Summary of Contents for Hawking HWUN1
- Page 2 If the product proves defective during this two-year warranty period, call Hawking Customer Service in order to obtain a Return Authorization number. Warranty is for repair or replacement only. Hawking Technology does not issue any refunds.
-
Page 3: Table Of Contents
6.1. VERIFY INSTALLATION (WINDOW 2000/XP) ... 14 6.2. NETWORK CONFIGURATION (WIN 2000/XP) ... 15 SETUP WLAN (WIN 2000/XP) ... 16 – USING HAWKING CONFIGURATION-UTILITY ... 16 7.1. NETWORK SECURITY (WEP, WPA…) ... 18 7.1.1. WEP S ... -
Page 4: Introduction
1. INTRODUCTION Thank you for purchasing the Hawking HWUN1 Wireless-N USB Adapter. Now you can enjoy the latest Wireless-N technology with excellent speeds, of up to 300Mbps*. The Wireless-N USB Adapter extends your wireless network coverage by up to 3 times and boosts transmission throughput 12 times more than a standard Wireless-G Network. -
Page 5: Package Contents
3. PACKAGE CONTENTS Before you begin the installation, please check the items of your package. The package should include the following items: • One HWUN1 Wireless-N USB network Adapter • One USB cable (1.0m) • One CD-ROM with User’s Manual & Drivers •... -
Page 6: System Requirements
4. SYSTEM REQUIREMENTS To begin using the WLAN USB Adapter, your PC/Notebook must meet the following minimum requirements: • Operating System – Microsoft Windows 2000/XP/Vista • An Available USB Port on your Laptop or Desktop • 256MB system memory or larger •... - Page 7 Select Install to begin the Installation Please wait a while as the installation process take place. After installation is complete, exit the wizard by clicking on the Finish button. Now, plug in your HWUN1 adapter.
-
Page 8: Using Windows Configuration (Vista)
USING WINDOWS CONFIGURATION (VISTA) 5.1. It is recommended that you use the Windows Configuration for the Wireless-N Adapter. a. To open up the Windows Configuration, go to Start Connect To b. Select the Network you wish to connect to. If you are connecting to an unsecure network, go to step c. - Page 9 c. If you are connecting to an open network (unsecured network), a warning may appear indicating that the network is an unsecured network. Select Connect Anyway and skip step d. If your selected network is a secured (encryption) network, then a window will prompt you to enter security key or passphrase.
- Page 10 Please wait while your HWUN1 is connecting. The HWUN1 Wireless-N USB Network Adapter is now connected, you may save this network as your preferred network.
-
Page 11: Installation (Windows 2000/Xp)
6. INSTALLATION Important! Please Install the HWUN1 Driver & Utility before connecting the HWUN1 into the USB port on your computer. The HWUN1 Driver & Utility is located on the CD. Insert the support CD into your CD Drive. In the CD drive folder, you will see the following file. - Page 12 Await instructions as you see the setup progress as shown below...
- Page 13 It may give you the option to restart. Click Finish to restart the PC/notebook. Restart your computer if the wizard prompted you to do so. Otherwise, please plug the Hawking HWUN1 Wireless-N Network Adapter into an available USB port on your desktop or notebook.
-
Page 14: Verify Installation (Window 2000/Xp)
6.1. Verify installation (WINDOW 2000/XP) 1. Open Control Panel Double-click on System. 2. Select Hardware tab Click on Device Manager. Select and double-click on 802.11N USB wireless LAN card. Verify the device status of the 802.11N USB Wireless LAN Card This device is working properly Click OK... -
Page 15: Network Configuration (Win 2000/Xp)
6.2. Network Configuration • Go to Start Menu Control Panel • Right-click on Wireless Network. • Select Local Area Connection icon • Select Internet Protocol (TCP/IP) (WIN 2000/XP) Network. select Properties. Click Properties. -
Page 16: Setup Wlan (Win 2000/Xp)
If the connection is successful, a message will appear on taskbar. The following steps guide you on how to initially setup a wireless network connection. The Hawking Configuration Utility should appear on the bottom right taskbar. Select the [General] tab. a. If your Wireless Router supports... - Page 17 Mouse over the “Hawk” icon and you’ll get a brief description and status of your WLAN. For example, the figure below shows the HWUN1 is connected to an NRouter. Right click on the “HAWK” icon and it will open up a menu as shown below Click on Launch Config Utilities Figure 6.4...
