  • Page 1 Table of Contents Introduction Instrument Cluster Warning and control lights Gauges Entertainment Systems AM/FM stereo cassette AM/FM stereo with CD CD changer Climate Controls Manual heating and air conditioning Automatic temperature control Rear window defroster Lights Headlamps Turn signal control Bulb replacement Driver Controls Windshield wiper/washer control...
  • Page 2: Table Of Contents

    Table of Contents Seating and Safety Restraints Seating Safety restraints Airbags Child restraints Tires, Wheels and Loading Tire Information Tire Inflation Vehicle loading Trailer towing Recreational towing Driving Starting Brakes Traction control Transmission operation Roadside Emergencies Getting roadside assistance Hazard flasher switch Fuel pump shut-off switch Fuses and relays Changing tires...
  • Page 3: Table Of Contents

    Ford Motor Company. Ford may change the contents without notice and without incurring obligation. Copyright © 2005 Ford Motor Company...
  • Page 4: Introduction

    The more you know and understand about your vehicle, the greater the safety and pleasure you will derive from driving it. For more information on Ford Motor Company and its products visit the following website: • In the United States: www.ford.com •...
  • Page 5 Introduction SAFETY AND ENVIRONMENT PROTECTION Warning symbols in this guide How can you reduce the risk of personal injury to yourself or others? In this guide, answers to such questions are contained in comments highlighted by the warning triangle symbol. These comments should be read and observed.
  • Page 6 • where the driver was positioning the steering wheel. To access this information, special equipment must be directly connected to the recording modules. Ford Motor Company and Ford of Canada do not access event data recorder information without obtaining consent,...
  • Page 7 Introduction Special instructions For your added safety, your vehicle is fitted with sophisticated electronic controls. Please read the section Supplemental restraint system (SRS) in the Seating and Safety Restraints chapter. Failure to follow the specific warnings and instructions could result in personal injury. Front seat mounted rear-facing child or infant seats should NEVER be placed in front of an active passenger air bag.
  • Page 8 Introduction These are some of the symbols you may see on your vehicle. Vehicle Symbol Glossary Safety Alert See Owner’s Guide Fasten Safety Belt Air Bag-Front Air Bag-Side Child Seat Child Seat Installation Child Seat Lower Warning Anchor Child Seat Tether Brake System Anchor Brake Fluid -...
  • Page 9 Introduction Vehicle Symbol Glossary Power Windows Power Window Lockout Front/Rear Interior Luggage Child Safety Door Compartment Release Lock/Unlock Symbol Panic Alarm Engine Oil Engine Coolant Engine Coolant Temperature Do Not Open When Hot Battery Avoid Smoking, Flames, Battery Acid or Sparks Explosive Gas Fan Warning Maintain Correct Fluid...
  • Page 10: Instrument Cluster

    Instrument Cluster WARNING LIGHTS AND CHIMES Warning lights and gauges can alert you to a vehicle condition that may become serious enough to cause expensive repairs. A warning light may illuminate when a problem exists with one of your vehicle’s functions. Many lights will illuminate when you start your vehicle to make sure the bulb works.
  • Page 11 Instrument Cluster Brake system warning light: To confirm the brake system warning light is functional, it will BRAKE momentarily illuminate when the ignition is turned to the ON position when the engine is not running, or in a position between ON and START, or by applying the parking brake when the ignition is turned to the ON position.
  • Page 12 Instrument Cluster Engine oil pressure: Illuminates when the oil pressure falls below the normal range, refer to Engine oil in the Maintenance and Specifications chapter. Traction Control active (if equipped): Flashes when the Traction Control is active. If the light remains on a malfunction has been detected;...
  • Page 13: Gauges

    Instrument Cluster GAUGES Speedometer: Indicates the current vehicle speed. Engine coolant temperature gauge: Indicates engine coolant temperature. At normal operating temperature, the needle will be in the normal range (between “H” and “C”). If it enters the red section, the engine is overheating. Stop the vehicle as soon as safely possible, switch off the engine and let the engine cool.
  • Page 14 Instrument Cluster Tachometer: Indicates the engine speed in revolutions per minute. Driving with your tachometer pointer continuously at the top of the scale may damage the engine. Fuel gauge: Indicates approximately how much fuel is left in the fuel tank (when the ignition is in the ON position).
  • Page 15: Entertainment Systems

    Entertainment Systems AUDIO SYSTEMS AM/FM stereo cassette/MACH AUDIO SYSTEM with AM/FM stereo cassette (if equipped) 1. Tape: Insert the cassette with the opening to the right. If a tape is already inserted into the system, press TAPE to begin tape play. 2.
  • Page 16 Entertainment Systems 5. Treble: Press TREB decrease/increase the treble output. 6. Balance: Press to shift sound to the left/right speakers. 7. Fade: Press to shift FADE sound to the rear/front speakers. 8. Scan: Press SCAN to hear a brief sampling of all listenable radio stations, tape or CD selections.
  • Page 17 Entertainment Systems 16. Tune: Works in radio mode or CD mode. Press to change frequency down/up or previous/next disc. 17. Cassette door: Insert a cassette into the cassette door. 18. Seek: Press and release for previous/next listenable radio station, tape selection or CD track.
  • Page 18 Entertainment Systems Audio System with AM/FM Stereo/Single CD Player (if equipped) 1. Clock: To set the hour, press and hold the H control. When the desired hour appears, release the control. To set the minute, press and hold the M control. When the desired minute appears, release the control.
  • Page 19 Entertainment Systems 6. Scan: Press to hear a brief sampling of all listenable radio stations or CD tracks. Press again to stop. 7. CD: Press to play a CD. Press again to toggle between single CD mode and CD Changer mode (if equipped).
  • Page 20: Cd Changer

    Entertainment Systems 16. EJ (Eject): Press to eject a CD. 17. AM/FM: Press to choose a frequency band (AM/FM1/FM2). CD changer (if equipped) Your CD changer is either located in the trunk or the center console. 1. Slide the door to access the CD changer magazine.
  • Page 21 Entertainment Systems 5. Line up the CD with the groove of the disc holder. Ensure that the label on the CD faces downwards. 6. Press the disc holder until it locks securely into the magazine. Ensure that the disc holder is evenly inserted and at the same level as the magazine (A).
  • Page 22 (12 cm) audio compact discs only. Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the CD player.
  • Page 23: Climate Controls

    Climate Controls MANUAL HEATING AND AIR CONDITIONING SYSTEM (IF EQUIPPED) 1. Temperature selection: Controls the temperature of the airflow in the vehicle. 2. Passenger airbag indicator light: Refer to Front passenger sensing system in the Seating and Safety Restraints chapter. 3.
  • Page 24 Climate Controls Operating tips • To reduce fog build up on the windshield during humid weather, place the air flow selector in the position. • To reduce humidity buildup within the cabin, do not drive with the selector in the OFF or MAX A/C position when outside temperature is below 40°F (3°C).
  • Page 25: Automatic Temperature Control

    Climate Controls AUTOMATIC TEMPERATURE CONTROL SYSTEM (IF EQUIPPED) 1. OFF: Outside air is shut out and the climate control system is turned off. 2. A/C: Press to activate/deactivate air conditioning. Use with the recirculated air to improve cooling performance and efficiency. Engages automatically in the AUTO, F (defrost) and (floor/defrost)
  • Page 26 Climate Controls 6. AUTO: Press to engage full automatic operation, and select the desired temperature using the temperature control. The system will automatically determine fan speed, airflow location, A/C on or off, and outside or recirculated air, to heat or cool the vehicle to reach the desired temperature.
  • Page 27: Rear Window Defroster

    Climate Controls • To reduce humidity build up inside the vehicle, do not drive with the airflow selector in the OFF position, or with (recirculated air) engaged without A/C engaged as well. • Do not put objects under the front seats that will interfere with the airflow to the back seats.
  • Page 28 • Protects the climate control components from particle deposits. The filter is located just in front of the windshield under the cowl grille on the passenger side of the vehicle. For more information, or to replace the filter, see your authorized Ford dealer. 2006 Taurus (tau)
  • Page 29: Lights

    Lights HEADLAMP CONTROL Turns the lamps off. Turns on the parking lamps, instrument panel lamps, license plate lamps and tail lamps. Turns the headlamps on. Autolamp control (if equipped) The autolamp system provides light sensitive automatic on-off control of the exterior lights normally controlled by the headlamp control.
  • Page 30 Lights High beams Push the lever toward the instrument panel to activate. Pull the lever towards you to deactivate. Flash to pass Pull toward you slightly to activate and release to deactivate. PANEL DIMMER CONTROL Use to adjust the brightness of the instrument panel and all applicable switches in the vehicle during headlamp and parklamp operation.
  • Page 31 Lights • (1) 8 feet (2.4 meters) • (2) Center height of lamp to ground • (3) 25 feet (7.6 meters) • (4) Horizontal reference line 2. Measure the height of the headlamp bulb center from the ground and mark an 8 foot (2.4 meter) horizontal reference line on the vertical wall or screen at this height (a piece of masking tape works well).
  • Page 32: Turn Signal Control

