QuickSpecs
Overview
1. Hot-plug Disks
2. Cell Boards
3. Redundant Hot-swap Power
DA - 12697
North America — Version 4 — March 3, 2008
4. Redundant Hot-swap Fans
5. PCI Power Supplies
6. Removable Media DVD/DAT
HP 9000 rp8440 Server
HP 9000 rp8440 Server
HP 9000 rp8440 Server
HP 9000 rp8440 Server
Page 1

Advertisement

loading

Related Manuals for HP 9000 rp8440

Summary of Contents for HP 9000 rp8440

  • Page 1 QuickSpecs HP 9000 rp8440 Server HP 9000 rp8440 Server HP 9000 rp8440 Server HP 9000 rp8440 Server Overview 1. Hot-plug Disks 4. Redundant Hot-swap Fans 2. Cell Boards 5. PCI Power Supplies 3. Redundant Hot-swap Power 6. Removable Media DVD/DAT DA - 12697 North America —...
  • Page 2 HP 9000 rp8440 Server Flexible Advantage Starter (FAST) Base Systems The F F F F lexible A A A A dvantage ST ST ST STarter base systems for the HP 9000 rp8440 Server allow for faster configurations due to the semi configured base system bundles.

  • Page 3: Standard Features

    Standard System Features Standard System Features Standard System Features Operating system support: HP UX 11i v1, HP UX 11i v2 and HP UX 11i v3 External Ultra320 SCSI channel Two Internal Ultra320 SCSI channels, one channel to each internal disk...
  • Page 4 QuickSpecs HP 9000 rp8440 Server HP 9000 rp8440 Server HP 9000 rp8440 Server HP 9000 rp8440 Server Standard Features High Availability High Availability High Availability High Availability N+1 Hot swap cooling Redundant and hot swap power supplies Cell Hot plug...
  • Page 5 Cell Boards Cell Boards A minimum of one and a maximum of four cells can be ordered in HP 9000 rp8440 Servers. Each cell can be purchased with up to four active PA 8900 processors, or in combination with Instant Capacity processors.
  • Page 6 Memory Configuration Memory Configuration The memory DIMMs used in the HP 9000 rp8440 Server are sold in pairs and are custom designed by HP. Each DIMM contains DDR II memory chips qualified to run at 267/533 MHz, with full ECC protection.
  • Page 7 I/O card slots. With one cell board, access to eight slots is enabled. The HP 9000 rp8440 Server can be purchased with either one or two core I/O boards (if an SEU 2 is added, then four core I/O boards with two core I/O in the SEU 2). Both core I/O boards are identical and provide console, SCSI, serial, and Management Processor (MP) functionality.
  • Page 8 "hot plugged" or serviced without affecting other slots. The hot plug operation is very easy, and can be done with minimal training and effort. The HP 9000 rp8440 Server supports a number of PCI and PCI X HBA (I/O) cards for I/O expansion. NOTE:...
  • Page 9 4 / 4 External Server Storage External Server Storage External Server Storage External Server Storage HP has the broadest, most robust server and storage line up in the industry, providing exactly the right fit Connectivity Connectivity Connectivity Connectivity for every need. Refer to the Storage Server matrix to see a matrix that highlights which storage device, server and operating system is interoperable.
  • Page 10 External SCSI port: Ultra320 SCSI port for connections to mass storage or media. Access to internal peripheral bay: The first core I/O card enables half of the HP 9000 rp8440 Server peripheral bay, which includes one removable media and two low profile disks. The second core I/O card enables the remaining internal peripherals, two disks and one removable media bays.
  • Page 11 3.6 msec (read); 3.9 40 MB/s msec (write) HP 9000 rp8400/rp8420/rx8620 disk drives can be carried forward to the HP 9000 rp8440 server. For HP-UX: Independent UltraSCSI controllers provide each disk drive with an independent SCSI channel Supported by MirrorDisk/UX across disk drives, controllers, and Core I/O boards...
  • Page 12 Addition I/O resources Addition I/O resources Addition I/O resources Addition I/O resources Additional I/O resources can be obtained by adding the HP Server Expansion Unit 2 (SEU 2). The SEU 2 using the Server using the Server using the Server...
