Page 1 G1000 Integrated Flight Deck ® Pilot’s Guide...
Page 3 Except as expressly provided herein, no part of this manual may be reproduced, copied, transmitted, disseminated, downloaded or stored in any storage medium, for any purpose without the express written permission of Garmin. Garmin hereby grants permission to download a single copy of this manual and of any revision to this manual onto a hard drive or other electronic storage medium to be viewed for per- sonal use, provided that such electronic or printed copy of this manual or revision must contain the complete text of this copyright notice and provided further that any unauthorized commercial distribution of this manual or any revision hereto is strictly prohibited.
Page 4: Limited Warranty
Within the warranty period, Garmin will, at its sole discretion, repair or replace any components that fail in normal use. Such repairs or replacement will be made at no charge to the customer for parts and/or labor incidental to the direct repair of said product. Garmin may, at its discretion with prior approval, reimburse an authorized Garmin Service Center for associated labor costs incurred for removal and replacement of the panel mount product installed in an aircraft.
Page 5 Terrain data is obtained from third party sources. Garmin is not able to independently verify the accuracy of the terrain data. The displayed minimum safe altitudes (MSAs) are only advisory in nature and should not be WARNING: relied upon as the sole source of obstacle and terrain avoidance information.
Page 6 WARNINGS, CAUTIONS, AND NOTES The Garmin G1000, as installed in the Socata TBM 850 aircraft, has a very high degree of WARNING: functional integrity. However, the pilot must recognize that providing monitoring and/or self-test capability for all conceivable system failures is not practical. Although unlikely, it may be possible for erroneous operation to occur without a fault indication shown by the G1000.
Page 7 ANTI-REFLECTIVE COATING. It is very important to clean the lens using a clean, lint-free cloth and an eyeglass lens cleaner that is specified as safe for anti-reflective coatings. The Garmin G1000 does not contain any user-serviceable parts. Repairs should only be made by CAUTION: an authorized Garmin service center.
Page 8 WARNINGS, CAUTIONS, AND NOTES lank Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 9 Added new database update procedures Added Iridium Satellite Telephone & SMS messaging Added GFDS Worldwide Weather Added WX LGND, LEGEND, and METAR softkeys Updated system messages Added other GDU 12.01 parameters 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 10 REVISION INFORMATION lank Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 11: Table Of Contents
System Alerting ....125 Auto-Tuning a NAV Frequency from the MFD ........80 Marker Beacon Annunciations ..........130 Marker Beacon Receiver ............ 80 Traffic Annunciation ............131 ADF/DME Tuning 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 12 Selected Altitude Intercept Arc 5.3 Waypoints ............. 184 ........353 GFDS Weather Data Requests ..............185 Airports ........358 Worldwide Weather Products ............192 Intersections ..........374 Abnormal Operations viii Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 13 7.7 AFCS Annunciations and Alerts ......517 ......... 464 Traffic Map Page Display Range ............ 517 AFCS Status Alerts ..............466 TAS Alerts ..........518 ............466 Overspeed Protection System Status 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 14 SVS Troubleshooting ........... 609 Reversionary Mode ............. 610 Unusual Attitudes APPENDICES Annunciations and Alerts ..........613 ............613 CAS Messages ........615 Comparator Annunciations ......616 Reversionary Sensor Annunciations Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 15: Section 1 System Overview
NOTE: In the aircraft, the GFC 700 Automated Flight Control System (AFCS) provides the Flight Director (FD), Autopilot (AP), and Yaw Damper (YD) functions of the G1000 system. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 16: Line Replaceable Units (Lru)
Each GIA 63W is paired with the on-side PFD via HSDB connection. The GIA 63Ws are not paired together and do not communicate with each other directly. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 17 • GMU 44 – Measures local magnetic field. Data is sent to the GRS 77 for processing to determine aircraft magnetic heading. This unit receives power directly from the GRS 77 and communicates with the GRS 77, using an RS-485 digital interface. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 18 • GSR 56 – The Iridium Transceiver operation for voice communication is by means of pilot and copilot headsets in the cockpit. The system is also capable of SMS text messaging. Connection to the system is through the RS- 232 bus. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 19 These units interface with each GIA 63W. The GSM 85/86 servo gearbox is responsible for transferring the output torque of the GSA 81 servo actuator to the mechanical flight-control surface linkage. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 20 • GA 58 – The GA 58 is directional antenna for the Traffic Avoidance System. One top-mounted directional antenna is required. Optional bottom mounted antenna offers better threat visibility. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 21 GSA 81 (Pitch) GSA 81 GTX 33D GTX 33 (Roll) GSA 81 GSR 56 (Yaw) GEA 71 #1 GEA 71 #2 Figure 1-1 Example G1000 System (LRU Configuration) 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 22: G1000 Controls
The G1000 system controls are located on the PFD and MFD bezels, MFD Control Unit, AFCS Control Unit and audio panel. The controls for the PFD and MFD are discussed within the following pages of this section. PFD CONTROLS Figure 1-2 PFD Controls Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 23 If a flight plan is not used, both the desired airport and the desired procedure may be selected. ENT Key – Validates or confirms a menu selection or data entry. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 24: Controls Associated With The Mfd
Theses procedures can then be loaded into the active flight plan. If a flight plan is not used, both the desired airport and the desired procedure may be selected. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 25: Afcs Controls
The GFC 700 AFCS is mainly controlled through the GMC 710 AFCS Control Unit. The AFCS Control Unit consists of the following controls: HDG Key – Selects/deselects the Heading Select mode. APR Key – Selects/deselects the Approach mode. NAV Key – Selects/deselects the Navigation mode. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 26 MET (Manual Electric Trim) Switch are additional AFCS controls and are located in the cockpit, separately from the AFCS Control Unit. These are discussed in detail in the AFCS section. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 27: Audio Panel Controls
COM2 Key, or COM1 can be added by pressing the COM1 Key. COM2 – When selected, audio from the #2 Com receiver can be heard. COM3 MIC – Not used on some aircraft.. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 28 MSTR Knob – The Master Volume Control adjusts volume for the blended NAV, COM, and intercom audio. Reversionary Mode Button – Pressing manually selects Reversionary Mode. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 29: Secure Digital Cards
SafeTaxi, FliteCharts, ChartView, and AOPA Airport Directory database storage. Not all SD cards are compatible with the G1000. Use only SD cards supplied by Garmin or the aircraft manufacturer.
Page 30: System Power-Up
(to ensure that no databases have expired), the pilot is prompted to continue. Pressing the ENT Key acknowledges this information and displays the Auxiliary (AUX) Weight Planning Page. Figure 1-7 PFD Initialization Figure 1-8 MFD Power-up Page Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 31: System Operation
MFD is dedicated to the Engine Indication and Crew Alerting System (EICAS). Figure 1-9 gives an example of the G1000 displays in normal mode. PFD1 PFD2 Figure 1-9 Normal Operation 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 32: Reversionary Mode
PFD by the on-side GIA 63W are flagged as invalid (red “x”) on the remaining PFD (see Figure 1-12). Figure 1-12 Inoperative Input (NAV1 Shown) Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 33 Magnetometer Data Air Data Air Data AHRS no- AHRS no-Mag/ AHRS AHRS Normal Mag Mode no-Air Mode no-GPS Operation Mode Attitude/Heading Invalid Heading Invalid Figure 1-13 AHRS Operation 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 34 However, if the aircraft is airborne, the heading output on the PFD does become invalid (as indicated by a red “x”). Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 35: G1000 System Annunciations
(Figure 1-14 displays all possible flags and responsible LRUs). Upon G1000 power-up, certain windows remain invalid as equipment begins to initialize. All windows should be operational within one minute of power-up. If any window remains flagged, the G1000 System should be serviced by a Garmin- authorized repair facility.
Page 36: Softkey Function
TRFC-1: Traffic displayed on inset map TRFC-2: Traffic Map Page is displayed in the inset map window TOPO Displays topographical data (e.g., coastlines, terrain, rivers, lakes) and elevation scale on Inset Map Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 37 Displays the DME information window BRG1 Cycles the Bearing 1 Information Window through NAV1, GPS/ waypoint identifier and GPS-derived distance information, and ADF/frequency. HSI FRMT Provides access to the HSI formatting softkeys 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 38 Activates the Special Position Identification (SPI) pulse for 18 seconds, identifying the transponder return on the ATC screen TMR/REF Displays Timer/References Window NRST Displays Nearest Airports Window Displays Messages Window Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 39 TRFC-2 Figure 1-17 INSET Softkeys Press the BACK Softkey to return to the top level softkeys. ADC2 AHRS1 AHRS2 BACK ADC1 Figure 1-18 SENSOR Softkeys 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 40 Figure 1-19 PFD Configuration Softkeys Press the BACK Softkey to return to the top-level softkeys. Press the BACK Softkey to return to the previous level softkeys. Figure 1-20 XPDR Softkeys Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 41 Selects desired amount of map detail; cycles through declutter levels: DCLTR (No Declutter): All map features visible DCLTR-1: Declutters land data DCLTR-2: Declutters land and SUA data DCLTR-3: Removes everything except the active flight plan 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 42: Gps Receiver Operation
If the sensor annunciation persists, check for a system failure message in the Messages Window on the PFD. If no failure message exists, check the GPS Status Page and compare the information for GPS1 and GPS2. Discrepancies may indicate a problem. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 43 RAIM Availability Prediction Enabled SBAS Options Satellite Signal Strength Bars GPS Selection RAIM Softkey Softkeys Selected SBAS Softkey Selected Figure 1-22 GPS Status Page (RAIM or SBAS Selected) 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 44 The RAIM prediction function also indicates whether RAIM is available at a specified date and time. RAIM computations predict satellite coverage within ±15 min of the specified arrival date and time. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 45 5) With ‘Set WPT to Present Position’ highlighted, press the ENT Key. 6) Press the ENT Key to accept the waypoint entry. 7) Use the FMS Knob to enter an arrival time and press the ENT Key. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 46 Each satellite has a 30-second data transmission that must be collected (signal strength bar is hollow) before the satellite may be used for navigation (signal strength bar becomes solid). Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 47: Accessing G1000 Functionality
The page titles are displayed in a list above the page group tabs. The current page group and current page within the group are shown in light blue. For some of these pages 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 48 (or from the page menu). In this case, the page remains set to the selected page until a different page softkey is selected, even if a different page group is selected. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 49 (STAR Softkey) - Approach Information (APR Softkey) - Weather Information (WX Softkey) Intersection Information NDB Information Airport VOR Information Information Screens User Waypoint Information Figure 1-26 Waypoint Pages 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 50 Figure 1-28 Flight Plan Pages The Flight Plan Pages may also be accessed using the FPL Key. Main pages within this group are selected by turning the small FMS Knob. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 51 Procedure Loading Page is opened. Turning the FMS Knob does not scroll through the Procedure pages (note the single page icon in the lower right corner). 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 52: Mfd System Pages
(see Flight Instruments Section) • GPS CDI scaling for GPS navigation source (see Flight Instruments Section) • Baro Transition Alert (see Flight Instruments Section) • COM Configuration (see Audio Panel and CNS Section) • Airspace Alerts (see Flight Management Section) • Nearest Airports display criteria • Arrival Alerts (see Flight Management Section) • Audio Alerts • Synchronization of Baro and CDI between PFDs • Flight Director Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 53 2) Turn the large FMS Knob to highlight the time offset field in the Date/Time Box. 3) Turn the FMS Knobs to enter the time offset and press the ENT Key. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 54 3) Turn the small FMS Knob to select from a list of measurement units and press the ENT Key when the desired unit is highlighted. Press the CLR Key to cancel the action without changing the units. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 55 1) Use the FMS Knob to select the AUX - System Setup Page. 2) Press the FMS Knob momentarily to activate the flashing cursor. 3) Turn the large FMS Knob to select the ON/OFF field in the Arrival Alert Box. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 56 5) Turn the large FMS Knob to highlight the ‘Timeout Seconds’ field in the Page navigation Box. 6) Turn the small FMS Knob to select the desired number of seconds 7) Press the FMS Knob momentarily to remove the flashing cursor. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 57 0.3 nm during an approach. Note that the Receiver Autonomous Integrity Monitoring (RAIM) protection limits follow the selected CDI range and corresponding flight phases. The GPS CDI Box on the System Setup Page displays the following: • Selected CDI range (auto, 2 nm, 1 nm, 0.3 nm) • Current system CDI range (2 nm, 1 nm, 0.3 nm) 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 58 2) Turn the large FMS Knob to highlight the minimum length field in the Nearest Airport Box. 3) Turn the FMS Knobs to enter the minimum runway length (zero to 99,999 feet) and press the ENT Key. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 59 6) In the next field, use the small FMS Knob to select the desired settings upon which to base the new profile. Profiles can be created based on Garmin factory defaults, default profile settings (initially based on Garmin factory defaults unless edited by the pilot), or current system settings.
Page 60 6) Press the ENT Key. 7) With ‘DELETE’ highlighted, press the ENT Key. 8) To cancel the process, use the large FMS Knob to select ‘CANCEL’ and press the ENT Key. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 61 DATABASE window. Selecting the softkey a third time will change the softkey label to PFD2 DB. PFD 2 database information is now displayed in the DATABASE window. The ANN TEST Softkey, when selected, causes an annunciation test tone to be played. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 62: Display Backlighting
4) Turn the large FMS Knob to highlight ‘AUTO’ to the right of ‘MFD DSPL’ or ‘PFD2 DSPL’, respectively, and repeat steps 2 and 3. 5) Press the CLR or MENU Key to remove the PFD Setup Menu Window from the display. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 63 ‘MFD KEY’ or ‘PFD2 KEY’, respectively. 7) Repeat steps 3 to 5. 8) Press the CLR or MENU Key to remove the PFD Setup Menu Window from the display. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 64 SYSTEM OVERVIEW lank Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 65: Section 2 Flight Instruments
– Barometric setting • Transponder Mode, Code, and Ident/Reply – Selected altitude • Timer/References Window, showing • Vertical Deviation, Glideslope, and Glidepath – Generic timer Indicators – Vspeed values • Vertical Speed Indicator (VSI) – Barometric minimum descent altitude (MDA) • Vertical Navigation (VNV) indications • Wind data The PFDs also displays various alerts and annunciations. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 66 Horizontal Situation Indicator (HSI) COM Frequency Box Outside Air Temperature (OAT) Navigation Status Box Softkeys AFCS Status Box System Time Slip/Skid Indicator Transponder Data Box Attitude Indicator Selected Heading Bug Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 67 Minimum Descent Altitude/Decision Height Radar Height Selected Course Selected Heading Current Vertical Speed Wind Data Glidepath Indicator Inset Map Terrain Annunciation DME Information Window AFCS Status Annunciation Bearing Information Windows 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 68: Flight Instruments
The trend vector is absent if the speed remains constant or if any data needed to calculate airspeed is not available due to a system failure. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 69 4) To remove all Vspeed flags, turn the FMS Knob to highlight All References Off and press the ENT Key. Restoring all defaults: 1) Presst the TMR/REF Softkey. 2) Press the MENU Key. 3) Turn the FMS Knob to highlight Restore Defaults and press the ENT Key. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 70: Attitude Indicator
The Slip/Skid Indicator is the bar beneath the roll pointer. The indicator bar moves with the roll pointer and moves laterally away from the pointer to indicate uncoordinated flight. Slip (inside the turn) or skid (outside the turn) is indicated by the location of the bar relative to the pointer. Figure 2-8 Slip/Skid Indication Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 71: Altimeter
Selected Altitude (Meters) Selected Altitude Indicated Altitude (Meters) Altitude Indicated Trend Altitude Vector Barometric Minimums Selected Barometric Altitude Barometric Setting Setting (Hectopascals) Figure 2-9 Altimeter (Standard and Metric) 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 72 Press the BARO Knob to select standard pressure. Or : 1) Press the PFD Softkey to display the second-level softkeys. 2) Press the STD BARO Softkey. Figure 2-10 Standard Barometric Altimeter Setting Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 73 4) Turn the small FMS Knob clockwise to ON or counterclockwise to OFF. 5) Press the FMS Knob to remove the cursor. Barometric Settings not Synchronized on PFD Figure 2-11 Baro Synchronization Setting (AUX - System Setup Page) 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 74 5) Turn the small FMS Knob to change the altitude and press the ENT Key. 6) To cancel the selection, press the FMS Knob. Figure 2-12 Baro Transition Alert (AUX - System Setup Page) Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 75: Vertical Speed Indicator (Vsi)
Glideslope Indicator Indicator Vertical Speed Required Pointer Vertical Speed Indicator Figure 2-13 Vertical Speed and Figure 2-14 Glideslope Indicator Figure 2-15 Glidepath Indicator Deviation Indicators (VSI and VDI) 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 76: Horizontal Situation Indicator (Hsi)
Lateral Deviation Scale Heading Bug Navigation Source Flight Phase Aircraft Symbol Turn Rate/Heading Trend Vector Course Deviation Indicator Current Heading (CDI) Rotating Compass Rose Lubber Line OBS Mode Active Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 77 Press the CRS Knob to re-center the CDI and return the course pointer to the bearing of the active waypoint or navigation station (see OBS Mode for adjusting a GPS course). Current Track Indicator Current Heading Selected Course Selected Heading Selected Heading Figure 2-18 Heading and Course Indications 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 78 • TRUE - References angles to true north (T) • MAGNETIC - Angles corrected to the computed magnetic variation (Mag Var) Figure 2-20 Navigation Angle Settings (AUX - System Setup Page) Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 79 Bearing Source Identifier Selected Bearing Pointer Pointer Bearing Source Icon Icon Source Bearing 1 Information Window Bearing 2 Information Window Figure 2-22 HSI with Bearing and DME Information 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 80 2) Press the DME Softkey to display the DME Information Window above the BRG1 Information Window. 3) To remove the DME Information Window, press the DME Softkey again. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 81: Course Deviation Indicator (Cdi)
CDI. If the CDI exceeds the maximum deviation on the scale (two dots) while navigating with GPS, the crosstrack error (XTK) is displayed below the white aircraft symbol. Navigation Source Selected on Both PFDs Figure 2-24 Navigation Sources 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 82 The system automatically switches from GPS to LOC navigation source and changes the CDI scaling accordingly when all of the following occur: • A localizer or ILS approach has been loaded into the active flight plan • The final approach fix (FAF) is the active leg, the FAF is less than 15 nm away, and the aircraft is moving toward the FAF • A valid localizer frequency has been tuned • The GPS CDI deviation is less than 1.2 times full-scale deflection GPS steering guidance is still provided after the CDI automatically switches to LOC until LOC capture, up to the Final Approach Fix (FAF) for an ILS approach, or until GPS information becomes invalid. Activating a Vector-to-Final (VTF) also causes the CDI to switch to LOC navigation source. GPS steering guidance is not provided after this switch. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 83 4) Turn the small FMS Knob clockwise to ON or counterclockwise to OFF. 5) Press the FMS Knob to remove the cursor. Figure 2-26 CDI Synchronization Setting (AUX - System Setup Page) 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 84 4) Turn the small FMS Knob to highlight the desired setting and press the ENT Key. 5) To cancel the selection, press the FMS Knob or the CLR Key. Figure 2-27 GPS CDI Settings (AUX - System Setup Page) When set to Auto (default), the GPS CDI scale automatically adjusts to the desired limits based upon the current phase of flight (Figure 2-28, Table 2-1). Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 85 - If the active waypoint is part of the missed approach procedure, the active leg and the preceding missed approach legs must be aligned with the final approach segment course and the aircraft must not have passed the turn initiation point. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 86 MAPR 0.3 nm * Flight phase annunciations are normally shown in magenta, but when cautionary conditions exist the color changes to yellow. Table 2-1 Automatic GPS CDI Scaling Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 87 Mode. The flight path on the moving map retains the modified course line. OBS Course Selected Mode Enabled Pressing the OBS Pressing the OBS Softkey Enables OBS Softkey Again Disables Mode OBS Mode Figure 2-31 Omni-bearing Selector (OBS) Mode 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 88 SUSP appears on the HSI at the lower right of the aircraft symbol. The OBS Softkey label changes to indicate the suspension is active as shown in figure 2-32. Selecting the SUSP Softkey deactivates the suspension and resumes automatic sequencing of approach waypoints. SUSP SUSP Annunciation Softkey Figure 2-32 Suspending Automatic Waypoint Sequencing Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 89: Supplemental Flight Data
In addition to the flight instruments, the PFD also displays various supplemental information, including temperatures, wind data, and Vertical Navigation (VNV) indications. TEMPERATURE DISPLAYS The Outside Air Temperature (OAT) is displayed in degrees Celsius (°C) by default in the lower left of the PFD under normal display conditions, or below the true airspeed in reversionary mode. Normal Display Reversionary Mode Figure 2-33 Outside Air Temperature 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 90 4) Turn the small FMS Knob to highlight either CELSIUS or FAHRENHEIT and press the ENT Key to confirm the selection. 5) To cancel the selection, press the FMS Knob or the CLR Key. Figure 2-34 Temperature Selection Setting (AUX - System Setup Page) Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 91: Wind Data
• OPTN 2: Wind direction arrow with numeric speed • OPTN 3: Wind direction arrow with numeric direction and speed 4) To remove the window, select the OFF Softkey. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 92: Vertical Navigation (Vnv) Indications
Current crosstrack or track angle error has exceeded limit Active altitude-constrained waypoint can not be reached within maximum allowed flight path angle and vertical speed Table 2-2 VNV Indication Removal Criteria Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 93: Pfd Annunciations And Alerting Functions
ADC2, AHRS1, and AHRS2 softkeys. These softkeys allow switching of the sensors being viewed on each PFD. With certain types of sensor failures, the system may make some sensor selections automatically. The GPS sensor cannot be switched manually. Comparator Window Reversionary Sensor Window Messages Window Softkey Flashes for New System Message Figure 2-37 G1000 Alerting System 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 94: Marker Beacon Annunciations
When a Traffic Advisory (TA) is detected, the following automatically occurs: • The PFD Inset Map is enabled, displaying traffic • A flashing black-on-yellow TRAFFIC annunciation appears to the top left of the Attitude Indicator for five seconds and remains displayed until no TAs are detected in the area • The aural alert “TRAFFIC” is generated If additional TAs appear, new aural and visual alerts are generated. Traffic Symbols PFD Traffic Annunciation PFD Inset Map with Traffic Displayed Figure 2-39 Traffic Annunciation and Inset Map with Traffic Displayed Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 95: Rev. A Garmin G1000 Pilot's Guide For The Socata Tbm
FLIGHT INSTRUMENTS TERRAIN ANNUNCIATIONS Terrain Awareness and Warning System (TAWS) or TERRAIN-SVS annunciations appear on the PFD to the upper left of the altimeter. Refer to the Hazard Avoidance Section and Appendix A for information on terrain alerts and annunciations. Figure 2-40 Traffic and Example Terrain Annunciations 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 96: Altitude Alerting
SBAS is available. This annunciation is not shown for systems with TAWS, unless TAWS is inhibited. When the Final Approach Fix (FAF) is the active waypoint in a GPS SBAS approach using vertical guidance, a Low Altitude Annunciation may appear if the current aircraft altitude is at least 164 feet below the prescribed altitude at the FAF. A black-on-yellow LOW ALT annunciation appears to the top right of the Altimeter, flashing for several seconds then remaining displayed until the condition is resolved. Altimeter Figure 2-42 Low Altitude on GPS SBAS Approach Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 97: Minimum Descent Altitude/Decision Height Alerting
4) Use the small FMS Knob to enter the desired altitude (from zero to 16,000 feet). 5) To remove the window, press the CLR Key or press the TMR/REF Softkey. Figure 2-44 Timer/References Window, MDA/DH Setting 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 98: Radar Altimeter
When the radar altimeter is selected as the altitude source for the minimum descent altitude alerting function (Figure 2-46), the color of the radar height changes to yellow upon reaching (or desending below) the altitude entered. (Figure 2-47). Figure 2-46 RAD ALT Setting (Timer/References Window) Figure 2-47 RA as Altitude Source for MDA/DH Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 99 Th e ‘RA TEST’ annunciation is displayed above the RA box (Figure 2-50). To cancel the test, select the RA TEST Softkey again, or turn the FMS Knob to exit the AUX - System Status Page. Figure 2-50 Radar Altimeter Test Display (KRA 405) 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 100: Abnormal Operations
It is important to note that estimated navigation data supplied by the G1000 in DR Mode may become increasingly unreliable and must not be used as a sole means of navigation. See the Flight Management section for more information about DR mode Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 101: Unusual Attitudes
Glidepath Indicators right corner of the PFD: • Inset Map • Altimeter Barometric Setting – Timer/References • Outside air temperature (OAT) • Selected Altitude – Nearest Airports • DME Information Window • VNV Target Altitude – Flight Plan • Wind data – Messages • Selected Heading readout – Procedures • Selected Course readout – ADF/DME Tuning • Transponder Status Box 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 102 FLIGHT INSTRUMENTS lank Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 103: Section 3 Engine And Airframe Systems