    Lights To see a clearer light pattern for adjusting, you may want to block the light from one headlamp while adjusting the other. 5. Locate the vertical adjuster on each headlamp. Using a 4 mm wrench, turn the adjuster either clockwise (to adjust down) or counterclockwise (to adjust up).
  • Page 33: Bulb Replacement

    Lights the lamp will remain on for 25 seconds after the door is shut. If any other door has been opened from the inside, the lamp will shut off immediately after the door is closed. To turn on the dome lamp manually, move the panel dimmer control to the full upright position, past detent.
  • Page 34 Lights Number Function Trade number of bulbs Front park/turn lamp 3457 AK (amber) Headlamp 9007 QL (9007 LL optional) Tail lamp/brake/turn lamp 3157K Backup lamp License plate lamp Must replace the hi-mount brake lamp High-mount brake lamp assembly Dome lamp 12V6W Dome/map lamp Visor vanity lamp...
  • Page 35 Lights Replacing headlamp bulbs To remove the headlamp bulb: 1. Make sure headlamp switch is in OFF position and open the hood. 2. Remove the bolt (1) from the headlamp housing. 3. At the back of the headlamp, pry up and remove the two retainer pins to release the headlamp assembly from the vehicle and pull headlamp forward.
  • Page 36 Lights 5. Disconnect the electrical connector from the bulb by pulling rearward. 6. Remove the bulb retaining ring by rotating it counterclockwise. 7. Remove the old bulb from the lamp assembly by pulling it straight out of the lamp assembly. To install the new bulb: Handle a halogen headlamp bulb carefully and keep out of children’s reach.
  • Page 37 Lights 2. Install the bulb retaining ring over the plastic base and lock the ring by rotating clockwise until it snaps into place. 3. Connect the electrical connector to the bulb. 4. Install the protective dust shield and lock the shield by rotating it clockwise until it locks into position.
  • Page 38 Lights 5. Carefully pull bulb straight out of the socket and push in the new bulb. 6. Install the bulb socket into the lamp assembly by rotating it clockwise. 7. Carefully position the headlamp assembly onto the vehicle. 8. Hold the headlamp assembly snugly against the vehicle and install the retainer pins straight down to lock the lamp into place.
  • Page 39 Lights To replace the LED module: 1. Remove the two outboard grommets from the inside of the decklid. 2. On the inside of the decklid, remove the three nuts that hold the spoiler on and remove the spoiler. 3. On the underside of the spoiler, remove the two decorative screw covers (on the LED module).
  • Page 40 Lights Replacing tail/brake/turn signal/backup lamp bulbs The tail lamp, brake lamp, turn signal lamp and backup lamp bulbs are located in the same portion of the tail lamp assembly. Follow the same steps to replace either bulb. 1. Make sure headlamp switch is in OFF position and open trunk and remove two plastic mushroom nuts, five push pins and the plastic cover...
  • Page 41: Driver Controls

    Driver Controls MULTI-FUNCTION LEVER Windshield wiper: Rotate the end of the control away from you to increase the speed of the wipers; rotate towards you to decrease the speed of the wipers. Windshield washer: Push the end of the stalk: •...
  • Page 42 Driver Controls ILLUMINATED VISOR MIRROR (IF EQUIPPED) Lift the mirror cover to turn on the visor mirror lamp. AUXILIARY POWER POINT (12VDC) Power outlets are designed for accessory plugs only. Do not insert any other object in the power outlet as this will damage the outlet and blow the fuse.
  • Page 43: Power Windows

    • Coin holder slots • Compact disc changer (if equipped) • Tissue holder • Rear ashtray (see your Ford, Lincoln Mercury dealer to obtain rear ashtray Use only soft cups in the cupholder. Hard objects can injure you in a collision.
  • Page 44: Mirrors

    Driver Controls One touch down Allows the driver’s window to open fully without holding the control down. Press completely down on AUTO and release quickly. Press again to stop. Window lock The window lock feature allows only the driver to operate the power windows.
  • Page 45: Speed Control

    Driver Controls POWER SIDE VIEW MIRRORS To adjust your mirrors: 1. Select L to adjust the left mirror or R to adjust the right mirror. 2. Move the control in the direction you wish to tilt the mirror. 3. Return to the center position to disable the adjust function.
  • Page 46 Driver Controls 3. Press the SET ACC control and release it. 4. Take your foot off the accelerator pedal. 5. The CRUISE indicator light on the instrument cluster will turn on. Note: • Vehicle speed may vary momentarily when driving up and down a steep hill.
  • Page 47 Driver Controls Increasing speed while using speed control There are three ways to set a higher speed: • Press and hold the SET ACC control until you get to the desired speed, then release the control. • Press and release the SET ACC control to operate the Tap-Up function.
  • Page 48 Driver Controls Turning off speed control There are two ways to turn off the speed control: • Depress the brake pedal. This will not erase your vehicle’s previously set speed. • Press the speed control OFF control. Note: When you turn off the speed control or the ignition, your speed control set speed memory is erased.
  • Page 49 Driver Controls HOMELINK WIRELESS CONTROL SYSTEM (IF EQUIPPED) The HomeLink Wireless Control System, located on the driver’s visor, provides a convenient way to replace up to three hand-held transmitters with a single built-in device. This feature will learn the radio frequency codes of most transmitters to operate garage doors, entry gate operators, security systems, entry door locks, and home or office lighting.
  • Page 50 Driver Controls 1. Press and hold the two outside buttons releasing only when the indicator light begins to flash after 20 seconds. Do not repeat Step 1 to program additional hand-held transmitters to the remaining two HomeLink buttons. This will erase previously programmed hand-held transmitter signals into HomeLink .
  • Page 51 Driver Controls Note: There are 30 seconds in which to initiate Step 8. 8. Return to the vehicle and firmly press, hold for two seconds and release the HomeLink button. Repeat the press/hold/release sequence again, and, depending on the brand of the garage door opener (or other rolling code equipped device), repeat this sequence a third time to complete the programming.
  • Page 52 Driver Controls Operating the HomeLink Wireless Control System To operate, simply press and release the appropriate HomeLink button. Activation will now occur for the trained product (garage door, gate operator, security system, entry door lock, or home or office lighting etc.).
  • Page 53: Message Center

    Driver Controls MESSAGE CENTER With the ignition in the ON position, the message center, located on your instrument cluster, displays important vehicle information through a constant monitor of vehicle systems. You may select display features on the message center for a display of status preceded by a brief indicator chime.
  • Page 54 Driver Controls The DTE function will display LOW FUEL LEVEL and sound a tone for one second when you have approximately 50 miles (80 km) to empty. If you RESET this warning message, this display and tone will return within 10 minutes. DTE is calculated using a running average fuel economy, which is based on your recent driving history of 500 miles (800 km).
  • Page 55 Driver Controls Trip elapsed drive time Select this function from the INFO menu to display a timer. To operate the Trip Elapsed Drive Time perform the following: 1. Press and release RESET in order to start the timer. 2. Press and release RESET to pause the timer. 3.
  • Page 56 Driver Controls Most geographic areas (zones) have a magnetic north compass point that varies slightly from the northerly direction on maps. This variation is four degrees between adjacent zones and will become noticeable as the vehicle crosses multiple zones. A correct zone setting will eliminate this error.
  • Page 57 Driver Controls 6. Release the RESET control, then slowly press RESET down again. 7. Press the SET control repeatedly until the correct zone setting for your geographic location is displayed on the message center. To exit the zone setting mode press and release the RESET control.
  • Page 58 Driver Controls 2. Pressing the RESET control cycles the message center through each of the language choices. 3. Press and hold the RESET control to set the language choice. Units (English/Metric) 1. Select this function from the SETUP menu for the current units to be displayed.
  • Page 59 Driver Controls 9. TRACTION CONTROL (if equipped) System warnings System warnings alert you to possible problems or malfunctions in your vehicle’s operating systems. In the event of a multiple warning situation, the message center will cycle the display to show all warnings by displaying each one for several seconds.
  • Page 60 Driver Controls Warnings Status Low brake fluid Warning returns after the ignition key is turned from OFF to RUN Check Traction Control (if equipped) Data error DRIVER’S DOOR AJAR. Displayed when the driver’s door is not completely closed. PASSENGER DOOR AJAR. Displayed when the passenger side door is not completely closed.
  • Page 61 Driver Controls CHECK FUEL CAP. Displayed when the fuel filler cap is not properly installed. Check the fuel filler cap for proper installation. Refer to Fuel filler cap in the Maintenance and Specifications chapter. CHECK CHARGING SYSTEM. Displayed when the electrical system is not maintaining proper voltage.
  • Page 62 Driver Controls POSITIVE RETENTION FLOOR MAT Position the driver floor mat so that the eyelet is over the pointed end of the retention post and rotate forward to lock in. Make sure that the mat does not interfere with the operation of the accelerator or the brake pedal.
  • Page 63: Locks And Security

