- Page 1 READ AND SAVE THESE INSTRUCTIONS OWNER’S MANUAL FOR BYPASS AND FAN POWERED HUMIDIFIERS Includes Safety, Operating and Maintenance Instructions ©2005 CAC/BDP 7310 West Morris St., Indianapolis, IN 46231 10006720 11.05 Form/Catalog: OG-HUM-03 B2203903A...
-
Page 2: Table Of Contents
Bypass and Fan Powered Humidifiers The humidifier operates in conjunction with the furnace blower motor. When the humidistat calls for humidity and the blower motor is operating, water flows Table of Contents to the distribution pan located at the top of the unit. The water is uniformly dis- Page tributed across the width of the pan and through a scientifically designed system of outlets. -
Page 3: Operating Instructions
II. Operating Instructions Your Automatic Humidifier, is a high precision system that will accurately maintain the relative humidity in your home. For every 1°F change in outdoor Your new humidifier is controlled by a manual humidistat, HumidiTrac ™ temperature, the control will automatically adjust the indoor relative humidity Thermidistat ™... - Page 4 To check the humidifier’s operation, note the current setting and set the To check the humidifier operation, set the humidifier control above the HumidiTrac ™ Control to the test mode when the furnace blower motor is click point, make sure that the water saddle valve is open and that there is operating.
-
Page 5: Effect Of Water Characteristics
III. Effect of Water Characteristics VI. Periodic Preventative Maintenance Your humidifier will operate effectively using either hard or mechanically NOTE: Periodic inspection and preventative maintenance of your total heat- softened water. ing system is important for efficient and safe operation. Your dealer will include Any type of water (hard, soft, hot, or cold) is acceptable for use with the humidifier service during a maintenance inspection. -
Page 6: Maintenance Instructions
MAINTENANCE INSTRUCTIONS FOR MAINTENANCE INSTRUCTIONS FOR SMALL AND LARGE BYPASS HUMIDIFIERS FAN POWERED HUMIDIFIER 1. Front Cover 1. Front Cover 2. Feed Tube 2. Base 3. Nozzle 3. Evaporative Assembly 4. Evaporative Assembly 4. Distribution Tray 5. Distribution Tray 5. ”V” Notches 6.
