CARRICK
C60GCIS
C60GCIW
C60GCIK
C60LCIS
C60LCIW
C60LCIK
Use and Installation Instructions
This appliance must be installed in accordance with the regulations in force and
only used in a well ventilated space.
Read these instructions before installing or using the appliance and retain
them for future reference.
Advertisement
Table of Contents
Related Manuals for Cannon Carrick
Summary of Contents for Cannon Carrick
- Page 1 CARRICK C60GCIS C60GCIW C60GCIK C60LCIS C60LCIW C60LCIK Use and Installation Instructions This appliance must be installed in accordance with the regulations in force and only used in a well ventilated space. Read these instructions before installing or using the appliance and retain...
-
Page 2: Table Of Contents
CONTENTS PAGE Introduction For Your Safety Oven Timer Operation Hotplate Grill Main Oven Main Oven Cooking Chart The “Slow Cook” Setting Top Oven Top Oven Cooking Chart Care and Cleaning Something wrong with your Cooker? Installation Instructions Guarantee Information Service Information... -
Page 3: Introduction
INTRODUCTION To help you make the best use of your cooker, PLEASE READ THIS BOOKLET CAREFULLY. Your new cooker is guaranteed and will give lasting service. The guarantee is only applicable if the cooker has been installed in accordance with the Installation Instructions. The cooker is designed specifically for domestic use and responsibility will not be accepted for use in any other installation. -
Page 4: For Your Safety
FOR YOUR SAFETY Please read the precautions below before using your cooker. ALWAYS . . . ALWAYS make sure you understand the controls before using the cooker. ALWAYS check that all controls on the cooker are turned off after use. ALWAYS stand back when opening an oven door to allow heat to disperse. - Page 5 FOR YOUR SAFETY NEVER . . . NEVER leave children unsupervised where the cooker is installed as all surfaces will get hot during and after use. NEVER allow anyone to sit or stand on any part of the cooker. NEVER store items that children may attempt to reach above the cooker.
-
Page 6: Oven Timer Operation
OVEN TIMER OPERATION The oven timer offers you the following features: 1. Time of Day 2. Automatic Cooking 3. Minute Minder AUTOMATIC COOKING The main oven can be controlled automatically. GUIDANCE ON AUTOMATIC COOKING 1. Select foods which will take the same time to cook. 2. - Page 7 OVEN TIMER OPERATION CLOCKFACE The timer incorporates a 24 hour clock. 0 0 0 Ensure the correct time of day is always set, before using your cooker. SYMBOLS A 'bell' symbol will light up when you select a Minute Minder Period and will remain lit for the 0 0 0 period set.
- Page 8 OVEN TIMER OPERATION SETTING THE TIME OF DAY Step 1 Make sure all oven controls are turned Off. 0 0 0 Step 2 Check the electricity supply to the cooker is turned on. Step 3 When switched on the display will show 0.00 and the Auto symbol, flashing intermittently.
- Page 9 OVEN TIMER OPERATION AUTO COOKING PROGRAMMES There are two Auto Cooking programmes that can be selected using your timer:- (a) To set the timer to switch the oven(s) On and Off Automatically (b) To set timer to switch on immediately and OFF automatically after a set cook period. a) TO SET THE TIMER TO SWITCH THE OVEN(S) ON AND OFF AUTOMATICALLY This allows you to cook at a specified time for a chosen period before the oven switches off Automatically.
- Page 10 OVEN TIMER OPERATION Note 1 When cooking automatically the Cook Period can be checked at any time by simply pressing the Cook Period button. Note 2 When cooking automatically the End Time can be checked at any time by simply pressing the End Time button.
- Page 11 OVEN TIMER OPERATION TO CANCEL AN AUTO COOKING PROGRAMME BEFORE THE COOK PERIOD HAS FINISHED. Step 1 Turn the oven control to the OFF position. Step 2 Press the Manual button to return the oven to "Manual" operation. The 'Auto' sym- bol will go out.