    Locks and Security KEYS The key operates all locks on your vehicle. In case of loss, replacement keys are available from your dealer. You should always carry a second key with you in a safe place in case you require it in an emergency. Refer to the SecuriLock passive anti-theft system section in this chapter for more information.
  • Page 64 Locks and Security 1. Turn the ignition to the 4 (ON) position, then press the power door UNLOCK control 3 times. 2. Turn the ignition to the 3 (OFF) position, then press the power door UNLOCK control 3 times. 3. Turn the ignition to the 4 (ON) position.
  • Page 65 Locks and Security Adults are advised to familiarize themselves with the operation and location of the release handle. To open the luggage compartment door (lid) from within the luggage compartment, pull the illuminated “T” shaped handle and push up on the trunk lid.
  • Page 66 Locks and Security REMOTE ENTRY SYSTEM (IF EQUIPPED) This device complies with part 15 of the FCC rules and with RS-210 of Industry Canada. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
  • Page 67 Locks and Security The inside lights will not turn off if: • they have been turned on using the dimmer control or • any door is open. The battery saver feature will turn off the interior lamps 10 minutes after the ignition is turned to the 3 (OFF) position.
  • Page 68 Locks and Security To replace the battery: 1. Twist a thin coin between the two halves of the remote entry transmitter near the key ring. DO NOT TAKE THE RUBBER COVER AND CIRCUIT BOARD OFF THE FRONT HOUSING OF THE REMOTE ENTRY TRANSMITTER.
  • Page 69 Locks and Security To reprogram the remote entry transmitters: 1. Ensure the vehicle is electronically unlocked. 2. Put the key in the ignition. 3. Turn the key from the 2 (LOCK) position to 3 (OFF). 4. Cycle eight times rapidly (within 10 seconds) between the 3 (OFF) position and 4 (ON).
  • Page 70 Locks and Security • any door is open. The battery saver will shut off the interior lamps 10 minutes after the ignition has been turned to the 3 (OFF) position. Perimeter lamps illuminated entry On vehicles equipped with the remote entry system, the following items will illuminate: •...
  • Page 71 Locks and Security Note: The puddle lamps (if equipped) cannot be deactivated; performing this procedure will only deactivate the head, park and tail lamps. KEYLESS ENTRY SYSTEM (IF EQUIPPED) You can use the keyless entry keypad to: 7 8 9 0 •...
  • Page 72 Locks and Security 2. Press and release the 1 • 2 within five seconds of completing Step 1. 3. Press and hold the 1 • 2 for two seconds to erase the customer programmed codes. All personal codes are now erased and only the factory set 5–digit code will work.
  • Page 73: Anti-Theft System

    Note: The SecuriLock passive anti-theft system is not compatible with non-Ford aftermarket remote start systems. Use of these systems may result in vehicle starting problems and a loss of security protection. Note: Large metallic objects, electronic devices that are used to purchase gasoline or similar items, or a second coded key on the same key chain may cause vehicle starting issues.
  • Page 74 Locks and Security • When the ignition is in the 2 (LOCK) position, the indicator will flash once every 2 seconds to indicate the SecuriLock system is functioning as a theft deterrent. • When the ignition is in the 4 (ON) position, the indicator will glow for 3 seconds, then turn off to indicate normal system functionality.
  • Page 75 Locks and Security • You must have two previously programmed coded keys (keys that already operate your vehicle’s engine) and the new unprogrammed key(s) readily accessible. • If no previously programmed coded keys are available, you must take your vehicle to your dealer to have the spare key(s) programmed. 1.
  • Page 76 Locks and Security Arming the system When armed, this system will respond if unauthorized entry is attempted. When unauthorized entry occurs, the system will flash the headlamps and/or parking lamps and will sound the horn. The system is ready to arm whenever key is removed from the ignition. Either of the following actions will prearm the alarm system: •...
  • Page 77: Seating And Safety Restraints

    Seating and Safety Restraints SEATING Notes: Reclining the seatback can cause an occupant to slide under the seat’s safety belt, resulting in severe personal injuries in the event of a collision. Do not pile cargo higher than the seatbacks to reduce the risk of injury in a collision or sudden stop.
  • Page 78 Seating and Safety Restraints To lower the head restraint: • Push the release control. • Push down on the head restraint. Using the manual lumbar support (if equipped) The lumbar control is located on the front of the seat cushion. Turn to adjust lumbar support.
  • Page 79 Seating and Safety Restraints Pull lever up to adjust seatback. Before returning the seatback to its original position, make sure that cargo or any objects are not trapped behind the seatback. After returning the seatback to its original position, pull on the seatback to ensure that it has fully latched.
  • Page 80: Safety Restraints

    Seating and Safety Restraints REAR SEATS 2nd seat/split-folding rear seat (if equipped) Pull the loop forward to release the seatback and then fold the seatback down. When raising the seatback(s), make sure you hear the seat latch into place. Make sure that the safety belt for the rear center passenger is properly routed over the rear seatback.
  • Page 81 Seating and Safety Restraints • Driver’s seat position sensor. • Front crash severity sensor. • Front passenger sensing system • Passenger Airbag Off indicator light. • Restraints Control Module (RCM) with impact and safing sensors. • Restraint system warning light and back-up tone. •...
  • Page 82 Seating and Safety Restraints allows your Personal Safety System to distinguish between different levels of crash severity and modify the deployment strategy of the dual-stage airbags and safety belt pretensioners. Driver’s seat position sensor The driver’s seat position sensor allows your Personal Safety System tailor the deployment level of the driver dual-stage airbag based on seat position.
  • Page 83 Seating and Safety Restraints will light and stay lit to remind you that the front passenger frontal airbag is off. See Front passenger sensing system in the airbags section of this chapter. Front safety belt usage sensors The front safety belt usage sensors detect whether or not the driver and front outboard passenger safety belts are fastened.
  • Page 84 Seating and Safety Restraints • A series of five beeps will be heard. The tone pattern will repeat periodically until the problem and warning light are repaired. If any of these things happen, even intermittently, have the Personal Safety System serviced at your dealership or by a qualified technician immediately.
  • Page 85 Seating and Safety Restraints Always transport children 12 years old and under in the back seat and always properly use appropriate child restraints. Combination lap and shoulder belts 1. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) until you hear a snap and feel it latch.
  • Page 86 Seating and Safety Restraints Vehicle sensitive mode This is the normal retractor mode, which allows free shoulder belt length adjustment to your movements and locking in response to vehicle movement. For example, if the driver brakes suddenly or turns a corner sharply, or the vehicle receives an impact of approximately 5 mph (8 km/h) or more, the combination safety belts will lock to help reduce forward movement of the driver and passengers.
  • Page 87 Seating and Safety Restraints How to disengage the automatic locking mode Ford Motor Company recommends that all safety belt assemblies and attaching hardware should be inspected by a qualified technician after any collision. Safety belt assemblies not in use during a collision should also be inspected and replaced if either damage or improper operation is noted.
  • Page 88 Seating and Safety Restraints activated, the safety belt pretensioner for that seating position will be activated if the seat belt is properly buckled. The driver and front outboard passenger safety belt system (including retractors, buckles and height adjusters) must be replaced if the vehicle is involved in a collision that results in the activation of the safety belt pretensioners.
  • Page 89 Seating and Safety Restraints Position the safety belt height adjusters so that the belt rests across the middle of your shoulder. Failure to adjust the safety belt properly could reduce the effectiveness of the seat belt and increase the risk of injury in a collision. Lap belts Adjusting the center front lap belt The center front lap belt does not adjust automatically.
  • Page 90 Seating and Safety Restraints Conditions of operation If... Then... The driver’s safety belt is not The safety belt warning light buckled before the ignition illuminates 1-2 minutes and the switch is turned to the ON warning chime sounds 4-8 seconds. position...
  • Page 91 Seating and Safety Restraints If... Then... The driver’s and front passenger’s The BeltMinder feature will not safety belts are buckled before the activate. ignition switch is turned to the ON position or less than 1-2 minutes have elapsed since the ignition switch has been turned ON...
  • Page 92 Seating and Safety Restraints Reasons given... Consider... “I was in a hurry” Prime time for an accident. BeltMinder reminds us to take a few seconds to buckle up. “Safety belts don’t Safety belts, when used properly, reduce risk of work” death to front seat occupants by 45% in cars, and by 60% in light trucks.
  • Page 93 Seating and Safety Restraints Read Steps 1 - 4 thoroughly before proceeding with the deactivation/activation programming procedure. Note: The driver and front passenger BeltMinder features must be disabled/enabled separately. Both cannot be disable/enabled during the same key cycle. The driver and front passenger BeltMinder features can be deactivated/activated by performing the following procedure: Before following the procedure, make sure that:...
  • Page 94 (if equipped), shoulder belt guide on seatback (if equipped), child safety seat LATCH and tether anchors, and attaching hardware, should be inspected after a collision. Ford Motor Company recommends that all safety belt assemblies in use in vehicles involved in a collision be replaced.
  • Page 95: Airbags

