American Standard FloWise 1.28 Elongated Toilet 2073.014 Specification Sheet

FloWise 1.28 ELONGATED
®
HIGH EFFICIENCy TOILET
❑ 2073.014
• Vitreous china
• Meets definition for HET (High Efficiency Toilet) –
20% less water usage than 1.6 gpf
• High efficiency (4.8 Lpf/1.28 gpf)
• EverClean surface inhibits the growth of
®
stain- and odor-causing bacteria, mold,
and mildew on the surface
• 4" non-adjustable, piston action Accelerator™
flush valve
• Elongated siphon action jetted bowl
• 2-1/8" fully-glazed trapway
• Speed Connect tank/bowl coupling system
®
• Chrome-plated trip lever
• Sanitary Dam on bowl
• 100% factory flush tested
• 2 bolt caps
• 10 year warranty
❑ 3018.013 Elongated Bowl
❑ 4023.014 Tank
Nominal Dimensions:
762 x 438 x 794mm
(30" x 17-1/4" x 31-1/4")
Fixture only, seat and supply by others
Compliance Certifications -
Meets or Exceeds the Following Specifications:
• ASME A112.19.2M for Vitreous China Fixtures -
includes Flush Performance, Ball Pass Diameter,
Trap Seal Depth and all Dimensions
• Los Angeles Department of Water and Power
Supplementary Purchase Specification for
Non-Adjustability
• Certified in EPA WaterSense HET program
• Qualifies in LEEDS Programs
To Be Specified:
❏ Color:
❏ White
❏ Seat: (please specify color)
❏ Slow Close Elongated #5325.010
❏ Rise & Shine Elongated #5324.019
❏ EverClean Elongated Seat with Slow Close
®
Snap-Off Hinges #5321.110
❏ Supply with stop:
© 2008 AS America Inc.
ELONGATED TOILET
FINISHED WALL
762mm
(30)
19mm ± 6mm
(3/4 ± 1/4)
222mm
(8-3/4)
470mm
(18-1/2)
C/L OF SEAT POST HOLES
140mm (5-1/2 CENTERS)
16mm
(5/8)
254mm
343mm
(13-1/2)
(10)
305mm
C/L OF OUTLET
(12)
NOTES:
THIS TOILET IS DESIGNED TO ROUGH-IN AT A MINIMUM DIMENSION OF
305MM (12") FROM FINISHED WALL TO C/L OF OUTLET.
SUPPLY NOT INCLUDED WITH FIXTURE AND MUST BE ORDERED
SEPARATELY.
DIMENSION SHOWN FOR LOCATION OF SUPPLY IS SUGGESTED.
*
IMPORTANT: Dimensions of fixtures are nominal and may vary within the
range of tolerances established by ANSI Standard A112.19.2.
These measurements are subject to change or cancellation. No responsibility
is assumed for use of superseded or voided pages.
Certified by
IAPMO R&T
K39
FloWise
®
VITREOUS CHINA
438mm
(17-1/4)
C/L
SUPPLY
AS
REQ'D
381mm
(15) 356mm
203mm
(14)
(8)
114mm
(4-1/2)
267mm
FINISHED
(10-1/2)
FLOOR
Revised 2/08
1.28
794mm
(31-1/4)
