Signature Series
T S Y S T EM MODUL AR SPE AKER S
O W N E R S M A N U A L
R E D E F I N I N G
P A R T N E R S H I P S
W I T H
S O U N D . ™

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the signature series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for RBH Sound signature series

Summary of Contents for RBH Sound signature series

  • Page 1 Signature Series T S Y S T EM MODUL AR SPE AKER S O W N E R S M A N U A L R E D E F I N I N G P A R T N E R S H I P S W I T H S O U N D .
  • Page 2 This page was left blank intentionally.

  • Page 3: Break-In Period

    Introduction Congratulations on your purchase of an RBH Sound speaker system! Your speakers are the result of many years of research and development dedicated to producing high quality products for home audio systems. This manual contains features, setup recommendations and specifications for the RBH Sound T System high performance speaker systems.
  • Page 4 Cabinets are constructed of ¾-inch medium density fiberboard because of its inert properties, thereby preventing sound coloration due to cabinet diffraction. The thickness of the front baffles also prevents excess acoustic radiation. Sophisticated computer modeling and measurement techniques are used extensively throughout the RBH Sound Signature Series speaker design process.
  • Page 5 Attaching Speaker Wires When using a banana jack to attach speaker wires to the binding post terminals, insert the speaker wire into the banana jack. Next insert the banana jack into the hole provided in the top of the terminal. Repeat for the other speaker wire(s) as necessary.

  • Page 6: Setup Suggestions

    Setup Suggestions The T System is a modular speaker system designed to be used individually or with the RBH Sound 1010-SEN or 1010-SEN/R subwoofer. This combination with the subwoofer provides full-range reproduction of the program material. There are four basic models or configurations within the T System: T-1 or T-1/R: The T-1 or T-1/R is the main speaker section that reproduces the high and mid-range frequencies.
  • Page 7 Often this positioning dictates placing the speaker either directly above or below a television monitor or screen. If using an RBH Sound Signature Series speaker, the speaker may be used in a horizontal (lying down) or vertical position. If using a T-1 or T-1/R as the center channel positioned below or equal in height of the Main T-1s, the tweeters must face up as shown in the illustration below.
  • Page 8 Setup Suggestions (continued) Surround Speakers The Surround Speakers may be placed either above, behind or to the sides of the listening position. The listening position should be centered between the surround speakers. For best performance, you may want to experiment with angling the surround speakers either towards or away from the listening position.
  • Page 9 Setup Suggestions (continued) OPTIONAL T-3 SUB SECOND OPTIONAL NOTE: There are several different surround formats available. Dolby Pro-Logic, Pro-Logic II, Dolby Digital and DTS generally have a 5 speaker plus subwoofer requirement. Dolby Digital EX and DTS ES add a center rear speaker.
  • Page 10 Clamping Bracket The clamping brackets provided with the T-2, T-2/R, T-3 or T-3/R systems, consists of (4) end pieces, (4) hex head bolts and (2) round rods. To install, attach an end piece to each end of the rod with the screws and place in between the two cabi- nets from side to side (not front to back).

  • Page 11: Specifications

    Specifications Model Speaker Type Modular Modular Tower Frequency Response: 45Hz – 20kHz ±3dB 20Hz – 20kHz ±3dB Sensitivity: 91dB (2.83V @ 1M) 92dB (2.83V @ 1M) Recommended Power: 100-500 Watts 100-1000 Watts* Woofer: (4) 6½” (165mm) Aluminum (2) 10” (254mm) Aluminum (4) 6½”...
  • Page 12 Specifications Model T-1/R T-2/R Speaker Type Modular Modular Tower Frequency Response: 45Hz – 20kHz ±3dB 20Hz – 20kHz ±3dB Sensitivity: 91dB (2.83V @ 1M) 92dB (2.83V @ 1M) Recommended Power: 100-500 Watts 300-1000 Watts* Woofer: (4) 6½” (165mm) Reference Aluminum (2) 10”...

  • Page 13: Troubleshooting

    Troubleshooting Situation: Probable Cause: Solution: No sound from Speaker wire not connected Make sure wire is connected speakers at both the speaker and the amplifier observing proper polarity Speaker selector on amplifier is Activate proper selector on not on amplifier No sound from Balance control on receiver Place balance control in the...
  • Page 14 This page was intentionally left blank...
  • Page 15 This page was intentionally left blank...
  • Page 16 382 Marshall Way, Layton, Utah • USA • 84041 Toll Free: (800) 543-2205 • Fax: (801) 543-3300 www.rbhsound.com It is RBH Sound policy to continuously incorporate improvements into products; all specifications are subject to change without notice. Copyright © 2008 RBH Sound. All Rights Reserved.

This manual is also suitable for:

T-1T-2T-3T-1/rT-2/rT-3/r ... Show all
