- Page 2 Hawking Customer Service in order to obtain a Return Authorization number. Warranty is for repair or replacement only. Hawking Technology does not issue any refunds. BE SURE TO HAVE YOUR PROOF OF PURCHASE. RETURN REQUESTS CAN NOT BE PROCESSED WITHOUT PROOF OF PURCHASE.
-
Page 3: Table Of Contents
1 INTRODUCTION ... 1 Features ... 1 Specifications... 1 Package Contents ... 2 2 INSTALLATION PROCEDURE ... 3 3 CONFIGURATION UTILITY ... 8 Site Survey ... 8 Profile... 9 3.2.1 Configure the Profile... 10 System Configuration... 10 Authentication vs. Security ... 12 Link Status ... -
Page 4: Introduction
1 Introduction Thank you for purchasing the Hawking Technologies Wireless-108G USB Adapter with Removable Antenna. This device complies with the IEEE 802.11g standard, which supports up to 108Mbps high-speed wireless networking when paired with the Hawking Wireless-108G router. It is also backwards compatible with IEEE 802.11b devices. -
Page 5: Package Contents
• Antenna: Hi-Gain Advanced Dual Design 5/5dBi Antenna (Rotate and Swivel) • Drivers: Mac OSX 10.3 – 10.4 (Supports Tiger OS) • LEDs: Power, Link • Transmit Power: 16dBm~18dBm (Before Antenna) • Power consumption: Tx: 350mA, Rx: 250mA • Receive Sensitivity: 54Mbps OFDM, 10% PER, -70dBm, 11Mbps CCK, 8% PER, -86dBm, 1Mbps BPSK, 8% PER, -92dBm •... -
Page 6: Installation Procedure
2 Installation Procedure Before you proceed with the installation, please notice following descriptions. Note1: Please do not install the wireless adapter into your laptop computer before installing the software program from the CD. Note2: The following installation was operated under Apple OSX 10.3 Panther. (Procedures are similar for other operating systems) Note3: If you have installed the Wireless adapter driver &... - Page 7 iii. Click Continue to begin (Note: the setup wizard may look different depends on the version of Mac OS X you are using. ) B. Select the location on your computer where you wish to install the software and click “Continue.” C.
- Page 8 E. When setup has completed. Click Restart to complete the driver installation. F. When your computer has successfully restarted. Insert the Hi-Gain Mini USB Wireless-G Adapter into an available USB port on your desktop or notebook computer. - Insert the USB adapter firmly into the USB port to ensure a proper connection is made. When the adapter is inserted carefully lift the antenna unit upright.
- Page 9 2) System Preferences and Network Settings (a) Click the APPLE icon on the top left corner of your desktop and open the SYSTEM PREFERENCES menu. (b) If this is your first time using the Wireless-G USB adapter on your computer, you will need to enable the device before using the Wireless Utility.
- Page 10 How to Change Your IP Address to Static mode If your wireless network uses a static IP address or requires manual configuration you may do so by highlighting the USB wireless adapter(Shown above). Select “Configure” to enter the configuration menu for the wireless adapter. Select the Tab that is named TCP/IP Select the menu button for “Configure IPv4”...
-
Page 11: Configuration Utility
3 Configuration Utility The Configuration Utility is a powerful application that helps you configure the HWU54DMA and monitor the link status and statistics of your wireless connection. Each time you insert the Hawking Hi-Gain card the Hawking Wireless Utility should automatically load. -
Page 12: Profile
Connect Button Add to Profile Button Profile The “Profiles List” is for you to manage the networks you connect to frequently. You are able to Add/Delete/Edit/Activate a profile. Parameter Profiles List Add/Delete/Edit Button Activate Button Click “Connect” to connect to the selected network. Add the selected network to Profiles list. -
Page 13: Configure The Profile
3.2.1 Configure the Profile System Configuration Parameter Profile Name SSID Power Saving Mode Description Define a recognizable profile name for you to identify the different networks. The SSID (up to 32 printable ASCII characters) is the unique name identified in a WLAN. The ID prevents the unintentional merging of two co-located WLANs. - Page 14 Parameter Network Type Transmit Power 11B Preamble Type RTS Threshold Fragment Threshold Channel Description Infrastructure – This operation mode requires the presence of an 802.11 Access Point. All communication is done via the Access Point or Router. Ad-Hoc – Select this mode if you want to connect to another wireless station in the Wireless LAN network without going through an Access Point or Router.
-
Page 15: Authentication Vs. Security
Authentication vs. Security Parameter Authentication Type Description This setting has to be consistent with the wireless networks that the card intends to connect to. All security keys within a network must match to allow successful communications. None – No authentication is needed among the wireless network. Shared –... - Page 16 Parameter Encryption Mode WPA Pre-Shared Key WEP Key (Key1 ~ Key4) Description None – Disable the WEP Data Encryption. WEP – Enable the WEP Data Encryption. When the item is selected, you have to continue setting the WEP Encryption keys. TKIP –...
-
Page 17: Link Status
Link Status From the “Link Status” option, you can view all the information of the network you are connecting to. You can use this tool in while at the same time repositioning the Hi-Gain antenna to find the optimal location for antenna placement. Parameter Status Current Channel... -
Page 18: Reading The Link Status Page And Obtaining The Strongest Connection
Signal Strength Reading the Link Status Page and Obtaining the Strongest Connection The Link Status page gives you information regarding your current wireless channel, transmit rate (speed) and link/signal quality. You will use this utility to figure out which antenna position results in the best performance and connection. 1) First you must determine where the location of your Wireless Access Point is within your network. -
Page 19: Statistics
Statistics This option enables you to view the available statistic information with its Tx counts (Tx success, Tx error, RTS Success and RTS Failed), and its Rx counts (Rx success, Rx error). You may reset the counters by clicking ”Reset Counter”. -
Page 20: Advanced
Advanced This option enables you to configure more advanced settings, for example: wireless mode, protection mode and etc. Parameter Wireless Mode Tx Burst B/G Protection Description 802.11 B/G mix – If you have a mix of 802.11b and 802.11g wireless stations in your network, it is recommended to setting the card to this mode. -
Page 21: About
Parameter ADHOC_OFDM Tx Rate Turn Off RF Button About By choosing this option, you can click the hyperlink to connect to the website for the information of the wireless chipset vendor and review basic information about the Utility such as the Driver, Utility and EEPROM Version. -
Page 22: Troubleshooting
4 Troubleshooting This chapter provides solutions to problems usually encountered during the installation and operation of the adapter. 1. What is the IEEE 802.11g standard? 802.11g is the new IEEE standard for high-speed wireless LAN communications that provides for up to 54 Mbps data rate in the 2.4 GHz band. 802.11g is quickly becoming the next mainstream wireless LAN technology for the home, office and public networks. - Page 23 6. What is BSS ID？ A specific Ad hoc LAN is called a Basic Service Set (BSS). Computers in a BSS must be configured with the same BSS ID. 7. What is WEP？ WEP is Wired Equivalent Privacy, a data privacy mechanism based on a 40 bit shared key algorithm, as described in the IEEE 802 .11 standard.
- Page 24 13. What is Spread Spectrum？ Spread Spectrum technology is a wideband radio frequency technique developed by the military for use in reliable, secure, mission-critical communication systems. It is designed to trade off bandwidth efficiency for reliability, integrity, and security. In other words, more bandwidth is consumed than in the case of narrowband transmission, but the trade off produces a signal that is, in effect, louder and thus easier to detect, provided that the receiver knows the parameters of the spread-spectrum signal being broadcast.
