EOA3630                                                                          Quick Start Guide
Wireless Multi‐Function AP
The  outdoor  wireless  device  EOA3630  is  a  powerful,  enhanced,  enterprise  scale
product with 7 multi‐functions. External N‐type connector provides antenna extend.
It features output power levels setting, Narrow bandwidth selection, Traffic Shaping
and Real‐time RSSI indicator.
EOA3630  comes  with  wall  mount  kit  and  supports  PoE  function  for  quick  outdoor
installation.  To  ensure  wireless  security,  it  provides  full  coverage  of  security
encryption mechanisms support including WEP, WPA/WPA2 and IEEE 802.1x.
Beside upgradable N‐type interface which make it a scalable solution for all possible
project  requirements.  Stable  and  high  reliability  design  let  users  don't  worry  about
the operation in harsh environment.
‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐
IP Address Configuration
The  default  IP  address  of  the  device  is
192.168.1.1. In order to log into this device, you
must  first  configure  the  TCP/IP  settings  of  your
PC/Notebook.

1.
In  the  control  panel,  double  click  Network
Connections  and  then  double  click  on  the
connection of your Network Interface Card
(NIC).  You  will  then  see  the  following
screen.
2.
Select  Internet  Protocol  (TCP/IP)  and  then
click  on  the  Properties  button.  This  will
allow  you  to  configure  the  TCP/IP  settings
of your PC/Notebook.
3.
Select  Use  the  following  IP  Address  radio
button  and  then  enter  the  IP  address
(192.168.1.21)
(255.255.255.0). Ensure that the IP address
and subnet mask are on the same subnet as
the device.
4.
Click  on  the  OK  button  to  close  this
window,  and  once  again  to  close  LAN
properties window.
Logging In
1.
To  configure  the  device  through  the
web‐browser,  enter  the  IP  address  of  the
Bridge  (default:  192.168.1.1)  into  the
address  bar  of  the  web‐browser  and
press Enter.
2.
After  connecting  to  the  IP  address,  the
web‐browser  will  display  the  login  page.
Specify  admin  as  the  default  User  Name
and  Password,  and  then  click  on  the  Login
button.
Quick Start Guide v.1.0
Refer to User's Manual for complete instructions


and
subnet
mask

Administration
1.
Click  on  the  Administration  link  under  the
Management  section.  This  option  allows
you  to  modify  to  new  user  name  and
password  for  the  device.  For  security  it  is
highly recommended for security reasons.
2.
Name:  Specify  a  user  name  into  the  first
field.
3.
Password: Specify a password into this field
and  then  re‐type  the  password  into  the
Confirm  Password  field.  Then  click  on  the
Apply button.
4.
Click  on  the  Apply  button  to  save  the
changes.
System Properties
1.
Click  on  the  System  Properties  link  on  the
System  section.  This  feature  allows  you  to
configure  the  device  as  an  Access  Point  or
Repeater.
2.
Device  Name:  Specify  a  name  for  the
device – this is not the SSID.
3.
Country/Region: Select the region from the
drop‐down list.
1