    Seating and Safety Restraints AIRBAG SUPPLEMENTAL RESTRAINT SYSTEM (SRS) The airbag supplemental restraint system (SRS) is designed to work in conjunction with the safety belts to help protect the driver and front outboard passenger from certain upper body injuries. The term “supplemental restraint”...
  • Page 96 Seating and Safety Restraints Important supplemental restraint system precautions Airbags DO NOT inflate slowly or gently and the risk of injury from a deploying airbag is greatest close to the trim covering the airbag module. All occupants of the vehicle, including the driver, should always properly wear their safety belts, even when an air bag supplemental restraint system (SRS) is provided.
  • Page 97 Seating and Safety Restraints Do not attempt to service, repair, or modify the airbag supplemental restraint system (SRS) or its fuses. See your Ford or Lincoln Mercury dealer. The front passenger airbag is not designed to offer protection to an occupant in the center front seating position.
  • Page 98 Seating and Safety Restraints How do the airbag supplemental restraints work? The airbags inflate and deflate rapidly upon activation. After airbag deployment, it is normal to notice a smoke-like, powdery residue or smell the burnt propellant. This may consist of cornstarch, talcum powder (to lubricate the bag) or sodium compounds (e.g., baking soda) that result from the...
  • Page 99 Seating and Safety Restraints that are part of the front passenger’s seat and safety belt. The sensors are designed to detect the presence of a properly-seated occupant and determine if the front passenger’s frontal airbag should be enabled (may inflate) or not. The front passenger sensing system is designed to meet the regulatory requirements of Federal Motor Vehicle Safety Standard (FMVSS) 208 and is designed to turn off the front passenger’s frontal airbag if:...
  • Page 100 Seating and Safety Restraints The front passenger sensing system is designed to enable (may inflate) the right front passenger’s frontal airbag anytime the system senses that a person of adult size is sitting properly in the front passenger seat. When the passenger sensing system has allowed the airbag to be enabled, the indicator will be unlit and stay unlit to remind you that the airbag is enabled (may inflate).
  • Page 101 If it is necessary to modify an advanced front airbag system to accommodate a person with disabilities, contact the Ford Customer Relationship Center at the phone number shown in the Customer Assistance section of this Owners Guide.
  • Page 102 Do not attempt to service, repair, or modify the airbag SRS, its fuses or the seat cover on a seat containing an airbag. See your Ford or Lincoln Mercury dealer. All occupants of the vehicle should always wear their safety belts even when an airbag SRS is provided.
  • Page 103 Seating and Safety Restraints How does the side airbag system work? The side airbag system consists of the following: • An inflatable nylon bag (airbag) with a gas generator concealed behind the outboard bolster of the driver and front passenger seatbacks.
  • Page 104: Child Restraints

    Seating and Safety Restraints If the side airbag has deployed, the airbag will not function again. The side airbag system (including the seat) must be inspected and serviced by a qualified technician in accordance with the vehicle service manual. If the airbag is not replaced, the unrepaired area will increase the risk of injury in a collision.
  • Page 105 To improve the fit of both the lap and shoulder belt on children who have outgrown child safety seats, Ford Motor Company recommends use of a belt-positioning booster. Booster seats position a child so that safety belts fit better. They lift the child up so that the lap belt rests low across the hips and the knees bend comfortably.
  • Page 106 Seating and Safety Restraints • Can the child sit all the way back against the vehicle seat back with knees bent comfortably at the edge of the seat without slouching? • Does the lap belt rest low across the hips? •...
  • Page 107 Seating and Safety Restraints The shoulder belt should cross the chest, resting snugly on the center of the shoulder. The lap belt should rest low and snug across the hips, never up high across the stomach. If the booster seat slides on the vehicle seat, placing a rubberized mesh sold as shelf or carpet liner under the booster seat may improve this condition.
  • Page 108 80 pounds (36 kg) using an upper torso harness and a belt-positioning booster. Ford Motor Company recommends the use of a child safety seat having a top tether strap. Install the child safety seat in a seating position with LATCH and tether anchors.
  • Page 109 Seating and Safety Restraints Installing child safety seats with combination lap and shoulder belts Airbags can kill or injure a child in a child seat. NEVER place a rear-facing child seat in front of an active airbag. If you must use a forward-facing child seat in the front seat, move the seat all the way back.
  • Page 110 Seating and Safety Restraints 3. While holding the shoulder and lap belt portions together, route the tongue through the child seat according to the child seat manufacturer’s instructions. Be sure the belt webbing is not twisted. 4. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) for that seating position until...
  • Page 111 Seating and Safety Restraints 7. Pull the lap belt portion across the child seat toward the buckle and pull up on the shoulder belt while pushing down with your knee on the child seat. 8. Allow the safety belt to retract to remove any slack in the belt.
  • Page 112 Seating and Safety Restraints 6. Before placing the child into the child seat, forcibly tilt the child seat from side to side and in forward direction to make sure that the seat is securely held in place. To check this, grab the seat at the belt path and attempt to move it side to side and forward and back.
  • Page 113 Seating and Safety Restraints 4. Open the tether anchor cover. 5. Clip the tether strap to the anchor as shown. If the tether strap is clipped incorrectly, the child safety seat may not be retained properly in the event of a collision. 6.
  • Page 114 Seating and Safety Restraints Your vehicle has LATCH anchors for child seat installation at the seating positions marked with the child seat symbol. All the LATCH lower anchors are equally spaced, so that a single LATCH child seat can be installed at any rear seating position.
  • Page 115 Seating and Safety Restraints lifting the front of the child seat. Keeping the child seat just touching the vehicle seat gives the best protection in a severe crash. Each time you use the safety seat, check that the seat is properly attached to the lower anchors and tether anchor.
  • Page 116: Tires, Wheels And Loading

    10 to 12 inches or limited production tires as defined in Title 49 Code of Federal Regulations Part 575.104(c)(2). U.S. Department of Transportation-Tire quality grades: The U.S. Department of Transportation requires Ford Motor Company to give you the following information about tire grades exactly as the government has written it.
  • Page 117 Tires, Wheels and Loading The traction grade assigned to this tire is based on straight-ahead braking traction tests, and does not include acceleration, cornering, hydroplaning or peak traction characteristics. Temperature A B C The temperature grades are A (the highest), B and C, representing the tire’s resistance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a specified indoor laboratory test wheel.
  • Page 118 (including spare, if equipped). Inflate all tires to the inflation pressure recommended by Ford Motor Company. Inspecting your tires Periodically inspect the tire treads for uneven or excessive wear and...
  • Page 119 Always inflate your tires to the Ford recommended inflation pressure even if it is less than the maximum inflation pressure information found on the tire. The Ford recommended tire inflation pressure is found on the Safety Compliance Certification Label which is located on the B-Pillar or the edge of the driver’s door.
  • Page 120: Tire Information