In combination with these, aural alerts, additional avionics messages, and master indicators are used to inform the crew of aberrant flight conditions. The system also provides an improved level of maintenance data for the ground crew. EICAS Display Figure 3-1 Multi Function Display 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 104 CAS messages appear in a window on the right of the display. Synoptics are not available while in Reversionary Mode. Display Window Figure 3-2 Reversionary Mode Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 105: Engine Indication System (Eis)
Oil Temperature Battery and Generator Currents CAS Display Battery and Essential Bus Voltages Cabin Pressure Altitude and Change Rate Elevator, Aileron, and Rudder Trim and Flap Position Differential Pressure 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 106: Engine Parameters
A propeller overspeed warning is indicated if propeller speed exceeds the maximum safe operating speed. Figure 3-6 Propeller RPM Gauge Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 107 Engine oil pressure and temperature are shown along horizontal bar indicators below the engine gauges. Oil pressure is shown in pounds per square inch (psi) and temperature in degrees Celsius (°C). Figure 3-9 Oil Pressure and Temperature Gauges 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 108: Cabin Pressurization
Readouts for fuel quantity and fuel flow are shown in Reversionary Mode. Tank Fuel Quantities Fuel Flow Fuel Pressure Figure 3-11 Fuel Display Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 109: Electrical Information
Flap positions for takeoff, landing, and up positions are labeled. In Reversionary Mode, only elevator trim is indicated and flap position (UP, T/O, LDG) is provided as a digital readout. Figure 3-13 Trim and Flap Indications 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 110: Synoptics
Displays the Electrical Synoptics Page • FUEL Displays the Fuel Synoptics Page • GEN Displays the General Synoptics Page for the de-ice system and doors Synoptic Page EICAS Figure 3-15 MFD Layout Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 111: Electrical System
Main Generator Battery Bus Voltage Ground Power Unit Door Essential Bus Voltage Battery DC Buses 1 through 4 Amperage Main Bus Battery Bus Figure 3-16 Electrical Synoptics Page 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 112 If the battery is disconnected from the main bus, the switch is closed. Battery overheating is indicated in red with a ‘BAT OVHT’ annunciation; a CAS message is also generated. Connected Disconnected Battery Overheat Figure 3-19 Battery Status Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 113 Essential Bus Connected to the Battery Bus to the Main Bus Figure 3-22 Essential Bus Connections A red “X” over a component indicates invalid data or a failed unit. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 114: Fuel System
Figure 3-23 Fuel Synoptics Page Fuel Pressure is displayed using a gauge. If fuel pressure is low the readout is displayed in red. Figure 3-24 Fuel Pressure Low Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 115 AUX - Weight Planning Page (see the Flight Management Section). Figure 3-25 Fuel Flow Data A red “X” over a component indicated invalid data or a failed unit. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 116: General Systems
Forward Cargo Door Open Figure 3-26 General Synoptics Page Windshield Windshield Left Windshield Heat On Heat On Heat Off Right Windshield Heat Selected Figure 3-27 Windshield Heat Status Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 117: Crew Alerting System (Cas)
EIS. The window size increases to fit up to 14 CAS messages; if more than 14 messages are generated, the messages can be scrolled through using the CAS softkeys (two left-most softkeys). Normal Mode Reversionary Mode Display Window Figure 3-28 CAS Messages 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 118: Cas Display Inhibits
If a GEA or GIA fails, all CAS messages depending on sensors associated with that LRU are automatically inhibited. Inhibits cannot be activated by invalid sensor data. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 119: Cas Messages And Prioritization
Oil pressure below 60 psi OXYGEN Oxygen cylinder closed PARK BRAKE Parking brake applied TORQUE Torque greater than or equal to 121.4% maximum torque Table 3-5 Warning CAS Messages 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 120 Vacuum pressure less than 3.75 in Hg * Only affected side (L, R, or L-R) displayed in CAS message; applicable messages listed here display L-R for example Table 3-6 Caution CAS Messages Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 121: Section 4 Audio Panel And Cns
Radio volume adjustments may be overridden by each crew position independently using the master volume control on the Audio Panel for the respective crew position. In addition, the master volume control for each Audio Panel affects all other system audio output to its designated crew position headset much like volume adjustments found on many aviation headsets. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 122: Pfd Controls And Frequency Display
AUDIO PANEL AND CNS PFD CONTROLS AND FREQUENCY DISPLAY Figure 4-1 PFD Controls, COM/NAV Frequency Tuning Boxes, and ADF/DME Tuning Window Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 123 Press the FMS Knob to turn the selection cursor on and off. The large knob moves the cursor in the window. The small knob selects individual characters for the highlighted cursor location. Transponder Data Box – Indicates the selected transponder code, operating mode, reply, and ident status for the applicable transponder. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 124: Audio Panel Controls
COM1 MIC – Selects the #1 transmitter for transmitting. COM1 receive is simultaneously selected when this key is pressed allowing received audio from the #1 COM receiver to be heard. COM2 receive can be added by pressing the COM2 Key. COM1 – When selected, audio from the #1 COM receiver can be heard. COM2 MIC – Selects the #2 transmitter for transmitting. COM2 receive is simultaneously selected when this key is pressed allowing received audio from the #2 COM receiver to be heard. COM1 receive can be added by pressing the COM1 Key. COM2 – When selected, audio from the #2 COM receiver can be heard. COM3 MIC – Not used in the TBM 850. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 125 ICS Knob – Turn to adjust intercom volume or squelch. Press to switch between volume and squelch control as indicated by illumination of VOL or SQ. The MAN SQ Key must be selected to allow squelch adjustment. MSTR Knob – The Master Volume Control adjusts volume for the blended NAV, COM, intercom audio, and alert warnings. DISPLAY BACKUP Button – Manually selects Reversionary Mode. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 126: Com Operation
Active Standby Fields Fields Top Section of the Audio Panel Tuning Box COM2 Radio is Selected on the Audio Panel Figure 4-3 Selecting a COM Radio for Transmit Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 127: Com Transceiver Manual Tuning
Key to Transfer COM Frequencies Between Active and Standby Frequency Boxes Turn the COM Knob to Tune the Frequency in the Tuning Box Figure 4-5 COM Frequency Tuning 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 128: Quick-Tuning And Activating 121.500 Mhz
Pressing and holding the COM Frequency Transfer Key for two seconds automatically loads the emergency COM frequency (121.500 MHz) in the active field of the COM radio selected for tuning (the one with the transfer arrow). In the example shown, pressing the Audio Panel COM2 MIC Key activates the transceiver. Press for Two Seconds to Load 121.500 MHz Figure 4-7 Quickly Tuning 121.500 MHz Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 129: Auto-Tuning The Com Frequency
4) Press the Frequency Transfer Key to transfer the frequency to the COM Active Frequency Field. Select the NRST Softkey to Open the Nearest Airports Window Figure 4-8 Nearest Airports Window (PFD) 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 130 Knob to Scroll Press the ENT Key to Load a Through a List Highlighted Frequency into the of Frequencies. COM Standby Frequency Box. Figure 4-9 Frequency Auto-Tuning from the MFD Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 131 6) Press the Frequency Transfer Key to transfer the frequency to the COM Active Frequency Field. Nearest Airports Menu Nearest Frequencies Menu Nearest Airspaces Menu Figure 4-10 Nearest Pages Menus 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 132 PFD1 COM Standby Field. Cursor then advances to the next frequency. Select INFO-x Softkey for AIRPORT, RUNWAYS, and FREQUENCIES Windows Figure 4-11 WPT – Airport Information Page Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 133 AUDIO PANEL AND CNS COM frequencies can also be auto-tuned from the NRST – Nearest Airspaces, NRST – Nearest Frequencies, and NRST – Nearest Airports Pages on the MFD in a similar manner using the appropriate softkeys or MENU Key, the FMS Knob, and the ENT Key. Figure 4-12 NRST – Nearest Airspaces, NRST – Nearest Airports, and NRST – Nearest Frequencies Pages 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 134: Frequency Spacing
4) Turn the small FMS Knob to select the desired channel spacing. 5) Press the ENT Key to complete the channel spacing selection. While the COM CONFIG Window is selected, the G1000 softkeys are blank. Select 8.33-kHz or 25.0-kHz COM Frequency Channel Spacing Figure 4-14 AUX – System Setup Page Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 135: Automatic Squelch
COM radio volume level can be adjusted from 0 to 100% using the VOL/SQ Knob. Turning the knob clockwise increases volume, turning the knob counterclockwise decreases volume. When adjusting volume, the level is displayed in place of the standby frequencies. Volume level indication remains for two seconds after the change. COM Volume Level Remains for Two Seconds Figure 4-16 COM Volume Level 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 136: Nav Operation
• GPS – If GPS Mode is selected, a magenta single line arrow (not shown) appears on the HSI and neither NAV radio is selected. Both active NAV frequencies are then displayed in white. Standby Active Fields Fields Tuning Box The NAV Radio is Selected by Pressing the CDI Softkey Figure 4-17 Selecting a NAV Radio for Navigation See the Flight Instruments Section for selecting the DME and Bearing Information windows and using VOR or ADF as the source for the bearing pointer. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 137: Nav Receiver Manual Tuning
Press the Frequency Transfer Key to Transfer NAV Frequencies Between Active and Standby Frequency Fields Turn the NAV Knob to Tune the Frequency in the Tuning Box Figure 4-19 NAV Frequency Tuning 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 138 NAV Radio volume level can be adjusted from 0 to 100% using the VOL/ID Knob. Turning the knob clockwise increases volume, counterclockwise decreases volume. When adjusting, the level is displayed in place of the standby frequencies. Volume level indication remains for two seconds after the change. NAV Volume Level Remains for Two Seconds Figure 4-22 NAV Volume Levels Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 139: Auto-Tuning A Nav Frequency From The Mfd
Press the ENT Key to Load a Through a List Highlighted Frequency into the of Frequencies. NAV Standby Frequency Box. Figure 4-23 NAV Frequency Auto-Tuning from the MFD 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 140 6) Press the Frequency Transfer Key to transfer the frequency to the NAV Active Frequency Field. Nearest Airports Menu Nearest VOR Menu Nearest Frequencies Menu Nearest Airspaces Menu Figure 4-24 Nearest Pages Menus Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 141 Place the Cursor on to Place the Cursor on the VOR Frequency the VOR Identifier Figure 4-25 Loading the NAV Frequency from the NRST – Nearest VOR Page 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 142 MENU Key, the FMS Knob, and the ENT Key. Figure 4-26 NRST – Nearest Frequencies, WPT – VOR Information, WPT – Airport Information, and NRST – Nearest Airports Pages Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 143 (within 15 nm of the FAF). See the Flight Management Section for details. NAV frequencies are automatically loaded into the NAV Frequency Box on approach activation, on both PFD1 and PFD2. When loading or activating a VOR or ILS/LOC approach, the approach frequency is automatically transferred to a NAV frequency field as follows: • If the current CDI navigation source is GPS, the approach frequency is transferred to the NAV1 or NAV2 active frequency fields. The frequency that was previously in the NAV1 or NAV2 active frequency fields are transferred to standby. • If the current CDI navigation source is GPS, and if the approach frequency is already loaded into the NAV1 or NAV2 standby frequency field, the standby frequency is transferred to active. • If the current CDI navigation source is NAV1 or NAV2, the approach frequency is transferred to the standby frequency fields of the selected CDI NAV radio. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 144: Marker Beacon Receiver
Pressing the HI SENS Key switches between high and low marker beacon receiver sensitivity. The HI SENS function (annunciator illuminated) is used to provide an earlier indication when nearing a marker during an approach. The LO SENS function (annunciator extinguished) results in a narrower marker dwell while over a station. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 145: Adf/Dme Tuning
Turning the large FMS Knob moves the selection cursor through the various fields (standby ADF frequency, ADF receiver mode, ADF radio volume, and DME tuning mode). Pressing the FMS Knob activates/deactivates the selection cursor in the ADF/DME Tuning Window. The ADF frequency is entered using the FMS Knob and the ENT Key. Active ADF Frequency Standby ADF Frequency Mode Volume Tuning Mode Figure 4-29 ADF/DME Tuning Window 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 146 1) Turn the large FMS Knob to place the selection cursor over the standby ADF frequency field. 2) Press the ENT Key to complete the frequency transfer. Press the ENT Key to Transfer the ADF Frequencies Figure 4-31 Transferring ADF Frequencies Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 147 1) Turn the large FMS Knob to place the selection cursor over the ADF volume field. 2) Turn the small FMS Knob to adjust volume as desired. Turn the Small FMS Knob to Select the Volume Figure 4-33 Adjusting ADF Receiver Volume 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 148 3) Press the ENT Key to complete the selection. Pressing the CLR Key or FMS Knob while in the process of DME pairing cancels the data entry and reverts back to the previously selected DME tuning state. Pressing the FMS Knob activates/deactivates the cursor in the ADF/DME Tuning Window. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 149: Gtx 33/33D Mode S Transponders
• Acquisition squitter – Acquisition squitter, or short squitter, is the transponder 24-bit identification address. The transmission is sent periodically, regardless of the presence of interrogations. The purpose of acquisition squitter is to enable Mode S ground stations and aircraft equipped with a Traffic Avoidance System (TAS) to recognize the presence of Mode S-equipped aircraft for selective interrogation. The Hazard Avoidance Section provides more details on traffic avoidance systems. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 150: Transponder Controls
1) Press the XPDR Softkey to display the Transponder Mode Selection Softkeys. 2) Press the XPDR1 or XPDR2 Softkey to select and activate the other transponder. When turning on the G1000 for use, the system activates Transponder 1 as the default unit, regardless of which transponder was active prior to shutdown. When switching between Transponder 1 and Transponder 2, the code and mode remain the same. If a new code is entered in the active transponder, switching transponders does not bring back the previous code. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 151: Transponder Mode Selection
When Standby is selected, a white STBY indication and transponder code appear in the mode field of the Transponder Data Box. In all other modes, these fields appear in green. STBY Mode (White Code Number and Mode) Figure 4-37 Standby Mode 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 152 Figure 4-39 Altitude Mode REPLY STATUS When the transponder sends replies to interrogations, a white R indication appears momentarily in the reply status field of the Transponder Data Box. Reply to Interrogation Figure 4-40 Reply Indication Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 153: Entering A Transponder Code
Turn the Large Enter Two Code FMS Knob Digits at a Time to Move the Cursor to the Next Code Field Figure 4-42 Entering a Code with the FMS Knob 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 154: Ident Function
After the IDENT Softkey is pressed while in Mode or Code Selection, the system reverts to the top-level softkeys. IDNT Indication Press the IDENT Softkey to Initiate the ID Function Figure 4-44 IDENT Softkey and Indication Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 155: Flight Id Reporting
AUDIO PANEL AND CNS FLIGHT ID REPORTING If the Flight ID is required but the system is not configured for it, contact a Garmin-authorized service NOTE: center for configuration. When the Flight ID must be entered before flight operation, the identifier is placed in the Timer/References Window on the PFD. The system allows entry of up to eight characters. No space is needed when entering Flight ID. When a Flight ID contains a space, the system automatically removes it upon completion of Flight ID entry. Entering a Flight ID: 1) Press the TMR/REF Softkey to display the Timer/References Window.
Page 156: Additional Audio Panel Functions
All of the radios can be heard over the cabin speakers. Speaker audio is muted when the PTT is pressed. Certain aural alerts and warnings (autopilot, traffic, altitude) are always heard on the speaker, even when the speaker is not selected. The speaker volume is adjustable within a nominal range. Contact a Garmin-authorized service center for volume adjustment. Figure 4-46 Music and Speaker Keys Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 157: Intercom
Master Volume when SQ Annunciation Control for Pilot is lit, Volume when Side or Copilot VOL Annunciation is lit. Side Volume Annunciation Squelch Annunciation Figure 4-47 Intercom Controls 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 158: Passenger Address (Pa) System
Figure 4-48 PA Key Selected for Cabin Announcements SIMULTANEOUS COM OPERATION Both the pilot and the copilot can transmit and receive simultaneously over separate COM radios. The selected COM MIC Annunciator flashes when either pilot’ s microphone PTT is pressed. If both pilots select the same COM radio, the pilot has priority on COM1 and the copilot has priority on COM2. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 159: Clearance Recorder And Player
Powering off the unit automatically clears all recorded blocks. PLAY Key Controls the Play Function Figure 4-49 Clearance Recorder PLAY Key 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 160: Entertainment Inputs
SiriusXM Satellite Radio audio from the Data Link Receiver may be heard by the pilot and passengers simultaneously (optional: requires subscription to SiriusXM Satellite Radio Service). Refer to the Additional Features Section for more details on the Data Link Receiver. Connecting a stereo input to either MUSIC 1 or MUSIC 2 jacks removes the SiriusXM Satellite Radio Audio from that input. For example, if passengers prefer their own music while the pilot listens to the SiriusXM Satellite Radio, the entertainment audio should be connected to the MUSIC 2 jack. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 161: Audio Panels Preflight Procedure
Control Squelch Control Volume Annunciation Squelch Annunciation Reversionary Mode Reversionary Mode for PFD1 and MFD for PFD2 and MFD Pilot Side Copilot Side Figure 4-50 Audio Panel Controls 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 162 Knobs Adjust Headphone NAV Radio Volume Level Audio ADF Radio Audio FMS Knob Adjusts ADF Volume Level Copilot Master Volume Control Figure 4-51 Radio and Headphone Volume Controls Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 163: Abnormal Operation
The COM1 MIC or COM2 MIC Key Annunciator on the Audio Panel flashes as long as the PTT Key remains stuck. Figure 4-52 Stuck Microphone Alert COM TUNING FAILURE In case of a COM system tuning failure, the emergency frequency (121.500 MHz) is automatically tuned in the radio in which the tuning failure occurred. Depending on the failure mode, a red X may appear on the frequency display. Emergency Channel Loaded Automatically Figure 4-53 COM Tuning Failure 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 164: Pfd Failure
Emergency Channel Loaded Automatically Figure 4-54 Frequency Section of PFD2 Display after PFD1 Failure If PFD2 fails, COM2 and NAV2 display a red X on the remaining PFD display. NAV2 is unavailable. COM2 tunes 121.500 MHz, but the frequency is not shown. The COM2 emergency frequency is available to both the copilot and pilot. Figure 4-55 PFD1 Display after PFD2 Failure Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 165: Audio Panel Fail-Safe Operation
REVERSIONARY MODE The red DISPLAY BACKUP Button selects the Reversionary Mode. See the System Overview Section for more information on Reversionary Mode. Figure 4-56 Reversionary Mode Button 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 166 AUDIO PANEL AND CNS lank Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 167: Section 5 Flight Management
The Direct-to Window, the Flight Plan Window, the Procedures Window, and the Nearest Airports Window can be displayed in the lower right corner of the PFD. Details of these windows are discussed in detail later in the section. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 168: Navigation Status Box
Figure 5-2 GPS Navigation Information on the MFD Navigation Page NAVIGATION STATUS BOX The Navigation Status Box located at the top of the PFD contains two fields displaying the following information: PFD Navigation Status Box Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 169 4) Turn the small FMS Knob to display and scroll through the data options list. 5) Select the desired data. 6) Press the ENT Key. Selecting the DFLTS Softkey returns all fields to the default setting. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 170: Using Map Displays
(track up, desired track up, or heading up). The map orientation is shown in the upper right corner of the map. Figure 5-3 Map Orientation Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 171 2) Press the ENT Key to display the Map Setup Window. 3) Turn the large FMS Knob, or press the ENT Key once, to select the ‘ORIENTATION’ field. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 172: Map Range
To change the map range turn the Joystick counter-clockwise to decrease the range, or clockwise to increase the range. Range Overzoom Figure 5-6 Map Range Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 173 • Flight plans that have a combination of long and short legs cause the range to increase and decrease as waypoints sequence. To avoid this, auto zoom can be disabled or the maximum/minimum times can be adjusted. • The ‘time out’ time (configurable on the Map Setup Page for the Map Group) determines how long auto zoom is overridden by a manual adjustment of the range knob. At the expiration of this time, the auto zoom range is restored. Setting the ‘time out’ value to zero causes the manual override to never time out. • When the maximum ‘look forward’ time is set to zero, the upper limit becomes the maximum range available (2000 nm). • When the minimum ‘look forward’ time is set to zero, the lower limit becomes 1.5 nm. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 174 9) Repeat step 8 for ‘MIN LOOK FWD’ (zero to 99 minutes) and ‘TIME OUT’ (zero to 99 minutes). 10) Press the FMS Knob to return to the Navigation Map Page. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 175: Map Panning
The map is normally centered on the aircraft’s position. If the map has been panned and there has NOTE: been no pointer movement for about 60 seconds, the map reverts back to centered on the aircraft position and the flashing pointer is removed. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 176 When any map feature or object is selected on the map display, pertinent information is displayed. Information about Point of Interest Map Pointer on Figure 5-9 Navigation Map - Map Pointer on Point of Interest Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 177 2) Move the Joystick to move the Map Pointer around the map. 3) Press the Joystick to remove the Map Pointer and recenter the map on the aircraft’s current position. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 178 3) Select the GO BACK Softkey, the CLR Key, or the ENT Key to exit the Waypoint Information Page and return to the Navigation Map showing the selected waypoint. NAVAID Information GO BACK Softkey Figure 5-11 Navigation Map - Information Window - NAVAID Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 179 Information Page for the selected airspace. 4) Press the CLR or ENT Key to exit the Airspace Information Page. Airspace Information Figure 5-12 Navigation Map - Information Window - Airspace 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 180: Measuring Bearing And Distance
5) To exit the Measure Bearing/Distance option, press the Joystick; or select ‘Stop Measuring’ from the Page Menu and press the ENT Key. Measurement Pointer Lat/Long Information Measurement Line Figure 5-13 Navigation Map - Measuring Bearing and Distance Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 181: Topography
4) Press the ENT Key. 5) Highlight the ‘TOPO DATA’ field. 6) Select ‘On’ or ‘Off’. 7) Press the FMS Knob to return to the Navigation Map Page. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 182 In addition, the Navigation Map can display a topographic scale (located in the lower right hand side of the map) showing a scale of the terrain elevation and current elevation values. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 183 5) Select ‘On’ or ‘Off’. 6) Press the FMS Knob to return to the Navigation Map Page. TOPO SCALE On/Off Figure 5-17 Navigation Map Setup Menu - TOPO SCALE Setup 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 184: Map Symbols
LARGE CITY (> 200,000) 1500 MEDIUM CITY (> 50,000) SMALL CITY (> 5,000) States and Provinces (STATE/PROV) 1500 Rivers and Lakes (RIVER/LAKE) USER WAYPOINT Table 5-1 Land Symbol Information Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 185 Class C Airspace/TCA (CLASS C/TCA) Class D Airspace (CLASS D) Restricted Area (RESTRICTED) Military Operations Area [MOA(MILITARY)] Other/Air Defense Interdiction Zone (OTHER/ADIZ) Temporary Flight Restriction (TFR) 2000 Table 5-2 Aviation Symbol Information 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 186 4) Press the ENT Key. The cursor flashes on the first field. 5) Select the desired land option. 6) Select the desired text size. 7) Press the ENT Key to accept the selected size. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 187 PFD Inset Map two range levels smaller than the range selected in the Map Setup pages (e.g., a setting of 100 nm removes the item at ranges above 100 nm on MFD navigation maps, while the PFD Inset Map removes the same item at 50 nm). 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 188 Decluttering the PFD Inset Map: 1) Press the INSET Softkey. 2) Press the DCLTR Softkey. The current declutter level is shown. With each selection, another level of map information is removed. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 189 Class C Airspaces/TCA Class D Airspaces Other Airspaces/ADIZ TFRs Obstacles Land/Country Text Cities Roads Railroads State/Province Boundaries River/Lake Names Table 5-3 Navigation Map Items Displayed by Declutter Level 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 190: Airways
When airways are selected for display on the map, the airway waypoints (VORs, NDBs and Intersections) are also displayed. Low Altitude Airway (Victor Airway) High Altitude Airway (Jet Route) Figure 5-22 Airways on MFD Navigation Page Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 191 5) To change the range setting, turn the small FMS Knob to display the range list. 6) Select the desired range using the small FMS Knob. 7) Press the ENT Key. 8) Press the FMS Knob to return to the Navigation Map Page. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 192: Track Vector
Use the FMS Knob to select the desired time. Press the ENT Key. 7) Press the FMS Knob to return to the Navigation Map Page. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 193: Wind Vector
4) Press the ENT Key. 5) Highlight the ‘WIND VECTOR’ field. 6) Select ‘On’ or ‘Off’. 7) Press the FMS Knob to return to the Navigation Map Page. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 194: Nav Range Ring
7) Press the FMS Knob to return to the Navigation Map Page. The Nav Range Ring is referenced to either magnetic or true north, based on the selection on the AUX NOTE: - System Setup Page. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 195: Fuel Range Ring
8) To change the reserve fuel time, enter a time (00:00 to 23:59; hours:minutes). The default setting is 00:45 minutes. 9) Press the ENT Key. 10) Press the FMS Knob to return to the Navigation Map Page. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 196: Field Of View (Svs)
