IBM Infoprint 2000 Quick Manual page 4

IBM Infoprint 2000 Multifunctional Production System at a glance (continued)
Physical Characteristics
Marking Engine
Finisher
MIP
Paper Supply Module
High Capacity Stacker
Booklet Maker 4
Post Fuse Inserter
Control Unit Enclosure 5
Power Requirements
1
IBM does not recommend reaching this monthly
maximum on a consistent basis.
2
Only for use in the middle and lower drawers of
the standard paper supply module, the optional
paper supply module, and the post fuse inserter.
3
Only for use in the middle drawers of the standard
paper supply module, the optional paper supply
module, and the post fuse inserter.
4
Requires High Capacity Stacker option.
5
Not currently available; please contact your sales
representative to ascertain availability.
(sizes & weights)
Height
64 in. (162.6 cm)
61.5 in. (156.2 cm)
26 in. (66 cm)
45 in. (114.3 cm)
49.5 in. (125.7 cm)
58 in. (147.2 cm)
59 in. (149.9 cm)
46.3 in. (117.6 cm)
Marking Engine/Paper Supply/Finisher
—AC Power
Stacker
—AC Power
Booklet Maker
—AC Power
Convenience Outlet #1 (scanner, scan workstation, scan monitor)
—AC Power
Convenience Outlet #2 (SCS, hub, SCS monitor, modem)
—AC Power
For information regarding 50 Hz support for the Infoprint 2000, please contact your sales representative.
The following terms are trademarks or registered
trademarks of IBM Corporation in the United
States and/or other countries: Advanced Function
Common Control Unit, Advanced Function
Presentation, AFCCU, AFP, AIX, IBM, Infoprint,
Intelligent Printer Data Stream, IPDS, MVS, Print
Services Facility, PSF and RISC.
Microsoft, Windows and Windows NT are
registered trademarks of Microsoft Corporation.
PostScript is a registered trademarks of Adobe
Systems Incorporated.
Other company, product and service names may
be trademarks or service marks of others.
IBM hardware is manufactured from new parts,
or new and used parts. Regardless, our warranty
terms apply.
References in this publication to IBM products or
services do not imply that IBM intends to make
them available outside the United States.
For expanded specifications, visit ibm.com/printers/2000mps
Depth
47 in. (119.4 cm)
34 in. (86.4 cm)
20.5 in. (51 cm)
33.5 in. (83.8 cm)
31.6 in. (78.7 cm)
24 in. (58.4 cm)
(90 in. (228.6 cm) w/conveyor)
33.5 in. (83.8 cm)
34.5 in. (87.7 cm)
—60 Hz, 120/208-127/208 volts, 24 amps
—60 Hz, 120 volts, 4 amps
—60 Hz, 120 volts, 10 amps
—60 Hz, 120 Volts, 15 amps
—60 Hz, 120 volts, 15 amps
Length
67 in. (170.2 cm)
22 in. (53.3 cm)
18 in. (45.7 cm)
31 in. (78.7 cm)
33 in. (84.8 cm)
62 in. (157.5 cm)
31 in. (78.7 cm)
23.6 in (60 cm)
© International Business Machines Corporation 2001
IBM Printing Systems
Dept. HT7/001H
P.O. Box 1900
Boulder, CO 80301-9191
Printed in the United States of America
9-01
All Rights Reserved
Visit the IBM Printing Systems Web site at
ibm.com/printers
The IBM home page can be found on the Internet
at ibm.com
G563-0113-02-H
Weight
1500 lbs. (567.3 kg)
650 lbs. (294.7 kg)
120 lbs. (54.4 kg)
545 lbs. (247.4 kg)
450 lbs. (203.7 kg)
970 lbs. (439.8 kg)
545 lbs. (247.4 kg)
180 lbs. (81.9 kg)
