- Page 1 PT-D4000 P ro d u c t N u m b e r : ™ Projectors P ro d u c t N a m e : As of May 2007. Specifications subject to change without notice. < 1 >...
-
Page 2: Specifications
PT-D4000 ™ Projectors Specifications Main Unit Power supply: North America: 120 V AC, 50/60 Hz Europe: 220–240 V AC, 50/60 Hz Power consumption: North America: 540 W (540 VA) (10 W during standby mode with fan stopped) Europe: 520 W (570 VA) (15 W during standby mode with fan stopped) DLP™... - Page 3 PT-D4000 ™ Projectors Dimensions (W x H x D): 530 x 167 x 441 mm (20-7/8˝ x 6-9/16˝ x 17-3/8˝) Weight: 13.7 kg (30.2 lbs) (with supplied lens) Operating temperature: 0°–45°C (32°–113°F) Operating humidity: 20%–80% (no condensation) Remote Control Unit...
- Page 4 PT-D4000 ™ Projectors Terminals 1 Video input 2 S-Video input 3 RGB 1 input 4 RGB 2 Input 5 DVI-D input 6 LAN connector 7 Remote 1 input and output 8 Remote 2 input 9 Serial input 10 Serial output...
-
Page 5: Standard Setting-Up Position
PT-D4000 ™ Projectors Standard setting-up position (when installed using the ET-PKD56H) *3 When the lens protrudes to the maxi- mum. 185 mm (7-9/32˝) with the supplied lens 177 mm (6-31/32˝) with the ET-DLE050 209 mm (8-7/32˝) with the ET-DLE100 208 mm (8˝-3/16˝) with the ET-DLE200 Upper edge of projected image 196 mm (7-23/32˝) with the ET-DLE300... - Page 6 PT-D4000 ™ Projectors Projection distance for 4:3 aspect ratio screen (meters) Screen Distance to screen (L) Height from the edge of screen to size Zoom Fixed-focus center of lens (H) (inch, diagonal) Zoom Fixed- ET-DLE100 Supplied lens ET-DLE200 ET-DLE300 ET-DLE400...
- Page 7 PT-D4000 ™ Projectors Calculation of the projection distance For a screen size different from the above, use the equation below to calculate the projection distance. Aspect ratio 4:3 ET-DLE100 minimum L (m) = (diagonal screen size in inches) x 0.0276 - 0.0452 maximum L (m) = (diagonal screen size in inches) x 0.0372 - 0.0478...
-
Page 8: List Of Compatible Signals
PT-D4000 ™ Projectors List of compatible signals This projector supports RGB signals with horizontal frequencies of 15 to 91 kHz, vertical frequencies of 50 to 85 Hz and up to 150 MHz dot clock. NOTE: The native resolution of this projector is 1,024 x 768 pixels. If the display resolution of the input signal is different from the native resolution, image compression or expansion will be used to convert the input signal to a level within the native resolution. - Page 9 PT-D4000 ™ Projectors Serial connector The serial connector complies with RS-232C. To control the projector from a personal computer, com- mands must be input through communication software, based on the format and satisfying the commu- nication conditions shown below. Pin assignments and signal names...
- Page 10 PT-D4000 ™ Projectors Cable specifications Projector PC (DTE) Control commands Item Command : Parameter Function Callback POWER Power on P O N Standby power off PO F FREEZE Freeze off OF Z : 0 OFZ:0 Freeze on OF Z : 1...
- Page 11 PT-D4000 ™ Projectors Status asking commands Item Command : Parameter Function Callback Description POWER CONDITION Main power status Standby (Off) FREEZE Freeze function status SHUTTER Shutter function status INPUT SIGNAL Input signal status RGB 1 RGB 2 Video S-Video TEST...
-
Page 12: Parameter Format
PT-D4000 ™ Projectors Parameter format Parameter format Size (Byte) Difinition <pl> 3 (1 or 2 bytes also Dicimal without signs: 0-999 (000, 001, 002...999) possible when Dicimal with signs: -99 to +99 (-99...-01, +00, +01, +02...+99) under control) Callback from the projector is 3 Byte. - Page 13 Dual stacked projection of the PT-D4000 is not recommended. If the projector is placed in a box or enclosure, ensure the temperature of the air surrounding the projector is between 0°C/32°F and 40°C/104°F *.
