Available imprint modes of the H1
Type 1, Enhanced exposure information:
Aperture
Shutter speed
Notes:
1 If an exposure adjustment is set on the camera, a value will appear after the exposure mode
symbol
2 If a TTL flash is used, a flash icon appears after the exposure mode symbol
3 If a flash exposure adjustment is set, a value will appear after the flash icon
4 If all options are active, no focal length will be shown
5 Light metering mode is shown only when a viewfinder is attached
6 Autofocus mode does not appear if set to Manual focus and focus assist is set to "Off"
Type 1
Prints all available
exposure info.
Type 3
Prints date and time
info only.
Type 5
Prints the text you entered together with
basic exposure information
Light metering
Auto focus
mode
mode
Exposure mode
H1 IMPRINT MODE
Frame number
Lens focal length
incl. converter
Type 2
Prints basic exposure
info only.
Type 4
Prints the text you entered
together with date and time
Type 6
Prints the text you entered
www.hasselblad.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Hasselblad H1
Summary of Contents for Hasselblad H1
- Page 1 Available imprint modes of the H1 Type 1 Prints all available exposure info. Type 3 Prints date and time info only. Type 5 Prints the text you entered together with basic exposure information Type 1, Enhanced exposure information: Aperture Light metering...
- Page 2 1 Seconds are only shown in 24 hour time format Type 4, Text & Date: Custom text Notes: 1 If the text is longer than 33 characters, the date will be excluded H1 IMPRINT MODE Lens focal length incl. converter Date (YY MM DD) www.hasselblad.com...
- Page 3 2 If the text is longer than 25 (19 with exposure adjustment) characters, part of the exposure info will be excluded Type 6, Text: Custom text. Max 37 characters H1 IMPRINT MODE Shutter speed Lens focal length incl. converter Aperture...
- Page 4 FLASH DRIVE Select one of the six options you want (see all options on page 1) with the front wheel and press “Save” H1 IMPRINT MODE FLASH DRIVE Scroll to the menu item “Settings” with the front wheel and press “Enter”...
- Page 5 “MENU” button. “Settings”, then press the “Drive” button. (marked with “Enter” on the LCD) H1 IMPRINT MODE Use the front wheel Use the front wheel to select the menu to select the menu “Imprint”, then press item “Text”, then the “Drive”...
- Page 6 DRIVE Continue in the same way with the other characters until the complete string is ready. Maxi- mum are 37 characters. H1 IMPRINT MODE FLASH DRIVE Press the button over the “Sel.” caption (AF button) to erase the character to the left of the cursor in the lower row.
-
Page 7: Magazine Settings
Magazine is correctly programmed for data imprint as indicated by the -icon at the top of the LCD H1 IMPRINT MODE 1 Mode button 2 Change down button 3 Change up button 4 Lock switch...