4) Press the ENT Key. 5) Highlight the ‘FIELD OF VIEW’ field. 6) Select ‘On’ or ‘Off’. 7) Press the FMS Knob to return to the Navigation Map Page. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 197: Selected Altitude Intercept Arc
4) Press the ENT Key. 5) Highlight the ‘SEL ALT ARC’ field. 6) Select ‘On’ or ‘Off’. 7) Press the FMS Knob to return to the Navigation Map Page. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 198: Waypoints
FMS Knob during the selection process. If duplicate entries exist for an identifier, a Duplicate Waypoints Window is displayed when the ENT Key is pressed. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 199: Airports
This information is viewed on the Airport Information Page by pressing the INFO softkey until INFO-1 is displayed. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 200 The following descriptions and abbreviations are used on the Airport Information Page: • Usage type: Public, Military, Private, or Heliport • Runway surface type: Hard, Turf, Sealed, Gravel, Dirt, Soft, Unknown, or Water • Runway lighting type: No Lights, Part Time, Full Time, Unknown, or PCL Freq (for pilot-controlled lighting) • COM Availability: TX (transmit only), RX (receive only), PT (part time), i (additional information available) Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 201 • Noise: Noise Abatement • Pilot Controlled Lighting: Transportation Type Available Procedures High/Med/Low Clicks/Second • Approach: Approach Facility • Charts: Low Altitude Chart • FBO: Type, Frequencies, Name, Frequency, Frequency Number Services, Fees, Fuel, Credit Parameter Cards, Phone/Fax Numbers 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 202 25 nearest airports (three entries can be displayed at one time). If there are more than three they are displayed in a scrollable list. If there are no nearest airports available, “NONE WITHIN 200NM” is displayed. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 203 If there are no items for display in a boxed area, text indicating that fact is displayed. The currently selected airport remains in the list until it is unselected. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 204 4) Turn the FMS Knob to highlight the desired airport. (Pressing the ENT Key also moves to the next airport.) 5) Press the FMS Knob to remove the flashing cursor. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 205 5) Press the FMS Knob to remove the flashing cursor. Nearest Airport Criteria - Type of Runway Surface - Minimum Runway Length Figure 5-38 System Setup Page - Nearest Airport Selection Criteria 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 206: Intersections
2) Press the ENT Key or turn either FMS Knob to select an identifier in the Nearest Intersection Box. 3) Press the FMS Knob to remove the flashing cursor. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 207 Showing Nearest intersection from Intersection aircraft position Intersection Lat/Long Nearest Nearest VOR Info Intersection - Identifier/Type (symbol) - VOR Frequency - Bearing/Distance to VOR Figure 5-40 Nearest Intersections Page 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 208: Ndbs
2) Press the ENT Key or turn either FMS Knob to select an identifier in the Nearest NDB Box. 3) Press the FMS Knob to remove the flashing cursor. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 209 Navigation Map - Bearing/Distance to Showing Selected NDB from aircraft position Nearest NDB NDB Information - Facility Name/City - Type - Lat/Long NDB Frequency Figure 5-42 Nearest NDB Page 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 210: Vors
2) Press the ENT Key or turn either FMS Knob to select an identifier in the Nearest VOR Box. 3) Press the FMS Knob to remove the flashing cursor. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 211 - Bearing/Distance to VOR Showing Nearest from aircraft position VOR Information - Facility Name/City - Class/Magnetic Variation - Lat/Long Nearest VOR VOR Frequency Figure 5-44 Nearest VOR Page 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 212: User Waypoints
2) Press the ENT Key or turn either FMS Knob to select an identifier in the Nearest USR Box. 3) Press the FMS Knob to remove the flashing cursor. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 213 Select “LAT/LON” using the small FMS Knob, press the ENT Key, and enter the latitude and longitude into the INFORMATION window using the FMS Knobs. 5) Press the ENT Key to accept the new waypoint. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 214 “TEMPORARY” and selecting the ENT Key to check or uncheck the box. 8) Press the FMS Knob to remove the flashing cursor. Figure 5-47 User Waypoint Information Page Menu Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 215 4) Turn the small FMS Knob to make any changes. 5) Press the ENT Key to accept the changes. 6) Press the FMS Knob to remove the flashing cursor. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 216 3) Select ‘NORMAL’ or ‘TEMPORARY’ as desired, and press the ENT Key. 4) Press the FMS Knob to remove the flashing cursor and return to the User Waypoint Information Page. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 217 2) Press the MENU Key. 3) Select ‘Delete All User Waypoints’. 4) Press the ENT Key twice to confirm the selection. 5) Press the FMS Knob to remove the flashing cursor. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 218: Airspaces
(Military), Other Airspace, Air Defense Interdiction Zone (ADIZ), and Temporary Flight Restriction (TFR). Class D Airspace MOA (Military) Class B Airspace Restricted Area Alert Area Class C Airspace ADIZ Warning Area Figure 5-48 Airspaces Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 219 4) Turn the small FMS Knob clockwise to turn the airspace alert ON or counterclockwise to turn the alert OFF. 5) Press the FMS Knob to remove the flashing cursor. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 220 Map ranges for the airspace boundaries are selected from the Aviation Group in the Map Setup Menu. See Table 5-2 for the default and maximum ranges for each type of airspace and the symbol used to define the airspace area. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 221 ENT Key. The cursor is placed in the ‘AIRSPACE ALERTS’ Box. 3) Select the desired airspace. 4) Press the FMS Knob to remove the flashing cursor. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 222 ARSPC NEAR – Airspace near – Special use airspace is within 2 nm of the aircraft position. less than 2 nm. Table 5-6 PFD Airspace Alert Messages Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 223: Direct-To-Navigation
VNV Constraints - City - Altitude at Arrival - Along Track Offset Map of Selected Point Location of Destination - Bearing/Distance Desired Course Figure 51 Direct-to Window - MFD 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 224 2) Turn the small FMS Knob counter-clockwise to display a list of flight plan waypoints (the FPL list is populated only when navigating a flight plan). Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 225 1) Press the NRST Softkey on the PFD; or turn the FMS Knob to display the Nearest Airports Page and press the FMS Knob. 2) Select the desired airport (the nearest one is already selected). 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 226 3) With ‘Cancel Direct-To NAV’ highlighted, press the ENT Key. If a flight plan is still active, the G1000 resumes navigating the flight plan along the closest leg. Page Menu - Cancel Direct-To Navigation Figure 5-54 Direct-to Window - Cancelling Direct-to Navigation Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 227 6) Press the ENT Key. The cursor is now flashing in the VNV offset distance field. 7) Enter the desired along-track distance before the waypoint. 8) Press the ENT Key. The ‘Activate?’ field is highlighted. 9) Press the ENT Key to activate. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 228 2) Press the MENU Key. 3) With ‘Clear Vertical Constraints’ highlighted, press the ENT Key. Page Menu - Clear Vertical Navigation Constraints Figure 5-55 Direct-to Window - Clearing Vertical Constraints Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 229: Flight Planning
If that happens, the airway waypoints are changed to regular (non-airway) flight plan waypoints, and an alert is displayed (see Miscellaneous Messages in Appendix A). 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 230: Flight Plan Creation
Turn Anticipation - Flight Path Angle - Vertical Speed Target - Time to Top of Descent - Vertical Deviation Non-Active, Flight Plan Leg Figure 5-56 Active Flight Plan Page Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 231 Selected Flight Plan Selected FPL Info - Departure Waypoint - Destination Waypoint - Total Flight Plan Distance - Enroute Safe Altitude Softkeys Figure 5-58 Flight Plan Catalog Page 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 232 7) When all waypoints have been entered, press the FMS Knob to return to the Flight Plan Catalog Page. The new flight plan is now in the list. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 233 9) Press the ENT Key again to confirm the import. Import/Export Softkeys List of Flight Plans to Import & Import Successful Details for the Selected File Figure 5-59 Flight Plan Import 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 234 The exported flight plan will not contain any procedures or airways. NOTE: Import/Export Softkeys Stored Flight Plan to be Exported & Export Successful Exported Flight Plan Name Figure 5-60 Flight Plan Export Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 235: Adding Waypoints To An Existing Flight Plan
- Distance to Waypoint - Waypoint Altitude Constraint Softkeys Figure 5-61 Stored Flight Plan Page Flight Plan Full Message Figure 5-62 Active Flight Plan Page - FPL Full 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 236 2) Press the FMS Knob to activate the cursor (not required on the PFD). 3) Select the point in the flight plan before which to add the new waypoint. The new waypoint is placed directly in front of the highlighted waypoint. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 237: Adding Airways To A Flight Plan
The G1000 also anticipates the desired airway and exit point based on loaded flight plan waypoints. Airway Entry Waypoint Selected Airway Airways Available at TOP Airway Waypoint Sequence Preview of Selected Airway Figure 5-64 Select Airway Page - Selecting Airway 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 238 Airway Entry Waypoint Selected Airway Selected Exit Point Preview of Selected Airway Airway Exit Points Selected Airway Exit Available Point Figure 5-65 Select Airway Page - Selecting Exit Point Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 239 • Starting from SARKI, the airway can be flown only to LIBRO. • Between NELDA and GZO, the airway can be flown in either direction. In the US, airways that are “one-way” for specified hours of operation are not uncommon. These airways are always bidirectional in the G1000 database. The system only allows correct airway sequences to be inserted. If the pilot subsequently inverts the flight plan, the system inverts the airway waypoint sequence and removes the airway header. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 240: Adding Procedures To A Stored Flight Plan
(arrival), and landing at an airport (approach). See the procedures section for more details. Flight Plan Name Flight Plan Waypoint List Softkeys Load Departure - Load Arrival - Load Approach - Activate Flight Plan Figure 5-67 Stored Flight Plan Page Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 241 5) Select a runway served by the selected departure, if required. Press the ENT Key. 6) Select a transition for the selected departure. Press the ENT Key. 7) Press the ENT Key to load the selected departure procedure. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 242 Figure 5-69 Departure Loading Page - Selecting Transition Inserted Departure Header - Departure Identifier: [departure airport]-[departure runway]. [departure transition]. [departure end point] (e.g., KMKC-ALL.WLDCT2.SLN) Figure 5-70 Stored Flight Plan Page - Departure Inserted Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 243 5) Select a transition for the selected arrival. Press the ENT Key. 6) Select a runway served by the selected arrival, if required. Press the ENT Key. 7) Press the ENT Key to load the selected arrival procedure. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 244 Figure 5-72 Arrival Loading Page - Selecting the Transition Inserted Arrival Header - Arrival Identifier: [arrival airport]-[arrival transition]. [arrival].[arrival runway] (e.g., KCOS-TBE.DBRY1.ALL) Figure 5-73 Stored Flight Plan Page - Arrival Inserted Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 245 4) Select an approach. Press the ENT Key. 5) Select a transition for the selected approach. Press the ENT Key. 6) Press the ENT Key to load the selected approach procedure. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 246 Figure 5-75 Approach Loading Page - Selecting the Transition Inserted Approach Header - Approach Identifier: [approach airport].[runway and approach type] (e.g., KCOS-RNAV 35R LPV) Figure 5-76 Stored Flight Plan Page - Approach Inserted Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 247: Flight Plan Storage
4) With ‘OK’ highlighted, press the ENT Key. The flight plan is stored in the next available position in the flight plan list on the Flight Plan Catalog Page. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 248 4) With ‘OK’ highlighted, press the ENT Key to copy the flight plan. To cancel the request, press the CLR Key, or highlight ‘CANCEL’ and press the ENT Key. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 249: Flight Plan Editing
3) With ‘OK’ highlighted, press the ENT Key to delete the active flight plan. To cancel the request, press the CLR Key, or highlight ‘CANCEL’ and press the ENT Key. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 250 3) Press the ENT Key. The ‘Remove <procedure name> from flight plan?’ window is displayed. 4) With ‘OK’ highlighted, press the ENT Key. To cancel the request, press the CLR Key, or highlight ‘CANCEL’ and press the ENT Key. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 251 7) With ‘OK’ highlighted, press the ENT Key. To cancel the request, press the CLR Key, or highlight ‘CANCEL’ and press the ENT Key. 8) Press the FMS Knob to remove the flashing cursor. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 252: Along Track Offsets
Along track offset waypoints lie along the path of the existing flight plan, and can be used to make the system reach a specified altitude before or after reaching the specified flight plan waypoint. Offset distances can be Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 253 4) Enter a positive or negative offset distance in the range of +/- 1 to 99 nm (limited by leg distances). 5) Press the ENT Key to create the offset waypoint. 6) Press the FMS Knob to remove the flashing cursor. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 254: Parallel Track
4) Turn the small FMS Knob to enter a distance from 1-99 nm and press the ENT Key. ‘ACTIVATE PARALLEL TRACK’ is highlighted. 5) Press the ENT Key to activate parallel track. Press the FMS Knob or the CLR Key to cancel the parallel track activation. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 255 Parallel Track cannot be activated if a course is set using direct-to or if the active leg is the first leg of the departure procedure. Attempting to activate parallel track with these conditions results in the message ‘Parallel Track Unavailable Invalid Route Geometry’. If an approach leg is active the status indicates that the system is unable to activate the parallel track with the message ‘Parallel Track Unavailable 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 256 2) Press the MENU Key, highlight ‘Parallel Track’, and press the ENT Key. The Parallel Track Window is displayed with ‘CANCEL PARALLEL TRACK?’ highlighted. 3) Press the ENT Key. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 257: Activating A Flight Plan Leg
5) Press the FMS Knob to remove the flashing cursor. Current Active Leg Selected Destination Waypoint Activate Leg Softkey Figure 5-84 Active Flight Plan Page - Selecting the Leg Destination Waypoint 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 258: Inverting A Flight Plan
The ‘Invert and activate stored flight plan?’ window is displayed. 4) With ‘OK’ highlighted, press the ENT Key. To cancel the request, press the CLR Key, or highlight ‘CANCEL’ and press the ENT Key. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 259: Flight Plan Views
3) Select the WIDE Softkey to display the wide view, or select the NARROW Softkey to display the narrow view. 4) Select the BACK Softkey to return to the top level active flight plan softkeys. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 260 “To” or the “Next” waypoint is automatically expanded. When an airway is loaded, airways are automatically expanded to facilitate flight plan review. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 261: Closest Point Of Fpl
(DIS) to the closest point along the flight plan to the selected reference waypoint and creates a user waypoint at this location. The name for the new user waypoint is derived from the identifier of the reference waypoint. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 262: Vertical Navigation
CURRENT VNV PROFILE box (defaults first waypoint in the active flight plan with an altitude enabled for vertical navigation (e.g., HABUK)). Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 263 (TOD) point is computed based on the default flight path angle; descent begins once the TOD is reached. Current Vertical Navigation Profile Current Vertical Navigation Profile Prior to VNV Direct-to After VNV Direct-to VNV Direct-To Softkey VNV PROF Softkey Figure 5-90 Vertical Navigation Direct-To 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 264: Altitude Constraints
Small Light Blue Text Cross AT Small Light Blue or BELOW Subdued Text 3,000 ft Altitude Constraint Small White Text with Examples Altitude Restriction Bar Figure 5-91 Waypoint Altitude Constraints Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 265 (only before the FAF). When a database altitude restriction of type “AT or ABOVE” or “AT or BELOW” is activated, the system uses the “AT” portion of the restriction to define the vertical profile. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 266 3) Press the CLR Key. A ‘Remove or Revert to published VNV altitude of nnnnnFT?’ confirmation window is displayed. 4) Select ‘REMOVE’ and press the ENT Key. The manually entered altitude is deleted (it is replaced by a system calculated altitude, if available). Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 267 4) Select ‘EDIT’ and press the ENT Key. 5) Edit the value using the FMS Knobs, and press the ENT Key. 6) Press the FMS Knob to remove the flashing cursor. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 268: Procedures
6) Select a runway (if required) and press the ENT Key. 7) Select a transition (if required) and press the ENT Key. ‘LOAD?’ is highlighted. 8) Press the ENT Key to load the departure procedure. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 269 Departure Airport Available Procedure Actions Departure Preview Departure Choices Loaded Procedures Figure 5-92 Departure Selection Loaded Departure Selected Departure Procedure Loading Page Selection Softkeys Figure 5-93 Departure Loading 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 270 4) With ‘OK’ highlighted, press the ENT Key. To cancel the removal request, highlight ‘CANCEL’ and press the ENT Key. 5) Press the FMS Knob to remove the flashing cursor. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 271: Arrivals
7) Select a runway (if required) and press the ENT Key. ‘LOAD?’ is highlighted. 8) Press the ENT Key to load the arrival procedure. Available Procedure Actions Destination Airport Arrival Choices Arrival Preview Loaded Procedures Figure 5-94 Arrival Selection 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 272 6) Turn the small FMS Knob to view the available runways. Press the ENT Key to select the runway. The cursor moves to the Sequence box. The arrival is previewed on the map. 7) Select the INFO-x Softkey to return to the Airport Information Page. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 273: Approaches
(e.g., VOR or ILS). The final course segment of ILS approaches, for example, must be flown by tuning the NAV receiver to the proper frequency and selecting that NAV receiver on the CDI. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 274 FOR GPS’ is displayed. GPS provides guidance to the approach, but the HSI must to be switched to a NAV receiver to fly the final course of the approach. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 275 Destination Airport Loaded Procedures Approach Choices Approach Preview Figure 5-96 Approach Selection Selected Approach Loaded Approach Procedure Loading Page Selection Softkeys LOAD or ACTIVATE? Annunciation Figure 5-97 Approach Loading 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 276 ‘NOT APPROVED FOR GPS’ is displayed. GPS provides guidance to the approach, but the HSI must to be switched to a NAV receiver to fly the final course of the approach. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 277 4) With ‘OK’ highlighted, press the ENT Key. To cancel the removal, highlight ‘CANCEL’ and press the ENT Key. 5) Press the FMS Knob to remove the flashing cursor. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 278 Course to Altitude leg when the missed approach procedure is activated. Course to Altitude Leg Figure 5-98 Course to Altitude Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 279: Trip Planning
• Departure time (DEP TIME) - This defaults to the current time in automatic page mode. The computations are from the aircraft present position, so the aircraft is always just departing. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 280 • Enroute safe altitude (ESA) - The ESA is shown as nnnnnFT • Destination sunrise and sunset times (SUNRISE, SUNSET) - These times are shown as hours:minutes and are the local time at the destination. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 281 - REM: Pres. Pos. to End of FPL Starting and Ending Waypoint of - NN: Pres. Pos. to End of Selected Leg Selected Flight Plan Segment Figure 5-100 Trip Planning Page - Flight Plan Mode 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 282 2) Turn the FMS Knobs to move the cursor onto the DEP TIME field and enter the desired value. Press the ENT Key. The statistics are calculated using the new value and the cursor moves to the next entry field. Repeat until all desired values have been entered. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 283: Weight Planning
4) Press the FMS Knob to remove the flashing cursor. The basic operating weight is calculated by adding the basic empty weight and the pilot and stores weight. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 284 Select the FOB SYNC Softkey; or press the MENU Softkey, highlight ‘Synchronize Fuel on Board’, and press the ENT Key. The actual measured fuel on board is displayed in the ‘FUEL ON BOARD’ field. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 285: Weight Caution And Warning Conditions
• Estimated fuel at landing weight • Excess fuel weight If the estimated landing fuel weight is zero or negative, then the following values are displayed in red: • Estimated fuel at landing weight • Excess fuel weight 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 286: Raim Prediction
RAIM PREDICTION Box - Prediction Waypoint - Arrival Time - Arrival Date - RAIM Status RAIM Softkey SBAS Softkey (displays RAIM (displays SBAS Selection) PREDICTION) Figure 5-103 RAIM Prediction Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 287 • ‘COMPUTE RAIM?’ - RAIM has not been computed. • ‘COMPUTING AVAILABILITY’ - RAIM calculation is in progress. • ‘RAIM AVAILABLE’ - RAIM is predicted to be available. • ‘RAIM NOT AVAILABLE’ - RAIM is predicted to be unavailable. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 288 SBAS SELECTION Box - EGNOS Enable/Disable - MSAS Enable/Disable - WAAS Enable/Disable RAIM Softkey SBAS Softkey (displays RAIM (displays SBAS Selection) PREDICTION) Figure 5-104 SBAS Display - Active Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 289 SBAS SELECTION Box - EGNOS Enable/Disable - MSAS Enable/Disable - WAAS Enable/Disable RAIM Softkey SBAS Softkey (displays RAIM (displays SBAS Selection) PREDICTION) Figure 5-105 SBAS Display - Disabled 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 290: Navigating A Flight Plan
2) Figure 5-106 shows the aircraft on the assigned heading of 240º. ‘TERM’ (Terminal) is the current CDI flight phase displayed on the HSI indicating 1.0 nm CDI scaling. Figure 5-106 Assigned Heading of 240º Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 291 290° as seen in Figure 5-107. Figure 5-107 Assigned Heading of 290º 4) Enter V4 into the flight plan. a) Press the FMS Knob to activate the cursor. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 292 Turn the small FMS Knob to display the Waypoint Information Window. Enter the desired entry point for V4, Topeka VOR (TOP), as shown in Figure 5-109. Figure 5-109 Entering V4 Entry Point Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 293 Select the LD AIRWY Softkey to display the list of available airways for TOP as seen in Figure 5-111. Figure 5-111 List of Available Airways for TOP g) Turn either FMS Knob to highlight V4 in the list as seen in Figure 5-111. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 294 Press the ENT Key. The selected airway and exit are displayed, and the prompt “LOAD?” highlighted as in Figure 5-113. Figure 5-113 Ready to Load V4 k) Press the ENT Key. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 295 Select the ACT LEG Softkey. The confirmation window is now displayed as in Figure 5-115. Note the TOP to ULNAZ leg is actually part of V4. Figure 5-115 Comfirm Active Leg 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 296 6) The aircraft continues on heading 290º. When crosstrack distance is less than 2.0 nm, the XTK disappears from the HSI and the CDI is positioned on the last dot indicating a 2.0 nm distance from the centerline of the next course. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 297 8) At SLN, Victor Airway 244 (V244) is intercepted. Turn prompts are displayed in the PFD Navigation Status Box as seen in Figure 5-118. Figure 5-118 Turn to Intercept V244 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 298 FLIGHT MANAGEMENT 9) As seen in Figure 5-119, V244 is now the active flight plan leg. Figure 5-119 V244 Now Active Leg Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 299 Turn the large FMS Knob to select OPSHN in the flight plan list. c) Press the Direct-to ( ) Key. The Direct-to Window is now displayed as shown in Figure 5-121. Figure 5-121 Direct To OPSHN 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 300 OPSHN is entered. In other words, the G1000 gives vertical guidance so the aircraft arrives at an altitude of 10,000 feet three miles prior to OPSHN. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 301 12) The aircraft is proceeding to OPSHN. The expected approach is the RNAV LPV approach to runway 35R, so it is selected. a) Press the PROC Key to display the Procedures Window. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 302 Press the ENT Key. A list of available approaches for the destination airport is displayed as in Figure 5-126. Figure 5-126 List of Available Approaches d) Turn either FMS Knob to select the LPV approach for 35R as shown in Figure 5-126. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 303 To set ‘MINIMUMS’, turn the small FMS Knob to select ‘BARO’, and press the ENT Key. Turn the small FMS Knob to select the altitude, and press the ENT Key. Or : To skip setting minimums, press the ENT Key. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 304 Figure 5-128 Barometric Minimums Set i) With ‘LOAD?’ highlighted, again press the ENT Key. The selected approach is added to the flight plan as seen in Figure 5-129. Figure 5-129 Loaded Approach Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 305 Note that altitude values are now filled in for waypoints back to where the previous altitude value was entered for OPSHN. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 306 FAF and on to the Missed Approach Point (MAP) is given using the WAAS GPS altitude source, therefore, the displayed altitude values are for reference only. Figure 5-132 Vertical Guidance is Active to the FAF Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 307 TOD that results in a -3.0 degree FPA descent to an altitude of 10,000 feet upon reaching the offset waypoint. Figure 5-133 Adjusting the Descent c) Press the ENT Key. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 308 Figure 5-134 Approaching Top of Descent (TOD) Target Altitude Vertical Deviation Indicator (VDI) Required Vertical Speed Indicator (RVSI) Figure 5-135 VDI & RVSI When Approaching Top of Descent (TOD) Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 309 17) When the aircraft is one minute from the bottom of descent (BOD) it is annunciated as shown in Figure 5-137. Upon reaching the offset waypoint for OPSHN, the aircraft is at 10,000 feet. Figure 5-137 Approaching Bottom of Descent (BOD) at OPSHN Offset Waypoint 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 310 PFD as seen in Figure 5-138. Initiate the turn and maneuver the aircraft on a track through the turn radius to intercept the magenta line for the OPSHN to FSHER leg and center the CDI. Figure 5-138 Turn to intercept OPSHN to FSHER Leg Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 311 A descent to HABUK is in the next leg. Note the TOD point on the map. Annunciations for the upcoming turn and descent, as well as the VDI and RVSI, appear on the PFD as the flight progresses. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 312 FLIGHT MANAGEMENT Figure 5-140 Approaching PYNON Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 313 Turn the large FMS Knob to highlight ‘ACTIVATE APPROACH’ as shown in Figure 5-142. c) Press the ENT Key to activate the approach. Figure 5-142 Manually Activate Approach 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 314 22) The IAF is the next waypoint. At the TOD, establish a descent vertical speed as previously discussed in Step 16. The aircraft altitude is 9,000 feet upon reaching HABUK. Figure 5-143 Descending Turn to the Initial Approach Fix (IAF) Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 315 “AT” 7,800 feet at the FAF. Note the altitude restriction lines over and under (At) the altitude in the ‘ALT’ field in Figure 5-143. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 316 Point (MAHP). In this case, the altitude would appear in the list of waypoints as ‘5500ft’. Again, if the aircraft altitude is lower than the prescribed altitude, a direct-to is established on a Course to Altitude leg when the missed approach procedure is activated. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 317 A direct-to is initiated to MOGAL, which is the Missed Approach Hold Point (MAHP) as seen in Figure 5-146. The aircraft is climbing to 10,000 feet. The CDI flight phase now changes from LPV to MAPR as seen on the HSI. Figure 5-146 Missed Approach Active 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 318 Figure 5-147 Establishing the Holding Pattern 27) The aircraft maintains 10,000 feet while following the magenta line through the hold as in Figure 5-148. Figure 5-148 Hold Established Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 319: Abnormal Operation