  • Page 13 AC Power Consumption AC Power Consumption The HP 9000 rp8440 Server power consumption will vary greatly depending on the hardware configuration and the input line voltages supplied at customer sites. Because of the disparity of line voltages throughout the world it's best to represent power consumption in VA (Volt Amperes).
  • Page 14 HP Server solution. For more details on PDUs, please refer to the PDU sales collateral. The drawing below is an example of how the PDU can be configured with the HP 9000 rp8440 Server in a dual grid configuration. In this case there are two HP 9000 rp8440 servers (average configurations drawing ~9 amps each) and two 60 amp PDUs configured with redundant power.
  • Page 15 I/O slots in partition 0 and four I/O slots in partition 1. Please refer to the "HP Server Expansion Unit 2" section in this guide or more specific details.
  • Page 16 HP 9000 rp8440 servers support virtual partitioning (vPars) to the single processor level similar to support on HP 9000 servers with HP UX 11i v1. With vPars, a user will be able to support up to eight separate virtual partitions each with an instance of HP UX within each hard partition. VPars will provide many of the features of nPars but without the electrical isolation and support for hardware failures that nPars provides.
  • Page 17 HP 9000 rp8440 Server HP 9000 rp8440 Server Configuration patches installed on an HP-UX 11i system and generating a report of recommended security patches. System Inventory Manager is for change and asset management. It enables you to easily collect, store, and manage inventory and configuration information for HP-UX-based servers. It provides an easy to use, web based interface, superior performance, and comprehensive reporting capabilities.
  • Page 18 At 17 EIA units (29.75 inches), two HP 9000 rp8440 servers can be mounted into a single HP rack two meter cabinet with 7 or 8 EIA units of extra space for mounting external peripherals. One rp8440 can be mounted in a rack along with a Server Expansion Unit 2.
  • Page 19 HP 10000 and 9000 HP 10000 and 9000 HP 10000 and 9000 HP 10000 and 9000 The HP 9000 and Integrity servers are supported for field installs into these racks. Factory integration will Racks Racks Racks Racks (These racks are the not be supported for HP 10000 and HP 9000 racks.
  • Page 20 HP 9000 rp84xx HP 9000 rp84xx HP 9000 rp84xx HP 9000 rp84xx All HP rp84xx servers are in box upgradeable to rp8440 servers in the current chassis. In box upgrades Upgrades to HP 9000 Upgrades to HP 9000 Upgrades to HP 9000 Upgrades to HP 9000 may take one to two 8 hour periods either of successive days or using successive shifts on the same day.
  • Page 21 QuickSpecs HP 9000 rp8440 Server HP 9000 rp8440 Server HP 9000 rp8440 Server HP 9000 rp8440 Server Upgrades Nameplates and labels "Read Me" documents, Upgrade Guide, CD ROM Miscellaneous cables For more information on upgrades, return credits and services products, please refer to the midrange upgrade guide on the Source/Partner Portal.

  • Page 22: Technical Specifications

    QuickSpecs HP 9000 rp8440 Server HP 9000 rp8440 Server HP 9000 rp8440 Server HP 9000 rp8440 Server Technical Specifications Server model number Server model number Server model number Server model number rp8440 Number of dual core HP Number of dual core HP...
  • Page 23 QuickSpecs HP 9000 rp8440 Server HP 9000 rp8440 Server HP 9000 rp8440 Server HP 9000 rp8440 Server Technical Specifications I/O Buses and Slots I/O Buses and Slots I/O Buses and Slots I/O Buses and Slots Total Hot-plug PCI-X Slots Total Hot-plug PCI-X Slots...
  • Page 24 Intel and Itanium are registered trademarks or trademarks of Intel Corporation in the U.S. and/or other countries. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
