22
Chapter 6 - Basic Configuration Guide
PPP Configuration
This section covers the settings required for PPP (point-to-point)
protocol operation of the WAN interfaces.
Link Configuration
Required for Dedicated/Leased Line Operation
Dedicated line operation is the simplest to set up.
•
Set Dedicated connection
•
Set PPP connection
CV: Use the Link Configuration: WAN 1 Dialog Box.
TB: Use configure and set the Mode and ConnectMode keywords in
the Link Config WAN 0 (and/or WAN 1) section.
Suggested for Dedicated/Leased Line Operation
Dedicated line operation generally does not require additional parame-
ters for operation.
Required for Dial-On-Demand Operation
Incoming dial-on-demand operation requires only slightly more infor-
mation than dedicated line setup. Outgoing dial-on-demand requires
additional information (see the suggested settings below).
•
Set dial-up connection
•
Set PPP connection
•
Set to allow dial-in and/or dial-out
CV: Use the Link Configuration: WAN Dialog Box.
TB: Use configure and set the Mode, ConnectMode, DialIn and/or
DialOut keywords in the Link Config WAN 0 (and/or WAN 1)
section.
Suggested for Dial-On-Demand Operation
This mode of operation is only supported on the WAN 1 RS-232 inter-
face. Outgoing dial-on-demand requires some additional information.
•
Create dial-out script
•
Set dialing method
•
Set dial-out script to be used
•
Set inactivity time
CV: Use the Link Configuration: WAN 1 Dialog Box to set the dialing