5-149. Also, while the G1000 is in DR Mode, TAWS, Terrain SVS or Terrain Proximity are disabled. Additionally, the accuracy of all nearest information (airports, airspaces, and waypoints) is questionable. Finally, airspace alerts continue to function, but with degraded accuracy. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 320 The Inset Map is removed from the PFD any time aircraft pitch is greater than +30° or less than –20°, NOTE: or when a 65° bank angle is reached. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 321: Section 6 Hazard Avoidance
This section is divided into the following groups: Weather • GDL 69/69A XM WX Satellite Weather (Optional) • GSR 56 Garmin Flight Data Services (GFDS) Worldwide Weather (Optional) • GWX 68 Airborne Color Weather Radar (Optional) • L-3 STORMSCOPE ® WX-500 Series II Weather Mapping Sensor (Optional) Terrain Avoidance • Terrain Proximity • Terrain-SVS (Standard with SVS Option) • Terrain Awareness and Warning System - Class B (TAWS-B) (Optional) Traffic • TIS (Traffic Information Service) • Garmin GTS 820 Traffic Advisory System (TAS) (Optional) ® • Honeywell KTA 870 TAS (Optional) 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 322: Xm Wx Satellite Weather
4) Verify that the desired services are activated. 5) Press the LOCK Softkey. 6) Turn the large FMS Knob to highlight ‘YES’. 7) To complete activation, press the ENT Key. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 323: Using Xm Wx Products
4) Turn the small FMS Knob to select 'Display XM Weather' and press the ENT Key. The page title will display 'Weather Data Link (XM)' to indicate XM WX is the selected weather datalink source. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 324 Minutes Cloud Tops Weather Product Enabled Icon Figure 6-2 Weather Data Link Page When a weather product is active on the Weather Data Link (XM) Page or the Navigation Map Page, the corresponding product symbol and age of the data are displayed inside a status box (Figure 6-2). The age of the product is based on the time difference between when the data was assembled on the ground and the current GPS time. Weather products are refreshed at specific intervals (defined in the Refresh Rate column in Table 6-1). If for any reason, a weather product is not refreshed within the defined Expiration Time intervals, the data is considered expired and is removed from the display, and the weather product age is replaced by dashes. This ensures that the displayed data is consistent with what is currently being transmitted by XM WX Satellite Weather services. If more than half of the expiration time has elapsed, the color of the product age is displayed in yellow. If a weather product is not available, 'N/A' is displayed instead of the product age. Table 6-1 shows the weather product symbols, the expiration time and the refresh rate. The refresh rate represents the interval at which SiriusXM provides new signals that may or may not contain new weather data. It does not represent the rate at which weather data is updated or new content is received by the Data Link Receiver. Weather data is refreshed at intervals that are defined and controlled by SiriusXM and its weather data suppliers, and are subject to change. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 325 No Radar Coverage no product image (RADAR CVRG) Temporary Flight Restrictions no product image (TFRs) Terminal Aerodrome Reports no product image (TAFs) Table 6-1 Weather Product Symbols and Data Timing 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 326: Xm Lightning (Ltng)
Turbulence (TURB) Radar Coverage TFRs TAFs * Winds Aloft data on Navigation Map Page displayed inside Profile View when enabled. Table 6-2 Weather Product Display Maps (XM WX) Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 327: Weather Softkeys On The Weather Data Link (Xm) Page
Figure 6-3 Weather Data Link Weather Product Softkeys The setup menus for the Navigation Map Page and the Weather Data Link (XM) Page control the map range settings above which weather products data are decluttered from the display. If a map range larger than the weather product map range setting is selected, the weather product data is removed from the map. The menus also provide a means in addition to the softkeys for enabling/disabling display of weather products. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 328 3) With Weather Setup highlighted, press the ENT Key. 4) Press the MENU Key. 5) Highlight the desired default(s) to restore (all or for selection) and press the ENT Key. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 329: Sigmets/Airmets (Sig/Air)
4) Turn the small FMS Knob to select the Weather Group and press the ENT Key (Figure 6-7). 5) Turn the large FMS Knob or press the ENT Key to scroll through product selections (Figure 6-8). 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 330 1) Select the Weather Data Link (XM) Page with the FMS Knob. 2) Select the LEGEND Softkey to display the legends for the displayed weather products. Or : 1) Press the MENU Key. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 331 RANGE Knob. If the map range is adjusted while panning is enabled, the map is re-centered on the Map Pointer. Additional Information on Weather Feature Selected with Map Pointer Flash Flood Warning Selected With Map Pointer Figure 6-9 Panning on the Weather Data Link (XM) Page 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 332 NEXRAD data is not real-time. The lapsed time between collection, processing, and dissemination of NEXRAD images can be significant and may not reflect the current radar synopsis. Due to the inherent delays and the relative age of the data, it should be used for long-range planning purposes only. Never use NEXRAD data or any radar data to penetrate hazardous weather. Instead, use it in an early-warning capacity of pre- departure and enroute evaluation. Figure 6-10 NEXRAD Data on the Weather Data Link Page NEXRAD data can be displayed on the following maps: • PFD Inset Map • Trip Planning Page • Navigation Map Page • Nearest Pages • Weather Data Link Page • Flight Plan Pages • Airport Information Page Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 333 (XM) Page. For the NEXRAD legend, select the LEGEND Softkey when NEXRAD is selected for display. No Radar Coverage Figure 6-11 NEXRAD Data with Legend The display of radar coverage is always active when either NEXRAD or Echo Tops is selected. Areas where NEXRAD radar coverage and Echo Tops information is not currently available or is not being collected are indicated in a gray shade of purple. eFlectivity Reflectivity is the amount of transmitted power returned to the radar receiver. Colors on the NEXRAD display directly correlate to the level of detected reflectivity. Reflectivity as it relates to hazardous weather can be very complex. The role of radar is essentially to detect moisture in the atmosphere. Simply put, certain types of weather reflect radar better than others. The intensity of a radar reflection is not necessarily an indication of the weather hazard level. For instance, wet hail returns a strong radar reflection, while dry hail does not. Both wet and dry hail can be extremely hazardous. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 334 • NEXRAD base reflectivity does not provide sufficient information to determine cloud layers or precipitation characteristics. For example, it is not possible to distinguish between wet snow, wet hail, and rain. • NEXRAD base reflectivity is sampled at the minimum antenna elevation angle. An individual NEXRAD site cannot depict high altitude storms at close ranges. It has no information about storms directly over the site. • When zoomed in to a range of 30 nm, each square block on the display represents an area of four square kilometers. The intensity level reflected by each square represents the highest level of NEXRAD data sampled within the area. • Any unknown precipitation type below 52ºN is displayed as rain. Each block covers an Area of 4 sq. km Figure 6-12 NEXRAD Data - Zoomed Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 335 The following may cause abnormalities in displayed NEXRAD radar images: • Ground clutter • Strobes and spurious radar data • Sun strobes (when the radar antenna points directly at the sun) • Interference from buildings or mountains, which may cause shadows • Metallic dust from military aircraft, which can cause alterations in radar scans neXRaD l imitatiOns anaDa • Radar coverage extends to 55ºN. • Any precipitation displayed between 52ºN and 55ºN is displayed as mixed. º No Coverage Above 55 Precipitation Above 52ºN Appears Mixed Figure 6-13 NEXRAD Data - Canada 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 336 1) Select the Weather Data Link (XM) Page with the FMS Knob. 2) Select the ECHO TOP Softkey. To display the Echo Tops legend, select the LEGEND Softkey when Echo Tops is selected for display. Since Echo Tops and Cloud Tops use the same color scaling to represent altitude, display of these weather products is mutually exclusive. When Echo Tops is activated, NEXRAD and Cloud Tops data are removed. No Radar Coverage Figure 6-15 Echo Tops Legend Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 337 Displaying Cloud Tops information: 1) Select the Weather Data Link (XM) Page with the FMS Knob. 2) Select the CLD TOP Softkey. To display the Cloud Tops legend, select the LEGEND Softkey when Cloud Tops is selected for display. Since Cloud Tops and Echo Tops use the same color scaling to represent altitude, display of these weather products is mutually exclusive. When Cloud Tops is activated, Echo Tops data is removed. Figure 6-17 Cloud Tops Legend 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 338 1) Select the MAP Softkey (for the PFD Inset Map, select the INSET Softkey). This step is not necessary on the Weather Data Link (XM) Page. 2) Select the XM LTNG Softkey. To display the XM Lightning legend on the Weather Data Link (XM) Page, select the LEGEND Softkey when XM Lightning is selected for display. Figure 6-19 Lightning Legend Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 339 Weather Data Link (XM) Page, Cell Movement must be turned on in the Navigation Map Setup Menu (see “Setting up and customizing weather data for the Navigation Map Page"). To display the Cell Movement legend on the Weather Data Link (XM) Page, select the LEGEND Softkey when Cell Movement is selected for display. Figure 6-21 Cell Movement Legend 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 340 4) Press the ENT key. The figure below shows a sample of SIGMET text. To display the SIGMET and AIRMET legend, select the LEGEND Softkey when SIGMETs and AIRMETs are selected for display. Sample SIGMET Text SIGMET/AIRMET Legend Figure 6-23 SIGMET/AIRMET Text and Legend Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 341 Displaying METAR and TAF text: 1) On the Weather Data Link (XM) Page, select the METAR Softkey 2) Select the RANGE Knob and pan to the desired airport. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 342 TAF text. Decoded METAR Text METAR Raw METAR Symbol Text Raw TAF Text Figure 6-25 METAR and TAF with Text Raw METAR text is also accessible while panning the map cursor over a METAR flag on any map page on which a METAR is displayed. The METAR text is shown in a box near the METAR flag. In addition, METAR flags and their associated text are displayed on the Active Flight Plan Page on the MFD. METAR flags appears next to waypoints in the flight plan with an associated METAR. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 343 4) When finished, press the FMS Knob to remove the cursor or press the FPL Key to exit the Active Flight Plan Page. To display the METAR legend on the Weather Data Link (XM) Page, select the LEGEND Softkey when METARs are selected for display. The METAR flag color is determined by the information in the METAR text. The METAR flag is gray when the METAR text does not contain adequate information. Figure 6-26 METAR Legend 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 344 3) Select the SFC Softkey. 4) Select the forecast time: CURRENT, 12 HR, 24 HR, 36 HR, or 48 HR. The SFC Softkey label changes to indicate selected the forecast time. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 345 HAZARD AVOIDANCE To display the Surface Analysis and City Forecast legend, select the LEGEND Softkey when Surface Analysis and City Forecast are selected for display. Figure 6-28 Surface Analysis and City Forecast Legend 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 346 1) Select the Weather Data Link (XM) Page with the FMS Knob. 2) Select the MORE WX Softkey. 3) Select the FRZ LVL Softkey. To display the Freezing Level legend (Figure 6-30), select the LEGEND Softkey when Freezing Level data is selected to be displayed. Figure 6-30 Freezing Level Legend Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 347: Winds Aloft
The WIND Softkey label changes to reflect the altitude selected. Figure 6-31 Winds Aloft at 24,000 Feet Figure 6-32 Winds Aloft Data with Legend Headwind and tailwind components aloft are available inside the Profile View on the Navigation Map Page (Figure 6-33). The displayed components are relative to current aircraft altitude and track, but not to aircraft speed. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 348: (Wind)
Table 6-4 Profile View Headwind/Tailwind Component Symbols Showing/Hiding Profile View (containing winds aloft data) 1) Select the Navigation Map Page. 2) Select the PROFILE Softkey. 1) Press the MENU Key. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 349 Figure 6-34 Navigation Map Page Menu Figure 6-35 Navigation Map Page Setup Menu Figure 6-36 Navigation Map Page Setup Menu, Weather Group To display the Winds Aloft legend (Figure 6-37), select the LEGEND Softkey when Winds Aloft is selected for display. Figure 6-37 Winds Aloft Data with Legend 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 350: County Warnings
1) Select the Weather Data Link (XM) Page with the FMS Knob. 2) Select the MORE WX Softkey. 3) Select the COUNTY Softkey. To display the County Warnings legend (Figure 6-39), select the LEGEND Softkey when County Warnings are selected to be displayed. Figure 6-39 County Warnings Legend Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 351: Cyclone
1) Select the Weather Data Link (XM) Page with the FMS Knob. 2) Select the MORE WX Softkey. 3) Select the CYCLONE Softkey. To display the Cyclone legend (Figure 6-41), select the LEGEND Softkey when Cyclones are selected to be displayed. Figure 6-41 Cyclone Legend 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 352: Icing Potential (Cip And Sld) (Icng)
The ICNG Softkey label changes to reflect the altitude selected. Icing Potential Supercooled Large Droplet threat Figure 6-42 Icing Data at 24,000 Feet To display the Icing Potential legend (Figure 6-43), select the LEGEND Softkey when Icing is selected for display. Figure 6-43 Icing Potential Legend Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 353 The TURB Softkey label changes to reflect the altitude selected. Light Turbulence Moderate Turbulence Figure 6-44 Turbulence Data at 27,000 Feet To display the Turbulence legend (Figure 6-45), select the LEGEND Softkey when Turbulence is selected for display. Figure 6-45 Turbulence Legend 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 354 6) Use the FMS Knob or the ENT Key to scroll through the PIREP or AIREP text. 7) Press the FMS Knob or the CLR Key to return to the Weather Data Link Page. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 355 Figure 6-48 AIREPs & PIREPs Legend TFRS The FAA issues Temporary Flight Restrictions (TFRs) to designate areas where flight is restricted. TFRs are issued to restrict flight for a variety of reasons including national security, law enforcement, firefighting, natural disasters., airshows, and large sporting events. TFRs may be issued at any time, and TFR data displayed on the G1000 is only intended to supplement official TFR information obtained from Flight Service Stations (FSS), and air traffic control. The age of TFR data is not shown; however, if TFR data is not available or has expired, the system displays 'TFR N/A' in the upper-left corner of maps on which TFRs can be displayed. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 356 4) If necessary, turn the FMS Knob to select 'Review Airspaces' and press the ENT Key. The system displays the TFR Information window. 5) Press the FMS Knob or the CLR Key to remove the TFR Information window. Figure 6-50 Full Text for Selected TFR Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 357 8) Press the FMS Knob or CLR Key to return to the Navigation Map Page with the changed settings. Figure 6-51 Navigation Map Page Menu Figure 6-53 Navigation Map Page Setup Menu, Weather Group Figure 6-52 Navigation Map Page Setup Menu 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 358: Gfds Worldwide Weather
Weather Data Link (GFDS) Page’ procedure to change the datalink source to GFDS prior to registration. 3) If the system displays the ‘Garmin Flight Data Service Registration’ window, proceed to step 7. Otherwise, press the MENU Key. The Page Menu window is now displayed as seen in Figure 6-54.
Page 359 Figure 6-54 Select Register With GFDS 5) Turn the large FMS Knob to select ‘Register With GFDS’ in the menu list. 6) Press the ENT Key. The Garmin Flight Data Service Registration window is displayed as shown in Figure 6-55. Figure 6-55 Enter Access Code 190-00709-04 Rev.
Page 360 7) Enter the access code provided by Garmin Flight Data Services in the ACCESS CODE field. 8) Press the ENT Key. ‘REGISTER’ will now be highlighted as in Figure 6-55. 9) Press the ENT Key. The system will contact Garmin Flight Data Services. System registration is complete when ‘REGISTERED’ is displayed in the STATUS field.
Page 361: Pilot Weather Report (Pireps)
Canadian radar precipitation data provided by Environment Canada. † ˆ Australian radar precipitation data provided by the Australian Bureau of Meteorology. Table 6-5 GFDS Weather Product Symbols and Data Timing 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 362 Radar Coverage TFRs TAFs * Winds Aloft data on Navigation Map Page displayed inside Profile View when enabled. Table 6-6 GFDS Weather Product Display Maps Softkeys control the display of weather information on most MFD pages and the PFD Inset Map (Figure 6-57 shows the weather product softkeys for the Weather Data Link (GFDS) Page). When a weather product is selected for display, the corresponding softkey label changes to gray to indicate the product display is enabled. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 363 7) Press the ENT Key to select an option. 8) Press the FMS Knob or CLR Key to return to the Weather Data Link (GFDS) Page with the changed settings. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 364 3) Press the MENU Key. 4) Turn the large FMS Knob to select ‘Display GFDS Weather’ or ‘Display XM’ Weather’ (choice dependent on current weather source) and press the ENT Key. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 365 7) Press the ENT Key to select an option. 8) Press the FMS Knob or CLR Key to return to the Navigation Map Page with the changed settings. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 366 2) Press the WX LGND Softkey. 3) To remove the weather product information box, press the WX LGND Softkey again or deselect all active GFDS weather products on the PFD Inset Map. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 367: Gfds Weather Data Requests
GFDS WEATHER DATA REQUESTS The GFDS Data Request window provides the flight crew with the options to enable or disable the requested weather coverage area(s), choose automatic weather update intervals (if desired), and the ability to send or cancel weather data requests. The status of the GFDS data request process is also displayed. Before a GFDS data request can occur, a valid request coverage area must be defined from which all currently available GFDS weather products will be retrieved. At a minimum, either the aircraft’ s present position or a waypoint (as part of a flight plan or entered directly in the ‘WAYPOINT’ coverage field) must be part of the request coverage area, otherwise the request status window will indicate ‘INVALID COVERAGE AREA’ and the system will not allow a request to occur. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 368 6) Turn the large FMS Knob until the ‘SEND REQ’ button is highlighted. Press the ENT Key to initiate the request immediately or press the FMS Knob to return to the Weather Data Link (GFDS) Page without requesting weather data. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 369 HAZARD AVOIDANCE Figure 6-64 Weather Data Link (GFDS) Page Menu Figure 6-65 GFDS Data Request Window 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 370 GFDS Data Request, regardless of which products (if any) are currently enabled for display. On subsequent requests, previously retrieved textual data (such as METARs and TAFS) is retained if it has not expired, while new textual weather data matching the current coverage area and all graphical weather data is downloaded during every data request. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 371 Press the ENT Key to immediately send an immediate GFDS Data Request. Or : Press the FMS Knob to return to the Weather Data Link (GFDS) Page. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 372: Worldwide Weather Products
Weather Data Link (GFDS) Page. 2) Press the PRECIP Softkey. Radar data shown represents highest level, composite reflectivity, of radar returns. The display of the information is color-coded to indicate the weather severity level. All weather product legends can be viewed on the Weather Data Link (GFDS) Page. For the Precipitation legend (Figure 6-68), select the LEGEND Softkey when Precipitation is selected for display. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 373 ReciPitatiOn imitatiOns Radar images may have certain limitations: • Radar composite reflectivity does not provide sufficient information to determine precipitation characteristics (wet hail vs. rain). For example, it is not possible to distinguish between wet snow, wet hail, and rain. • The radar beam may overshoot precipitation occurring below the lowest antenna beam tilt angle (0.5°), causing no precipitation to be displayed. An individual radar site cannot depict high altitude storms at close ranges. It has no information about storms directly over the radar site. • When zoomed in to a range of 30 nm, each square block on the display represents an area of four square kilometers. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 374 HAZARD AVOIDANCE Block represents 4 km Figure 6-69 Precipitation Data - Zoomed The following may cause abnormalities in displayed radar images: • Ground clutter • Strobes and spurious radar data • Sun strobes (when the radar antenna points directly at the sun) • Interference from buildings or mountains, which may cause shadows • Metallic dust from military aircraft, which can cause alterations in radar scans Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 375 Displaying Cloud Tops information: 1) Select the Weather Data Link (GFDS) Page. 2) Press the IR SAT Softkey. To display the Infrared Satellite legend (Figure 6-71), select the LEGEND Softkey when Infrared Satellite data is selected for display. Figure 6-71 Infrared Satellite Legend 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 376 1) Press the MAP Softkey (for the PFD Inset Map, select the INSET Softkey). This step is not necessary on the Weather Data Link (GFDS) Page. 2) Press the DL LTNG Softkey. To display the Datalink Lightning legend on the Weather Data Link (GFDS) Page (Figure 6-73), select the LEGEND Softkey when Datalink Lightning is selected for display. Figure 6-73 Datalink Lightning Legend Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 377 3) To view the text of the SIGMET or AIRMET, press the RANGE Knob and move the Map Pointer over the icon. 4) Press the ENT key. Figure 6-75 shows sample SIGMET text. To display the SIGMET and AIRMET legend (Figure 6-76), select the LEGEND Softkey when SIGMETs and AIRMETs are selected for display. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 378 METARs are shown as colored flags at airports that provide them. Instructions for Viewing METAR and TAF Text Selected Airport Figure 6-77 METAR Flags on the Weather Data Link (GFDS) Page Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 379 4) Use the FMS Knob or the ENT Key to scroll through the METAR and TAF text. Note that the METAR text must be completely scrolled through before scrolling through the TAF text. METAR Text METAR Symbol Text Figure 6-78 METAR and TAF Text 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 380 4) Select the desired altitude level: SFC (surface) up to 42,000 feet. Select the NEXT or PREV Softkey to cycle through the altitude softkeys. The WIND Softkey label changes to reflect the altitude selected. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 381 HAZARD AVOIDANCE Figure 6-80 Winds Aloft at 24,000 Feet To display the Winds Aloft legend (Figure 6-81), select the LEGEND Softkey when Winds Aloft is selected for display. Figure 6-81 Winds Aloft Data with Legend Headwind and tailwind components aloft are available inside the Profile View on the Navigation Map Page (Figure 6-82). The displayed components are relative to current aircraft altitude and track, but not to aircraft speed. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 382 Figure 6-82 Navigation Map Page with Winds Aloft Data on Profile View Arrows pointing to the left indicate headwind components; tailwind component arrows point to the right, as shown in Table 6-8. Headwind Tailwind Headwind/Tailwind Symbol Symbol Component None None Less than 5 knots 5 knots 10 knots 50 knots Table 6-8 Profile View Headwind/Tailwind Component Symbols Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 383 7) Press the FMS Knob or CLR Key to return to the Navigation Map Page with the changed settings. Figure 6-83 Navigation Map Page Menu Figure 6-84 Navigation Map Page Setup Menu Figure 6-85 Navigation Map Page Setup Menu, Weather Group 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 384 6) Use the FMS Knob or the ENT Key to scroll through the PIREP text. 7) Press the FMS Knob or the CLR Key to close the PIREP text window and return to the Weather Data Link (GFDS) Page. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 385 The PIREP color is determined by the type (routine or urgent). Figure 6-88 PIREPs Legend TFRS Temporary Flight Restriction (TFR) data from GFDS is only available in the United States (not NOTE: including any U.S. territories.) Refer to fly.garmin.com/fly-garmin/gfds-weather for GFDS product coverage information. In the United States, the FAA issues Temporary Flight Restrictions (TFRs) to designate areas where flight is restricted. TFRs are issued to restrict flight for a variety of reasons including national security, law enforcement, firefighting, natural disasters., airshows, and large sporting events. TFRs may be issued at any time, and TFR data displayed on the G1000 is only intended to supplement official TFR information obtained from Flight Service Stations (FSS), and air traffic control.
Page 386 4) If necessary, turn the FMS Knob to select 'Review Airspaces' and press the ENT Key. The system displays the TFR Information window. 5) Press the FMS Knob or the CLR Key to remove the TFR Information window. Figure 6-90 Full Text for Selected TFR Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 387 8) Press the FMS Knob or CLR Key to return to the Navigation Map Page with the changed settings. Figure 6-91 Navigation Map Page Menu Figure 6-93 Navigation Map Page Setup Menu, Weather Group Figure 6-92 Navigation Map Page Setup Menu 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 388: Abnormal Operations
A server error has occurred or invalid data received. GFDS Login Invalid There is a problem with the GFDS registration. Contact Garmin Flight Data Services at 1-866-739- 5687 in the United States or 913-397-8200, ext. 1135 for assistance. GFDS Server...