-
Page 12: Hotplate
HOTPLATE The hotplate lid is fitted with a safety device which cuts off the gas supply to the hotplate burners unless the lid is fully open. Do not use the safety device as a means of controlling the hotplate burners. The hotplate has two high speed burners and two simmering burners which will accommodate pans between 100mm (4”) and 240mm (9 ½”) diameter. - Page 13 HOTPLATE SAFETY REQUIREMENTS FOR DEEP FAT FRYING 1. Never fill chip pans more than one third full with oil or fat. 2. Never leave oil or fat unattended during the heating or cooling period. 3. Never heat fat or fry with a lid on the pan. 4.
-
Page 14: Grill
GRILL CAUTION - ACCESSIBLE PARTS MAY BECOME HOT WHEN THE GRILL IS USED. YOUNG CHILDREN SHOULD BE KEPT AWAY. The grill is fitted with a safety device that will cut off the gas supply to the burner if the flame is extinguished for any reason. - Page 15 TO USE THE GRILL 1. Open the top oven/grill door and remove the grill pan. 2. Remove the heat shield from the rear of the shelf for maximum grilling area and place shelf in appropriate position. 3. Push in and turn the control knob clockwise to the large flame symbol. Continue to push in the control knob for a further 3 seconds after the gas has lit, to allow time for the safety device to operate.
-
Page 16: Main Oven
MAIN OVEN The main oven is fitted with a safety device that re-lights the burner if the flame has been extinguished for any reason and another safety device that reduces the gas flow to a safe level if, for any reason, the burner fails to light. - Page 17 MAIN OVEN COLD START COOKING Anything requiring long slow cooking such as casseroles and rich fruit cakes can be put into a cold oven. Satisfactory results can also be obtained with creamed mixture, rich pastries or yeast mixtures, but for perfection we recommend preheating the oven for about 15 minutes at the gas mark you require for cooking.
-
Page 18: Main Oven Cooking Chart
MAIN OVEN COOKING CHART The following times and setting are for guidance only. You may wish to alter the setting to give a result more to your satisfaction. When a different setting to that shown below is given in a recipe, the recipe instructions should be followed. - Page 19 MAIN OVEN COOKING CHART Shelf Food Approx. Cooking Time and Comments Mark Positions CAKES, PASTRIES AND BISCUITS Small cakes - 2 trays 1 & 3 17 - 25 mins 2 or 3 - 1 tray " only Victoria sandwich 2x8" (205mm) 1 &...
-
Page 20: The “Slow Cook” Setting
THE ‘SLOW COOK’ SETTING The 'Slow Cook' setting on the main oven thermostat is used for slow cooking, keeping food warm and warming plates for short periods. USING THE 'SLOW COOK' SETTING FOR SLOW COOKING 1. All dishes cooked by the 'Slow Cook' setting should be cooked for a minimum 6 hours. They will 'hold' at this setting for a further hour but marked deterioration in appearance will be noticed in some cases. -
Page 21: Top Oven
TOP OVEN The top oven can be used to cook small quantities of food or used in conjunction with the main oven to provide additional cooking space. The top oven is fitted with a safety device that will cut off the gas supply to the burner if the flame is extinguished for any reason. -
Page 22: Top Oven Cooking Chart
TOP OVEN COOKING CHART The following times and setting are for guidance only. You may wish to alter the setting to give a result more to your satisfaction. When a different setting to that shown below is given in a recipe, the recipe instructions should be followed. - Page 23 TOP OVEN COOKING CHART Shelf Food Approx. Cooking Time and Comments Mark Positions CAKES, PASTRIES AND BISCUITS Small Cakes (16 per tray) 20 - 25 mins Victoria sandwich (2x180mm / 7 ") 25 - 30 mins. Swiss Roll (3 egg quantity) 10 - 12 mins.
-
Page 24: Care And Cleaning
CARE AND CLEANING ! Never use steam cleaners or pressure cleaners on the appliance. Clean the glass part of the oven door using a sponge and a non-abrasive cleaning product, then dry thoroughly with a soft cloth. Do not use rough abrasive material or sharp metal scrapers as these could scratch the surface and cause the glass to crack. - Page 25 CARE AND CLEANING COOKER FINISH CLEANING METHOD Cloth wrung out in warm soapy water. Stubborn stains can be Vitreous Enamel removed with a cream paste, liquid cleaner or by rubbing with Door inner panels, pan supports, burner caps, fine steel wool soap pads. roasting dish, grill pan, main oven base, inside Check that the cleaning agent is approved by the Vitreous of grill compartment.