    Tires, Wheels and Loading which is located on the B-Pillar or the edge of the driver’s door. The cold inflation pressure should never be set lower than the recommended pressure on the Safety Compliance Certification Label. When weather temperature changes occur, tire inflation pressures also change.
  • Page 121 Only use replacement tires and wheels that are the same size and type (such as P-metric versus LT-metric or all-season versus all-terrain) as those originally provided by Ford. Use of any tire or wheel not recommended by Ford can affect the safety and performance of your vehicle, which could result in an increased risk of loss of vehicle control, vehicle rollover, personal injury and death.
  • Page 122 Tires, Wheels and Loading Information on “P” type tires P215/65R15 95H is an example of a tire size, load index and speed rating. The definitions of these items are listed below. (Note that the tire size, load index and speed rating for your vehicle may be different from this example.) 1.
  • Page 123 Tires, Wheels and Loading Note: You may not find this information on all tires because it is not required by federal law. Letter rating Speed rating - mph (km/h) 81 mph (130 km/h) 87 mph (140 km/h) 99 mph (159 km/h) 106 mph (171 km/h) 112 mph (180 km/h) 118 mph (190 km/h)
  • Page 124 Tires, Wheels and Loading 11. Maximum Load: Indicates the maximum load in kilograms and pounds that can be carried by the tire. Refer to the Safety Compliance Certification Label, which is located on the B-Pillar or the edge of the driver’s door, for the correct tire pressure for your vehicle.
  • Page 125 Tires, Wheels and Loading Additional information contained on the tire sidewall for “LT” type tires “LT” type tires have some additional information beyond those of “P” type tires; these differences are described below: 1. LT: Indicates a tire, designated by the Tire and Rim Association (T&RA), that is intended for service on light trucks.
  • Page 126 Tires, Wheels and Loading Information on “T” type tires “T” type tires have some additional information beyond those of “P” type tires; these differences are described below: T145/80D16 is an example of a tire size. Note: The temporary tire size for your vehicle may be different from this example.
  • Page 127 Tires, Wheels and Loading the road in adverse (wet, snowy, etc.) conditions. Visually check your tires for uneven wear, looking for high and low areas or unusually smooth areas. Also check for signs of tire damage. When the tread is worn down to 1/16th of an inch (2 mm), tires must be replaced to prevent your vehicle from skidding and hydroplaning.
  • Page 128 If your vehicle seems to pull to one side when you’re driving, the wheels may be out of alignment. Have a qualified technician at a Ford or Lincoln Mercury dealer check the wheel alignment periodically.
  • Page 129 Sometimes irregular tire wear can be corrected by rotating the tires. Note: If your tires show uneven wear ask a qualified technician at a Ford or Lincoln Mercury dealership to check for and correct any wheel misalignment, tire imbalance or mechanical problem involved before tire rotation.
  • Page 130: Vehicle Loading

    Tires, Wheels and Loading SNOW TIRES AND CHAINS Snow tires must be the same size and grade as the tires you currently have on your vehicle. The tires on your vehicle have all weather treads to provide traction in rain and snow. However, in some climates, you may need to use snow tires and chains.
  • Page 131 Tires, Wheels and Loading Payload – is the combined weight of cargo and passengers that the vehicle is carrying. The maximum payload for your vehicle can be found on the Tire Label on the B-Pillar or the edge of the driver’s door. Look for “THE COMBINED WEIGHT OF OCCUPANTS AND CARGO SHOULD NEVER EXCEED XXX kg OR XXX lb.”...
  • Page 132 Tires, Wheels and Loading Example only: Cargo Weight – includes all weight added to the Base Curb Weight, including cargo and optional equipment. When towing, trailer tongue load or king pin weight is also part of cargo weight. 2006 Taurus (tau) Owners Guide (post-2002-fmt) USA (fus)
  • Page 133 Tires, Wheels and Loading GAW (Gross Axle Weight) – is the total weight placed on each axle (front and rear) – including vehicle curb weight and all payload. GAWR (Gross Axle Weight Rating) – is the maximum allowable weight that can be carried by a single axle (front or rear). These numbers are shown on the Safety Compliance Certification Label located on the B-Pillar or the edge of the driver’s door.
  • Page 134 Tires, Wheels and Loading GVWR (Gross Vehicle Weight Rating) – is the maximum allowable weight of the fully loaded vehicle (including all options, equipment, passengers and cargo). The GVWR is shown on the Safety Compliance Certification Label located on the B-Pillar or the edge of the driver’s door.
  • Page 135 Tires, Wheels and Loading mandatory options, no cargo (internal or external), a tongue load of 10–15% (conventional trailer) or king pin weight of 15–25% (fifth wheel trailer), and driver only (150 lb. [68 kg]). Consult your dealership (or the RV and Trailer Towing Guide provided by your dealership) for more detailed information.
  • Page 136: Trailer Towing

    Your vehicle is classified as a light duty towing vehicle. Your vehicle does not come from the factory fully equipped to tow. No towing packages are available through Ford or Mercury/Lincoln dealers. Do not tow a trailer until your vehicle has been driven at least 800 km (500 miles).
  • Page 137 Tires, Wheels and Loading Passenger Luggage Load - #/lb. (kg) Load - lb. (kg) Trailer Wt.- lb. (kg) 5 /750 (340) 800 (365) 4/600 (270) 150 (70) 800 (365) 2/300 (135) 150 (70) 1100 (500) 2/300 (135) 1250 (565) The above chart is based on the specified vehicle at a maximum GCW (Vehicle weight + Trailer weight) equal to 4,950 lb.
  • Page 138 Tires, Wheels and Loading Do not connect a trailer’s hydraulic brake system directly to your vehicle’s brake system. Your vehicle may not have enough braking power and your chances of having a collision greatly increase. The braking system of the tow vehicle is rated for operation at the GVWR not GCWR.
  • Page 139: Recreational Towing

    Tires, Wheels and Loading • To aid in engine/transmission cooling and A/C efficiency during hot weather while stopped in traffic, place the gearshift lever in P (Park). • Vehicles with trailers should not be parked on a grade. If you must park on a grade, place wheel chocks under the trailer’s wheels.
  • Page 140: Driving

    Driving STARTING Positions of the ignition 1. ACCESSORY, allows the electrical accessories such as the radio to operate while the engine is not running. 2. LOCK, locks the automatic transmission gearshift lever and allows key removal. 3. OFF, shuts off the engine without locking the steering wheel.
  • Page 141 Driving Do not park, idle, or drive your vehicle in dry grass or other dry ground cover. The emission system heats up the engine compartment and exhaust system, which can start a fire. Do not start your vehicle in a closed garage or in other enclosed areas.
  • Page 142 Driving • Make sure the parking brake is set. • Make sure the gearshift is in P P R N (Park). • Turn the key to 4 (ON) without turning the key to 5 (START). 2006 Taurus (tau) Owners Guide (post-2002-fmt) USA (fus)
  • Page 143 Cold starting performance can also be improved by using an engine block heater. Engine block heaters are available as an option and can be obtained from your Ford dealer. Consult the engine block heater section for proper use of the engine block heater.
  • Page 144: Brakes

    Driving 2. When the engine starts, release the key, then gradually release the accelerator pedal as the engine speeds up. If the engine still fails to start, repeat Step 1. Guarding against exhaust fumes Carbon monoxide is present in exhaust fumes. Take precautions to avoid its dangerous effects.
  • Page 145 Driving “continuous squeal” sound is present while braking, the brake linings may be worn-out and should be inspected by a qualified service technician. If the vehicle has continuous vibration or shudder in the steering wheel while braking, the vehicle should be inspected by a qualified service technician.
  • Page 146 Driving ABS warning lamp The ABS lamp in the instrument cluster momentarily illuminates when the ignition is turned on. If the light does not illuminate during start up, remains on or flashes, the ABS may be disabled and may need to be serviced. Even when the ABS is disabled, normal braking is still effective.
  • Page 147: Traction Control

    Driving Park brake warning chime Sounds when the parking brake is set, the engine is running, the vehicle speed is greater than 3 mph (5 km/h), and the transaxle is not in P (Park) or N (Neutral). The chime will shut off when the parking brake is disengaged.
  • Page 148 Driving If a system fault is detected, the traction control active light will illuminate, the Traction Control button will not turn the system on or off and your vehicle should be serviced. STEERING To prevent damage to the power steering system, never hold the steering wheel at its furthest turning points (until it stops) for more than a few seconds when the engine is running.
  • Page 149 Driving If you cannot move the gearshift lever out of P (Park) with ignition in the ON position and the brake pedal depressed: 1. Apply the parking brake, turn ignition key to LOCK, then remove the key. 2. Insert the key and turn it to OFF. Apply the brake pedal and shift to N (Neutral).
  • Page 150 Driving Driving with an automatic overdrive transaxle Your automatic overdrive transaxle provides fully automatic operation in either (Overdrive) or D (Drive). Driving with the gearshift lever (Overdrive) gives the best fuel economy for normal driving conditions. For manual control, start in 1 (First) and then shift manually.
  • Page 151: Transmission Operation