Page 389 HAZARD AVOIDANCE WORLDWIDE WEATHER IN REVERSIONARY MODE When the G1000 is operating in Reversionary Mode, only those weather products which can be displayed on the PFD Inset map will be available for display (see Table 6-6 for a list of weather products and their associated map availability). If manual weather data requests were enabled prior to entering Reversionary Mode, no new GFDS weather data can be retrieved while operating in Reversionary Mode. If automatic weather data requests were enabled prior to Reversionary Mode operation, the system will continue the automatic data requests in Reversionary Mode (provided automatic requests have not been inhibited due to a system error). 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 390: Airborne Color Weather Radar
PRINCIPLES OF PULSED AIRBORNE WEATHER RADAR The term RADAR is an acronym for RAdio Detecting And Ranging. Pulsed radar locates targets by transmitting a microwave pulse beam that, upon encountering a target, is reflected back to the radar receiver as a return echo. The microwave pulses are focused and radiated by the antenna, with the most intense energy in the center of the beam and decreasing intensity near the edge. The same antenna is used for both transmitting and receiving. The returned signal is then processed and displayed on the G1000 MFD. Radar detection is a two-way process that requires 12.36 µs for the transmitted microwave pulses to travel out and back for each nautical mile of target range. It takes 123.6 µs for a transmitted pulse to make the round trip if a target is ten nautical miles away. Airborne weather radar should be used to avoid severe weather, not for penetrating severe weather. The decision to fly into an area of radar targets depends on target intensity, spacing between the targets, aircraft capabilities, and pilot experience. Pulse type weather radar detects only precipitation, not clouds or turbulence. The display may indicate clear areas between intense returns, but this does not necessarily mean it is safe to fly between them. Only Doppler radar can detect turbulence. Airborne weather radar has other capabilities beyond weather detection. It also has the ability to detect and provide distance to cities, mountains, coastlines, rivers, lakes, and oceans. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 391 Range (nautical miles) Figure 6-94 Radar Beam from a 10 inch Antenna The curvature of the earth can also be a factor in missing areas of precipitation, especially at range settings of 150 nautical miles or more. Here the beam overshoots the precipitation at less than 320 nautical miles. 320 nm Figure 6-95 Radar Beam in Relation to the Curvature of the Earth 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 392 RADAR SIGNAL REFLECTIVITY ReciPitatiOn Precipitation or objects more dense than water, such as the surface of the earth or solid structures, are detected by the weather radar. The weather radar does not detect clouds, thunderstorms, or turbulence directly. It detects precipitation associated with clouds, thunderstorms, and turbulence. The best radar signal reflectors are raindrops, wet snow, or wet hail. The larger the raindrop, the better the reflectivity. The size of the precipitation droplet is the most important factor in radar reflectivity. Because large drops in a small concentrated area are characteristic of a severe thunderstorm, the radar displays the storm as a strong return. Ice crystals, dry snow, and dry hail have low levels of reflectivity as shown in the illustration, and often is not displayed by the radar. Additionally, a cloud that contains only small raindrops, such as fog or drizzle, does not reflect enough radar energy to produce a measurable target return. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 393 Mountains also provide strong return signals to the antenna, but also block the areas behind. However, over mountainous terrain, the radar beam can be reflected back and forth in the mountain passes or off canyon walls, using up all or most of the radar energy. In this case, no return signal is received from this area, causing the display to show a dark spot which could indicate a pass where no pass exists. ngle OF nciDence The angle at which the radar beam strikes the target is called the Angle of Incidence. The figure illustrates the incident angle (‘A’). This directly affects the detectable range, the area of illumination, and the intensity of the displayed target returns. A large incident angle gives the radar system a smaller detectable range and lower display intensity due to minimized reflection of the radar energy. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 394: Safe Operating Distance
The following information establishes a minimum safe distance from the antenna for personnel near operating weather radar. The minimum safe distance is based on the FCC’ s exposure limit at 9.3 to 9.5 GHz for general population/uncontrolled environments, which is 1 mW/cm2. See Advisory Circular 20-68B for more information on safe distance determination. MAXIMUM PERMISSIBLE EXPOSURE LEVEL (MPEL) The zone in which the radiation level exceeds the US Government standard of 1 mW/cm2 is the semicircular area of at least 9.16 feet from the 10-inch antenna. All personnel must remain outside of this zone. With a scanning or rotating beam, the averaged power density at the MPEL boundary is significantly reduced. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 395: Basic Antenna Tilt Setup
The following discussion is a simple method for setting up the weather radar antenna tilt for most situations. It is not to be considered an all encompassing setup that works in all situations, but this method does provide good overall parameters for the monitoring of threats. Ultimately, it is desired to have the antenna tilted so that the bottom of the radar beam is four degrees below parallel with the ground. The following example explains one way of achieving this. With the aircraft flying level, adjust the antenna tilt so ground returns are displayed at a distance that equals the aircraft’ s current altitude (AGL) divided by 1,000. For example, if the aircraft is at 14,000 feet, adjust the tilt so the front edge of ground returns are displayed at 14 nautical miles. Note this antenna tilt angle setting. Now, raise the antenna tilt 6 degrees above this setting. The bottom of the radar beam is now angled down 4º from parallel with the ground. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 396 Figure 6-99 Vertical Change in Radar Beam per Nautical Mile Therefore, with the antenna tilt set so that the bottom of the beam is four degrees below parallel with the ground, a target return at 10 nm is approximately 4,000 feet below the aircraft; at 20 nm, 8,000 feet; at 50 nm, 20,000 feet. In other words, at this tilt setting, a ground return (such as a mountain peak) being displayed at 10 nm would have a maximum distance below the aircraft of 4,000 feet. When that ground target return moves to 5 nm, the maximum distance below the aircraft is 2,000 feet. This setup provides a good starting point for practical use of the GWX 68. There are many other factors to consider in order to become proficient at using weather radar in all situations. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 397: Weather Mapping And Interpretation
41 dBZ to < 50 dBZ 0.5 - 2 Magenta 50 dBZ and greater > 2 Table 6-10 Precipitation Intensity Levels hUnDeRstORms Updrafts and downdrafts in thunderstorms carry water through the cloud. The more severe the drafts, the greater the number and size of the precipitation droplets. With this in mind, the following interpretations can be made from what is displayed on the weather radar. Avoid these areas by an extra wide margin. • In areas where the displayed target intensity is red or magenta (indicating large amounts of precipitation), the turbulence is considered severe. • Areas that show steep color gradients (intense color changes) over thin bands or short distances suggest irregular rainfall rate and strong turbulence. • A reas that show red or magenta are associated with hail or turbulence, as well as heavy precipitation. Vertical scanning and antenna tilt management may be necessary to identify areas of maximum intensity. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 398 Targets showing wide areas of green are generally precipitation without severe turbulence. Irregularities in the target return may also indicate turbulence, appearing as hooks, fingers, or scalloped edges. These irregularities may be present in green areas with no yellow, red, or magenta areas and should be treated as highly dangerous areas. Avoid these areas as if they are red or magenta. Squall Line Steep Gradient Hook or Finger Scalloped Edge Figure 6-100 Cell Irregularities Thunderstorm development is rapid. A course may become blocked within a short time. When displaying shorter ranges, periodically select a longer range to see if problems are developing further out. That can help prevent getting trapped in a blind alley or an area that is closed at one end by convective weather. Figure 6-101 The Blind Alley - Horizontal Scan Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 399 Hail results from updrafts carrying water high enough to freeze. Therefore, the higher the top of a thunderstorm, the greater the probability that it contains hail. Vertically scanning the target return can give the radar top of a thunderstorm that contains hail. Radar top is the top of a storm cell as detected by radar. It is not the actual top, or true top of the storm. The actual top of a storm cell is seen with the eyes in clear air and may be much higher than the radar top. The actual top does not indicate the top of the hazardous area. Hail can fall below the minimum reflectivity threshold for radar detection. It can have a film of water on its surface, making its reflective characteristics similar to a very large water droplet. Because of this film of water, and because hail stones usually are larger than water droplets, thunderstorms with large amounts of wet hail return stronger signals than those with rain. Some hail shafts are extremely narrow (100 yards or less) and make poor radar targets. In the upper regions of a cell where ice particles are dry (no liquid coating), target returns are less intense. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 400 In Reversionary mode, the weather radar system automatically switches to Standby mode. The system remains in Standby mode until both displays are restored. In Reversionary mode, the weather radar system cannot be controlled. Radar Mode Scan Line Antenna Stabilization Status Figure 6-103 Horizontal Scan Display Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 401 4) Turn the RANGE Knob to select the desired map range. 5) The horizontal scan is initially displayed (Figure 6-103). If desired, select the VERTICAL Softkey to change to vertical scanning. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 402 8) To select a new area to be vertically scanned, select the HORIZON Softkey to return to the Horizontal Scan view and repeat the previous steps. The RANGE Knob can also be used to adjust bearing from left to right. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 403 2) Turn the small FMS Knob to select the desired antenna tilt angle. 3) Press the ENT Key. 4) Press the FMS Knob to remove the cursor. The RANGE Knob can also be used to adjust tilt up and down. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 404 2) Turn the small FMS Knob to adjust the antenna tilt angle. The selected tilt angle is implemented when Horizontal Scan is again selected. The RANGE Knob can also be used to adjust tilt. Tilt Line Scan Line Figure 6-107 Adjusting Tilt on Vertical Scan Display Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 405 4) Select the GAIN Softkey again to recalibrate the gain. CALIBRATED is displayed in the GAIN field. Manual Gain Set Below Calibrated Calibrated Gain Figure 6-108 Gain Calibration 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 406 6) If desired, readjust the Bearing Line as discussed previously to change the center of the Sector Scan. 7) Select the BRG Softkey again to remove the Bearing Line and cursor. The bearing reference is also reset to 0º. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 407 2) Select the STAB ON Softkey to activate antenna stabilization or select the STAB OFF Softkey to deactivate. The current stabilization condition is shown in the upper right of the weather radar display. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 408 Displayed intensity is questionable. Areas of Potentially stronger than displayed. Attenuated Signal ® ® Horizontal Scan Without WATCH Horizontal Scan With WATCH Figure 6-111 Horizontal Scan Without and With WATCH™ Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 409 If a Weather Alert is detected within ±10° of the aircraft heading, an alert is displayed on the PFD in the Messages Window. If the antenna tilt is adjusted too low, a weather alert can be generated by ground returns. To avoid unwanted weather alerts, deselect the WX ALRT Softkey.. Weather Alerts Figure 6-112 Weather Alert Indications To activate or deactivate Weather Alerts, select the WX ALRT Softkey. Activating and deactivating also enables or inhibits the alert on the PFD. Figure 6-113 Weather Alert on PFD 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 410 6) Adjust the antenna tilt angle by turning the small FMS Knob to display ground returns at the desired distance. 7) Press the FMS Knob to remove the cursor. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 411: Stormscope
5) When an item is highlighted, turn the small FMS Knob to select the option. 6) Press the ENT Key. 7) Press the FMS Knob to return to the Navigation Map Page (Figure 6-116). 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 412 HAZARD AVOIDANCE The following Stormscope options are available (Figure 6-115): • STRMSCP LTNG – Turns the display of Stormscope data on or off. • STRMSCP MODE – Selects the CELL or STRIKE mode of lightning activity. Cell mode identifies clusters or cells of electrical activity. Strike mode indicates the approximate location of lightning strikes. • STRMSCP SMBL – Selects the range at which Stormscope data displays. Stormscope data is removed when a map range greater than the STRMSCP SMBL value is selected. Figure 6-114 Page Menu Figure 6-115 Map Setup Menu Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 413 7) Press the FMS knob to return to the Navigation Map Page. Stormscope Icon 80 nm Map Range Figure 6-116 Navigation Map Page with Stormscope Lightning Data If heading input is lost, strikes and/or cells must be cleared manually after the execution of each turn. This is to ensure that the strike and/or cell positions are depicted accurately in relation to the nose of the aircraft. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 414 6) Turn the small FMS Knob to select the maximum display range. 7) Press the ENT Key. 8) Press the FMS Knob to return to the Navigation Map Page. To change the display range on the Navigation Map Page, turn the RANGE Knob clockwise to zoom out or counter-clockwise to zoom in. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 415: Selecting The Stormscope Page
2) Turn the small FMS Knob to select the Stormscope Page. 3) To change the map range, turn the RANGE Knob clockwise to zoom out or counter-clockwise to zoom in. Figure 6-118 Stormscope Page 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 416 3) Select ‘Clear Lightning Data’. 4) Press the ENT Key. Or : 1) Select the Stormscope Page. 2) Select the CLEAR Softkey. Figure 6-119 Stormscope Page Options Menu Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 417 2) Press the MENU Key. 3) Turn the small FMS Knob to choose between ‘View Arc’ and ‘View 360˚ options. 4) When an item is selected, press the ENT Key. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 418: Terrain Proximity
Terrain Proximity requires the following components to operate properly: • Valid 3-D GPS position • Valid terrain/obstacle database Terrain Proximity displays altitudes of terrain and obstructions relative to the aircraft position and altitude with reference to a database that may contain inaccuracies. Terrain and obstructions are shown only if they are in the database. Terrain and obstacle information should be used as an aid to situational awareness. They should never be used to navigate or maneuver around terrain. Note that all obstructions may not be available in the terrain and obstacle database. No terrain and obstacle information is shown without a valid 3-D GPS position. The G1000 GPS receiver provides the horizontal position and altitude. GPS altitude is derived from satellite position. GPS altitude is then converted to the height above geodetic sea level (GSL), which is the height above mean sea level calculated geometrically. GSL altitude is used to determine terrain and obstacle proximity. GSL altitude accuracy is affected by satellite geometry, but is not subject to variations in pressure and temperature that normally affect pressure altitude sensors. GSL altitude does not require local altimeter settings to determine MSL altitude. It is a widely-used MSL altitude source. Terrain and obstacle databases are referenced to GSL. Using the GPS position and altitude, the Terrain Proximity feature portrays a 2-D picture of the surrounding terrain and obstacles relative to the position and altitude of the aircraft. GPS position and GSL altitude are used to calculate and predict the aircraft’ s flight path in relation to the surrounding terrain and obstacles. In this way, the pilot can view predicted dangerous terrain and obstacle conditions. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 419: Displaying Terrain Proximity Data
1) Select the MAP Softkey (for the PFD Inset Map, select the INSET Softkey). 2) Select the TERRAIN Softkey to display terrain and obstacle data. When Terrain Proximity is selected on maps other than the Terrain Proximity Page, an icon to indicate the feature is enabled for display and a legend for Terrain Proximity colors are shown (Figure 6-124). The Navigation Map Page Setup Menu provides a means in addition to the softkey for enabling/disabling display of terrain and obstacles. The setup menu also controls the map range settings above which terrain and obstacle data are decluttered from the display. If a map range larger than the map range setting is selected, the data is removed from the map. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 420 8) Press the FMS Knob or CLR Key to return to the Navigation Map Page with the changed settings. Figure 6-121 Navigation Map Page Menu Figure 6-122 Navigation Map Page Setup Menu Figure 6-123 Navigation Map Page Setup Menu, Map Group Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 421: Terrain Proximity Page
Or : a) Press the MENU Key. b) Select ‘View Arc’ or ‘View 360º’ (choice dependent on current state) and press the ENT Key to change the view. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 422 (Above or Within 100’ Below the Aircraft Altitude) Map Range Arcs Black Terrain (Terrain More than 1000’ Below the Aircraft Altitude) Terrain Legend Figure 6-126 Terrain Proximity Page (ARC View) Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 423: Terrain-Svs
• Valid 3-D GPS position • Valid terrain/obstacle database Terrain-SVS displays altitudes of terrain and obstructions relative to the aircraft position and altitude with reference to a database that may contain inaccuracies. Terrain and obstructions are shown only if they are in the database. Terrain and obstacle information should be used as an aid to situational awareness. They should never be used to navigate or maneuver around terrain. Note that all obstructions may not be available in the terrain and obstacle database. No terrain and obstacle information is shown without a valid 3-D GPS position. The G1000 GPS receiver provides the horizontal position and altitude. GPS altitude is derived from satellite position. GPS altitude is then converted to the height above geodetic sea level (GSL), which is the height above mean sea level calculated geometrically. GSL altitude is used to determine terrain and obstacle proximity. GSL altitude accuracy is affected by satellite geometry, but is not subject to variations in pressure and temperature that normally affect pressure altitude sensors. GSL altitude does not require local altimeter settings to determine MSL altitude. It is a widely-used MSL altitude source. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 424: Displaying Terrain-Svs Data
1000 ft below the aircraft altitude Table 6-14 Terrain-SVS Obstacle Colors and Symbology Potential Impact Alert Type Example Annunciation Point Symbol Warning Caution Table 6-15 Terrain-SVS Potential Impact Point Symbols with Alert Types Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 425 7) Press the ENT Key to select an option. 8) Press the FMS Knob or CLR Key to return to the Navigation Map Page with the changed settings. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 426: Terrain-Svs Page
2) Select the 360 or ARC Softkey to select the desired view. Or : 1) Press the MENU Key. 2) Select ‘View Arc’ or ‘View 360º’, dependent on current state, and press the ENT Key to change the view. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 427 (Above or Within 100’ Map Range Arc Below the Aircraft Altitude) Black Terrain (More than 1000’ Below Terrain Legend the Aircraft Altitude) Annunciation Window Figure 6-132 Terrain-SVS Page, ARC View 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 428: Terrain-Svs Alerts
HAZARD AVOIDANCE TERRAIN-SVS ALERTS Alerts are issued when flight conditions meet parameters that are set within Terrain-SVS software algorithms. Terrain-SVS alerts typically employ a CAUTION or a WARNING alert severity level, or both. When an alert is issued, visual annunciations are displayed and aural alerts are simultaneously issued. Table 6-16 shows Terrain- SVS alert types with corresponding annunciations and aural messages. When an alert is issued, annunciations appear on the PFD and MFD. The Terrain-SVS Alert Annunciation is shown to the upper left of the Altimeter on the PFD and below the Terrain Legend on the MFD. If the Terrain- SVS Page is not displayed at the time, a pop-up alert appears on the MFD. To acknowledge the pop-up alert: • Press the CLR Key (returns to the currently viewed page), or • Press the ENT Key (accesses the Terrain-SVS Page) Alert Annunciation Potential Impact Point Figure 6-133 Alert Annunciation on the PFD Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 429 HAZARD AVOIDANCE Figure 6-134 Alert Pop-up on the MFD Potential Impact Points Alert Annunciation Figure 6-135 Terrain-SVS Alert Annunciation on the MFD 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 430 “Caution; Obstacle, Obstacle” Caution (ROC) Imminent Obstacle Impact Caution (IOI) “Caution; Obstacle, Obstacle” * Annunciation is displayed on the MFD when terrain display is enabled. Table 6-16 Terrain-SVS Alerts Summary Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 431 Required Clearance Level (FT) Descending (FT) Distance From Runway (NM) Distance From Runway (NM) Figure 6-137 FLTA Alert Minimum Terrain and Obstacle Clearance Values FLTA alerts are automatically inhibited when the aircraft is less than 200 feet above the destination runway elevation while within 0.5 nm of the approach runway or the aircraft is between runway ends. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 432: System Status
“Terrain System Not Available” area “Terrain System Available” when aircraft re-enters coverage area * Annunciation is displayed on the MFD when terrain display is enabled. Table 6-18 Terrain-SVS Status Annunciations Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 433: Taws-B
Terrain data is not displayed when the aircraft is outside of the terrain database coverage area. NOTE: The data contained in the TAWS databases comes from government agencies. Garmin accurately NOTE: processes and cross-validates the data but cannot guarantee the accuracy and completeness of the data.
