LICHFIELD
NOTE: This appliance is fitted with a battery
powered ignition system. Should the ignition
system start to spark slowly - or not at all, the
battery will need replacing. See the section on
battery replacement.
Use and Installation Instructions
The cooker must be installed in accordance with the regulations in force
and only used in a well ventilated space.
Read these instructions prior to using the cooker and retain them for
future reference.
Part no. 4966200040-01