-
Page 26: Something Wrong With Your Cooker
SOMETHING WRONG WITH YOUR COOKER Before contacting your nearest Service Centre/Installer, check the problem guide below; there may be nothing wrong with your cooker. PROBLEM CHECK Burner will not light: If all burners fail to ignite: Check that sparks appear at the burners; a clicking noise should be heard. - Page 27 SOMETHING WRONG WITH YOUR COOKER PROBLEM CHECK This is normal and should cease after a short period. Slight odour or small amount of smoke when grill / oven used first time. Check that the oven temperature and shelf positions are as Oven cooks too fast or too slow.
-
Page 28: Installation Instructions
INSTALLATION INSTRUCTIONS Prior to installation, ensure that the local distribution conditions (nature of the gas and gas pressure) and the adjustment conditions are compatible. The adjustment conditions for this appliance are stated on the data badge which is fitted on the back panel. This appliance is not designed to be connected to a combustion products evacuation device. - Page 29 INSTALLATION INSTRUCTIONS TECHNICAL DATA Gas connection Rp ½ (½" BSP female) Pressure test point Front left hotplate injector Gas rate adjustment None Aeration adjustment None Electrical connection Flexible cord fitted with a 3 pin 13 amp plug 230/240V a.c. 50Hz. 13A fuse. G30 at 28-30mbar G20 at 20mbar G31 at 37mbar...
- Page 30 INSTALLATION INSTRUCTIONS SPACE FOR FIXING The cooker can be close fitted below hotplate level. This requires a minimum distance of 600mm between cupboard units of hotplate height. When installing next to a tall cupboard, partition or wall, for a minimum distance of 400mm above hotplate level, allow a side clearance of at least 65mm.
- Page 31 INSTALLATION INSTRUCTIONS UNPACKING THE COOKER Unpack the components from inside the grill and oven. Check that the following parts are present: Grill pan and grid Top oven/grill shelf heat shield Baking dish Pan supports Main oven shelves (2) Enamelled burner caps (4) Top oven/grill shelf (1) Literature Aluminium burner bodies (4)
- Page 32 INSTALLATION INSTRUCTIONS STABILITY CHAIN A hole in the gas inlet valve bracket can be used to engage a stability chain. CONNECTING TO GAS SUPPLY Connection to the cooker should be made with an approved appliance flexible connection to BS 669. A length of 0.9 to 1.25m is recommended.
- Page 33 ELECTRICAL CONNECTION WARNING - THIS APPLIANCE MUST BE EARTHED. CONNECT TO A 230-240V A.C. SUPPLY ONLY. Connection to the electricity supply should be made via a properly earthed, readily accessible wall socket which is adjacent to but not directly above, and not more than 1.25m away from the appliance and capable of electrical isolation.
- Page 34 INSTALLATION INSTRUCTIONS INSTALLATION AND OPERATIONAL CHECKS After installation, check for gas soundness. The supply pressure can be checked at the front left hotplate burner injector. Fit the hotplate burner bodies and caps, pan supports and shelf shield(s). Referring to the instructions for use where necessary, 1.
-
Page 35: Guarantee Information
We have a dedicated team who can provide free advice and assistance with your appliance if you experience any technical difficulties within the first 90 days of ownership. Simply call our Cannon Service Hotline on 08709 066 066 (ROI 0818 313 413) for telephone assistance, or, where necessary, to arrange for an engineer to call. -
Page 36: Service Information
After Sales Service No one is better placed to care for your Cannon appliance during the course of its working life than us - the manufacturer. Essential Contact Information Cannon Service We are the largest service team in the country offering you access to 400 skilled telephone advisors and 1100 fully qualified engineers on call to ensure you receive fast, reliable, local service.
