Faber CRIS30 Datasheet

Cristal HC - Slide Out Range Hood
powerful, practical, efficient under cabinet range hood
For a streamlined look in the kitchen, the Cristal HC is your integrated range hood solution. The Cristal HC has a sleek
pull-out visor which slides in, flush with your cabinets, neatly tucking the hood away. For total integration, the front
strip can be replaced with material to match your cabinets, hiding the range hood completely.
Model # Size | Color
CRIS30
30 BK,WH,AL
CRIS36
36 BK,WH,AL
white, black and brushed aluminum front trims come with every Cristal HC in the box
* Note – ran 30 minutes a day on low speed with the lights on, 365 days, using the North American average of 12.2 cents per kWh.
p.o. box 435 • Wayland, MA 01778 • tel: (508) 358-5353 • fax: (508) 358-5730 • e-mail: info@faberonline.com • www.faberonline.com
Performance Range
170 - 500 CFM
170 - 500 CFM
Cabinet Cut Out
Convertible to Recirculating
Controls
Lighting
Ducting Top
Ducting Direct Rear Vent
Grease Filters
Auto On / Off
Integrate front panel
Built In Mounting Hardware
AC Input
AC Power
Green Energy Saver Mode Yes
Annual Electricty Costs
Sound Levels
2.0 - 6.0 sones
2.0 - 6.0 sones
Feature Chart
25 1/8" or 31 1/8" (W) x 9 5/8" (D)
Yes - charcoal kit needed, need air return back
into the kitchen out of the cabinet
3 Speed Slider
1 X 15 (W) Fluorescent
6" Round
6" Round
dishwasher safe mesh
Yes - fan / lights turn on when pulled out
Yes - Use your own custom wood front
Yes - EasySnap Mounting Clips
120 V - 60 hz
Max 315 W at 2.9 A
$2.47 / Year *
Choose from a white, black, or
brushed aluminum front strip (all
are included in the box). For a
totally integrated look, the front
strip can also be replaced with a
custom built strip to match your
cabinets. See reverse for front
panel dimensions.