    Driving Understanding the gearshift positions of the 4–speed automatic transaxle This vehicle is equipped with an adaptive Transmission Shift Strategy. Adaptive Shift Strategy offers the optimal transmission operation and shift quality. When the vehicle’s battery has been disconnected for any type of service or repair, the transmission will need to relearn the normal shift strategy parameters, much like having to reset your radio stations when your vehicle battery has been disconnected.
  • Page 152 Driving • Move the gearshift lever and securely latch it in P (Park) Always set the parking brake fully and make sure the gearshift is latched in P (Park). Turn the ignition to the LOCK position and remove the key whenever you leave your vehicle. R (Reverse) With the gearshift lever in R (Reverse), the vehicle will move backward.
  • Page 153 Driving If your vehicle gets stuck in mud or snow If your vehicle gets stuck in mud or snow, it may be rocked out by shifting between forward and reverse gears, stopping between shifts in a steady pattern. Press lightly on the accelerator in each gear. If necessary, try turning the Traction Control system off.
  • Page 154: Roadside Emergencies

    50,000 miles (80,000 km) on Lincoln vehicles. Roadside assistance will cover: • a flat tire change with a good spare (except Ford GT which has a tire inflation kit) • battery jump start • lock-out assistance (key replacement cost is the customer’s responsibility) •...
  • Page 155: Fuel Pump Shut-Off Switch

    1–800–241–3673; Lincoln vehicle customers call 1–800–521–4140. Canadian customers who require roadside assistance, call 1–800–665–2006. If you need to arrange roadside assistance for yourself, Ford Motor Company will reimburse a reasonable amount. To obtain reimbursement information, U.S. Ford or Mercury vehicles customers call 1-800-241-3673;...
  • Page 156 Roadside Emergencies The fuel pump shut-off switch is located on the right side of the trunk behind the trunk liner. Use the following procedure to reset the fuel pump shut-off switch. 1. Turn the ignition to the OFF position. 2. Check the fuel system for leaks. 3.
  • Page 157 Roadside Emergencies Standard fuse amperage rating and color COLOR Cartridge Fuse Mini Standard Maxi Fuse link Maxi rating fuses fuses fuses cartridge fuses Grey Grey — — — Violet Violet — — — Pink Pink — — — — — —...
  • Page 158 Roadside Emergencies The fuses are coded as follows. Fuse/relay Fuse amp Passenger compartment fuse panel location rating description — Accessory delay relay — Driver one touch down relay — Blower motor relay — Flasher relay — Not used — Not used Rear defrost relay coil feed Blower motor —...
  • Page 159 Roadside Emergencies Fuse/relay Fuse amp Passenger compartment fuse panel location rating description Heated mirrors, Rear defrost switch indicator Restraints (air bag module/OCS module) Transmission range sensor (transmission position switch) Front washer pump, Cluster (RUN/ACC), Integrated Control Panel (ICP) logic, Electrochromatic mirror Front wiper motor —...
  • Page 160 Roadside Emergencies Fuse/relay Fuse amp Passenger compartment fuse panel location rating description Autolamp, Daytime Running Lamps (DRL), Flash-to-pass, Headlamp switch Horn, Diagnostic connector (OBD II) — Not used — Not used — Not used — Not used CB - Circuit Breaker Power distribution box The power distribution box is located in the engine compartment.
  • Page 161 Roadside Emergencies The high-current fuses are coded as follows. Fuse/relay Fuse amp Power distribution box description location rating 60A** Fuse junction panel 30A** Powertrain Control Module (PCM) 60A** Fuse junction panel 10A CB Low speed cooling fan 40A** Cooling fan (main) —...
  • Page 162 Roadside Emergencies Fuse/relay Fuse amp Power distribution box description location rating — Not used — Not used Heated PCV valve — Starter motor relay — Fan relay — Wiper speed relay 10A* Alternator Rear control unit 15A* HEGO sensor, Transmission shift solenoid, A/C clutch relay, Canister vent —...
  • Page 163 Roadside Emergencies If you use the temporary spare tire continuously or do not follow these precautions, the tire could fail, causing you to lose control of the vehicle, possibly injuring yourself or others. When driving with the temporary spare tire do not: •...
  • Page 164 Roadside Emergencies the road tires and wheels that were originally provided by Ford. If the dissimilar spare tire or wheel is damaged, it should be replaced rather than repaired. When driving with the dissimilar spare tire/wheel, do not: • Exceed 70 mph (113 km/h) •...
  • Page 165 Roadside Emergencies To help prevent the vehicle from moving when you change a tire, be sure the parking brake is set, then block (in both directions) the wheel that is diagonally opposite (other side and end of the vehicle) to the tire being changed. If the vehicle slips off the jack, you or someone else could be seriously injured.
  • Page 166 Roadside Emergencies 5. Loosen each wheel lug nut one-half turn counterclockwise but do not remove them until the wheel is raised off the ground. 6. Put the jack in the jack notch next to the door of the tire you are changing.
  • Page 167: Lug Nut Torque

    M12 x 1.5 * Torque specifications are for nut and bolt threads free of dirt and rust. Use only Ford recommended replacement fasteners. When a wheel is installed, always remove any corrosion, dirt or foreign materials present on the mounting surfaces of the wheel or the surface of the front disc brake hub and rotor that contacts the wheel.
  • Page 168: Jump Starting

    Roadside Emergencies JUMP STARTING The gases around the battery can explode if exposed to flames, sparks, or lit cigarettes. An explosion could result in injury or vehicle damage. Batteries contain sulfuric acid which can burn skin, eyes and clothing, if contacted. Do not attempt to push-start your vehicle.
  • Page 169 Roadside Emergencies Connecting the jumper cables 1. Connect the positive (+) jumper cable to the positive (+) terminal of the discharged battery. Note: In the illustrations, lightning bolts are used to designate the assisting (boosting) battery. 2. Connect the other end of the positive (+) cable to the positive (+) terminal of the assisting battery.
  • Page 170 Roadside Emergencies 3. Connect the negative (-) cable to the negative (-) terminal of the assisting battery. 4. Make the final connection of the negative (-) cable. Make the connection to an exposed metal part of the stalled vehicle’s engine, away from the battery and the fuel injection system.
  • Page 171 Roadside Emergencies Jump starting 1. Start the engine of the booster vehicle and run the engine at moderately increased speed. 2. Start the engine of the disabled vehicle. 3. Once the disabled vehicle has been started, run both engines for an additional three minutes before disconnecting the jumper cables.
  • Page 172 Roadside Emergencies 3. Remove the jumper cable from the positive (+) terminal of the booster vehicle’s battery. 4. Remove the jumper cable from the positive (+) terminal of the disabled vehicle’s battery. After the disabled vehicle has been started and the jumper cables removed, allow it to idle for several minutes so the engine computer can relearn its idle conditions.
  • Page 173: Wrecker Towing

    It is recommended that your vehicle be towed with a wheel lift or flatbed equipment. Do not tow with a slingbelt. Ford Motor Company has not approved a slingbelt towing procedure. If your vehicle is to be towed from the rear using wheel lift equipment, it is recommended that the front wheels (drive wheels) be placed on a dolly to prevent damage to the transaxle.
  • Page 174: Customer Assistance

    Center at 1-800-392-3673 (FORD). Away from home If you own a Ford or Mercury vehicle and are away from home when your vehicle needs service, or if you need more help than the dealership could provide, after following the steps described above, contact the Ford Customer Relationship Center to find an authorized dealership to help you.
  • Page 175 If you own a Lincoln vehicle and are away from home when your vehicle needs service, or if you need more help than the dealership could provide, after following the steps described above, contact the Ford Customer Relationship Center to find an authorized dealership to help you.
  • Page 176 Customer Assistance In some states (in the U.S.) you must directly notify Ford in writing before pursuing remedies under your state’s warranty laws. Ford is also allowed a final repair attempt in some states. In the United States, a warranty dispute must be submitted to the...
  • Page 177 THE DISPUTE SETTLEMENT BOARD (U.S. ONLY) The Dispute Settlement Board is: • an independent, third-party arbitration program for warranty disputes. • available free to owners and lessees of qualifying Ford Motor Company vehicles. The Dispute Settlement Board may not be available in all states. Ford...
  • Page 178 • The name of the dealer(s) who sold or serviced the vehicle. • A brief description of your unresolved concern. • A brief summary of the action taken by the dealer(s) and Ford Motor Company. • The names (if known) of all the people you contacted at the dealership(s).
  • Page 179 After a case is reviewed, the Board mails you a decision letter and a form on which to accept or reject the Board’s decision. The decisions of the Board are binding on Ford (and, in some cases, on the dealer) but not on consumers who are free to pursue other remedies available to them under state or federal law.
  • Page 180 4,600 participating Ford or Lincoln Mercury and Ford of Canada dealers. If you did not take advantage of the Ford Extended Service Plan at the time of purchasing your vehicle, you may still be eligible. Since this 2006 Taurus (tau)
  • Page 181 Customer Assistance information is subject to change, please ask your dealer for complete details about Ford Extended Service Plan coverage options, or visit the Ford ESP website at www.ford-esp.com. GETTING ASSISTANCE OUTSIDE THE U.S. AND CANADA Before exporting your vehicle to a foreign country, contact the appropriate foreign embassy or consulate.
  • Page 182: Reporting Safety Defects (U.s. Only)

