KORTING HG 695 CX Instruction Manual

Built-in gas hobs
Hide thumbs

Advertisement

Quick Links

Download this manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the HG 695 CX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for KORTING HG 695 CX

Summary of Contents for KORTING HG 695 CX

  • Page 3 HG 695 CX – HG 695 CTX – HG 695 CTN – HG 995 CTX –...
  • Page 5 93/68: 90/396: 2006/95/CE: “ ” 2004/108/CE: 1935/2004: 2002/95/CE: RoHS . .) ..)
  • Page 6 220-240 V ~ 50/60 Hz 100° C; . 1.1 . 1.2 . 1.1.
  • Page 7 . 1.2. . 2. F = 10mm G = 15mm E = 180cm² H = 50mm D = 120cm² C = 30mm . 2.
  • Page 8 (C), (B), . 3. 1 kW (A). (A).
  • Page 9 . 4. (C), (E), - (L) - (N) – . 5.
  • Page 10 L- N- III, 50° C T90°C). Ø 0,75 ².
  • Page 11 ½ D – E – F – . 6. (J), . 7.
  • Page 12 G30/G31 20 mbar 28-30/37 mbar , kW , kW Ø 1.00 0.30 0.72 0.50 1.75 0.44 0.97 0.65 3.00 0.75 1.15 0.85 3.30 1.50 1.24 0.91 G30/G31 . 8.1 . 8.2 . 8.3...
  • Page 13 . 9.
  • Page 14 . Ø, . Ø, . Ø, . Ø, – 180 - 200 . 10). . 10. . 11. “WOK” ( . 11) – «WOK» «WOK»...
  • Page 15 “E” . 12. “T” . 12), . 12...
  • Page 16 2002/96/EC, WEEE,...
  • Page 17 INSTRUCTIONS MANUAL Built-in gas hobs HG 695 CX – 60 cm gas hob HG 695 CTX – 60 cm gas hob HG 695 CTN – 60 cm gas hob HG 995 CTX – 90 cm gas hob...

  • Page 19: Declaration Of Compliance

    DECLARATION OF COMPLIANCE This appliance complies with the following European Directives: 93/68: General Regulations 90/396: “Gas Appliances” 2006/95/CE: “Low voltage” 89/336/CEE: Electromagnetic compatibility CE Regulation 1935/2004: this appliance is suitable to come in contact with food products. 2002/95/CE: RoHS directive GENERAL WARNINGS Read carefully the instructions manual before starting to use the appliance.

  • Page 20: Installation

    TECHNICAL CHARACRETISTICS Voltage and power supply frequency: 220-240 V ~ 50/60 Hz For the detailed information about the technical characteristics of the oven, see the technical data label on the back of the last page of the present manual, or the product data plate, that is located on the bottom of the appliance.
  • Page 21 Figure 1.2. Important: If the hob is installed and there is no oven below it, you need to put a separator panel between the bottom of the hob and the top of the furniture below, which should be positioned at a minimum distance of 10 mm below the hob.
  • Page 22 Fixing the hob to the worktop. To fix the hob in the housing, proceed as follows, see figure 3 below: - Position the special gasket supplied (C) along the outer perimeter of the worktop, following the scheme shown in figure 1.1 or 1.2 above, so that the ends of the gasket meet exactly without overlapping. - Position the hob into the worktop, ensuring that it is placed exactly in the centre.

  • Page 23: Electrical Connection

    C = Hood for exhaust removal of combustion fumes E = Electric extractor fan for removal of combustion fumes A = Opening for air supply Figure 4. The opening A must be free and keep assured that it is not obstructed from the inside or outside. Preferably position it on the floor level, on the opposite side of the fume exhaust devices.

  • Page 24: Connection To Gas Supply

    1. Open the terminal board by placing a screwdriver under the side flaps on the cover, pull and then open the cover. 2. Install the power supply cable, unscrew the screws on the cable grip and the three screws on contacts L- and then attach the wires under the screw heads respecting the colours: 3.
  • Page 25 D – Gas supply connector E – Seal F – Gas pipe Figure 6. Important: to connect the appliance to LPG supply, place a pressure regulator which is compliant with the current standards between the pipe and the gas tank. Attention: when finished, check that there are no gas leaks.

  • Page 26: Injectors Table

    INJECTORS TABLE Type of gas G30/G31 Gas pressure 20 mbar 28-30/37 mbar Burner type Max power input, kW Min power input, kW injector Ø Auxiliary 1.00 0.30 0.72 0.50 Semi-Rapid 1.75 0.44 0.97 0.65 Rapid 3.00 0.75 1.15 0.85 Triple Ring 3.30 1.50 1.24...
  • Page 27 HOW TO USE THE GAS HOB The release of the gas into the burners is controlled by the taps which are controlled by the knobs as shown in Figure 9 below. The corresponding symbols of different models may be printed either on the knobs or on the control panel. By moving the indicator in correspondence of the printed symbols, the following adjustments can be made: Tap closed, (no gas released).

  • Page 28: Cleaning And Maintenance

    Pan diameter table Type of hob Type of burner All models 60 cm front control Min. Ø, mm Max. Ø, mm Min. Ø, mm Max. Ø, mm Auxiliary with reducer with reducer front – 180 Semi-Rapid rear - 200 Rapid Triple Ring USING THE GRIDS The grids are designed to make the appliance easy and safe to use.
  • Page 29 Enameled hobs. All the enameled parts must be cleaned with a sponge and soapy water or specific detergents. Rinse and dry the hob carefully after cleaning. Stainless Steel hobs. The stainless steel hobs should be cleaned with damp cloth and special detergents available in commerce. Rinse and dry the hob carefully after cleaning.
  • Page 30 DISPOSAL Packaging. The parts of the hob packaging (cardboard, EPS expanded polystyrene, PE plastic bags) should be disposed of in compliance with local environmental regulations and using appropriate separated collection channels. Hob. Disconnect the hob from the power supply. Before scrapping the appliance, make it unusable by cutting the power cord. This appliance is marked in compliance with European Directive 2002/96/EC, Waste Electrical and Electronic Equipment (WEEE).
  • Page 32 H01A7750...
