  • Page 1 PT-D4000 P ro d u c t N u m b e r : ™ Projectors P ro d u c t N a m e : As of January 2009. Specifications subject to change without notice. < 1 >...

  • Page 2: Specifications

    PT-D4000 ™ Projectors Specifications Main Unit Power supply: North America: 120 V AC, 50/60 Hz Europe: 220–240 V AC, 50/60 Hz Power consumption: North America: 540 W (540 VA) (10 W during standby mode with fan stopped) Europe: 520 W (570 VA) (15 W during standby mode with fan stopped) DLP™...
  • Page 3 PT-D4000 ™ Projectors Dimensions (W x H x D): 530 x 167 x 441 mm (20-7/8˝ x 6-9/16˝ x 17-3/8˝) Weight: 13.7 kg (30.2 lbs) (with supplied lens) Operating temperature: 0°–45°C (32°–113°F) Operating humidity: 20%–80% (no condensation) Remote Control Unit...
  • Page 4 ™ Projectors Dimensions 478.5 (18-27/32) unit : mm (inch) NOTE: This illustration is not drawn to scale. The illustration shows the PT-D4000. 436 (17-5/32) 530 (20-7/8) Terminals 1 Video input 6 LAN connector 2 S-Video input 7 Remote 1 input and output...
  • Page 5 PT-D4000 ™ Projectors Standard setting-up position (when installed using the ET-PKD56H) *1 When the lens protrudes to the maxi- mum. 185 mm (7-9/32˝) with the supplied lens 209 mm (8-7/32˝) with the ET-DLE100 208 mm (8-3/16˝) with the ET-DLE200 220 mm (8-21/32˝) with the ET-DLE310 209 mm (8-7/32˝) with the ET-DLE410...
  • Page 6 PT-D4000 ™ Projectors Projection distance for 4:3 aspect ratio screen: ET-DLE100/DLE200/DLE310/DLE410/DLE050 Unit: millimeters Screen Distance to screen (L) Height from the edge of screen to size Zoom Fixed-focus center of lens (H) (inch, diagonal) Zoom Fixed- ET-DLE100 ET-DLE200 ET-DLE310 ET-DLE410...
  • Page 7 PT-D4000 ™ Projectors Projection distance for 4:3 aspect ratio screen: Supplied lens and ET-DLE150/DLE250/DLE350/DLE450/DLE055 Unit: millimeters Screen Distance to screen (L) Height from the edge of screen to size Zoom Fixed-focus center of lens (H) (inch, diagonal) Zoom Fixed- ET-DLE150...

  • Page 8: Calculation Of The Projection Distance

    PT-D4000 ™ Projectors Calculation of the projection distance For a screen size different from the above, use the equation below to calculate the projection distance. Aspect ratio 4:3 ET-DLE100 minimum L (m) = (diagonal screen size in inches) x 27.6 - 45 maximum L (m) = (diagonal screen size in inches) x 37.2 - 48...
  • Page 9 PT-D4000 ™ Projectors Shift range Optical axis shift function allows to shift the position of a projected image as shown. • Floor mount • Ceiling mount (Width of projected image) Standard postition of projected image 0.1H 0.1H 0.1H 0.1H Standard postition...

  • Page 10: List Of Compatible Signals

    PT-D4000 ™ Projectors List of compatible signals This projector supports RGB signals with horizontal frequencies of 15 to 91 kHz, vertical frequencies of 50 to 85 Hz and up to 150 MHz dot clock. NOTE: The native resolution of this projector is 1,024 x 768 pixels. If the display resolution of the input signal is different from the native resolution, image compression or expansion will be used to convert the input signal to a level within the native resolution.
  • Page 11 PT-D4000 ™ Projectors Serial connector The serial connector complies with RS-232C. To control the projector from a personal computer, com- mands must be input through communication software, based on the format and satisfying the commu- nication conditions shown below. Pin assignments and signal names...
  • Page 12 PT-D4000 ™ Projectors Cable specifications Projector PC (DTE) Control commands Item Command : Parameter Function Callback POWER Power on PO N Standby power off PO F FREEZE Freeze off OF Z : 0 OFZ:0 Freeze on OF Z : 1...
  • Page 13 PT-D4000 ™ Projectors Status asking commands Item Command : Parameter Function Callback Description POWER CONDITION Main power status Standby (Off) FREEZE Freeze function status SHUTTER Shutter function status INPUT SIGNAL Input signal status RGB 1 RGB 2 Video S-Video TEST...

  • Page 14: Parameter Format

    PT-D4000 ™ Projectors Parameter format Parameter format Size (Byte) Difinition <pl> 3 (1 or 2 bytes also Dicimal without signs: 0-999 (000, 001, 002...999) possible when Dicimal with signs: -99 to +99 (-99...-01, +00, +01, +02...+99) under control) Callback from the projector is 3 Byte.
  • Page 15 Dual stacked projection of the PT-D4000 is not recommended. If the projector is placed in a box or enclosure, ensure the temperature of the air surrounding the projector is between 0°C/32°F and 40°C/104°F *.
