Contents Contents Fridge freezer levelling and door alignment Levelling the fridge freezer Introduction Adjust the doors Install the door handles Safety is important Installing the water filter In the box Installing the water line Safety information Disposal and Guarantee Important safety information Disposal Warnings Guarantee... -
Page 4: Introduction
• User guide • Spanner • Egg case • Water supply kit (connector, water pipe) • Water filter Note: If any of the items listed are damaged or missing, please contact your local John Lewis branch. Fridge freezer user guide... -
Page 5: Safety Information
To avoid accidents to property or people it is important to carefully before use follow the instructions given. Failure to do so removes any liability from John Lewis. Take note of the following safety information which appears on the back of this fridge freezer: Warnings Warning! To prevent fi... -
Page 6: Cautions
• When the fridge freezer is to be scrapped, cut off the • Do not install the fridge freezer on a wet fl oor or in a place electrical supply cable and destroy the plug with the with a high humidity / moisture content. remaining cable. -
Page 7: Electrical Information
Electrical information Mains supply Warning! This fridge freezer MUST BE EARTHED. Should the power supply cable need to be replaced, this must be carried out by an approved service engineer. John Lewis declines any liability should this safety measure not be observed. -
Page 8: Parts Identification
Parts identification Control panel Display panel symbol - Current status of the Display panel symbol - Fridge compartment water filter temperature indicator Display panel symbol – Freezer compartment Display panel symbol - Ice dispensing lock selected temperature indicator (“Ice” button for 3 seconds to lock or release) Display panel symbol - Water dispensing Fridge temperature change/supercool button selected... -
Page 9: Operation
Operation Temperature control Notes: • The Interior lights of the fridge turn off when the doors are When the fridge freezer is first plugged in, the default left open for more than 10 minutes. temperature settings for the fridge and freezer are mid range. •... -
Page 10: How To Use The Fridge Storage Areas
How to use the fridge storage areas The following list is a suggestion of the usage for each of the compartments within the fridge: Upper / Lower freezer door compartments – for Egg case storing ice cream or short-term storage foood Adjustable fridge glass shelf Mid freezer door compartments –... -
Page 11: Food Storage Tips
Food storage tips Wash you food before storing. Divide and separate food into smaller pieces. Place watery food or food with moisture on the front shelves close to the edges of the fridge compartment. If they are placed close to the cold air spout, they can be frozen. Warm or hot food should be cooled down before storing to reduce power consumption and to enhance refrigeration performance. -
Page 12: Automatic Ice Maker
Automatic ice maker Cautions: • Avoid using thin fragile cups or crystal The automatic ice maker makes approximately eight ice cubes glasses when taking ice cubes. at a time and it does these approximately 15 times a day. If the ice storage case is full, the automatic ice maker detects this •... -
Page 13: Care, Cleaning And Servicing
Care, cleaning and servicing Ice cubes storage case Switch off and unplug the fridge freezer before carrying out any cleaning or maintenance work. Press the release button and remove the ice cube container. Care and cleaning Clean the interior exterior casing using a cloth with water and mild (neutral) Detergent. -
Page 14: Fridge And Freezer Shelves
Freezer & Fridge shelves Door compartment rack Remove a shelf by lifting it up at the front, pulling it, unhook it Hold both ends of the rack and remove by pulling it up. and then remove it. Replace the shelf by locating the rear lugs, lower the shelf and the pushing it all the way back in. -
Page 15: Servicing
Servicing This fridge freezer should only be serviced by an authorised service engineer, and only genuine spare parts should be used. Under no circumstances should you attempt to repair the fridge freezer yourself. Repairs carried out by inexperienced persons may cause injury or serious malfunction. Fridge freezer user guide... -
Page 16: Installation
Installation Preparation for installation 3 Turn top hinge fastener (turn in an anti-clockwise direction) and disconnect the harness wires. Before unpacking your fridge freezer, be aware of the following points: Find a suitable location for the fridge freezer; it should be positioned as follows: •... -