    Obtaining a French owner’s guide French Owner’s Guides can be obtained from your dealer or by writing to Ford Motor Company of Canada, Limited, Service Publications, P.O. Box 1580, Station B, Mississauga, Ontario L4Y 4G3. REPORTING SAFETY DEFECTS (U.S. ONLY)
  • Page 183: Cleaning

    Cleaning WASHING THE EXTERIOR Wash your vehicle regularly with cool or lukewarm water and a neutral pH shampoo, such as Motorcraft Detail Wash (ZC-3–A), which is available from your dealer. • Never use strong household detergents or soap, such as dish washing or laundry liquid.
  • Page 184 Cleaning • Remove particles such as bird droppings, tree sap, insect deposits, tar spots, road salt and industrial fallout before repairing paint chips. • Always read the instructions before using the products. ALUMINUM WHEELS AND WHEEL COVERS Aluminum wheels and wheel covers are coated with a clearcoat paint finish.
  • Page 185 Cleaning • 3.0L Vulcan engine • Never wash or rinse the engine while it is running; water in the running engine may cause internal damage. PLASTIC (NON-PAINTED) EXTERIOR PARTS Use only approved products to clean plastic parts. These products are available from your dealer.
  • Page 186 Cleaning INSTRUMENT PANEL AND CLUSTER LENS Clean the instrument panel with a damp cloth, then with a clean, dry cloth, or use Motorcraft Dash & Vinyl Cleaner (ZC-38-A). • Avoid cleaners or polish that increase the gloss of the upper portion of the instrument panel.
  • Page 187 FORD AND LINCOLN MERCURY CAR CARE PRODUCTS Your Ford or Lincoln Mercury dealer has many quality products available to clean your vehicle and protect its finishes. These quality products have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and appearance of your vehicle.
  • Page 188 Cleaning Motorcraft Custom Vinyl Protectant (U.S. only) (ZC-40-A) Motorcraft Dash and Vinyl Cleaner (ZC-38–A) Motorcraft Deluxe Leather and Vinyl Cleaner (U.S. only) (ZC-11–A) Motorcraft Detail Wash (ZC-3–A) Motorcraft Dusting Cloth (ZC-24) Motorcraft Engine Shampoo and Degreaser (U.S. only) (ZC-20) Motorcraft Engine Shampoo (Canada only) (CXC-66-A) Motorcraft One Step Wash and Wax Concentrate (ZC-6-A) Motorcraft Paint Sealant (ZC-45) Motorcraft Premium Car Wash Concentrate (U.S.
  • Page 189: Maintenance And Specifications

    Maintenance and Specifications SERVICE RECOMMENDATIONS To help you service your vehicle: • We highlight do-it-yourself items in the engine compartment for easy location. • We provide scheduled maintenance information which makes tracking routine service easy. If your vehicle requires professional service, your dealership can provide the necessary parts and service.
  • Page 190 Maintenance and Specifications OPENING THE HOOD 1. Inside the vehicle, pull the hood release handle located under the bottom of the instrument panel. 2. Go to the front of the vehicle and release the auxiliary latch located in the center between the hood and the grille.
  • Page 191: Engine Compartment

    Maintenance and Specifications IDENTIFYING COMPONENTS IN THE ENGINE COMPARTMENT 3.0L V6 Vulcan engine 1. Automatic transmission fluid dipstick 2. Brake fluid reservoir 3. Air filter assembly 4. Battery 5. Engine oil filler cap 6. Engine oil dipstick 7. Power steering fluid reservoir 8.
  • Page 192 In very cold weather, do not fill the reservoir completely. Only use a washer fluid that meets Ford specification WSB-M8B16–A2. Refer to Lubricant specifications in this chapter. State or local regulations on volatile organic compounds may restrict the use of methanol, a common windshield washer antifreeze additive.
  • Page 193: Engine Oil

    Maintenance and Specifications CHANGING THE WIPER BLADES 1. Pull the wiper arm away from the vehicle. Turn the blade at an angle from the wiper arm. Push the lock pin manually to release the blade and pull the wiper blade down toward the windshield to remove it from the arm.
  • Page 194 Maintenance and Specifications • 3.0L Vulcan engine 6. Wipe the indicator clean. Insert the indicator fully, then remove it again. • If the oil level is between the two holes or between the MIN and MAX marks (depending on application), the oil level is acceptable. DO NOT ADD OIL.
  • Page 195 Approval Committee (ILSAC), comprised of U.S. and Japanese automobile manufacturers. To protect your engine’s warranty use Motorcraft SAE 5W-20 or an equivalent 5W-20 oil meeting Ford specification WSS-M2C930-A. SAE 5W-20 oil provides optimum fuel economy and durability performance meeting all requirements for your vehicle’s engine.
  • Page 196: Battery

    Change your engine oil and filter according to the appropriate schedule listed in scheduled maintenance information. Ford production and aftermarket (Motorcraft) oil filters are designed for added engine protection and long life. If a replacement oil filter is used that does not meet Ford material and design specifications, start-up engine noises or knock may be experienced.
  • Page 197 Maintenance and Specifications If you see any corrosion on the battery or terminals, remove the cables from the terminals and clean with a wire brush. You can neutralize the acid with a solution of baking soda and water. Batteries normally produce explosive gases which can cause personal injury.
  • Page 198: Engine Coolant

    Maintenance and Specifications 7. Drive the vehicle to complete the relearning process. • The vehicle may need to be driven 10 miles (16 km) or more to relearn the idle and fuel trim strategy. • If you do not allow the engine to relearn its idle trim, the idle quality of your vehicle may be adversely affected until the idle trim is eventually relearned.
  • Page 199 Maintenance and Specifications • Enables calibrated gauges to work properly. When the engine is cold, check the level of the engine coolant in the reservoir. • The engine coolant should be at the “FULL COLD” level or within the “COLD FILL RANGE” as listed on the engine coolant reservoir (depending upon application).
  • Page 200 • Add Motorcraft Premium Gold Engine Coolant (yellow-colored), VC-7–A (U.S., except CA, OR and NM), VC-7–B (CA, OR and NM), meeting Ford Specification WSS-M97B51–A1. Note: Use of Motorcraft Cooling System Stop Leak Pellets, VC-6, may darken the color of Motorcraft Premium Gold Engine Coolant from yellow to golden tan.
  • Page 201 Recycled engine coolant Ford Motor Company does NOT recommend the use of recycled engine coolant in vehicles originally equipped with Motorcraft Premium Gold Engine Coolant since a Ford-approved recycling process is not yet available.
  • Page 202 Maintenance and Specifications Used engine coolant should be disposed of in an appropriate manner. Follow your community’s regulations and standards for recycling and disposing of automotive fluids. Coolant refill capacity To find out how much fluid your vehicle’s cooling system can hold, refer to Refill capacities in this section.
  • Page 203 Maintenance and Specifications WHAT YOU SHOULD KNOW ABOUT AUTOMOTIVE FUELS Important safety precautions Do not overfill the fuel tank. The pressure in an overfilled tank may cause leakage and lead to fuel spray and fire. The fuel system may be under pressure. If the fuel filler cap is venting vapor or if you hear a hissing sound, wait until it stops before completely removing the fuel filler cap.
  • Page 204 Maintenance and Specifications • Avoid getting fuel liquid in your eyes. If fuel is splashed in the eyes, remove contact lenses (if worn), flush with water for 15 minutes and seek medical attention. Failure to seek proper medical attention could lead to permanent injury.
  • Page 205 Maintenance and Specifications Flexible fuel components and standard unleaded gasoline fuel components are not interchangeable. If your vehicle is not serviced in accordance with flexible fuel vehicles procedures, damage may occur and your warranty may be invalidated. When refueling always shut the engine off and never allow sparks or open flames near the filler neck.
  • Page 206 The customer warranty may be void for any damage to the fuel tank or fuel system if the correct genuine Ford or Motorcraft fuel filler cap is not used. The fuel system may be under pressure. If the fuel filler cap is venting vapor or if you hear a hissing sound, wait until it stops before completely removing the fuel filler cap.
  • Page 207 Maintenance and Specifications contains more metallic additives than regular fuel. We recommend using regular grade fuel. In Canada, many fuels contain metallic additives, but fuels free of such additives may be available; check with your local fuel dealer. Do not use fuel containing methanol. It can damage critical fuel system components.
  • Page 208 10 to 30 seconds. If the problems persist below this temperature, see your dealer or a qualified service technician. Cleaner air Ford endorses the use of reformulated “cleaner-burning” gasolines to improve air quality. Running out of fuel Avoid running out of fuel because this situation may have an adverse affect on powertrain components.
  • Page 209 Maintenance and Specifications FUEL FILTER For fuel filter replacement, see your dealer or a qualified service technician. Refer to scheduled maintenance information for the appropriate intervals for changing the fuel filter. Replace the fuel filter with an authorized Motorcraft part. The customer warranty may be void for any damage to the fuel system if an authorized Motorcraft fuel filter is not used.
  • Page 210 Maintenance and Specifications • Always use fuel with the recommended octane rating. • Use a known quality gasoline, preferably a national brand. • Use the same side of the same pump and have the vehicle facing the same direction each time you fill up. •...
  • Page 211 Maintenance and Specifications • Anticipate stopping; slowing down may eliminate the need to stop. • Sudden or hard accelerations may reduce fuel economy. • Slow down gradually. • Driving at reasonable speeds (traveling at 55 mph [88 km/h] uses 15% less fuel than traveling at 65 mph [105 km/h]).
  • Page 212 If other than Ford, Motorcraft or Ford-authorized parts are used for maintenance replacements or for service of components affecting emission control, such non-Ford parts should be equivalent to genuine Ford Motor Company parts in performance and durability.
  • Page 213 Maintenance and Specifications Do not park, idle, or drive your vehicle in dry grass or other dry ground cover. The emission system heats up the engine compartment and exhaust system, which can start a fire. Illumination of the indicator, charging system warning light or the temperature warning light, fluid leaks, strange odors, smoke or loss of engine power, could indicate that the emission control system is not working properly.
  • Page 214 Maintenance and Specifications driving cycles without these or any other temporary malfunctions present, the Check engine/Service engine soon light should turn off. (A driving cycle consists of a cold engine startup followed by mixed city/highway driving.) No additional vehicle service is required. If the Check engine/Service engine soon light remains on, have your vehicle serviced at the first available opportunity.
  • Page 215 Maintenance and Specifications 3. Turn the engine off. 4. Check the fluid level on the dipstick. It should be between the arrows in the FULL HOT range. Do not add fluid if the level is within this range. 5. If the fluid is low, add fluid in small amounts, continuously checking the level until it reaches the FULL HOT range.
  • Page 216 Maintenance and Specifications 1. Drive the vehicle 20 miles (30 km) or until it reaches normal operating temperature. 2. Park the vehicle on a level surface and engage the parking brake. 3. With the parking brake engaged and your foot on the brake pedal, start the engine and move the gearshift lever through all of the gear ranges.
  • Page 217: Part Numbers

