OPERATION
Audio Connections
Input - 1/4" connection for input signal. Connect your guitar here.
Output - 1/4" connection for output. Connect the output to your amp.
Controls
Noise Gate - Threshold setting for the built-in Noise Gate. Using a gate
is always a compromise between eliminating the noise when you are
not playing yet still being able to play phrases with a low dynamic
content. Experiment to find the best setting for your setup.
Boost/Distortion - Selects boost or distortion function. Use boost for a
clean boost that will raise the level on clean/crunch sounds and use the
distortion to experience the classic distortion that gives you a fat easy
to control distortion sound.
Distortion - Sets the amount of distortion when the pedal is used in
distortion mode.
Bass - Add a bit of bass for extra punch or attenuate if you feel you are
about to blow your speakers.
10 Classic Booster + Distortion
Treble - Adding boost or distortion to a sound always changes the
perceived amount of treble. Use the Treble control to adjust the amount
of high-end frequencies in the sound.
Output Level - Sets the overall output level for both the distortion and
boost modes.