-
Page 18: Network Security (Wep, Wpa
“none” will be listed under Encryption column.) When you are successfully connected, a handshake icon next to the selected AP. When the HWUN1 fails to connect, the status bar (bottom left of the HWUN1 Wireless Utility) will show “Disconnected”. NETWORK SECURITY (WEP, WPA…) 7.1. -
Page 19: Wpa Setup
An Authentication and Security Window (figure 7.1b) should appear shortly. WEP Setup Instructions: (All settings should correspond with settings of the wireless AP that you are connecting to.) a. Authentication Type field: indicates the authentication type of the AP/Router. Please confirm the setting of the AP/Router. •... - Page 20 WPA-PSK and WPA2-PSK Setting the Authentication and Security Page: a. Authentication Type: Select WPA-PSK or WPA2-PSK (note: your AP must support this function). b. Encryption: Select TKIP or AES in the drop down menu.(Must Correspond to the Value on your c.
- Page 21 WPA and WPA2 1. If you wish to connect to an AP with WPA or WPA2 authentication, select the AP or SSID and select Connect. (For example the NRouter is being selected, the security settings must correspond to Wireless Access Point) Setting the Authentication and Security Page: a.
-
Page 22: Adding Profiles
Click OK to finish setting. Adding Profiles 7.2. 1. Select an AP in the SSID column (example: NRouter the page shown below will appear. 2. Setting items in the configuration tab: • Profile Name: Enter the connected AP profile, eg: PROF1. Click Add to Profile and... - Page 23 • SSID: Click the drop-down menu and select one AP. You can also enter the AP manually. • PSM: When CAM is selected, it indicates that the product is not in power saving status. When PSM is selected, the product is in power saving status. (Only select it under Infrastructure network type).
-
Page 24: Wps Configuration
WPS Configuration 7.3. Wi-Fi Protected Setup (WPS) configuration function - provides easy procedures to set up wireless security. Wi-Fi Protected Setup gives you a variety of setup options. It uses familiar methodologies such as typing in a Personal Identification Number /numeric code (PIN method), and pushing a button (Push-Button Configuration, or PBC) to enable users to automatically configure network names and strong WPA2 (Wi-Fi Protected Access 2TM) data encryption and authentication. -
Page 25: Qos
WMM provides prioritized media access and is based on the Enhanced Distributed Channel Access (EDCA) method. Click WMM Enable to turn on the WMM capability. Click WMM – Power Save Enable and this can improve the power savings by atleast 15% as far as the HWUN1 power consumption is concerned. -
Page 26: Advanced Settings
9. Advanced Settings TX-Burst: Turbo Mode. When it is checked and the HWUN1 Wireless N-Adapter is connected to an Access Point with TX-Burst function, the transmission throughput will be improved. (Note: This only works with Access Point that supports this function) Enable TCP Window Size : When checked, the reception speed will improve.) -
Page 27: Statistics
10. Statistics The Statistics tab displays detailed information about Wireless LAN TX/RX. • Transmit Statistics: Statistic of transmitted frames. • Receive Statistics: Statistic of received frames. • [Reset Counters]: Click [Reset Counter] to start over at zero the statistic numbers of transmitting and receiving data. -
Page 28: Link Status
11. Link Status This tab displays the information of the Wireless connection status. • Status: Displays the linked AP name and MAC address. When [Disconnect] appears in this box, the connection is failed. • Extra Info: link status and strength. •... -
Page 29: About
12. About The About tab displays version information of 1. Driver 2. Utility 3. EEPROM binary 4. Firmware 5. IP Address (current) 6. MAC address of the PHY 7. Subnet MASK Address 8. Default Gateway... -
Page 30: Uninstalling Hawking Utility/Driver
13. Uninstalling Hawking Utility/Driver Select Uninstall option from the start menu. You can see the wizard preparing for uninstallation Select Remove All. When asked if you are sure you want to remove application and all its features, click Yes. - Page 31 Removing the utility is in progress. At any time you may press cancel to abort uninstallation.
- Page 32 You will need to restart your computer to ensure a clean removal of the Hawking Utility.
-
Page 33: Appendix A - Specifications
APPENDIX A – SPECIFICATIONS Data Rates 1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, 54, 72, 84, 150 and 300Mbps (with 2-stream on both ends) Standards / Compliance IEEE802.3, IEEE802.3u, IEEE802.11b, IEEE802.11g, 802.11n 2.0 Regulation Certifications FCC Part 15, ETSI 300/328/CE Operating Voltage 5 V ±... -
Page 34: Product Support Information
PRODUCT SUPPORT INFORMATION Thank you for choosing Hawking Technologies. Please do not hesitate to contact us if you have any questions regarding the installation of your product. We’re here to help you 24 hours a day, 7 days a week! PHONE SUPPORT •...
