Hearth and Home Technologies 4100I-GD-B Manual

Advanced combustion technology wood insert
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Models:
4100I-GD-B
4100I-NL-B
•
Important operating
a n d m a i n t e n a n c e
instructions included.
If the information in these
instructions is not followed
exactly, a fire may result causing
property damage, personal injury,
or death.
• Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
• Do not overfire - If heater or chimney
connector glows, you are overfiring.
Overfiring will void your warranty.
• Comply with all minimum clearances to
combustibles as specified. Failure to
comply may cause house fire.
Installation and service of this appliance should
be performed by qualified personnel. Hearth &
Home Technologies recommends NFI certified
professionals, or technicians supervised by an
NFI certified professional.
1445 North Highway
Colville, WA 99114-2008
4100- I ACT WOOD INSERT
Advanced Combustion Technology (ACT)
DO NOT DISCARD THIS MANUAL
• Read, understand and
follow these instructions
for safe installation and
operation.
WARNING
250-7201E
NOTICE
• Leave this manual with
party responsible for
use and operation.
Hot glass will cause burns.
• Do not touch glass until it is cooled
• NEVER allow children to touch glass
• Keep children away
• CAREFULLY SUPERVISE children in the same room
as appliance
• Alert children and adults to hazards of high
temperatures
High temperatures may ignite clothing or other
flammable materials.
• Keep clothing, furniture, draperies and other
combustibles away.
Fire Risk.
For use with solid wood fuel only.
Other fuels may overfire and generate
poisonous gases (i.e. carbon monoxide).
September 1, 2008
R
O-T L
Portland
Tested and
Oregon USA
Listed by
C
US
OMNI-Test Laboratories, Inc.
WARNING
HOT SURFACES!
G L A S S A N D O T H E R
S U R FA C E S A R E H O T
DURING OpERATION AND
COOL DOWN.
WARNING
www.quadrafire.com

Advertisement

Table of Contents
loading

Summary of Contents for Hearth and Home Technologies 4100I-GD-B

  • Page 1 Advanced Combustion Technology (ACT) Models: 4100I-GD-B 4100I-NL-B • Important operating a n d m a i n t e n a n c e instructions included. WARNING If the information in these instructions is not followed exactly, a fire may result causing property damage, personal injury, or death.
  • Page 2 and Welcome to the Quadra-Fire Family Hearth & Home Technologies welcomes you to our tradition of excellence! In choosing a Quadra-Fire appliance, you have our assurance of commitment to quality, durability, and performance. This commitment begins with our research of the market, including ‘Voice of the Customer’...

  • Page 3: Table Of Contents

    SAFETY & OVERVIEW OF AppLIANCE Dimensions ----------------------------------------------------- 4 Minimum Clearances to Combustibles ------------------ 5 Listings ---------------------------------------------------------- 6 Chimney Height & Draft and 2-10- Rule -------------- 6 Installation Recommendations ---------------------------- 6 General Installation Procedures -------------------------- 7 Alternate Floor Protection Worksheet ------------------- 7 Chimney Requirements ------------------------------------- 8 Ovalizing Round Stainless Steel Liner ------------------ 8 INSTALLATION OpTIONS...

  • Page 4: Dimensions

    0" (762mm) 24" (610mm) 12-1/8" (08mm) TOp VIEW FRONT VIEW 45-/4" (1162mm) Page 4 4100-I ACT WOOD INSERT DIMENSIONS 16-1/4" (41mm) 9-5/16" (15mm) 7-7/8" (200mm) 21-5/8" (549mm) 10-7/8" (276mm) panel Size Standard Large 0-7/8" (784mm) 250-7201E SIDE VIEW 20-7/8" (50mm) 44-/4”...

  • Page 5: Minimum Clearances To Combustibles

    Sidewall to Stove Mantel to Stove Top Trim to Stove Side Trim to Stove Hearth Extension from Glass Hearth Extension from Side of Insert Thermal protection must be 1/2 Inch (12.7mm) minimum thickness ('k" value = 0.84) or equivalent material* See Alternative Floor Protection Worksheet on page 7.

  • Page 6: Listings

    LISTINGS These installation instructions describe the installation and operation of the Quadra-Fire 4100-I Wood Insert. This insert meets the U.S. Environmental Protection Agency’s 1990 particulate emission standards. This product is listed by OMNI-Test Laboratories, Inc. to UL Safety Standard 1482, and ULC S628, and (UM) 84-HUD.

