Appendix B - Connector and Cable Pin Outs

Appendix B - Connector and
Cable Pin Outs

Pin Outs for V.35 Female Connector (DTE)

V.35 (DTE) Signal
A Chassis Ground
B Signal Ground
C Request to Send
D Clear to Send
E Data Set Ready
F Receive Line Signal Detect
H Data Terminal Ready
J Local Loopback
P Tx Data
R Rx Data
S Tx Data
T Rx Data
U Tx Clock Out
V Rx Clock In
W Tx Clock Out
X Rx Clock In
Y Tx Clock In
AA Tx Clock In
31
↔
↔
→
←
←
←
→
→
→
←
→
←
→
←
→
←
←
←
