Features
Options
AC Power
Power
Linking
Fuse
Replacement
·
3, 4, or 9-channel tri color LED wash fixture with ID addressing
·
Operating modes:
3-channel:
4-channel:
9-channel:
·
RGB color mixing with or without DMX control
·
Automatic (pre-set) and custom (editable) programs
·
Recall auto and custom programs via DMX
·
Pre-programmed color macros
·
Color temperature presets (3,200~8,500 K)
·
Master/Slave operation
·
Transfer custom programs between fixtures
·
High-power, 3 W tri-color LEDs
·
IEC power connectors
·
Power linking: max 20 units @ 120 V
·
Includes 6.6 ft (2 m) power extension cable
·
3-pin DMX input and output connectors
·
LCD display with password protection
·
Double-bracketed yoke for overhead or floor mounting
·
Adjustable barn doors to direct output (includes gel frame)
·
Additional threaded hole on rear for mounting (size M 10)
·
33 ft (10 m) power extension cable (EXT-2)
This product has an auto-ranging power supply that can work with an input
voltage range of 100~240 VAC, 50/60 Hz.
You can link up to twenty (20) COLORdash™ Par-Tri units to this fixture
at 120 VAC. Make sure to never exceed this number when linking this
fixture.
1.
With a Phillips #2 head screwdriver, unscrew the fuse holder cap
from its housing.
2.
Remove the blown fuse from the fuse holder cap and replace it
with a good fuse of the exact same type and rating.
3.
Screw the fuse holder cap back in its place and reconnect power.
COLORdash™ Par-Tri QRG
RGB control
RGB, dimmer
RGB, dimmer, color macro, strobe, auto/custom,
auto speed, ID addressing
Page 3 of 8