  • Page 7: General Installation Procedures

    GENERAL INSTALLATION pROCEDURE • DO NOT CONNECT THIS UNIT TO A CHIMNEY FLUE SERVING ANOTHER AppLIANCE. • Install liner, if required, for your chosen installation. • Attach metal warning plate to the back of the fireplace with screws or nails. •...

  • Page 8: Chimney Requirements

    CHIMNEY REqUIREMENTS A chimney must be the required height above the roof or other obstruction for safety and for proper draft oper- ation. The requirement is that the chimney must be at least  feet (91cm) higher than the highest point where it passes through the roof, and at least 2 feet (61cm) higher than the highest part of the roof or structure that is within10 feet (05cm) of the chimney, measured hori-...

  • Page 9: Mobile Home

    INSTALLATIONS INTO ZERO CLEARANCE FIREpLACES IN MOBILE HOMES (iN USA ONlY) An outside air inlet must be provided for combustion and must remain clear of leaves, debris, ice and/or snow. It must be unrestricted while unit is in use to prevent room air starvation which can cause smoke spillage and an inability to maintain a fire.

  • Page 10: Masonry Fireplace

    Refer to: Clearances to Combustibles on page 5, Canadian installation requirements on page 12, Hearth Requirements on page 5 and Zero Clearance Adjustable Support Kit on page 16. MASONRY FIREpLACE USING DIRECT-CONNECT METHOD This product conforms with the UL Standard for Safety 1482 (USA) and ULC S628 (Canada) in all respects, and is approved to UL &...

  • Page 11: Factory-Built Zero Clearance Fireplace

    FACTORY-BUILT ZERO CLEARANCE FIREpLACE The Quadra-Fire 4100-I ACT Wood Stove Insert is listed to UL 1482 Standard and approved for installation into listed factory built zero clearance fireplaces listed to UL 127 con- forming to the following specifications and instructions: The original factory-built clearance fireplace chimney cap must be re-installed after installing the approved chim- ney liner meeting type H.T.

  • Page 12: Canadian Masonry & Heat Circulating

    (INSTALLATIONS INTO FACTORY-BUILT FIREPLACES ARE PROHIBITED IN CANADA) Whether installed in a masonry or heat-circulating fireplace, this fireplace insert must be installed with a continuous chim- ney liner of six inch (152mm) diameter extending from the fireplace insert to the top of the chimney. The chimney liner must conform to the Class  requirements of CAN/ULC-S65, Standard for Lining Systems for Existing Masonry Chimneys and Vents, or CAN/ULC-S640, Standard for Lining Systems for New Masonry Chimneys.

  • Page 13: Securing Liner To Chimney Ring

    SECURING LINER TO CHIMNEY RING There are two options to secure the liner to the chim- ney ring: See Figure 13A. Option One: If there is enough room on the top of the insert to work, hand bend the two tabs upward 90°. Secure the liner with the supplied hex head bolts 1/4- 20-/4.

  • Page 14: Panel Sets And Trim Sets

    STANDARD SIZE: 30-1/2” h x 44-3/4”w panel and Cast Trim must be ordered separately. Included in Panel Kit: (2) side panels, left and right; (1) panel top; (2) trim pieces; (1) trim top; (1) fastener package. Included in Cast Trim Kit: (2) cast trim legs, left and right; (1) cast trim header; (2) cast trim footers, left and right. Tools Needed: Powered Phillips Head Screw Driver 1.

  • Page 15: Blower Cord Installation

    BLOWER CORD LOCATION & BLOWER CONTROL BOX WITH SWITCH This insert comes standard with a blower, installed at the factory with blower cord on right side of insert (as you face the unit). The blower cord can also be installed on the left side.

  • Page 16: Zero Clearance Adjustable Trim Support

    ZERO ClEARANCE ADJUSTABlE TRiM SUPPORT Two sizes: 9”d x 45”w and 12”d x 50”w, both 2” to10” Height Adjustment Included in Kit: ( 1) Trim Top, (1) Trim Front, (2) Trim Sides, Double-Sided Tape (already installed) Tools Needed: Phillips Head Screwdriver, Sheet Metal Shears, Measuring Tape, Gloves 1.

  • Page 17: Wood Selection & Storing

    urn only dry seasoned wood. Dry, well-seasoned wood will not only minimize the chance of creosote formation but will give you the most efficient heat output. Even dry wood contains at least 15% moisture by weight and should be burned hot enough to keep the chimney hot enough to maintain particulate (smoke) burning.

