104Z and set the panel controls for the ‘basic’ setup. Next, we'll explain how your MF-104Z works. After that we'll go through the panel features and give you suggestions on how to use your MF-104Z in some specific applications. At the end of this booklet, you'll find technical specifications, service, and warranty information, and information about Moog Music.
Here are simple instructions on how you can quickly plug in and try out your MF-104Z. 1. Unpack your MF-104Z. You can place it on a table or on a floor. We suggest that you place it on a table while you become familiar with its features.
Page 4
5. Connect an instrument cable from your signal source to the AUDIO IN jack. You can feed virtually any instrument-level or line-level signal through your MF-104Z. Examples are guitar, bass, keyboard, theremin, drum machine, or Effects Send output on your mixer.
Page 5
With the FEEDBACK control above 8, the echoes build up chaotically into some amazing electronic textures. In the next sections we'll explain how an analog delay works and look at your MF-104Z in more detail. For now, get a feel for your MF- 104Z's controls by experimenting with different settings.
The design of your MF-104Z Analog Delay is unique because it combines authentic, finely-tuned vintage analog bucket-brigade delay circuitry with analog-synthesizer-style voltage control of delay...
This characteristic gives a natural-sounding mix for most music signals. If you're applying a sustained steady pitch to the MF-104Z and the MIX control is set near midposition, you may find that the direct and delayed signals alternately reinforce and cancel each other in rapid succession as the delay time is varied.
Then, when you switch your MF-104Z on again, a new echo stream will begin to build up. This is a convenient way of `canceling' an echo stream while you're playing.
MF-104Z audio input circuitry. Once you set the DRIVE control as described above, the input level is optimized for best operation of your MF-104Z's circuitry. Do not change the DRIVE setting except to tweak the input level or to compensate for changes in the level of your instrument signal.
Page 10
LOOP OUT jack and the LOOP IN jack. Connect the external sound processor and set the LOOP GAIN control as follows: 1. Use patch cords to connect a) the MF-104Z LOOP OUT jack to the Audio In (instrument) jack on your processor, and b) the Audio Out (amplifier) jack on your processor to the MF-104Z LOOP IN jack.
TIME, and FEEDBACK, has an expression pedal/control input which duplicates its effect. This enables you to plug in up to three expression pedals to play the MF-104Z with your feet as well as your hands. The moogerfooger EP-1 Expression Pedal is designed for this purpose or you can use expression pedals with equivalent specifications.
MIDI-to-CV converters, etc. You will find examples of interfacing your MF-104Z with external control signals on Pages 19-20, and you will find technical information on Pages 17-18. TYPICAL SETUPS Here are a few interesting setups for your to experiment with. Try changing the knobs with your hands.
Page 13
This setup uses a moogerfooger CP-251 Control Processor to supply the slow random wave and to adjust the wave's amplitude with an attenuator. MF-104Z SETTINGS: DELAY TIME about .15 FEEDBACK Figure 5 - Setup for ECHOES WITH Setup continues on next page...
Page 14
(Adjusts depth of chorus.) CONNECTIONS: From SAMPLE-AND-HOLD OUT 2 to ATTENUATOR IN From ATTENUATOR OUT to TIME jack on MF-104Z AIRSHOW (FIG. 6) The FEEDBACK control is turned all the way up, so the background noise builds up to a constant rumble.
Page 15
Left Switch SHORT Right Switch INT.LOOP CP-251 LFO RATE 9 o'clock position (about 0.5 Hz) CONNECTIONS: From CP-251 LFO square wave output jack, to MF-104Z AUDIO IN jack. From MF-104Z MIX OUT jack, to your amplifier. NEPTUNE'S CANYON (RING MODULATOR IN EXTERNAL LOOP;...
Page 16
From MF-104Z LOOP OUT jack to MF-102 AUDIO IN jack. From MF-102 AUDIO OUT jack to MF-104Z LOOP IN jack. Sound source is plugged in to the MF-104Z AUDIO IN jack Amplifier is plugged in to the MF-104Z MIX OUT jack.
The AUX OUT goes directly to one input on your amplifier or mixer, while the main AUDIO OUT goes through the MF-104Z. Thus, the direct sound is not colored, but the echoes swirl because of the phaser modulation.
Page 18
CIRCUIT CONFIGURATION: Figure 9 is a simplified block diagram of the MF-104Z Analog Delay. Some unique features of the circuit are described in the following paragraphs. The input signal goes directly to a low -noise, high-input- Figure 9 - Simplified Block Diagram of the MF-104Z impedance buffer amplifier.
Page 19
MF-104SD. or worn potentiometers will contribute to audio noise. Technical specifications of all input and output jacks are given at the end of this booklet. POWER: The MF-104Z works satisfactorily on +9 to +15 volts DC and uses...
Page 20
The ring terminal should not be connected to anything, so that the MF-104Z's source of +5.0 volts is not shorted out. Or, if you do not plan to use any expression pedals with your MF-104Z but would...
During the one-year period, any defective products will be repaired or replaced, at Moog Music’s option, on a return-to-factory basis. This Warranty covers defects that Moog Music determines are no fault to the user.
Page 22
MF-104Z SPECIFICATIONS DESCRIPTION: JACK PANEL FEATURES: Analog effects module incorporating bucket brigade AUDIO IN 1/4” phone jack - accepts any analog delay circuit with voltage-controlled delay instrument - level or line-level signal from -16 time, feedback, and direct-delayed signal mix.