Page 434: Displaying Taws-B Data
1000 ft below the aircraft altitude Table 6-19 TAWS-B Obstacle Colors and Symbology Potential Impact Alert Type Example Annunciation Point Symbol Warning Caution Table 6-20 TAWS-B Potential Impact Point Symbols with Alert Types Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 435 4) Turn the small FMS Knob to select the ‘Map’ Group and press the ENT Key (Figure 6-141). 5) Turn the large FMS Knob or press the ENT Key to scroll through product selections (Figure 6-142). 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 436 Map range is adjustable with the RANGE Knob from 1 to 200 nm, as indicated by the map range rings (or arcs). Displaying the TAWS-B Page: 1) Turn the large FMS Knob to select the Map Page Group. 2) Turn the small FMS Knob to select the TAWS-B Page. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 437 Yellow Terrain (Between 100’ and 1000’ Below the Aircraft Altitude) Black Terrain (More than 1000’ Below the Aircraft Altitude) Terrain Legend Annunciation Window Figure 6-143 TAWS-B Page, 360º View 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 438: Taws-B Alerts
TAWS-B alerts typically employ a CAUTION or a WARNING alert severity level, or both. When an alert is issued, visual annunciations are displayed and aural alerts are simultaneously issued. Table 6-21 shows TAWS-B alert types with corresponding annunciations and aural messages. When an alert is issued, annunciations appear on the PFD and MFD. The TAWS-B Alert Annunciation is shown to the upper left of the Altimeter on the PFD and below the Terrain Legend on the MFD. If the TAWS-B Page is not displayed at the time, a pop-up alert appears on the MFD. To acknowledge the pop-up alert: • Press the CLR Key (returns to the currently viewed page), or • Press the ENT Key (accesses the TAWS-B Page) Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 439 HAZARD AVOIDANCE Potential Impact Points Alert Annunciation Figure 6-145 TAWS-B TERRAIN Alert Annunciation on the MFD Alert Annunciation Figure 6-146 Alert Annunciation on the PFD 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 440 HAZARD AVOIDANCE Potential Impact Points Figure 6-147 Alert Pop-up on the MFD Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 441 ** Annunciation is displayed on the MFD when terrain display is enabled. Table 6-21 TAWS-B Alerts Summary 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 442 Reduced Required Terrain Clearance (RTC) and Reduced Required Obstacle Clearance (ROC) alerts are issued when the aircraft flight path is above terrain, yet is projected to come within the minimum clearance values in Figure 6-149. When an RTC alert is issued, a potential impact point is displayed on the TAWS-B Page. Imminent Terrain Impact (ITI) and Imminent Obstacle Impact (IOI) alerts are issued when the aircraft is below the elevation of a terrain or obstacle cell in the aircraft’ s projected path. ITI and IOI alerts are accompanied by a potential impact point displayed on the TAWS-B Page. The alert is annunciated when the projected vertical flight path is calculated to come within minimum clearance altitudes in Figure 6-149. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 443 A Premature Descent Alert (PDA) is issued when the system detects that the aircraft is significantly below the normal approach path to a runway (Figure 6-150). PDA alerting begins when the aircraft is below 700 feet AGL within 15 nm of the destination airport and ends when the aircraft is 0.5 nm from the runway threshold. PDA ALERTING AREA Distance to Destination (NM) Figure 6-150 PDA Alerting Threshold 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 444 “Five Hundred” aural alert is based on the nearest runway threshold elevation. When the aircraft is more than 5 nm of the nearest airport, the “Five Hundred” aural alert is based on the height above terrain (as determined by the GPS altitude and Terrain Database). There are no display annunciations or pop-up alerts that accompany the aural message. NEGATIVE CLIMB RATE AFTER TAKEOFF ALERT (NCR) The Negative Climb Rate (NCR) After Takeoff alert (also referred to as “Altitude Loss After Takeoff”) provides alerts when the system determines the aircraft is losing altitude (closing upon terrain) after takeoff. The aural message “Don’t Sink” is given for NCR alerts, accompanied by an annunciation and a pop-up terrain alert on the display. NCR alerting is only active when departing from an airport and when the following conditions are met: • Height above the terrain is less than 700 feet • Distance from the departure airport is 5 nm or less • Heading change from the departure heading is less than 110 degrees Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 445 “DON’T SINK” “TOO LOW, TERRAIN” 1000 1500 2000 2500 3000 3500 4000 4500 5000 5500 6000 6500 7000 Sink Rate (FPM) Figure 6-153 Negative Climb Rate (NCR) Sink Rate 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 446: System Status
Figure 6-154 TAWS-B Page Menu TAWS-B continually monitors several system-critical items such as database validity, hardware status, and GPS status. If the terrain/obstacle database is not available, the aural message “TAWS System Failure” is generated along with the ‘TAWS FAIL’ alert annunciation. TAWS-B requires a 3-D GPS navigation solution along with specific vertical accuracy minimums. Should the navigation solution become degraded or if the aircraft is out of the database coverage area, the annunciation ‘TAWS N/A’ is generated in the annunciation window and on the TAWS-B Page. The aural message “TAWS Not Available” is generated. When sufficient GPS signal is returns and the aircraft is within the database coverage area, the aural message “TAWS Available” is generated. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 447 “TAWS Not Available” area “TAWS Available” when aircraft re-enters database coverage area. * Annunciation is displayed on the MFD when terrain display is enabled. Table 6-23 TAWS-B Abnormal Conditions 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 448: Profile View Terrain
2) Select ‘Show Profile View’ or ‘Hide Profile View’ (choice dependent on current state) and press the ENT Key. Enabling/Disabling Profile View Terrain on the Navigation Map (when Profile View is enabled): 1) Select the Navigation Map Page. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 449: Profile View Display
Profile View Length is One Half of the Navigation Map Range Distance Scale Figure 6-156 Profile View on Navigation Map with Terrain Display Enabled The Profile View is based on the current aircraft track (or heading if track is unavailable) and shows the highest known terrain or obstacles within a predetermined width from the present aircraft position to the end of the profile range. The width of the Profile View is determined by the phase of flight, as annunciated on the HSI, and is widest during enroute and oceanic phases (Table 6-25). 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 450 7) Press the ENT Key to select an option. 8) Press the FMS Knob or CLR Key to return to the Navigation Map Page with the changed settings. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 451 HAZARD AVOIDANCE Figure 6-157 Navigation Map Page Menu Figure 6-158 Navigation Map Page Setup Menu Figure 6-159 Navigation Map Page Setup Menu, Profile Group 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 452: Traffic Information Service (Tis)
Table 6-26 TIS Traffic Symbols A Traffic Advisory (TA) indicates that the current track of the intruder could result in a collision. When traffic meets the advisory criteria for the TA, a solid yellow circle symbol is generated. A TA which is detected, but is outside the range of the map, is indicated with a message in the lower left corner of the map and a half TA symbol at the relative bearing of the intruder. TIS also provides a vector line showing the direction in which the traffic is moving, to the nearest 45°. Traffic information for which TIS is unable to determine the bearing (non-bearing traffic) is displayed in the center of the Traffic Map Page (Figure 6-164) or in a banner at the lower left corner of maps other than the Traffic Map Page on which traffic can be displayed. The altitude difference between the requesting aircraft and other intruder aircraft is displayed above/below the traffic symbol in hundreds of feet. If the other aircraft is above the requesting aircraft, the altitude separation appears above the traffic symbol; if below, the altitude separation appears below. Altitude trend is displayed as an up/down arrow (for speeds greater than 500 fpm in either direction) to the right of the target symbol. Traffic symbols for aircraft without altitude reporting capability appear without altitude separation or climb/descent information. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 453: Displaying Traffic Data
Figure 6-160 TIS Traffic on the Navigation Map Page Displaying traffic information (PFD Inset Map): 1) Select the INSET Softkey. 2) Select the TRAFFIC Softkey to display traffic data on the inset map (TRFC-1). 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 454 8) Press the FMS Knob or CLR Key to return to the Navigation Map Page with the changed settings. Figure 6-161 Navigation Map Page Menu Figure 6-162 Navigation Map Page Setup Menu Figure 6-163 Navigation Map Page Setup Menu, Traffic Group Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 455: Traffic Map Page
Select the OPERATE Softkey to begin displaying traffic. Or : a) Press the MENU Key. b) Select ‘Operate Mode’ (shown if TIS is in Standby Mode) and press the ENT Key. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 456 Traffic Advisory Off Scale 400’ Below, Level Non-Threat Traffic, Altitude Not Reported Traffic Status Banners Select to Mute “TIS Not Available” Figure 6-164 Traffic Map Page Voice Alert Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 457: Tis Alerts
Inset Map Displays When TA is Detected Figure 6-165 Traffic Annunciation (PFD) A “TIS Not Available” (TNA) voice alert is generated when the TIS service becomes unavailable or is out of range. TIS may be unavailable in the radar coverage area due to the following: • Radar site TIS Mode S sensor is not operational or is out of service • Traffic or requesting aircraft is beyond the maximum range of the TIS-capable Mode S radar site. • Traffic or requesting aircraft is above the radar site in the cone of silence and out of range of an adjacent site. • Traffic or requesting aircraft is below radar coverage. In flat terrain, the coverage extends from about 3000 feet upward at 55 miles. Terrain and obstacles around the radar site can further decrease radar coverage in all directions. • Traffic does not have an operating transponder. The “TIS Not Available” (TNA) voice alert can be manually muted to reduce nuisance alerting. TNA muting status is shown in the upper left corner of the Traffic Map Page. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 458: System Status
FAILED The transponder has failed* UNAVAILABLE TIS is unavailable or out of range * Contact a service center or Garmin dealer for corrective action Table 6-27 TIS Failure Annunciations System Test has Failed Data Not Received from Transponder Figure 6-166 TIS Power-up Test Failure Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 459 Traffic Map Page. Or : a) Press the MENU Key. b) Select ‘Operate Mode’ or ‘Standby Mode’ (choice dependent on current state) and press the ENT Key. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 460 The traffic service is unavailable or out of range *Shown as symbol on Traffic Map Page **Shown in center of Traffic Map Page Table 6-29 TIS Traffic Status Annunciations Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 461: Gts 820 Traffic
TIS is disabled when TAS installed. NOTE: The optional Garmin GTS 820 is a Traffic Advisory System (TAS). The GTS 820 enhances flight crew situational awareness by displaying traffic information for transponder-equipped aircraft. The GTS 820 also provides visual and aural traffic alerts including voice announcements to assist in visually acquiring traffic. The GTS 820 is capable of tracking up to 45 intruding aircraft equipped with Mode A or C transponders, and up to 30 intruders equipped with Mode S transponders. A maximum of 30 aircraft with the highest threat potential can be displayed simultaneously. No TAS surveillance is provided for aircraft without operating transponders. THEORY OF OPERATION When the GTS 820 is in Operating Mode, the unit interrogates the transponders of intruding aircraft while monitoring transponder replies. The GTS 820 uses this information to derive the distance, relative bearing, and if reported, the altitude and vertical trend for each aircraft within its surveillance range. The GTS 820 then calculates a closure rate to each intruder based on the projected Closest Point of Approach (CPA). If the closure rate meets the threat criteria for a Traffic Advisory (TA), visual and aural alerting is provided. TAS SURVEILLANCE VOLUME The GTS 820 surveillance system monitors the airspace within ±10,000 feet of own altitude. Under ideal conditions, the unit scans transponder traffic up to 40 nm in the forward direction. Range is somewhat reduced to the sides and aft of own aircraft due to the directional interrogation signal patterns. In areas of greater transponder traffic density or when TCAS II systems are detected, the GTS 820 automatically reduces its interrogation transmitter power (and therefore range) in order to limit potential interference from other signals. TAS SYMBOLOGY The GTS 850 uses symbology to depict intruding traffic using the symbols shown in Table 6-30. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 462 A vertical trend arrow to the right of the intruder symbol (Figure 6-167) indicates climbing or descending traffic with an upward or downward-pointing arrow respectively. Relative Altitude Vertical trend arrow Figure 6-167 Intruder Altitude and Vertical Trend Arrow Flight IDs may also be displayed with traffic symbols; see the Flight IDs discussion in this section for more information. The GTS 820 automatically suppresses the display of altitude-reporting aircraft on the ground under either of the following conditions: • On-ground aircraft is equipped with a Mode S transponder. • On-ground aircraft is equipped with a Mode C transponder, and own aircraft’ s radar altimeter (if installed) is displaying 1700’ AGL or less. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 463 Intruder range is within 0.55 nm and vertical separation is within 800 feet. Intruder range is less than 20 seconds. Table 6-31 TA Sensitivity Level and TA Alerting Criteria 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 464: Tas Alerts
200 feet of own altitude), or “One Mile” through “Ten Miles”, or “Altitude not available” “More than ten miles” or “No Bearing” Table 6-32 TA Descriptive Voice Announcements Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 465: System Test
1000’ Distance Above, Level 3.6 nm, 1000’ Below, Descending TA at 9 o’clock, Distance 2.0 nm, 200’ Below, Climbing Figure 6-169 System Test in Progress with Test Pattern 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 466: Operation
2) Press the ENT Key. The GTS 820 switches from Standby Mode to Operating Mode as necessary. TRAFFIC MAP PAGE The Traffic Map Page shows surrounding TAS traffic data in relation to the aircraft’ s current position and altitude, without basemap clutter. Aircraft orientation is always heading up unless there is no valid heading. Map range is adjustable with the RANGE Knob from 2 to 40 nm, as indicated by the map range rings. The traffic mode and altitude display mode are annunciated in the upper left corner of the page. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 467 4) Select the STANDBY Softkey to place the system in the Standby mode. STANDBY is displayed in the Traffic mode field. 5) Turn the RANGE Knob clockwise to display a larger area or counter-clockwise to display a smaller area. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 468 3) Select the ENT Softkey. iD D light isPlay The Flight IDs of other aircraft (when available) can be enabled for display on the Traffic Map Page (Figure 6-171). When a flight ID is received, it will appear above or below the corresponding traffic symbol on the Traffic Map Page when this option is enabled. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 469 2) Turn the small FMS Knob to choose ‘Show Flight IDs’ or ‘Hide Flight IDs’ (choice dependent on current state) (Figure 6-172). 3) Press the ENT Key. Figure 6-172 Traffic Map Page Menu 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 470 1) Ensure the TAS system is operating. With the Navigation Map displayed, select the MAP Softkey. 2) Select the TRAFFIC Softkey. Traffic is now displayed on the map as shown in the figure. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 471 6) Turn the small FMS Knob to scroll through options (ON/OFF, range settings, etc.). 7) Press the ENT Key to select an option. 8) Press the FMS Knob or CLR Key to return to the Navigation Map Page. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 472 2) Select the TRAFFIC Softkey to display traffic data on the inset map (TRFC-1). 3) Select the softkey again to display the traffic-only inset (TRFC-2). 4) Select the softkey again to remove traffic data. SYSTEM STATUS The traffic mode is annunciated in the upper left corner of the Traffic Map Page. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 473 Data is not being received from the TAS unit *Shown as symbol on Traffic Map Page **Shown in center of Traffic Map Page Table 6-35 TAS Traffic Status Annunciations 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 474: Kta 870 Traffic
Non-Threat Traffic Proximity Advisory (PA) Traffic Advisory (TA) Traffic Advisory Off Scale Table 6-36 TAS Symbol Description A Non-threat Advisory, shown as an open white diamond, indicates that an intruding aircraft is at greater than ±1200 feet relative altitude or the distance is beyond 5 nm. A Proximity Advisory indicates that the intruding aircraft is within ±1200 feet and is within 5 nm range, but is still not considered a threat. A Traffic Advisory (TA) alerts the crew to a potentially hazardous intruding aircraft. Closing rate, distance, and vertical separation meet TA criteria. A Traffic Advisory that is beyond the selected display range is indicated by a half TA symbol at the edge of the screen at the relative bearing of the intruder. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 475: Operation
5) Select the STANDBY Softkey to place the system in the Standby mode. STANDBY is displayed in the Traffic mode field. 6) Turn the RANGE Knob clockwise to display a larger area or counter-clockwise to display a smaller area. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 476 Displaying traffic information (maps other than the Traffic Map Page): 1) Select the MAP Softkey. 2) Select the TRAFFIC Softkey. Traffic is now displayed on the map. When traffic is selected on maps other than the Traffic Map Page, a traffic icon is shown to indicate TAS is enabled for display. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 477 2) Select the TRAFFIC Softkey to display traffic data on the inset map (TRFC-1). 3) Select the softkey again to display the traffic-only inset (TRFC-2). 4) Select the softkey again to remove traffic data. The Navigation Map Page Setup Menu also controls the display of traffic. The setup menu controls the map range settings. Traffic data symbols and labels can be decluttered from the display. If a map range larger than the map range setting is selected, the data is removed from the map. Maps besides the Traffic Map Page use settings based on those selected for the Navigation Map Page. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 478: Altitude Display
2) The following range options are available: • 2 nm • 2 and 6 nm • 6 and 12 nm • 12 and 24 nm • 24 and 40 nm Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 479 8) Press the FMS Knob or CLR Key to return to the Navigation Map Page. Figure 6-179 Navigation Map Page Menu Figure 6-180 Navigation Map Page Setup Menu Figure 6-181 Navigation Map Page Setup Menu, Traffic Group 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 480: Tas Alerts
TAS Operating STANDBY TAS Standby (also shown in white in center of page) TAS Failed* FAIL * See Table 6-38 for additional failure annunciations Table 6-37 TAS Modes If the unit fails, an annunciation as to the cause of the failure is shown in the center of the Traffic Map Page. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 481 Data is not being received from the TAS unit *Shown as symbol on Traffic Map Page **Shown in center of Traffic Map Page Table 6-39 TAS Traffic Status Annunciations 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 482 HAZARD AVOIDANCE lank Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 483: Section 7 Automatic Flight Control System
• Manual Electric Yaw Trim (MEYT) — The yaw trim adapter provides manual electric yaw trim capability when the autopilot is not engaged. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 484: Afcs Controls
Engages/disengages the autopilot BANK Key Manually selects/deselects Low Bank Mode BC Key Selects/deselects Backcourse Mode HDG Knob Adjusts the Selected Heading and bug in 1° increments on the HSI (both PFDs) Press to synchronize the Selected Heading to the current heading on the pilot-side PFD Annunciator Light Figure 7-1 GMC 710 AFCS Control Unit Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 485: Automatic Flight Control System
MEYT Switch Used to command manual electric yaw trim (Manual Electric An MEYT Switch is located on each control wheel. Yaw Trim) 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 486: Flight Director Operation
NAV or APR Key press activates flight director. ***The selected navigation receiver must have a valid LOC signal before BC Key press activates flight director. Table 7-1 Flight Director Activation Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 487: Afcs Status Box
Flight Director Active Mode Armed Indicator Arrow Reference AFCS Status Box Selected Altitude Command Bars Vertical Speed Reference GPS is Selected Navigation Source Figure 7-2 PFD AFCS Display 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 488: Flight Director Modes
XFR Key. When the flight directors are switched, the vertical and lateral modes revert to default. Pilot-side Flight Director Copilot-side Flight Director Figure 7-4 Flight Director Selection Indications Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 489: Command Bars
Command Bars Aircraft Symbol Figure 7-5 Single-cue Command Bars If the attitude information being sent to the flight director becomes invalid or unavailable, the Command Bars are removed from the display. The flight director Command Bars also disappear if the pitch exceeds +30˚/-20˚ or bank exceeds 65˚. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 490: Vertical Modes
VNV Target Altitude ** ALTV armed automatically under VPTH when VNV Target Altitude is to be captured instead of Selected Altitude Table 7-2 Flight Director Vertical Modes Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 491: Pitch Hold Mode (Pit)
• Pressing the CWS Button, hand-flying the aircraft to establish a new pitch reference, then releasing the CWS Button Pitch Hold Selected Altitude Mode Active Capture Mode Armed Selected Altitude Command Bars Maintain Desired Pitch Reference Figure 7-6 Pitch Hold Mode 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 492: Selected Altitude Capture Mode (Alts)
Pressing the CWS Button while in Selected Altitude Capture Mode does not cancel the mode. NOTE: Use of the ALT SEL Knob to change the Selected Altitude while Selected Altitude Capture Mode is active causes the flight director to revert to Pitch Hold Mode with Selected Altitude Capture Mode armed for the new Selected Altitude. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 493: Altitude Hold Mode (Alt)
CWS Button is released at the desired altitude, the new altitude is established as the Altitude Reference. Altitude Hold Altitude Mode Active Reference Selected Altitude Selected Altitude Command Bars Hold Pitch Attitude to Maintain Altitude Reference Figure 7-8 Altitude Hold Mode 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 494: Vertical Speed Mode (Vs)
Mode Active Reference Mode Armed Selected Vertical Altitude Speed Reference Vertical Speed Reference Command Bars Indicate Climb to Attain Vertical Speed Reference Figure 7-9 Vertical Speed Hold Mode Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 495: Flight Level Change Mode (Flc)
Change Mode Airspeed Altitude Capture Active Reference Mode Armed Airspeed Reference Airspeed Reference Command Bars Indicate Climb to attain Selected Altitude Figure 7-10 Flight Level Change Mode (IAS) 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 496 Altitude Capture Active (Mach) Mode Armed Airspeed Reference Airspeed Reference Current Command Bars Indicate Climb Mach to Attain Selected Altitude Number Figure 7-11 Flight Level Change Mode (Mach) Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 497: Vertical Navigation Modes (Vpth, Altv)
When a vertical profile (VNV flight plan) is active and the VNV Key is pressed, Vertical Path Tracking Mode is armed in preparation for descent path capture. ‘VPTH’ (or ‘/V’ when Glidepath or Glideslope Mode is concurrently armed) is annunciated in white in addition to previously armed modes. If applicable, the appropriate altitude capture mode is armed for capture of the next VNV Target Altitude (ALTV) or the Selected Altitude (ALTS), whichever is greater. Figure 7-12 Vertical Path Tracking Armed Annunciations 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 498 Mode Active Acknowledgment Required) VNV Target Altitude Required Vertical Speed Bug GPS is Selected Enroute Navigation Phase of Source Flight Vertical Deviation Indicator Figure 7-13 Vertical Path Capture Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 499 For large adjustments, it may take several minutes for the aircraft to re- establish on the descent path. If the change is made while nearing a waypoint with a VNV Target Altitude, the aircraft may not re-establish on the descent path in time to meet the vertical constraint. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 500 FLC Key is pressed while Vertical Path Tracking Mode is selected, Vertical Path Tracking Mode reverts to armed along with the appropriate altitude capture mode to allow profile re-capture. Figure 7-15 Flight Level Change VNV Non-Path Descent To prevent immediate profile re-capture, the following must be satisfied: • At least 10 seconds have passed since the non-path transition was initiated • Vertical deviation from the profile has exceeded 250 feet, but is now less than 200 feet Pressing the VNV Key twice re-arms Vertical Path Tracking for immediate profile re-capture. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 501 VNV Target Altitude or the Selected Altitude, depending on which altitude is to be intercepted first. VNV target altitudes can be changed while editing the active flight plan (see the Flight Management Section for details). 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 502: Glidepath Mode (Gp)
Upon reaching the glidepath, the flight director transitions to Glidepath Mode and begins to capture and track the glidepath. Figure 7-17 Glidepath Mode Armed Once the following conditions have been met, the glidepath can be captured: • The active waypoint is at or after the final approach fix (FAF). • Vertical deviation is valid. • The CDI is at less than full scale deviation • Automatic sequencing of waypoints has not been suspended (no ‘SUSP’ annunciation on the HSI) Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 503 AUTOMATIC FLIGHT CONTROL SYSTEM GPS Approach Glidepath Mode Active Mode Active Command Bars Indicate GPS is Selected LNAV/VNAV Descent on Glidepath Navigation Approach Source Active Glidepath Indicator Figure 7-18 Glidepath Mode 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 504: Glideslope Mode (Gs)
Glideslope Active ILS Mode Active Mode Active Frequency Tuned Command Bars Indicate Descent NAV2 (localizer) is Selected on Localizer/Glideslope Path Navigation Source Glideslope Indicator Figure 7-20 Glideslope Mode Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 505: Takeoff (To) And Go Around (Ga) Modes
Go Around Mode Active Autopilot Disconnect Annunciation Flashes Yellow for 5 seconds Command Bars Indicate Climb Figure 7-21 Go Around Mode Takeoff Mode Active Figure 7-22 Takeoff Mode 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 506: Lateral Modes
The CWS Button does not change lateral references for Heading Select, Navigation, Backcourse, or Approach Mode. The autopilot guides the aircraft back to the Selected Heading/Course upon release of the CWS Button. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 507: Roll Hold Mode (Rol)
Low Bank Mode can be manually selected/deselected by pressing the BANK Key while in Heading Select or Navigation Modes (GPS and VOR). Low Bank Mode is activated automatically climbing above 25,000 ft (FL250), and deactivated when descending below 25,000 ft. The annunciator light next to the BANK Key illuminates while Low Bank Mode is selected. Low Bank Arc Figure 7-24 Low Bank Mode Limits 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 508: Heading Select Mode (Hdg)
Turns are commanded in the same direction as Selected Heading Bug movement, even if the bug is turned more than 180° from the present heading (e.g., a 270° turn to the right). However, Selected Heading changes of more than 330° at a time result in turn reversals. Heading Select Pitch Hold Mode Active Mode Active Command Bars Track Selected Heading Selected Selected Heading Heading Figure 7-25 Heading Select Mode Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 509: Navigation Modes (Gps, Vor, Loc)
Mode is armed automatically when the navigation source switch takes place if the APR Key is not pressed prior to the automatic source switch. If Navigation Mode is active and either of the following occur, the flight director reverts to Roll Hold Mode (wings rolled level): • Different VOR tuned while in VOR Navigation Mode (VOR Navigation Mode reverts to armed) • Navigation source manually switched (with the CDI Softkey) • During a LOC/ILS approach, the FAF is crossed while in GPS Navigation Mode after the automatic navigation source switch from GPS to LOC 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 510 Mode Active Command Bars Indicate Left Turn GPS is Selected Selected to Track GPS Course and Climb to Navigation Course Intercept Selected Altitude Source Figure 7-27 Navigation Mode Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 511: Approach Modes (Gps, Vapp, Loc)
2) Ensure that GPS is the selected navigation source (use the CDI Softkey to cycle through navigation sources if necessary). 3) Press the APR Key. Figure 7-28 GPS Approach Mode Armed 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 512: Backcourse Mode (Bc)
Backcourse Mode captures and tracks a localizer signal in the backcourse direction. The mode may be selected by pressing the BC Key. Backcourse Mode is armed if the CDI is greater than one dot when the mode is selected. If the CDI is less than one dot, Backcourse Mode is automatically captured when the BC Key is pressed. The flight director creates roll steering commands from the Selected Course and deviation when in Backcourse Mode. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 513 Heading Mode or Roll Mode, the AFCS will not automatically intercept or track the arc unless the pilot activates the arc leg of the flight plan and arms GPS Navigation Mode. The AFCS will not intercept and fly a DME arc before reaching an IAF that defines the beginning of the arc segment. Likewise, if at any point while established on the DME arc the pilot deselects GPS Navigation Mode, the AFCS will no longer track the arc. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 514: Autopilot And Yaw Damper Operation
It also uses lateral acceleration to coordinate turns. Yaw damper operation is independent of autopilot engagement. When the yaw damper is not engaged, the yaw trim adapter may be used to provide manual electric yaw trim (MEYT). This allows the aircraft to be trimmed using a control wheel switch. Trim speeds are scheduled with airspeed to provide more consistent response. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 515: Engagement
At the same time, the flight director is synchronized to the aircraft attitude during the maneuver. CWS activity has no effect on yaw damper engagement. The ‘AP’ annunciation is temporarily replaced by ‘CWS’ in white for the duration of CWS maneuvers. Control Wheel Steering Figure 7-31 CWS Annunciation In most scenarios, releasing the CWS Button reengages the autopilot with a new reference. Refer to flight director mode descriptions for specific CWS behavior in each mode. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 516: Disengagement
This means the yaw damper can remain operational in some cases where the autopilot automatically disengages. A localized failure in the yaw damper system or invalid sensor data also cause yaw damper disengagement. Figure 7-34 Automatic Autopilot and Yaw Damper Disengagement Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 517: Example Flight Plan
This scenario-based set of procedures (based on the example flight plan found in the Flight Management Section) shows various GFC 700 AFCS modes used during a flight. In this scenario, the aircraft departs Charles B. Wheeler Downtown Airport (KMKC), enroute to Colorado Springs Airport (KCOS). After departure, the aircraft climbs to 12,000 ft and airway V4 is intercepted, following ATC vectors. Airway V4 is flown to Salina VOR (SLN) using VOR navigation, then airway V244 is flown using a GPS flight plan. The ILS approach for runway 35L and LPV (WAAS) approach for runway 35R are shown and a missed approach is executed. KMKC KCOS Figure 7-35 Flight Plan Overview 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 518: Departure
At 50 feet from the Selected Altitude, the green ‘ALT’ annunciation flashes for up to 10 seconds; the autopilot transitions to Altitude Hold Mode and levels the aircraft. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 519 AUTOMATIC FLIGHT CONTROL SYSTEM Selected Altitude of 12,000 MSL ALT Mode KMKC Figure 7-36 Departure 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 520: Intercepting A Vor Radial
Mode and the ‘VOR’ annunciation flashes green. The autopilot begins turning to intercept the Selected Course. 3) The autopilot continues the turn until the aircraft is established on the Selected Course. Figure 7-37 Intercepting a VOR Radial Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 521: Flying A Flight Plan/Gps Course
