Summary of Contents for Hasselblad Flextight 848

  • Page 1 User's Guide Flextight 848...
  • Page 2 Hasselblad A/S assumes no responsibility or liability for any errors or inaccuracies that may appear in this manual. Hasselblad A/S assumes no responsibility or liability for loss or damage incurred during or as a result of using Hasselblad software or products.

  • Page 3: Table Of Contents

    Table of Contents Hardware Reference - Flextight 848 Warnings and Restrictions System Requirements Front Panel Back Panel & Connectors Cut-Away View Setting up the Scanner Environmental Requirements Electrical Requirements Installation Procedure, FireWire Interface Operating Instructions Resolutions True Resolutions Calibrating the Scanner...
  • Page 4 User's Guide - Flextight 848...

  • Page 5: Hardware Reference - Flextight 848

    • Operating instructions • Special considerations for scanning 35mm originals • Calibration instructions • Maintenance advice • Disposal instructions • Technical specifications • Declarations of FCC and CE regulation conformity User's Guide - Flextight 848 Hardware Reference - Flextight 848...

  • Page 6: Warnings And Restrictions

    • When you turn on the scanner, the drum will roll to the load position, if it is not there already. Do not touch the scanner while the drum is rotating. • Do not place your fingers or any other object into the scanner while it is connected to power.

  • Page 7: System Requirements

    “Software Reference” manual, that comes with the FlexColor software. • Screen resolution of 800 x 600 pixels with true colors (24-bits). • Mouse or other pointing device. • FireWire interface. User's Guide - Flextight 848 Hardware Reference - Flextight 848 System Requirements...
  • Page 8 Hardware Reference - Flextight 848 User's Guide - Flextight 848...

  • Page 9: Front Panel

    Front Panel Figure 1: Front panel features of Flextight 848 Feed Table: must be in lower position for normal scanning. When scanner is not in use you can turn it to upright position flushing with the scanner front to protect it from dust etc. Adjust to horizontal position when using the 35 mm slide mount holder (see page 15).

  • Page 10: Back Panel & Connectors

    Hardware Reference - Flextight 848 Back Panel & Connectors Back Panel & Connectors Figure 2: Back panel features of Flextight 848 Power Cable Socket: plug the power cable into this socket. FireWire Interface Sockets: plug a FireWire cable (max. 6 m) here and connect it to your computer.

  • Page 11: Cut-Away View

    Cut-Away View Figure 3: Cut-away view of Flextight 848 CCD Housing: this movable platform contains the light sensor and holds the optics. Positioning Lead Screws: for positioning of the CCD housing and optics housing for the appropriate resolution and original size.

  • Page 12: Setting Up The Scanner

    Avoid using the scanner in areas where there is a high level of dust. Electrical Requirements The Flextight 848 power supply requires a mains voltage of between 100 and 240 V AC at a frequency of 50 to 60 Hz. This is within the normal wall-socket power standards of most countries.

  • Page 13: Installation Procedure, Firewire Interface

    IMPORTANT: Make sure that the wall socket you are planning to use meets the electrical requirements outlined earlier. Plug the Flextight 848 power supply into a wall socket. Note that the power supply may emit a low buzzing sound when plugged in. This is normal and will not damage the power supply or scanner.
  • Page 14 Hardware Reference - Flextight 848 Operating Instructions HORIZONTAL NORMAL Figure 4: Operating the Flextight 848 scanner CLOSED User's Guide - Flextight 848...

  • Page 15: Operating Instructions

    If not already done, turn the feed table (A) to normal position. Press the red power button (F) on the front of the scanner to switch it on. The green light (G) starts flashing. This means that no firmware has been downloaded yet.
  • Page 16 Hardware Reference - Flextight 848 Operating Instructions HORIZONTAL NORMAL Figure 4: Operating the Flextight 848 scanner CLOSED User's Guide - Flextight 848...
  • Page 17 NOTE! Each original holder has it's own unique identification code (a combination of small rectangular holes at the holder's leading edge). These codes, combined with the scanner's ability to detect the feed table position, ensure that the scanner will not operate unless the feed table position matches the selected original holder.
  • Page 18 Hardware Reference - Flextight 848 Operating Instructions ...continued Lay the top layer of the holder down flat over the original. • For transparency holders, the top layer is magnetic, which will hold the original fast. • For the reflective holder, note the four metal pegs (the top two are shown as A and C in Figure 5 below);...

  • Page 19: Resolutions

    60 x 60 - 60 x 70 mm 4" x 5" Portrait 13 x 18 Portrait A4 Portrait Table 1: True Resolutions User's Guide - Flextight 848 Hardware Reference - Flextight 848 Max. resolution (ppi) at full scanning width. 8000 5000...

  • Page 20: Calibrating The Scanner

    The focus calibration is stored in the scanners flash PROM, so it is preserved when you move the scanner to a new computer. See "Focus Calibration" on page 21 for more information.

  • Page 21: Focus Calibration

    Focus Calibration The Flextight 848 scanner uses an adjustable zoom and focus mechanism to optimize its scanning resolution for each of the original formats it can handle. If you suspect your scans are not as sharp as they should be, then you may need to calibrate your scanner.

  • Page 22: White Calibration For Reflectives

    Use procedure below to make White Calibration: Find the white calibration sheet that came with your scanner. It is a square white piece of paper (219 x 219 mm (8.6" x 8.6")).
  • Page 23 Figure 6: Positioning the white calibration sheet on the reflective holder Click on Calibrate. The scanner will take several scans of the white target. The process will take about eight minutes. User's Guide - Flextight 848 Hardware Reference - Flextight 848...
  • Page 24 Hardware Reference - Flextight 848 The Light Tubes Figure 7: Replacing the Light Tubes PRESS PRESS PULL OUT à PULL OUT User's Guide - Flextight 848...

  • Page 25: The Light Tubes

    The Light Tubes General The Flextight 848 contains two light tubes: one for illuminating reflective originals from above, the other for shining light through transparencies from below. Replacing the Light Tubes If your scans are suddenly coming out black (or all white if you are scanning negatives), then one of your light tubes may be defective.
  • Page 26 Hardware Reference - Flextight 848 The Light Tubes Figure 7: Replacing the Light Tubes PRESS PRESS PULL OUT à PULL OUT User's Guide - Flextight 848...

  • Page 27: Cleaning The External Surface Of The Scanner

    14. Turn on the scanner and check function of the new tube. Cleaning the External Surface of the Scanner If the external surface of the scanner becomes dirty, then clean it with a damp cloth. Be careful not to get any moisture inside the scanner or on any of the connectors.

  • Page 28: Technical Specifications

    Hardware Reference - Flextight 848 Technical Specifications Technical Specifications Power Connector: 24 VDC Power Consumption Max. 60 W during operation Power Requirements 100-240V AC, 1.3A, 50-60Hz Interface to Computer FireWire (IEEE 1394) Front Panel One multifunction switch (on/off switch) Status indicator LED’s Drum Force 1kg (2.2lbs)

  • Page 29: Fcc Notice

    Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. User's Guide - Flextight 848 Hardware Reference - Flextight 848 FCC Notice...

  • Page 30: User's Guide - Flextight

    Hardware Reference - Flextight 848 CE - Declaration of conformity CE - Declaration of conformity HASSELBLAD A/S HEJREVEJ 30 DK - 2400 COPENHAGEN NV TELEPHONE +45 7026 0800 TELEFAX +45 7026 0900 REG./VAT NO. 18635445 www.hasselblad.com Declaration of conformity Application of Council Directives: ...
