RS 17/102H
HERITAGE TRACTOR
Code149D
INSTRUCTION BOOK
(English Version)
MANUAL PART NO: 111-0442 (A)
Code From serial No.
149D 260000001
Issue 01/11/05

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Heritage RS 17/102H and is the answer not in the manual?

Questions and answers

Summary of Contents for Hayter Heritage RS 17/102H

  • Page 1 RS 17/102H HERITAGE TRACTOR Code149D INSTRUCTION BOOK (English Version) MANUAL PART NO: 111-0442 (A) Code From serial No. 149D 260000001 Issue 01/11/05...
  • Page 3 Ø19 x Ø26 Ø20 x Ø42...
  • Page 4 Ø 6 (2x) M6 x 45 (2x) M6 (2x) Ø 6 x Ø 12 (4x)
  • Page 5 Ø6 x Ø Ø6 x Ø12...
  • Page 6 ¾ ½ ¼...
  • Page 8: Table Of Contents

    Before assembly and start of operation, please read the operating instructions at all costs and comply with them. Dear Customer, You have bought a totally tested quality product. However, should you have any reason for complaints, please get in touch with your dealer, stating the code and serial number (see nameplate).
  • Page 9: Safety Precautions

    SAFETY PRECAUTIONS General remarks 1.1 Read the operating instructions carefully. Familiarise yourself with the proper use of the machine. 1.2 People under 16 or people who have not read the operating instructions are not allowed to use the machine. 1.3 Do not operate the machine when there are others, in particular children or animals, in the area.
  • Page 10: Unpacking Lawntractor

    Instructions for maintenance and storage 4.1 Make sure that the nuts, bolts and screws are tight. 4.2 Be careful when adjusting - danger of injuries. Do not trap your fingers between the housing and the blade. Wear protective gloves. 4.3 Never store the lawn tractor with fuel in the tank inside a building in which petrol fumes can possibly come into contact with naked flames or with sparks - danger of explosion!
  • Page 11: Assembly

    ASSEMBLY The following assembly work must be carried out before the first operation: 1. Installation of the wheels. 2. Installation of the steering wheel. 3. Installation of the driver's seat. 4. Assembly of the grass box 5. Fitting the grass box to the lawn tractor. Attention! Putting into operation (even test operation) before complete assembly has taken place is strictly forbidden - dangers of...
  • Page 12: Assembling The Grass Box

    Assembling the grass box Place the lower part of the frame on a suitable base (e.g. a table). Screw the upper part of the frame onto the lower part of the frame on both sides. M 6 x 35 hexagonal head screw Ø...
  • Page 13: Safety Systems

    FIRST OPERATION The lawn tractor may only be put into operation when the assembly has been completed. Safety systems The lawn tractor is fitted with 3 safety contacts which are operated the driver's seat the grass box and the pedal. The engine can only be started if the driver is sitting on the driver's seat, the brake has been operated and the mowing appliance has been switched off.
  • Page 14: Starting The Engine

    Meaning of the symbols on the pedal Clutch Brake "Clutch / Brake" pedal If the pedal is half pushed down, the clutch is disengaged. If the pedal is completely pushed down, the clutch is disengaged and the disk brake of the transmission operated. With the pedal completely pressed down, the pedal can be locked in the "Brake"...
  • Page 15: Setting The Cutting Height

    Brakes • Press the right-hand pedal down completely in order to brake. Switching the mowing appliance on • Only switch the mowing appliance on with the engine running. • Put the gas lever into the • Set the required cutting height. •...
  • Page 16: Emptying The Grass Box

    Always have the mowing blade resharpened or replaced by a customer service centre (measurement of imbalance). Unbalanced blades will cause the lawn mower to vibrate violently – risk of accident! GB 16...
  • Page 17: Maintenance And Service

    Mowing system On the mowing deck, there are two connections for a ½" water hose coupling. The mowing system can be cleaned by connecting a water hose. During the cleaning process, the grass box or a suitable accessory must be fitted. 1.
  • Page 18: Oil Change

    Lubrication plan In order to ensure the ease of movement of the moving parts, we recommend lubricating the following parts after 10 hours of operation. Front axle: Steering swivel right and left (lubrication nipple): - with multi-purpose grease Bearing of the front axle on the frame - with spray oil Steering: Gear segment and steering pinion on steering gear...
  • Page 19: Charging The Starter Battery

    Charging the starter battery IMPORTANT! The starter battery may only be charged in dry rooms. Remove the ignition key. Connect the charging device to the mains and connect the termi nals to the connection poles on the battery. Pay attention to the polarity: red terminal = positive pole (+) black terminal = negative pole (-) Function of the charging device: see operating instructions for charging...
  • Page 20: Trouble Shooting

    TROUBLE SHOOTING FAULT POSSIBLE CAUSES Engine does not start Lack of fuel Bad, contaminated fuel, old fuel in the tank Air filter contaminated No ignition spark Engine "flooded" due to repeated attempts to start Starter does not react Starter battery empty or weak Safety switch on driver's seat not functioning Safety switch on brake pedal not functioning Mowing appliance switched on...
  • Page 21: Warranty

    Hayter Limited warrants to the original user / purchaser that this unit shall be free from defects in material and workmanship under normal use and service for a period of three years from the date of purchase. The manufacturers of the engine and battery pack system (where applicable) fumish their own warranty and services are provided through their authorised network (Refer to "Engine/Battery Pack Warranty Statement').
  • Page 22: Declaration Of Conformity

    Lawntractor vibration information. RMS acceleration measured in 3 - axes at operators contact position an, CODE 149D = 4,2 ms² the handlebars. Manufactured by AL-KO Kober GmbH, A-8742 Obdach AUSTRIA Heritage RS 17/102H Code 149D 1020 mm B & S Intek OHV AVS 2900 rpm 99 dB(A)
