User's manual
IS741
DECT 6.0 accessory doorbell
for use with VTech models
IS7121/IS7121-2/IS7121-22
on purchasing your new VTech product. Before using this
product, please read Important safety instructions on page 3
of this manual.
This manual has instructions on how to set up and
register your new doorbell. For more information, see the
Installation guide and Abridged user's manual that came
with your telephone base.
You may also view or download the online Complete
user's manual for a full set of installation and operation
instructions at www.vtechphones.com. In Canada, visit
www.vtechcanada.com.
Register online to get an additional 3-month warranty!
Visit www.vtechphones.com.
Congratulations
Registration
Register your product online for enhanced
warranty support.
Product news
Learn about the latest VTech products.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for VTech IS741IS741
Summary of Contents for VTech IS741IS741
- Page 1 DECT 6.0 accessory doorbell for use with VTech models IS7121/IS7121-2/IS7121-22 Congratulations on purchasing your new VTech product. Before using this product, please read Important safety instructions on page 3 of this manual. This manual has instructions on how to set up and register your new doorbell.
-
Page 2: Parts Checklist
Parts checklist Your telephone package contains the following items. Save your sales receipt and original packaging in the event warranty service is necessary. Doorbell power Screws for doorbell Screw for doorbell adapter wall mount () (bottom) Doorbell with Wall anchors () Alkaline wall mount cover batteries () - Page 3 Install doorbell battery • The doorbell can be supported by either AA batteries or AC power. However, you need to plug in AC power during doorbell registration or deregistration. Doorbell power adapter installation Loosen the screws and the metallic plates, then slide the metal part of the wires underneath the metallic plates as shown.
- Page 4 Plug the adapter into the domestic power supply. Plug! Add and register a doorbell Make sure you plug in AC power before pairing it to the telephone base. You can add another new doorbell (purchased separately) to your IS7121 telephone system. This telephone system accommodates up to two doorbells.
- Page 5 Doorbell location testing Before mounting the doorbell on a wall, make sure you test if the location you install the doorbell is in range, and adjust the camera angle to best suit your needs. You may unplug the AC power first so that you can move around more conveniently to make the tests.
- Page 6 • Avoid placing other cordless devices near the doorbell. They may cause interference. • Two built-in infrared LEDs are for night vision. Make sure the surrounding light source is sufficient for infrared operation. Test at the front door to determine when the infrared LEDs turn on.
- Page 7 Doorbell wall mount installation Make sure you have done Step 4 above before you mount the doorbell on the wall. Use the two holes on the doorbell wall mount cover to mark the desirable installation location on the wall. If you drill the holes into a stud, go to Step 3. -OR- If you drill the holes into the wall, insert the wall anchors into the holes.
- Page 8 Align the holes on the wall mount cover with the holes on the wall. Tighten the screws into the holes to secure the wall mount cover onto the wall. Align Use a sharp object to open a hole on the soft plastic part on the doorbell wall mount cover, then route the power adapter cord through the hole.
- Page 9 Loosen the screws and the metallic plates, then slide the metal part of the wires underneath the metallic plates as shown. Twist the screws to secure. Metallic Screws plate Metallic plate Wire with red end Wire with black end If you already have a wired doorbell installed, see Installing the doorbell with an existing wired doorbell on pages 12 and 13 to install your new IS741 doorbell unit.
- Page 10 7. Tighten the screw into the threaded socket at the bottom to secure. Tighten the screw Plug the adapter into the indoor domestic power supply. Plug!
-
Page 11: Remove The Screw
Detach doorbell from wall mount cover After an extended exposure to cold, heat or humidity, the doorbell gasket rubber may become sticky. If you need to remove the doorbell from its wall mount cover in case of battery replacement or doorbell relocation, follow the steps below. - Page 12 Installing the doorbell with an existing wired doorbell (optional) If you already have a wired doorbell installed, follow the instructions below to install your new IS741 doorbell unit. Turn off the power supply to the existing wired doorbell. Follow Step through Step 5 in Doorbell wall mount installation from pages to .
- Page 13 View View Right Left Option 2: Ring the rear doorbell of the existing wired doorbell and the IS7121 doorbell simultaneously. Angle Adjustment View View Right Left Transformer Transformer Rear Trans Front Chime/buzzer of wired doorbell If you do not connect domestic power supply nor install AA batteries to the IS741 doorbell, only the existing wired doorbell will ring when being pressed.
- Page 14 What does this limited warranty cover? The manufacturer of this VTech Product warrants to the holder of a valid proof of purchase (“Consumer” or “you”) that the Product and all accessories provided in the sales package (“Product”) are free from defects in material and workmanship, pursuant to the following terms and conditions, when installed and used normally and in accordance with the Product operating instructions.
- Page 15 VTech will return repaired or replaced Product under this limited warranty. Transportation, delivery or handling charges are prepaid. VTech assumes no risk for damage or loss of the Product in transit. If the Product failure is not covered by this limited warranty, or proof of purchase does not meet the terms of this limited warranty, VTech will notify you and will request that you authorize the cost of repair prior to any further repair activity.
- Page 16 A member of THE VTECH GROUP OF COMPANIES. Distributed in the U.S.A. by VTech Communications, Inc., Beaverton, Oregon 008. Distributed in Canada by VTech Technologies Canada Ltd., Richmond, B.C. V6W L5. VTech is the registered trademark of VTech Holdings Limited.