Page 17: Removing The Fridge Door
Removing the fridge door Replacing the freezer door 1 Remove the retaining screws from the top hinge cover 1 Insert the water tube into the hole of the bottom and remove the hinge cover. hinge pint first. 2 Align the top of door and ensure it is secure against the cabinet. -
Page 18: Replacing The Fridge Door
Replacing the fridge door Fridge freezer levelling and door alignment 1 Insert the bottom hole of fridge door straight into the bottom hinge pin. The fridge freezer must be level in order to maintain optimal performance and visual presentation. If the floor underneath is uneven, the fridge freezer doors will look unbalance. -
Page 19: Adjust The Doors
Adjust the doors If the door heights are uneven, follow the next steps to adjust the height: 1 Insert a spanner(A part) into the hinge nut(1) and turn in clockwise direction. 2 Insert a spanner(B part) into the hinge unt(2) and turn clockwise to lower the door or turn it anti- clockwise to raise the door. -
Page 20: Install The Door Handles
Install the door handles After final installation and door levelling, install the fridge door handles. Note: Both handles are installed in the same way. • Position one of the door handles into the guides on the door, the set screws on the handle needs to point to the centre of the fridge freezer. -
Page 21: Installing The Water Filter
1 Connect the water pipe / tube to the fridge freezer. Change the water filter every 6 months. Concact your local John Lewis branch or our warranty administrator to buy a new genuine water filter. Installing the water line... - Page 22 Water Tube Rubber Washer 3 Connect the fridge freezer to the power supply and switch it on. Caution - You must wait at least 8 hours after installing the fridge freezer before switching on to allow for oil in the compressor to settle.
-
Page 23: Disposal And Guarantee
For more detailed information about recycling of this product, please contact your local council office, your household waste disposal service or the John Lewis branch where you purchased the product. Guarantee Your John Lewis American Style Fridge Freezer is covered by a three year parts and labour guarantee. -
Page 24: Troubleshooting
Troubleshooting To assist in locating possible faults use the help guide below: Troubleshooting Problem Cause Correction Running of fridge Compressor does not run. Fridge is in defrost cycle. This is normal for a fully automatic defrost fridge. The defrost cycle occurs periodically, lasting about 30 minutes. - Page 25 (continued) Troubleshooting Temperatures are too warm Fridge/freezer temperature is too Doors are opened too frequently or for too Warm air enters the fridge freezer whenever warm. long. one of the doors is opened. Open the door less often. Door is slightly open. See problem column for the opening/closing of doors/drawers.
- Page 26 (continued) Troubleshooting Automatic ice maker Ice maker is not making any Ice. Water supply is not connected to fridge. Connect water supply (see installation guide). Household water line valve is not open. Turn on household water line valve. Freezer is not cold enough. See problem column temperatures are too warm.
- Page 27 Troubleshooting (continued) Water dispenser Dispenser will not dispense Water supply not connected. Connect water supply (see connecting the water. water supply section). Household water line valve is not open. Open household water line valve. Freezer door is not closed. Ensure that freezer door is closed. Ice and water fi...
- Page 28 If none of the suggestions seem to work, please contact your local John Lewis branch (see inside back page for full branch listing). Never attempt to repair the fridge freezer yourself.
-
Page 29: Repairs - After Sales Service
• Your name, address and post code persons may cause injury or serious malfunctioning. • Your telephone number Contact your local John Lewis branch. • Clear and concise details of fault • The purchase date as found on your receipt •... -
Page 30: Specification
Specification Specifications of the fridge freezer that you have just purchased may vary from the information in this table due to technical innovations. Dimensions 906 mm wide x 735 mm deep x 1770 mm high (including door handles) Net Weight 122 Kg (boxed), 107 Kg (product) Net Fridge Capacity 370 litres... - Page 32 John Lewis Partnership 171 Victoria Street London SW1E 5NN www.johnlewis.com...