2) Following the flight plan, the autopilot continues to steer the aircraft under GPS guidance. Note that in GPS Navigation Mode, course changes defined by the flight plan are automatically made without pilot action required. Figure 7-38 Transition to GPS Flight Plan 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 522: Descent
Altitude Hold Mode and levels the aircraft. Cruise Altitude of 12,000 MSL ALT Mode Selected Altitude of 10,000 MSL ALT Mode Figure 7-39 FLC Descent Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 523 Cruise Altitude of 12,000 MSL ALT Mode VNAV Target Altitude of 10,000 MSL Selected Altitude (set below VNAV Target Altitude) Along-track Offset, 3 nm before OPSHN 3 nm Figure 7-40 VPTH Descent 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 524 The green ‘ALT’ annunciation flashes for up to 10 seconds upon reaching 50 feet from the VNV Target Altitude; the autopilot transitions to Altitude Hold Mode and levels the aircraft at the vertical waypoint. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 525 VNAV Target Altitude of 10,000 MSL ALT Mode ALT Mode Selected Altitude of 9,400 MSL ALT Mode VNAV Target Altitude of 9,000 MSL Selected Altitude OPSHN HABUK 3 nm Figure 7-41 Non-path Descent 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 526: Approach
3) There are two options available at this point, as the autopilot flies the ILS approach: • Push the AP DISC Switch at the decision height and land the aircraft • Use the GA Switch to execute a missed approach. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 527 AUTOMATIC FLIGHT CONTROL SYSTEM KCOS PETEY PYNON Figure 7-42 ILS Approach to KCOS 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 528 • Push the AP DISC Switch at the decision height and land the aircraft. • Use the GA Switch to execute a missed approach. KCOS CEGIX FALUR HABUK PYNON Figure 7-43 LPV Approach to KCOS Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 529: Go Around/Missed Approach
Altitude Hold Mode and levels the aircraft. 4) The autopilot flies the holding pattern after the missed approach is activated. Annunciations are displayed in the Navigation Status Box, above the AFCS Status Box. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 530 AUTOMATIC FLIGHT CONTROL SYSTEM MOGAL KCOS Figure 7-44 Go Around/Missed Approach Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 531: Afcs Annunciations And Alerts
Power must be cycled to the servos to remedy the situation. Preflight system test failed; aural alert sounds at failure Table 7-5 AFCS Status Alerts 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 532: Overspeed Protection
Overspeed protection is provided in situations where the flight director cannot acquire and maintain the mode reference for the selected vertical mode without exceeding the certified maximum autopilot airspeed. When an autopilot overspeed condition occurs, the Airspeed Reference appears in a box above the Airspeed Indicator, flashing a yellow ‘MAXSPD’ annunciation. Engine power should be reduced and/or the pitch reference adjusted to slow the aircraft. The annunciation disappears when the overspeed condition is resolved. Airspeed Indicator Figure 7-46 Overspeed Annunciation Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 533: Section 8 Additional Features
AOPA’ s Airport Directory offers detailed information for a selected airport, such as available services, hours of operation, and lodging options. The optional SiriusXM Radio entertainment audio feature of the GDL 69A Data Link Receiver handles more than 170 channels of music, news, and sports. SiriusXM Radio offers more entertainment choices and longer range coverage than commercial broadcast stations. The Scheduler feature can be used to enter and display short term or long term reminder messages such as Switch fuel tanks, Change oil, or Altimeter-Transponder Check in the Messages Window on the PFD. Optional checklists help to quickly find the proper procedure on the ground or during flight. The Flight Data Logging feature automatically stores critical flight and engine data on an SD data card. Approximately 1,000 flight hours can be recorded for each 1GB of available space on the card. Telephone Service and SMS text messaging is an optional subscription service offered through Iridium Satellite LLC. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 534: Synthetic Vision System (Svs)
The optional Terrain Awareness and Warning System (TAWS) or standard Terrain-SVS is integrated within SVS to provide visual and auditory alerts to indicate the presence of terrain and obstacle threats relevant to the projected flight path. Terrain alerts are displayed in red and yellow shading on the PFD. The terrain display is intended for situational awareness only. It may not provide the accuracy or fidelity on which to base decisions and plan maneuvers to avoid terrain or obstacles. Navigation must not be predicated solely upon the use of the Terrain–SVS or TAWS terrain or obstacle data displayed by the SVS. The following SVS enhancements appear on the PFD: • Pathways • Airport Signs • Flight Path Marker • Runway Display • Horizon Heading Marks • Terrain Alerting • Traffic Display • Obstacle Alerting Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 535: Svs Operation
TERR Softkey, the HRZN HDG, APTSIGNS, and PATHWAY softkeys may be activated in any combination to display desired features. When system power is cycled, the last selected state (on or off) of the SYN TERR, HRZN HDG, APTSIGNS, and PATHWAY softkeys is remembered by the system. • PATHWAY Softkey enables display of rectangular boxes that represent course guidance. • SYN TERR Softkey enables synthetic terrain depiction. • HRZN HDG Softkey enables horizon heading marks and digits. • APTSIGNS Softkey enables airport signposts. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 536 1) Press the PFD Softkey. 2) Press the SYN VIS Softkey. 3) Press the APTSIGNS Softkey. Display of airport signs will cycle on or off with the APTSIGNS Softkey. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 537: Svs Features
The color of the rectangular boxes may be magenta, green, or white depending on the route of flight and navigation source selected. The active GPS or GPS overlay flight plan leg is represented by magenta boxes that correspond to the Magenta CDI. A localizer course is represented by green boxes that correspond to a green CDI. An inactive leg of an active flight plan is represented by white boxes corresponding to a white line drawn on the Inset map or MFD map indicating an inactive leg. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 538 Programmed Altitudes Figure 8-4 Programmed and Selected Altitude Pathways provide supplemental glidepath information on an active ILS, LPV, LNAV/VNAV, and some LNAV approaches. Pathways are intended as an aid to situational awareness and should not be used independent of the CDI, VDI, glide path indicator, and glide slope indicator. They are removed from the display when the selected navigation information is not available. Pathways are not displayed beyond the active leg when leg sequencing is suspended and are not displayed on any portion of the flight plan leg that would lead to intercepting a leg in the wrong direction. ePaRtURe anD nROUte Prior to intercepting an active flight plan leg, pathways are displayed as a series of boxes with pointers at each corner that point in the direction of the active waypoint. Pathways are not displayed for the first leg of the flight plan if that segment is a Heading-to-Altitude leg. The first segment displaying pathways is the first active GPS leg or active leg with a GPS overlay. If this leg of the flight plan route is outside the SVS field of view, pathways will not be visible until the aircraft has turned toward this leg. While approaching the center of the active leg and prescribed altitude, the number of pathway boxes decreases to a minimum of four. Pathways are displayed along the flight plan route at the highest of either the selected altitude or the programmed altitude for the leg. Climb profiles cannot be displayed due to the variables associated with aircraft performance. Flight plan legs requiring a climb are indicated by pathways displayed at a level above the aircraft at the altitude selected or programmed. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 539 Selected Altitude for Step Down Programmed descent displayed by pathway Selected Altitude or Programmed Altitude (whichever is higher) Figure 8-5 SVS Pathways, Enroute and Descent 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 540 Selected Altitude or Programmed Altitude (whichever is higher) Turn Segment Climbs NOT displayed NOT displayed by pathway by pathway MAHP Figure 8-6 SVS Pathways, Approach, Missed Approach, and Holding Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 541 Active Color of Flight Path Pathways Marker match the (FPM) CDI color Wind Vector Figure 8-7 Flight Path Marker and Pathways ZERO PITCH LINE The Zero Pitch Line is drawn completely across the display and represents the aircraft attitude with respect to the horizon. It may not align with the terrain horizon, particularly when the terrain is mountainous or when the aircraft is flown at high altitudes. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 542 4.5 nm. Airport signs are shown without the identifier until the aircraft is approximately eight nautical miles from the airport. Airport signs are not shown behind the airspeed or altitude display. Airport signs are activated and deactivated by pressing the APTSIGNS Softkey. Airport Sign with Airport Identifier Sign (Between without 4.5 nm and Identifier 8 nm) (Between 8 nm and 15 nm) Figure 8-8 Airport Signs Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 543 Not all airports have runways with endpoint data in the database, therefore, these runways are not NOTE: displayed. Runway data provides improved awareness of runway location with respect to the surrounding terrain. All runway thresholds are depicted at their respective elevations as defined in the database. In some situations, where threshold elevations differ significantly, crossing runways may appear to be layered. As runways are displayed, those within 45 degrees of the aircraft heading are displayed in white. Other runways will be gray in color. When an approach for a specific runway is active, that runway will appear brighter and be outlined with a white box, regardless of the runway orientation as related to aircraft heading. As the aircraft gets closer to the runway, more detail such as runway numbers and centerlines will be displayed. Other Runway Runway on Airport Selected for Approach Figure 8-9 Airport Runways 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 544 In these cases, the conflict is outside the SVS field of view to the left or right of the aircraft. TERRAIN Annunciation Terrain Warning Potential Impact Points Figure 8-10 Terrain Alert Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 545 Unlike the Inset map and MFD moving map display, obstacles on the synthetic terrain display do not change colors to warn of potential conflict with the aircraft’ s flight path until the obstacle is associated with an actual FLTA alert. Obstacles greater than 1000 feet below the aircraft altitude are not shown. Obstacles are shown behind the airspeed and altitude displays. TERRAIN Annunciation Obstacle Potential Impact Point Figure 8-11 Obstacle 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 546: Field Of View
4) Turn the large FMS Knob to scroll through the Map Group options to FIELD OF VIEW. 5) Turn the small FMS Knob to select On or Off. 6) Press the FMS Knob to return to the Navigation Map Page. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 547 The following figure compares the PFD forward looking depiction with the MFD plan view and FIELD OF VIEW turned on. Lines Depict PFD Field of View Field of View on the MFD SVS View on the PFD Figure 8-13 PFD and MFD Field of View Comparison 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 548: Safetaxi
• User Waypoint Information Page • Weather Datalink Page • Trip Planning Page • Airport Information Page • Nearest Pages • Intersection Information Page • Active and Stored Flight Plan Pages • NDB Information Page During ground operations the aircraft’ s position is displayed in reference to taxiways, runways, and airport features. In the example shown, the aircraft is on taxiway Bravo inside the High Alert Intersection boundary on KSFO airport. Airport Hot Spots are outlined in magenta. When panning over the airport, features such as runway holding lines and taxiways are shown at the cursor. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 549 Figure 8-14 SafeTaxi Depiction on the Navigation Map Page The DCLTR Softkey (declutter) label advances to DCLTR-1, DCLTR -2, and DCLTR-3 each time the softkey is selected for easy recognition of decluttering level. Selecting the DCLTR Softkey removes the taxiway markings and airport feature labels. Selecting the DCLTR-1 Softkey removes VOR station ID, the VOR symbol, and intersection names if within the airport plan view. Selecting the DCLTR-2 Softkey removes the airport runway layout, unless the airport in view is part of an active route structure. Selecting the DCLTR-3 Softkey cycles back to the original map detail. Refer to Map Declutter Levels in the Flight Management Section. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 550 7) Press the ENT Key to complete the selection. 8) Press the FMS Knob to return to the Navigation Map Page. SAFETAXI Option SafeTaxi Range Options Figure 8-16 MAP SETUP Menu, Aviation Group, SAFETAXI Range Options Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 551: Safetaxi Cycle Number And Revision
Normal operation. SafeTaxi database is valid and within current cycle. SafeTaxi database has expired. Database card contains no SafeTaxi data. Table 8-1 SafeTaxi Annunciation Definitions The SafeTaxi Region, Version, Cycle, Effective date and Expires date of the database cycle can also be found on the AUX - System Status page, as seen in Figure 8-18. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 552 S – Indicates the data is for SafeTaxi 3 – Indicates the third issue of the SafeTaxi database for the year The SafeTaxi EFFECTIVE date 07–MAY–11 is the beginning date for the current database cycle. SafeTaxi EXPIRES date 02–JUL–11 is the revision date for the next database cycle. SafeTaxi Data Figure 8-18 AUX – System Status Page, SafeTaxi Current Information SafeTaxi information appears in blue and yellow text. The EFFECTIVE date appears in blue when data is current and in yellow when the current date is before the effective date. The EXPIRES date appears in blue when data is current and in yellow when expired (Figures 8-18 and 8-19). NOT AVAILABLE appears in blue in the REGION field if SafeTaxi data is not available on the database card (Figure 8-19). An expired SafeTaxi database is not disabled and will continue to function indefinitely. Select the MFD1 DB Softkey a second time. The softkey label will change to PFD1 DB. The DATABASE window will now be displaying database information for PFD1. As before, scroll through the listed information by turning the FMS Knob or pressing the ENT Key until the SafeTaxi database information is shown. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 553 Page. The EFFECTIVE date is the beginning date for this database cycle. If the present date is before the effective date, the EFFECTIVE date appears in yellow and the EXPIRES date appears in blue. The EXPIRES date is the revision date for the next database cycle. NOT AVAILABLE indicates that SafeTaxi is not available on the database card or no database card is inserted. Current Date is before Effective Date SafeTaxi Database has Expired SafeTaxi Database Not Installed Figure 8-19 AUX – System Status Page, SafeTaxi Database Status 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 554: Chartview
PROFILE MINIMUMS FIT WDTH FULL SCN BACK Selecting the BACK Softkey returns to the Chart Selection Softkeys. Figure 8-20 ChartView SHW CHRT, Chart Selection, and Chart Option Softkeys Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 555: Terminal Procedures Charts
Waypoint Airport Information Page OPTIONS Menu Figure 8-21 Option Menus On the Waypoint Airport Information Page OPTIONS Menu, select the desired chart and press the ENT Key to display the chart. When no terminal procedure chart is available, the banner CHART NOT AVAILABLE appears on the screen. The CHART NOT AVAILABLE banner does not refer to the FliteCharts subscription, but rather the availability of a particular airport chart selection or procedure for a selected airport. Figure 8-22 Chart Not Available Banner If there is a problem in rendering the data (such as a data error or a failure of an individual chart), the banner UNABLE TO DISPLAY CHART is then displayed. Figure 8-23 Unable To Display Chart Banner 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 556 9) Press the ENT Key to complete the chart selection. Chart Scale Select Desired Approach Chart from Menu Scroll Through Complete Chart With the Joystick Figure 8-24 Approach Information Page, Chart Selection Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 557 (Figure 8-28). If the Chart Scale Box displays a banner NOT TO SCALE, the aircraft symbol is not shown. The Aircraft Not Shown Icon may appear at certain times, even if the chart is displayed to scale. Selecting the CHRT Softkey switches between the ChartView diagram and the associated map in the WPT page group. In the example shown, the CHRT Softkey switches between the Gainesville, FL (KGNV) Airport Diagram and the navigation map on the WPT – Airport Information page. Select CHRT Softkey to Switch Between ChartView and WPT - Airport Information Page Figure 8-25 CHRT Softkey, Airport Information Page 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 558 This information source is not related to the INFO-1 or INFO-2 Softkey. When the INFO Box is selected using the FMS Knob, the G1000 softkeys are blank. The Charlotte, NC airport has five additional charts offering information; the Airport Diagram, Take-off Minimums, Class B Airspace, Airline Parking Gate Coordinates, and Airline Parking Gate Location. (The numbers in parentheses after the chart name are Jeppesen designators.) Aircraft Current Position Figure 8-26 Airport Information Page, INFO View, Full Screen Width Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 559 Figure 8-27 Airport Information Page, Class B Chart Selected from INFO View Selecting the DP Softkey displays the Departure Procedure Chart if available. Chart Not To Scale Aircraft Not Shown Icon Figure 8-28 Departure Information Page 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 560 Change Range and Scroll Through the Chart With the Joystick Aircraft Not Shown Icon Figure 8-29 Arrival Information Page Selecting the APR Softkey displays the approach chart for the airport if available. Figure 8-30 Approach Information Page Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 561 NOTAM Softkey is selected. There may be other NOTAMs available pertaining to the flight that may not be displayed. Contact Jeppesen for more information regarding Jeppesen database- published NOTAMs. Recent NOTAMS applicable to the current ChartView cycle are included in the ChartView database. Selecting the NOTAM Softkey shows the local NOTAM information for selected airports, when available. When NOTAMS are not available, the NOTAM Softkey label appears subdued and is disabled as shown in Figure 8-31. The NOTAM Softkey may appear on the Airport Information Page and all of the chart page selections. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 562 Figure 8-32 NOTAM Available Local NOTAM on This Airport NOTAM Softkey Selected Figure 8-33 Airport Information Page, Local NOTAMs Selecting the NOTAM Softkey again removes the NOTAMS information. Selecting the GO BACK Softkey reverts to the previous page (Navigation Map Page, Nearest Pages, or Flight Plan Page). Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 563: Chart Options
ADDITIONAL FEATURES CHART OPTIONS Selecting the CHRT OPT Softkey displays the next level of softkeys, the chart options level (Figure 8-20). Selecting the ALL Softkey shows the entire approach chart on the screen. Complete Chart Shown Figure 8-34 Approach Information Page, ALL View 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 564 Selecting the HEADER Softkey shows the header view (approach chart briefing strip) on the screen. Approach Chart Briefing Strip Figure 8-35 Approach Information Page, Header View Selecting the PLAN Softkey shows the approach chart two dimensional plan view. Approach Chart Plan View Figure 8-36 Approach Information Page, Plan View Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 565 Figure 8-37 Approach Information Page, Profile View, Full Screen Width Selecting the MINIMUMS Softkey displays the minimum descent altitude/visibility strip at the bottom of the approach chart. Minimum Descent Altitude/ Visibility Strip Figure 8-38 Approach Information Page, Minimums View, Full Screen Width 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 566 ADDITIONAL FEATURES If the chart scale has been adjusted to view a small area of the chart, selecting the FIT WIDTH Softkey changes the chart size to fit the available screen width. Select FIT WDTH Softkey to Show Full Chart Width Figure 8-39 Airport Information Page, FIT WDTH Softkey Selected Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 567 Select FULL SCN Softkey to Switch Between Chart on Full Screen and Chart with Info Window Figure 8-40 Airport Information Page, Full Screen and Info Window Selecting the BACK Softkey, or waiting for 45 seconds reverts to the chart selection softkeys. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 568 3) Turn the large FMS Knob to move between the FULL SCREEN and COLOR SCHEME Options. 4) Turn the small FMS Knob to choose between the On and Off Full Screen Options. Chart Setup Option Full Screen On/Off Selection Figure 8-41 Page Menus Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 569: Day/Night View
The display must be changed in order for the new setting to become active. This may be accomplished by selecting another page or changing the display range. 6) Press the FMS Knob when finished to remove the Chart Setup Menu. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 570 ADDITIONAL FEATURES Figure 8-43 Arrival Information Page, Day View Figure 8-44 Arrival Information Page, Night View Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 571: Chartview Cycle Number And Expiration Date
Figure 8-45 Power-up Page, ChartView Database Power-up Page Display Definition Blank Line. System is not configured for ChartView. Contact a Garmin- authorized service center for configuration. System is configured for ChartView but no chart database is installed. Contact Jeppesen for a ChartView database.
Page 572 Data Figure 8-46 AUX – System Status Page, ChartView Current and Available The ChartView database is obtained directly from Jeppesen. Refer to Updating Jeppesen Databases in Appendix B for instructions on revising the ChartView database. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 573 ChartView has Expired, but is not Disabled ChartView Database is Disabled ChartView Database is Not Available Figure 8-47 AUX – System Status Page, ChartView Database Status 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 574: Flitecharts
FIT WDTH FULL SCN BACK Selecting the BACK Softkey returns to the Chart Selection Softkeys. Figure 8-48 FliteCharts SHW CHRT, Chart Selection, and Chart Option Softkeys Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 575: Terminal Procedures Charts
Waypoint Airport Information Page OPTIONS Menu Figure 8-49 Option Menus On the Waypoint Airport Information Page OPTIONS Menu, select the desired chart and press the ENT Key to display the chart. When no terminal procedure chart is available, the banner CHART NOT AVAILABLE appears on the screen. The CHART NOT AVAILABLE banner does not refer to the FliteCharts subscription, but rather the availability of a particular airport chart selection or procedure for a selected airport. Figure 8-50 Chart Not Available Banner If there is a problem in rendering the data (such as a data error or a failure of an individual chart), the banner UNABLE TO DISPLAY CHART is then displayed. Figure 8-51 Unable To Display Chart Banner 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 576 9) Press the ENT Key to complete the chart selection. Chart Not To Scale Select Desired Approach Chart from Menu Pan Complete Chart With the Joystick Aircraft Not Shown Icon Figure 8-52 Approach Information Page, Chart Selection Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 577 Joystick centers the chart on the screen. The aircraft symbol is not shown on FliteCharts. The Chart Scale Box displays a banner NOT TO SCALE, and the Aircraft Not Shown Icon is displayed in the lower right corner of the screen. Selecting the CHRT Softkey switches between the FliteCharts diagram and the associated map in the WPT page group. In the example shown, the CHRT Softkey switches between the Gainesville, FL (KGNV) Airport Diagram and the navigation map on the WPT – Airport Information page. Select CHRT Softkey to Switch Between Navigation Map Page and FliteCharts Figure 8-53 CHRT Softkey, Airport Information Page 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 578 Selecting the INFO-1 or INFO-2 Softkey returns to the airport diagram when the view is on a different chart. If the displayed chart is the airport diagram, the INFO-1 or INFO-2 Softkey has no effect. Another source for additional airport information is from the INFO Box above the chart (Figure 8-53) or to the right of the chart (Figure 8-54) for certain airports. This information source is not related to the INFO-1 or INFO-2 Softkey. When the INFO Box is selected using the FMS Knob, the G1000 softkeys are blank. The DeKalb Peachtree Airport has three additional charts offering information; the Airport Diagram, Alternate Minimums, and Take-off Minimums. Info Box Selected Figure 8-54 Airport Information Page, INFO View with Airport Information Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 579 ADDITIONAL FEATURES In the example shown in Figure 8-54, ALTERNATE MINIMUMS is selected. Pressing the ENT Key displays the IFR Alternate Minimums Chart (Figure 8-55). Figure 8-55 Airport Information Page, ALTERNATE MINIMUMS Selected from INFO View Selecting the DP Softkey displays the Departure Procedure Chart if available. Figure 8-56 Departure Information Page 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 580 ADDITIONAL FEATURES Selecting the STAR Softkey displays the Standard Terminal Arrival Chart if available. Figure 8-57 Arrival Information Page Selecting the APR Softkey displays the approach chart for the airport if available. Figure 8-58 Approach Information Page Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 581 Available Chart Not To Scale Softkeys are Blank during Info Box Selection WX Softkey Selected Figure 8-59 Weather Information Page, WX Softkey Selected Selecting the GO BACK Softkey reverts to the previous page (Navigation Map Page or Flight Plan Page). 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 582: Chart Options
ADDITIONAL FEATURES CHART OPTIONS Selecting the CHRT OPT Softkey displays the next level of softkeys, the chart options level (Figure 8-48). Selecting the ALL Softkey shows the entire chart on the screen. Complete Chart Shown Figure 8-60 Airport Information Page, ALL View Selected Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 583 ADDITIONAL FEATURES Selecting the FIT WIDTH Softkey fits the width of the chart in the display viewing area. In the example shown, the chart at close range is replaced with the full width chart. Select FIT WDTH Softkey to Show Full Chart Width Figure 8-61 Approach Information Page, FIT WDTH Softkey Selected 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 584 2) Turn the large FMS Knob to highlight the Chart Setup Menu Option and press the ENT Key. 3) Turn the large FMS Knob to move between the FULL SCREEN and COLOR SCHEME Options. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 585: Day/Night View
5) If Auto Mode is selected, turn the large FMS Knob to select the percentage field. Use the small FMS Knob to change the percentage value. The percentage value is the day/night crossover point based on the percentage of 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 586 6) Press the FMS Knob when finished to remove the Chart Setup Menu. Figure 8-65 Approach Information Page, Day View Figure 8-66 Approach Information Page, Night View Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 587: Flitecharts Cycle Number And Expiration Date
Figure 8-67 Power-up Page, FliteCharts Database Power-up Page Display Definition Blank Line. system is not configured for FliteCharts. Contact a Garmin- authorized service center for configuration. System is configured for FliteCharts but no chart database is installed. Refer to Updating Garmin Databases in Appendix B for the FliteCharts database Normal operation.
Page 588 Select the MFD1 DB Softkey to place the cursor in the DATABASE window. Scroll through the listed information by turning the FMS Knob or pressing the ENT Key until the FliteCharts database information is shown. The FliteCharts database cycle number shown in the figure, 1105, is deciphered as follows: 11 – Indicates the year 2011 05 – Indicates the fifth issue of the FliteCharts database for the year The FliteCharts EFFECTIVE date 07–MAY–11 is the first date that this database is current. The FliteCharts EXPIRES date 04–JUN–11 is the last date that this database is current. The DISABLES date 01–DEC–11 is the date that this database becomes inoperative. FliteCharts Data Figure 8-68 AUX – System Status Page, FliteCharts Current and Available Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 589 Current Date is Before Effective Date FliteCharts Expired, but is not Disabled FliteCharts Database is Disabled FliteCharts Database is Not Available Figure 8-69 AUX – System Status Page, FliteCharts Datbase Status 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 590: Aopa Airport Directory
Information Page by selecting the INFO Softkey until INFO-2 is displayed as shown in Figure 8-70. Figure 8-70 AOPA Information on the Airport Information Page AOPA DATABASE CYCLE NUMBER AND REVISION The AOPA Airport Directory database is revised four times per year. Check fly.garmin.com for the current database. The Airport Directory is always available for use after the expiration date. When turning on the system, the Power-up Page indicates whether the databases are current, out of date, or not available. AOPA Database Figure 8-71 Power-up Page, Airport Directory Database Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 591 The Airport Directory database cycle number shown in the figure, 11D2, is deciphered as follows: 11 – Indicates the year 2011 D – Indicates the data is for Airport Directory 2 – Indicates the second issue of the Airport Directory database for the year The Airport Directory EFFECTIVE date 15–APR–11 is the beginning date for the current database cycle. The Airport Directory EXPIRES date 14–JUL–11 is the revision date for the next database cycle. Airport Directory Data Figure 8-72 AUX – System Status Page, Airport Directory Current Information Airport Directory information appears in blue and yellow text. The EFFECTIVE date appears in blue when data is current and in yellow when the current date is before the effective date. The EXPIRES date appears in blue when data is current and in yellow when expired (Table 8-4). NOT AVAILABLE appears in blue in the REGION field if Airport Directory data is not available on the database card. An expired Airport Directory database is not disabled and will continue to function indefinitely. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 592: Siriusxm Radio Entertainment
3) Select the next to last page in the AUX Page Group. 4) Select the INFO Softkey to display the XM Information Page. 5) Verify that the desired services are activated. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 593 Radio ID Weather Products Window LOCK Softkey is Used to Save Activation Data RADIO During Initial and INFO Setup Softkeys Figure 8-73 XM Information Page If XM WX Satellite Weather Services have not been activated, all the weather product boxes are blank on the XM Information Page and a yellow Activation Required message is displayed in the center of the Weather Data Link Page (Map Page Group). The Service Class refers to the groupings of weather products available for subscription. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 594: Using Siriusxm Radio
2) Select the CH + Softkey to go up through the list in the Channel Box, or move down the list with the CH – Softkey. Or : Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 595 Turn the small FMS Knob to display the Categories list. Highlight the desired category with the small FMS Knob and press the ENT Key. Selecting All Categories places all channels in the list. Figure 8-75 Categories List 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 596 Softkey is selected, the volume can also be adjusted using the small FMS Knob.) 3) Select the MUTE Softkey to mute the audio. Select the MUTE Softkey again to unmute the audio. Figure 8-77 Volume Control SiriusXM Radio volume may also be adjusted on each passenger headset. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 597: Scheduler
7) Press the ENT Key again or use the large FMS Knob to move the cursor to the next field. 8) For periodic and one-time messages, use the FMS Knob to enter the timer value (HH:MM:SS) from which to countdown and press the ENT Key. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 598 5) Press the ENT Key while the message line is cleared to clear the message time. Scheduler messages appear in the Messages Window on the PFD. When a scheduler message is waiting, the MSG Softkey label flashes. Selecting the MSG Softkey opens the Messages Window and acknowledges the scheduler message. Pressing the MSG Softkey again removes the Messages Window from the display, and the scheduler message is deleted from the message queue. Figure 8-79 PFD Messages Window Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 599: Electronic Checklists
TBM 850. The information described in this section is not intended to replace the checklist information described in the AFM or the Pilot Safety and Warning Supplements document. Garmin is not responsible for the content of checklists. TBM 850 checklists are created, modified, NOTE: and updated by the aircraft manufacturer.
