame of system cabinet cabinet 3.0 or less Screw Screw 3.0 or less Details of A Figure 3.2 Mounting frame structure C141-E282...

  • Page 5

    Because of breather hole mounted to the HDD, do not allow this to close during mounting. Locating of breather hole is shown as Figure 3.3. For breather hole of Figure 3.3, at least, do not allow its around φ 3 to block. Figure 3.3 Location of breather hole C141-E282...

  • Page 6

    Table 3.1. Figure 3.4 shows the temperature measurement point. Figure 3.4 Surface cover temperature measurement points Table 3.1 Surface temperature measurement points and standard values Measurement point Temperature 60 °C max DE cover C141-E282...

  • Page 7

    Static: When handling the device, disconnect the body ground (500 k Ω or greater). Do not touch the printed circuit board, but hold it by the edges. (6) Handling cautions Please keep the following cautions, and handle the HDD under the safety environment. C141-E282...

  • Page 8

    Please observe the tightening torque of the screw strictly. M3 ⋅⋅⋅⋅⋅⋅ 0.49N · m (5 kgf · cm). Recommended equipments Contents Model Maker Wrist strap JX-1200-3056-8 SUMITOMO 3M ESD mat SKY-8A (Color Seiden Mat) Achilles Shock Low shock driver SS-6500 HIOS C141-E282...

  • Page 9: Connections With Host System

    3.3 Connections with Host System 3.3.1 Device connector The disk drive has the SATA interface connectors listed below for connecting external devices. Figure 3.7 shows the locations of these connectors and terminals. SATA interface and power connectors Figure 3.7 Connector locations C141-E282...

  • Page 10

    The connection reliability per number of insertion/extractions varies with the condition of the connection with the host system. Therefore, we recommend that the customer evaluate the connector on the customer's system and select it from the connectors complying with the Serial ATA Revision 2.5 specification. 3-10 C141-E282...

  • Page 11

    Connecting/removing the cable without releasing the SATA interface Latch may lead to connector damage and the loss of the Latch function. Accordingly, be sure to connect/remove the cable while releasing the Latch. C141-E282 3-11...

  • Page 12

    This page is intentionally blank. left...