    Refer to the scheduled maintenance information for the appropriate intervals for changing the PCV valve. Replace the PCV valve with one that meets Ford material and design specifications for your vehicle, such as a Motorcraft or equivalent replacement part. The customer warranty may be void for any damage to the emissions system if such a PCV valve is not used.
  • Page 218: Refill Capacities

    Refer to scheduled maintenance information for the appropriate intervals for changing the spark plugs. Replace the spark plugs with ones that meet Ford material and design specifications for your vehicle, such as Motorcraft or equivalent replacement parts. The customer warranty may be void for any damage to the engine if such spark plugs are not used.
  • Page 219: Lubricant Specifications

    Maintenance and Specifications LUBRICANT SPECIFICATIONS Ford Part Ford Part Ford Items Name or Number Specification equivalent Brake fluid Motorcraft High PM-1 ESA-M6C25-A Performance and DOT 3 DOT 3 Motor Vehicle Brake Fluid Door latch, hood Multi-Purpose XG-4 or XL-5 ESA-M1C93-B...
  • Page 220 Maintenance and Specifications Ford Part Ford Part Ford Items Name or Number Specification equivalent Power steering Motorcraft XT-2-QDX MERCON fluid MERCON ATF Windshield Motorcraft ZC-32–A WSB-M8B16–A2 washer fluid Premium Windshield Washer Concentrate Ensure the correct automatic transmission fluid is used. Transmission fluid requirements are indicated on the dipstick or on the dipstick handle.
  • Page 221 Maintenance and Specifications Engine 3.0L V6 Vulcan 3.0L FFV V6 engine engine Spark plug gap 0.042–0.046 inch 0.042–0.046 inch (1.1–1.2mm) (1.1–1.2mm) Compression ratio 9.7:1 9.7 :1 VEHICLE DIMENSIONS Vehicle dimensions Inches (mm) (1) Overall length 197.6 (5020) (2) Overall width 73.0 (1855) (3) Overall height 56.1 (1426)
  • Page 222 Maintenance and Specifications IDENTIFYING YOUR VEHICLE Certification label The National Highway Traffic Safety Administration Regulations require that a Safety Compliance Certification Label be affixed to a vehicle and prescribe where the Safety Compliance Certification Label may be located. The Safety Compliance Certification Label is located on the structure by the trailing edge of the driver’s door or...
  • Page 223 Maintenance and Specifications Vehicle identification number (VIN) The vehicle identification number is attached to a metal tag and is located on the driver side XXXXXXXXXXXXXXXXX instrument panel. (Please note that in the graphic XXXX is representative of your vehicle identification number.) The Vehicle Identification Number (VIN) contains the following information: 1.
  • Page 224 Maintenance and Specifications TRANSMISSION/TRANSAXLE CODE DESIGNATIONS You can find a transmission/transaxle code on the Safety Compliance Certification Label . The following table tells you which transmission or transaxle each code represents. Code Description Automatic overdrive 2006 Taurus (tau) Owners Guide (post-2002-fmt) USA (fus)
  • Page 225: Accessories

    In addition, each accessory is made from high quality materials and meets or exceeds Ford’s rigorous engineering and safety specifications. Ford Motor Company will repair or...
  • Page 226 Accessories Lifestyle Bike racks Cargo organization and management Smoker’s pack Peace of mind First aid and highway safety kits Keyless entry pad Wheel locks Vehicle security systems Remote keyless entry Remote start Full vehicle covers For maximum vehicle performance, keep the following information in mind when adding accessories or equipment to your vehicle: •...
  • Page 227: Index

    Index acid, treating emergencies ..196 jumping a disabled battery ..168 Accessory delay ......44 maintenance-free ....196 replacement, specifications ...217 Air cleaner filter .......217 servicing ........196 Air conditioning ......25 BeltMinder ........90 Airbag supplemental restraint Brakes ........144 system ......95–96, 102 and child safety seats ....97 anti-lock ........145 description ......96, 102 anti-lock brake system (ABS)
  • Page 228 Emergency Flashers ....155 Cruise control Emission control system ..212 (see Speed control) ....45 Engine ........220–221 Customer Assistance ....154 cleaning ........184 Ford Extended Service coolant ........198 idle speed control ....196 Plan ..........180 lubrication Getting assistance outside the specifications ....219–220 U.S. and Canada .....181 refill capacities ......218...
  • Page 229 Index specifications ....219–220 Exhaust fumes ......144 Hazard flashers ......155 Headlamps ........29 aiming ........30 autolamp system .......29 Flexible Fuel Vehicle (FFV) ..203 bulb specifications ....33 Floor mats ........62 daytime running lights .....29 Fluid capacities ......218 flash to pass ......30 Fuel ..........203 high beam .........30 calculating fuel replacing bulbs ......35...
  • Page 230 Index Keys Motorcraft parts ..187, 209, 217 positions of the ignition ..140 Octane rating ......207 Lamps Oil (see Engine oil) ....193 autolamp system .......29 Overdrive ........150 bulb replacement specifications chart ....33 daytime running light ....29 headlamps .........29 headlamps, flash to pass ..30 Parking brake ......146 instrument panel, dimming ..30 Parts (see Motorcraft parts) ..217...
  • Page 231 Index Safety belts (see Safety Steering wheel tilting .........41 restraints) ......80, 84–88 Safety defects, reporting ..182 Safety restraints ....80, 84–88 Tilt steering wheel ......41 belt minder .......90 Tires ......116–117, 162 extension assembly ....94 alignment ........128 for adults ......85–87 care ..........126 for children .....104–105 changing ......162, 164 lap belt ........89...
  • Page 232 Index Vehicle Identification Number Water, Driving through .....153 (VIN) ..........223 Windows Vehicle loading ......130 power .........43 Ventilating your vehicle ...144 Windshield washer fluid and wipers ..........41 checking and adding fluid ..192 replacing wiper blades ...193 Warning lights (see Lights) ..10 Wrecker towing ......173 Washer fluid ......192 2006 Taurus (tau)

Table of Contents

Save PDF