  • Page 18: Operating Tips

    For maximum operating efficiency with the lowest emissions, follow these operating procedures: Regardless of desired heat output, when loading insert, burn your Quadra-Fire with both air controls wide open for a minimum of 5 to 15 minutes. Regulate burn rate (heat output) by using the Primary Control (top rod). The Start-Up Air Control (bottom rod) is used for initial start-up and reloading.

  • Page 19: Burning Process

    BURNING pROCESS In recent years there has been an increasing concern about air quality. Much of the blame for poor air quality has been placed on the burning of wood for home heating. In order to improve the situation, we at Quadra-Fire have developed cleaner-burning wood stoves and inserts that surpass the requirements for emissions established by our governing agencies.

  • Page 20: Maintenance

    CARE AND CLEANING OF pLATED SURFACES IMpORTANT: You must clean all the fingerprints and oils from the plated surfaces before firing the insert for the first time. Use warm soapy water and a soft rag, glass cleaner and a paper towel, or vinegar and a paper towel to remove the oils. DO NOT use abrasive cleaners! If not cleaned properly prior to lighting the first fire, the oils can cause permanent stains.

  • Page 21: Brick Replacement

    BRiCK REPlACEMENT iNSTRUCTiONS The firebox is lined with high quality firebrick which has excep- tional insulating properties. There is no need for a grate, simply build a fire on the firebox of your insert. . Be certain coals are completely cold. Remove all old brick and ash from unit and vacuum out firebox.

  • Page 22: Exploded View

    Figure 22C Item Description Ashcatcher Blower, 180 cfm Blower Mount Base Blower Housing, Cast Blower Mount Clamp Wire Harness Manifold Tubes Set Page 22 4100-I ACT WOOD INSERT EXpLODED VIEWS Item Description Baffle, Fiberboard Ceramic Blanket, 1/2” Door Latch Box Assembly Snap Disc 110 degree Knob, Air Control Blower Control Box w/Switch...
  • Page 23 Service parts and Accessories IMpORTANT: THIS IS DATED INFORMATION. quadrafire.com. When ordering, supply serial and model numbers to ensure correct part. Item Ashcatcher Baffle, Fiberboard Blanket, Ceramic 1/2” thick Blower Mount Base Blower Mount Clamp Blower Assembly, 180 cfm Blower Control Box with Switch (included wire harness) Blower Housing, Cast Brick Set Brick, Single (give dimensions of brick, see page 21)
  • Page 24 Item Top, Cast Trim, Cast, Footer, Left Trim, Cast, Footer, Right Trim, Cast, Header Trim, Cast, Leg, Left Trim, Cast, Leg, Right Trim, Cast, Set, Matte Black (5 piece) Trim, Ring, Front, Gold Trim, Ring, Front, Nickel Trim, Ring, Side, Gold Trim, Ring, Side, Nickel Wire Harness Only Figure 24A...

  • Page 25: Service & Maintenance Log

    4100-I ACT WOOD INSERT Service and Maintenance log Date of Service performed By Description of Service September 1, 2008 250-7201E Page 25...

  • Page 26: Warranty Policy

    Warranty policy Hearth & Home Technologies liMiTED WARRANTY Hearth & Home Technologies (“HHT”) and its respective brands extends the following warranty for HHT gas, wood, pellet and electric appliances purchased from an authorized HHT dealer and installed in the United States of America or Canada.
  • Page 27 Hearth & Home Technologies liMiTED WARRANTY (Cont’d)  HHT’s obligation under this warranty does not extend to damages resulting from: (1) installation, operation or maintenance of the appliance not in accordance with the installation instructions; operating instructions and the list- ing agent identification label furnished with the appliance;...

  • Page 28: Contact Information

    please contact your quadra-Fire dealer with any questions or concerns. For the number of your nearest quadra-Fire dealer, SERIAL NUMBER: __________________ DATE pURCHASED: __________________ DATE INSTALLED: __________________ This product may be covered by one or more of the following patents: (United States) 459510, 4686807, 4766876, 47922, 481154, 5000162, 5016609, 5076254, 51184, 5191877, 521895, 526471, 52856, 541794, 54798, 5429495, 5452708, 5542407, 560107, 561487, 564740, 5688568, 5762062, 5775408, 5890485, 591661, 594127, 5947112, 5996575, 600674, 6019099, 6048195, 605165, 6145502, 6170481, 627588, 6296474, 674822, 641079,...
