QUICK START

Thank you, and congratulations on your choice of the Roland
Before using this unit, carefully read the sections entitled: "IMPORTANT SAFETY
INSTRUCTIONS" (Owner's Manual p. 2), "USING THE UNIT SAFELY" (Owner's
Manual p. 3), and "IMPORTANT NOTES" (Owner's Manual p. 4). These sections
provide important information concerning the proper operation of the unit.
Additionally, in order to feel assured that you have gained a good grasp of every
feature provided by your new unit, Quick Start, Owner's Manual, Sound/
Parameter List, and Q&A should be read in their entirety. These manuals should
be saved and kept on hand as a convenient reference.
How to Read This Manual
The Fantom comes with four manuals: Quick Start, Owner's Manual, Sound/Parameter List,
and Q&A.
The manual you're reading now, Quick Start, offers a basic introduction to the Fantom, and
provides simple, easy-to-understand explanations, allowing the beginner to quickly
experience many of the Fantom's exciting features. As you read the Quick Start, we
recommend actually performing the described operations on your Fantom. This'll help you
understand most of what you need to know for basic operations. For feature details, and for
explanations of advanced uses, read the separate Owner's Manual. Sound/Parameter List
contains parameter and sound lists and information on the Fantom's MIDI implementation.
Q&A provides answers to frequently asked questions about the Fantom, and offers
examples of ways in which the Fantom can be used.
Copyright © 2001 ROLAND CORPORATION
All rights reserved. No part of this publication may be reproduced in any form without
the written permission of ROLAND CORPORATION.
(FA-76).