Page 600 3) Turn the small FMS Knob to select the desired procedure and press the ENT Key. 4) Turn the large FMS Knob to select the Checklist field. 5) Turn the FMS Knob to select the desired checklist and press the ENT Key. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 601 9) Select the EXIT Softkey or hold down the CLR Key momentarily to exit the Checklist Page and return to the page last viewed. Figure 8-83 Checklist Page Example 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 602 ADDITIONAL FEATURES Immediately accessing emergency procedures: 1) From any page, select the CHKLIST Softkey. 2) Select the EMERGCY Softkey. Figure 8-84 Sample Emergency Checklist Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 603: Flight Data Logging
• Amps 1 (amps) • Gnd Speed (kts) • Amps 2 (amps) • Vertical Alert Limit (VAL, meters) • AFCS On ( 0 – false, 1 – true) • Vertical Speed (fpm) • Latitude (degrees) • NAV1 Frequency (MHz) • AFCS Roll Mode (e.g. HDG, LOC, GPS, VOR, ROL) • NAV2 Frequency (MHz) • Longitude (degrees) • Horizontal Protection Level (HPLWAS, meters) • Right Fuel Qty (gals or lbs) • Pitch (degrees) • Left Fuel Qty (gals or lbs) • Roll (degrees) • Center Fuel Qty (gals or lbs) • Horizontal Protection Level (HPLFD, meters) • AFCS Pitch Mode (e.g. ALT, GS, GP, VS) • Vertical Protection Level (VPLWAS, meters) • Barometric Altitude (feet) • COM1 Frequency (MHz) • Altimeter Setting (in. Hg.) • COM2 Frequency (MHz) • GPS Altitude (ft) • Lateral Acceleration (g) • Pitch Commanded (degrees) • CDI Deflection (0.0 to 1.0) 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 604 The file containing the recorded data will appear in the format shown in Figure 8-82. This file can be imported into most computer spreadsheet applications. Nearest Airport (A blank will be Local Date Local 24hr Time inserted if no YYMMDD HHMMSS airport is found) log_110210_104506_KIXD.csv Figure 8-85 Log File Format Data logging status can be monitored on the AUX-UTILITY Page. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 605: Satellite Telephone & Sms Messaging Service
1) Turn the large FMS Knob on the MFD to select the AUX page group. 2) Turn the small FMS Knob to select the AUX-TELEPHONE Page. The PHONE STATUS display, as shown in Figure 8-87, gives a graphical representation of the current disposition of the connection with the Iridium network. Table 8-5 describes symbology used on PHONE STATUS display. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 606 1) With the AUX-TELEPHONE Page displayed, select the MENU Key on the MFD to display the Page Menu. 2) Turn either FMS Knob to place the cursor on ‘Disable Iridium Transmission’. 3) Press the ENT Key. Figure 8-88 Enable Iridium Telephone System Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 607 Phone is disabled Phone is reserved for data transmission Calling other phone or incoming call from other phone Other phone is on hold Phones are connected Table 8-5 Telephone Symbols 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 608 2) Turn either FMS Knob to place the cursor on ‘Disable Incoming Call Alerts’. 3) Press the ENT Key. The voice and pop-up alert will not be displayed now when an incoming call is received. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 609 Press the MENU Key to display the Page Menu. c) Turn either FMS Knob to place the cursor on ‘Dial a Phone Call’. d) Press the ENT Key. Figure 8-90 Enter Phone Number 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 610 4) Press the ENT Key. ‘OK’ is highlighted as in Figure 8-91. Figure 8-91 Make the Call 5) Press the ENT Key. The system will begin calling the number, as in Figure 8-92. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 611 ADDITIONAL FEATURES Figure 8-92 System is Making the Connection When the phone is answered, the connection is established as shown in Figure 8-93. To exit the call, select the HANGUP Softkey. Figure 8-93 Phone is Answered, Connection Complete 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 612: Text Messaging (Sms)
2) Turn the small FMS Knob to select the SATELLITE PHONE. 3) If necessary, select the SMS Softkey to display the AUX-TEXT MESSAGING Page as shown in Figure 8-94. Figure 8-94 Text Messaging Page Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 613 New Text Message Pop-up New Text Message Symbol on MFD Page Figure 8-95 New Text Message Received Select the VIEW Softkey to view the message (Figure 8-96). Selecting the IGNORE Softkey will extinguish the pop-up window and leave the text message unopened. Selecting the IGNR ALL Softkey will extinguish the pop-window and ignore all future incoming text messages. Selecting the SMS Softkey will display the AUX-TEXT MESSAGING Page. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 614 2) Turn either FMS Knob to place the cursor on ‘Disable New Message Popups’ or ‘Enable New Message Popups’. 3) Press the ENT Key. The pop-up alert will not be displayed when an incoming text message is received. Figure 8-97 Disabling New Text Message Pop-Ups Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 615 Special characters can be accessed by selecting the SYMBOLS Softkey. See Figure 8-98. 3) Press the ENT Key. The cursor is now displayed in the ‘MESSAGE’ field. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 616 Creating a predefined text message: 1) While viewing the AUX-TEXT MESSAGING Page, press the MENU Key to display the Page Menu. Figure 8-99 Creating/Editing Predefined Messages Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 617 10) Press the MENU Key to display the Page Menu. 11) Turn either FMS Knob to place the cursor on ‘Stop Editing Predefined Message’. 12) Press the ENT Key. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 618 Figure 8-101 Predefined Message Softkey Shown When Composing a Message 4) Select the PREDEFD Softkey. The PREDEFINED MESSAGE MENU Window is displayed as seen in Figure 8-102. Figure 8-102 Predefined Message List Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 619 2) Turn either FMS Knob to place the cursor on ‘Show Inbox Messages’. 3) Press the ENT Key. The message box selected for viewing is indicated at the bottom left of the list window. Figure 8-103 Text Message Inbox 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 620 3) Press the ENT Key. The sorting selection is indicated at the bottom center of the list window. Viewing messages sorted by address: While viewing the AUX-TEXT MESSAGING Page, select the ARRANGE Softkey, then select the ADDRESS Softkey. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 621 Press the ENT Key. Message content is displayed as shown in Figure 8-104. Figure 8-104 Veiwing Message Content 5) To close the text message, select the CLOSE Softkey. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 622 Press the MENU Key to display the Page Menu. b) Turn either FMS Knob to place the cursor on ‘Delete Selected Message’. c) Press the ENT Key. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 623: Abnormal Operation
ADDITIONAL FEATURES 8.11 ABNORMAL OPERATION SVS TROUBLESHOOTING SVS is intended to be used with traditional attitude, heading, obstacle, terrain, and traffic inputs. SVS is disabled when valid attitude or heading data is not available for the display. In case of invalid SVS data, the PFD display reverts to the standard blue-over-brown attitude display. SVS becomes disabled without the following data resources: • Attitude data • Heading data • GPS position data • 9 Arc-second Terrain data • Obstacle data • TAWS function is not available, in test mode, or failed • The position of the aircraft exceeds the range of the terrain database. REVERSIONARY MODE SVS can be displayed on the Multifunction Display (MFD) in Reversionary Mode. If it is enabled when switching to Reversionary Mode, SVS will take up to 30 seconds to be displayed. The standard, non-SVS PFD display will be shown in the interim. Figure 8-105 SVS Reversionary Mode 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 624: Unusual Attitudes
Unusual attitudes are displayed with red chevrons overlaid on the display indicating the direction to fly to correct the unusual attitude condition. The display shows either a brown or blue colored bar at the top or bottom of the screen to represent earth or sky. This is intended to prevent losing sight of the horizon during extreme pitch attitudes. Figure 8-106 Unusual Attitude Display The blue colored bar is also displayed when terrain gradient is great enough to completely fill the display. Blue Band Terrain Completely Fills Display Figure 8-107 Blue Sky Bar with Full Display Terrain Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 625 1) Turn the large FMS Knob to select the AUX Page Group. 2) Turn the small FMS Knob to select the AUX - System Status Page. Figure 8-108 LRU Information Window on System Status Page 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 626 Weather Datalink Page - center of page within last 5 minutes ACTIVATION REQUIRED Weather Datalink Page - center of page SiriusXM subscription is not activated Table 8-7 GDL 69/69A Data Link Receiver Error Messages Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 627: Annunciations And Alerts
OIL PRESS Oil pressure below 60 psi OXYGEN Oxygen cylinder closed PARK BRAKE Parking brake applied TORQUE Torque greater than or equal to 121.4% maximum torque Warning Messages 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 628 Vacuum pressure less than 3.75 in Hg * Only affected side (L, R, or L-R) displayed in CAS message; applicable messages listed here display L-R for example Caution Messages Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 629: Comparator Annunciations
No data from one or both heading sensors. PIT NO COMP No data from one or both pitch sensors. ROL NO COMP No data from one or both roll sensors.. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 630: Reversionary Sensor Annunciations
SYSTEM ANNUNCIATIONS When a new message is issued, the MSG Softkey flashes to alert the flight crew of a new message. It continues to flash until acknowledged by selecting the softkey. Active messages are displayed in white text. Messages that have become inactive change to gray text. The MSG Softkey flashes if the state of a displayed message changes or a new message is displayed. The inactive messages can be removed from the Message Window by selecting the flashing MSG Softkey. Message Advisories are displayed in the Messages Window and convey messages to the flight crew regarding problems with the G1000 or certain aircraft systems. Typically, a large red ‘X’ appears in a window when a related LRU fails or detects invalid data. The following section describes various system annunciations. Refer to the POH for additional information regarding pilot responses to these annunciations. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 631 Upon power-up of the G1000 system, certain windows remain invalid as G1000 equipment begins to NOTE: initialize. All windows should be operational within one minute of power-up. Should any window continue to remain flagged, the G1000 system should be serviced by a Garmin-authorized repair facility. System Annunciation Red ‘X’...
Page 632 Display system is not receiving altitude input from the air data computer. Display system is not receiving vertical speed input from the air data computer. Display system is not receiving valid transponder information. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 633: Message Advisories
MANIFEST – PFD2 software The PFD and/or MFD has incorrect software installed. The G1000 system should be mismatch, communication halted. serviced. MANIFEST – MFD1 software mismatch, communication halted. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 634: Database Message Advisories
The MFD and/or PFD detected a failure in the navigation database. Attempt to reload database error exists. the navigation database. If problem persists, the G1000 system should be serviced. PFD2 DB ERR – PFD2 navigation database error exists. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 635 PFD1 DB ERR – PFD1 airport terrain The airport terrain database is present on another LRU, but is missing on the specified database missing. LRU. PFD2 DB ERR – PFD2 airport terrain database missing. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 636 TERRAIN DSP – [PFD1, PFD2 or One of the terrain, airport terrain, or obstacle databases required for TAWS in the MFD1] Terrain awareness display specified PFD or MFD is missing or invalid. unavailable. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 637: Gia 63W Message Advisories
GIA1 COOLING – GIA1 over temperature. The GIA1 and/or GIA2 temperature is too high. If problem persists, the G1000 system should be serviced. GIA2 COOLING – GIA2 over temperature. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 638 Press the transfer switch again to cycle its operation. If the problem COM2 RMT XFR – COM2 remote persists, the G1000 system should be serviced. transfer key is stuck. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 639 A failure has been detected in glideslope receiver 1 and/or receiver 2. The receiver may still be available. The G1000 system should be serviced when possible. G/S2 SERVICE – G/S2 needs service. Return unit for repair. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 640: Gea 71 Message Advisories
AHRS1 GPS – AHRS1 not receiving The #1 AHRS is not receiving any or any useful GPS information. Check AFMS any GPS information. limitations. The G1000 system should be serviced. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 641: Gmu 44 Message Advisories
GSR 56 MESSAGE ADVISORIES Message Comments GSR1 FAIL – GSR1 has failed. A failure has been detected in the #1 GSR 56. The system should be serviced. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 642: Gdl 69A Message Advisories
S addres sconfigured or the mode S address does not match both XPDR mode S addresses. MANIFEST – GTS software The GTS has incorrect software installed. The G1000 system should be serviced. mismatch, communication halted. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 643: Gmc 710 Message Advisories
Verify stored airways. with the navigation database. This alert is issued only after an navigation database update. Verify use of airways in stored flight plans and reload airways as needed. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 644 A parallel course has been selected, causing the vertical deviation to go invalid. selected. TRAFFIC FAIL – Traffic device has The G1000 is no longer receiving data from the traffic system. The traffic device failed. should be serviced. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 645 An engine exceedance log has been captured. data is being logged. REGISTER GFDS – Data services are The system is not registered with Garmin Flight Data Services, or its current inoperative, register w/GFDS. registration data has failed authentication. TRN AUD FAIL – Trn Awareness audio The audio source for terrain awareness is offline.
Page 646: Afcs Alerts
NOTE: the preflight system test to fail or never to start (if servos fail their power-up tests). Power must be cycled to the servos to remedy the situation. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 647: Terrain-Svs Alerts
No GPS position Available” Excessively degraded GPS signal, Out of “Terrain System Not None database coverage area Available” Sufficient GPS signal received after loss None None “Terrain System Available” 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 648: Taws-B Alerts
Premature Descent Alert Caution (PDA) “Too Low, Terrain” Altitude Callout “500” None None “Five-Hundred” Excessive Descent Rate Caution (EDR) “Sink Rate” Negative Climb Rate Caution (NCR) “Don’t Sink” “Too Low, Terrain” Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 649: Other G1000 Aural Alerts
“Altitude not available” “Less than one mile”, Played to indicate distance of traffic from own aircraft (GTS 820 only). “One Mile” through “Ten Miles”, or “More than ten miles” 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 650: Flight Plan Import/Export Messages
The stored flight plan was not successfully exported to the SD card. The SD card may not have sufficient available memory or the card may have been removed prematurely. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 651: Database Management
NOTE: power-up screen and the effective date on the AUX-System Status Page being displayed in yellow. Garmin requests the flight crew report any observed discrepancies related to database information. NOTE: These discrepancies could come in the form of an incorrect procedure; incorrectly identified terrain, obstacles and fixes;...
Page 652 The dual navigation database feature allows each display to store an upcoming navigation database on the bottom SD card so that the system can automatically load it to replace the active database when the new database becomes effective (the next cycle becomes available seven days prior to its effective date). Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 653 5) After the navigation database files are copied to the bottom SD card, the display will appear as shown in Figure B-4. Figure B-4 Standby Navigation Database Update Complete 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 654 19) Press the Display Database Selection Softkey to show standby navigation database information for each display (MFD1 DB, PFD1 DB, PFD2 DB). Verify the correct standby navigation database cycle information is shown for each display. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 655: Garmin Databases
The obstacle database contains data for obstacles, such as towers, that pose a potential hazard to aircraft. Obstacles 200 feet and higher are included in the obstacle database. It is very important to note that not all obstacles are necessarily charted and therefore may not be contained in the obstacle database. This database is updated on a 56-day cycle. The data contained in the terrain and obstacle databases comes from government agencies. Garmin NOTE: accurately processes and cross-validates the data, but cannot guarantee the accuracy and completeness of the data. The AOPA Airport Directory provides data on airports and heliports throughout the U.S., and offers detailed information for over 5,300 U. S. airports, along with the names and phone numbers of thousands of FBOs. This...
Page 656 An indication of ‘Complete’ still requires a power cycle before the synchronized databases will be used by the system. Figure B-8 AUX-System Status Page, Database Window Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 657 Displayed for all other errors that may cause the synchronization process to be halted Timeout System timed-out prior to the database transfer completing Table B-1 Database Synchronization Error Messages UPDATING GARMIN DATABASES The Garmin database updates can be obtained by following the instructions detailed in the ‘Aviation Databases’ section of the Garmin website (fly.garmin.com). Once the updated files have been downloaded from the website, a PC equipped with an appropriate SD card reader is used to unpack and program the new databases onto an existing Supplemental Data Card. Equipment required to perform the update is as follows: • Windows-compatible PC computer (running Windows XP, Vista, or Windows 7) • SD Card Reader: SanDisk SDDR-93, SanDisk SDDR-99, Verbatim #96504, or equivalent...
Page 658 1) With system power OFF, remove the MFD database card from the bottom card slot of the MFD. 2) Update the Garmin databases on the MFD card. 3) Insert the MFD database card into the bottom card slot of the MFD.
Page 659 2) When the upload is complete, the prompt for the next GRS upload is displayed, as seen in Figure B-14. Figure B-14 GRS2 Magnetic Field Variation Database Update Prompt 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 660 3) With ‘OK’ highlighted, press the ENT Key on the MFD. A progress monitor is displayed as shown in Figure B-15. When the upload is complete, the system is ready for use. Figure B-15 Uploading Database to GRS2 Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 661: Glossary
The compass direction from the present cylinder position to a destination waypoint. beat frequency oscillator D ALT density altitude BKSP backspace DB, DBASE database bearing decibels ‘Z’ (radar return) center runway 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 662 Fuel On Board The total amount of usable fuel on board desired course on an active flight plan or the aircraft. direct-to. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 663 Left Over Fuel On Board The amount of fuel remaining on board hectopascal after the completion of one or more legs Horizontal Protection Level of a flight plan or direct-to. hour HSDB High-Speed Data Bus 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 664 Military Operations Area movement right, right runway meters per minute radial Minimum Safe Altitude RAIM Receiver Autonomous Integrity MSAS Multi-functional Satellite Augmentation Monitoring System random access memory Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 665 Heading Vector to Altitude standard VAPP VOR approach STRMSCP Stormscope variation Special Use Airspace Heading Vector to DME Distance SUSP suspend volts, direct current Synthetic Vision System 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 666 WAAS Wide Area Augmentation System WARN warning (GPS position error) WGS-84 World Geodetic System - 1984 waypoint(s) world wide weather XFER, XFR transfer XPDR transponder XTALK cross-talk cross-track Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 667: Frequently Asked Questions
If RAIM is not predicted to be available for the final approach course, the approach does not become NOTE: active, as indicated by the “RAIM not available from FAF to MAP” message and the LOI annunciation flagging on the HSI. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 668 Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 669 DOes tURn anticiPatiOn Begin The G1000 smooths adjacent leg transitions based on a normal 15° bank angle (with the ability to roll up to 30°) and provides three pilot cues for turn anticipation: • A waypoint alert (‘Next DTK ###° in # seconds’ or ‘Next HDG ###° in # seconds’) appears on the PFD 10 seconds before the turn point and flashes as it counts down to zero. • A flashing turn advisory (‘Turn [right/left] to ###° in # seconds’) appears on the PFD 10 seconds before the turn and flashes as it counts down to zero. ‘Turn [right/left] to ###° now’ or ‘Next [DTK/HDG] to ###° now’ is displayed when the pilot is to begin the turn and the HSI (GPS mode) automatically sequences to the next DTK or HDG value. • The To/From indicator on the HSI flips momentarily to indicate that the midpoint of the turn has been crossed. 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 670 FMS Knobs. Press the ENT Key to accept the selected airport, then follow the steps in the preceding paragraph to select an approach for the new airport. Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 671: Map Symbols
State or Province Border Heliport International Border NAVAIDS Road Item Symbol Railroad Intersection Latitude/Longitude LOM (compass locator at outer marker) NDB (non-directional radio beacon) VOR/DME VOR/ILS VORTAC TACAN 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 672 Traffic Enabled User Waypoint Vertical Navigation Along Track Waypoint Parallel Track Waypoint Unanchored Flight Path Waypoint Top of Descent (TOD) Bottom of Descent (BOD) Navigating using Dead Reckoning Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 673 Obstacle within 100 ft of (WARNING) or above aircraft altitude Yellow Obstacle within 1000 ft of (CAUTION) aircraft altitude Obstacle more than 1000 Gray ft below aircraft altitude Obstacle Symbols and Colors 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 674 Cyclone Warnings display enabled Icing Potential (CIP and SLD) (ICNG) Pilot Weather Report (PIREPs) Air Report (AIREPs) Turbulence (TURB) Loss of hazard avoidance feature (due to loss of GPS position) Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 675: Index
Bearing line ------------------------------------------ 388, 392 Annunciations, G1000 System ---------------------------- 21 Annunciator lights -----------------------------------------142 ANT/BFO ----------------------------------------------------133 Antenna stabilization -------------------------------------393 Cabin pressure altitude --------------------------------91, 94 Antenna tilt -------------------------------------------------390 Warning ------------------------------------------- 105, 613 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 676 Decision height (DH) --------------------------------------- 53 Flight director (FD) Declutter ----------------------------------------------------- 27 Switching -------------------------------------------------474 Declutter, display -------------------------------------------- 87 Flight ID -----------------------------------------------------141 Delete Flight Plans -----------------------------------------235 Flight Level Change Mode ------------------------- 481, 508 Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 677 LPV ---------------------------------------------- 276, 303, 503 GMA 1347 --------------------------------------------1, 16, 48 GMU 44 -------------------------------------------------------- 1 Go Around Mode -----------------------------491, 515–516 Magnetometer ------------------------------------------- 1, 20 GPS Window ------------------------------------------------643 Map pages --------------------------------------------------- 35 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 678 Nearest Airports Page ------------------------ 189, 190, 191 Operation -------------------------------------------------386 Nearest Pages (NRST) -------------------------------------- 37 Reflectivity ------------------------------------------------378 NEXRAD --------------------------------------------------23, 27 Safe Operating Distance -------------------------------380 NEXRAD Softkey -------------------------------------------358 Radar altitude -------------------------------------------83, 84 Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 679 SiriusXM radio presets ------------------------------------582 Terrain ------------------------------- 27, 414, 425, 622, 634 SiriusXM radio service class ------------------------------579 Color indications ----------------------------------------659 SiriusXM radio troubleshooting --------------------------611 Terrain Awareness and Warning System ----------------419 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 680 WIND Softkey -----------------------------------------------366 VDI ---------------------------------------------------- 294, 295 XM WX lightning ----------------------------------------23, 27 Vertical deviation ------------------------------------- 58, 485 XM WX Satellite Weather ---------------------------------308 Vertical deviation guidance ------------------------------251 AIRMETs --------------------------------------------------363 Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 681 Freezing Level --------------------------------------------332 Icing (CIP & SLD) ----------------------------------------338 Lightning -------------------------------------------------324 NEXRAD --------------------------------------------------318 Limitations -----------------------------------------------320 Pirep -------------------------------------------------------340 PIREPs-----------------------------------------------------340 SIGMETs --------------------------------------------------363 Surface Analysis -----------------------------------------330 Turbulence ------------------------------------------------339 Winds Aloft -----------------------------------------------333 Zoom Auto -------------------------------------------------------159 190-00709-04 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850...
Page 682: Index
INDEX lank Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-04 Rev. A...
Page 684 Garmin International, Inc. Garmin AT, Inc. Garmin (Europe) Ltd. Garmin Corporation 1200 East 151st Street 2345 Turner Road SE Liberty House, Bulls Copse Road No. 68, Jangshu 2nd Road Olathe, KS 66062, U.S.A. Salem, OR 97302, U.S.A. Houndsdown Business Park Shijr, Taipei County, Taiwan p:913.397.8200...
