Page 1: Washing Machine
Wasautomaat ZANKER SF 2000 Lave-linge SF 2200 Waschautomat Washing machine Gebruiksaanwijzing Notice d’utilisation Bedienungsanleitung User manual 132989980... - Page 2 Dear customer, Please read these operating instructions carefully and pay particular attention to the safety notes indicated in the first pages. We recommend that you keep this instruction booklet for future reference and pass it on to any future owners. Transport damages When unpacking the appliance, check that it is not damaged.
-
Page 3: Table Of Contents
Contents Warnings 68-69 Maintenance Bodywork Disposal Door seal Detergent dispenser drawer Tips for environmental protection Drain pump 82-83 Water inlet filter Technical specifications Emergency emptying out Frost precautions Installation Unpacking Something not working? 84-85 Positioning and levelling Water inlet 71-72 Water drainage Electrical connection Your new washing machine... -
Page 4: Warnings
Warnings The following warnings are provided in the interests of overall safety. You must read them carefully before installing or using the appliance. Installation • All internal packing must be removed before using • Leave the porthole door slightly ajar when the the appliance. -
Page 5: Disposal
Child safety • Keep all detergents in a safe place out of • Children are often not aware of how dangerous children’s reach. electrical appliances can be. When the machine is working, children should be carefully supervised • Make sure that children or pets do not climb into and not be allowed to play with the appliance. -
Page 6: Technical Specifications
Technical specifications DIMENSIONS Height 85 cm Width 60 cm Depth 59 cm MAXIMUM LOAD Cotton 4.5 kg Synthetics 2 kg Delicates 2 kg Woollens 1 kg SPIN SPEED 1000 rpm max. (SF 2000) 1200 rpm max. (SF 2200) POWER SUPPLY VOLTAGE/FREQUENCY 220-230 V/50 Hz TOTAL POWER ABSORBED 2200 W... -
Page 7: Installation
Installation Unpacking 7. Plug all the holes with the plugs which you will All transit bolts and packing must be find in the envelope containing the instruction removed before using the appliance. booklet. You are advised to keep all transit devices so that they can be refitted if the machine ever has to be transported again. -
Page 8: Water Drainage
The other end of the inlet hose which connects to Directly into a drain pipe at a height of not less the machine can be turned in any direction. Simply than 60 cm and not more than 90 cm. loosen the fitting, rotate the hose and retighten the The end of the drain hose must always be fitting, making sure there are no water leaks. -
Page 9: Your New Washing Machine
Your new washing machine This new machine meets all modern requirements for effective treatment of laundry with low water, energy and detergent consumption. • The temperature selector dial will allow you to choose the most suitable temperature for your laundry. •... -
Page 10: Use
Control panel 1 Detergent dispenser drawer 6 Extra Rinse button (SPOELEN + / RINCAGE +) 2 Mains on light By depressing this button the machine will perform the rinses with more water. It can be used only for This light comes on when the machine starts cotton programmes. -
Page 11: Washing Hints
Laundry weights Washing hints The following weights are indicative: bathrobe 1200 g Sorting the laundry napkin 100 g Follow the wash code symbols on each garment quilt cover 700 g label and the manufacturer’s washing instructions. sheet 500 g Sort the laundry as follows: whites, coloureds, synthetics, delicates, woollens. -
Page 12: Detergents And Additives
Ink: depending on the type of ink, moisten the fabric Quantity of detergent to be used first with acetone (*), then with acetic acid; treat any The type and quantity of detergent will depend on residual marks on white fabrics with bleach and then the type of fabric, load size, degree of soiling and rinse thoroughly. -
Page 13: International Wash Code Symbols
International wash code symbols These symbols appear on fabric labels, in order to help you choose the best way to treat your laundry. Energetic wash Max. wash Max. wash Max. wash Max. wash temperature temperature temperature temperature 95°C 60°C 40°C 30°C Hand wash Do not... -
Page 14: Operating Sequence
Operating sequence Before the first wash we recommend that you pour 2 litres of water into the main wash compartment 4. Select the desired option of the detergent drawer in order to activate the ECO Depress the button “SPOELEN + / RINCAGES + ”, if valve. - Page 15 7. Select the programme and start the machine Turn the programme selector dial clockwise to the required programme and press the ON/OFF button: the mains on light comes on and the machine starts to operate. 8. At the end of the programme The machine stops automatically.
-
Page 16: Washing Programmes
Programme table Washing programmes for cotton and linen Consumptions* Additional Wash Programme Temp. Fabrics Energy Water Duration functions load max. min. Katoen m. WHITES WITH SPIN SUPPRESSION voorwas PREWASH, for SPIN example work 60°-95° 4.5 kg REDUCTION Coton avec garments, sheets, prélavage household linen, EXTRA RINSE... - Page 17 Programme table Washing programmes for synthetics, mixed fabrics, delicates and wool Consumptions* Additional Wash Programme Temp. Fabrics Energy Water Duration functions load max. min. Synthet. m. SYNTHETICS WITH voorwas PREWASH, for example 30°-60° 2 kg Synthét. underwear, prélavage coloured items, shirts, blouses SYNTHETICS Synthetica...
-
Page 18: Maintenance
Maintenance 1. Bodywork Detergent can also accumulate inside the drawer recess: clean it with an old toothbrush. Refit the Clean the outside of the machine with soap and drawer after cleaning. water only. Rinse with clean water and dry with a soft cloth. -
Page 19: Water Inlet Filter
• Remove any objects from the pump impeller by 7. Frost precautions rotating it. If the machine is installed in a place where the • Put the cap back on the emergency emptying temperature could drop below 0°C, proceed as hose and place the latter back in its seat. -
Page 20: Something Not Working
Something not working? Problems which you can resolve yourself, before calling the After Sales Service. Problem Possible cause • The machine does not start up: • The door is not firmly closed. • The machine is not plugged in or there is no power at the socket. - Page 21 Problem Possible cause • Water is not visible in the machine: • The machine, which is the result of modern technology, runs in a very economical way with low water consumption. Performance is nevertheless excellent. • Spinning starts late or the machine •...
- Page 22 From the Electrolux Group. The world’s No. 1 choice The Electrolux Group is the world's largest producer of powered appliances for kitchen, cleaning and outdoor use. More than 55 million Electrolux Group products (such as refrigerators, cookers, washing machines, vacuum cleaners, chain saws and lawn mowers) are sold each year to a value of approx. USD 14 billion in more than 150 countries around the world.
