This manual covers the information you need to service or upgrade both the LP200C and LP200T LCD PCs. The two
models mainly differ in appearance. All the description in this manual applies to both models unless otherwise speci-
fied.
Information about operating the computer (e.g. getting started, and the System Configuration Utility) is in the User's
Manual. Information about drivers (e.g. VGA & audio) is also found in the User's Manual. That manual is shipped
with the computer.
Operating systems (e.g. Windows 98 Second Edition, Windows 2000 Professional, etc.) have their own manuals as do
application software (e.g. word processing and database programs). If you have questions about those programs, you
should consult those manuals.
The LCD PC comes with a built-in 15" LCD display and is upgradeable in the areas of CPU, system memory and hard
disk. See Chapter 3, "Disassembly," for a detailed description of the upgrade procedure for each specific component.
This chapter briefly introduces the computer's technical specifications, external features and system board features.
1 – 1
Advertisement
Table of Contents
Related Manuals for Clevo LP200C
Summary of Contents for Clevo LP200C
- Page 1 NTRODUCTION VERVIEW This manual covers the information you need to service or upgrade both the LP200C and LP200T LCD PCs. The two models mainly differ in appearance. All the description in this manual applies to both models unless otherwise speci- fied.
-
Page 2: Systm Specifications
1. I NTRODUCTION YSTM PECIFICATIONS NTEL ELERON Socket Type Socket 370 (PPGA) Speed 500/533/600/633MHz L1 cache (in CPU) 16KB code + 16KB data L2 cache (on die) 128KB NTEL ENTIUM Socket Type Socket 370 (FCPGA) Speed 600/650/700/750/800MHz L1 cache (in CPU) 16KB code + 16KB data L2 cache (on die) 256KB... -
Page 3: Storage Devices
1. I NTRODUCTION BIOS Insyde 2Mb Flash ROM, APM 1.2, ACPI IDEO Controller built-in SiS630 Memory* SSMA Interface digital I/F Display built-in 15” LCD color TFT XGA (1024 x 768), 256K colors Port analog 15-pin VGA port for CRT *The system allocates or “shares” a portion of system memory for video use. “Shared memory size is user-configurable via the SCU. - Page 4 TI 1420 Socket (x 2) Type II or (x 1) Type III Controller SMSC37N869 Ports (x 4) LP200C (x 2) LP200T Serial (x 1) 9-pin, 16550A compatible (x 1) infrared (modes: IrDA, ASK, FIR) Parallel (x 1) 25-pin (modes: Standard AT, Bidirectional, ECP, EPP)
-
Page 5: Power System
1. I NTRODUCTION NPUT Keyboard (dealer option) 104-key, AT-compatible, with special function keys OMMUNICATIONS ODEM Type MDC, V.90, 56K (software-based) Output RJ-11 jack (on-board) (* The modem module is a dealer option.) Type built-in SiS630 Output RJ-45 jack (on-board) ECURITY BIOS Password Kensington Lock Port OWER... -
Page 6: Physical Specifications
1. I NTRODUCTION HYSICAL PECIFICATIONS Dimensions W: 369mm (14.5”) L: 384mm (15.1”) D: 175mm (6.9”) Weight 7.9Kg/17.4lbs Panel Tilt to 15 Stand Swivel NVIRONMENTAL PECIFICATIONS EMPERATURE Operating C to 35 F to 95 Storage C to 65 C (14 F to 149 UMIDITY CONDENSING Operating... - Page 7 1. I NTRODUCTION XTERNAL OCATOR The following figures show the external locations of the main features of the LCD PC. LP200C LP200T RONT . 1 – 1 1. LCD 2. Speakers 3. FDD activity LED 4. CD-device activity 5. HDD activity LED 6.
- Page 8 1. I NTRODUCTION . 1 - 2 1. PC Card (PCMCIA) socket 2. PC Card eject button 3. LCD brightness control 4. Microphone input jack 5. Line-in jack 6. Phones out jack 7. Volume control knob 8. HDD bay Left View 1 –...
- Page 9 1. FDD bay 2. CD-Device bay 3. Emergency eject button - Use a probe (e.g. a straightened paper clip). 4. Eject button 5. Kensington lock port 6. AC-in port 7. two USB ports (* LP200C only) Right View 1 – 9...
- Page 10 1. I NTRODUCTION . 1 - 4 1. Serial port (COM A) 2. Printer/Parallel port 3. VGA port 4. PS/2 mouse port 5. PS/2 keyboard port 6. USB ports (x2)) 7. IEEE1394 port 8. RJ-45 LAN port 9. RJ-11 Modem port Rear View 1 –...
-
Page 11: Key Parts
1. I NTRODUCTION YSTEM OARD VERVIEW ARTS Top View Bottom View ARTS . 1 - 5 1. CPU (Intel Pentium III or Celeron) with Fan 2. SMSC37N869 Super I/O Controller 3. Flash ROM 4. two DIMM Sockets 5. CMOS Battery 6. -
Page 12: Cable Connectors , Switches & Jumpers
1. I NTRODUCTION & & J ONNECTORS WITCHES ABLE ONNECTORS WITCHES UMPERS UMPERS . 1 - 6 1. CN1 (Inverter Cable) 2. CN2 (Power Cable) 3. CN4 (Power Cable) 4. CN6 (FDD Cable) 5. CN22 (CD Device Cable) 6. CN35 (USB Cable) 7.
