Summary of Contents for ViewSonic VIEWPAD G70
- Page 1 ViewPad E70/G70 User Guide Guide de l’utilisateur Guía del usuario Bedienungsanleitung Gebruikshandleiding Guia do usuário Руководство пользователя 使用手冊 ( 繁中 ) 使用手册 （简中） Model No. VS14572...
-
Page 2: Compliance Information
Compliance Information FCC NOTICE The following statement applies to all products that have received FCC approval. Applicable products bear the FCC logo, and/or an FCC ID in the format FCC ID: GSS- VS14572G on the product label.This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. - Page 3 The FCC has granted an Equipment Authorization for this device with all reported SAR levels evaluated as in compliance with the FCC RF exposure guidelines. SAR information on this device is on file with the FCC and can be found under the Display Grant section of www.fcc.gov/oet/ea/fccid after searching on FCC ID: GSS- VS14572G.
- Page 4 The mark indicates the requirement NOT to dispose the equipment as unsorted municipal waste, but use the return and collection systems according to local law. If the batteries, accumulators and button cells included with this equipment, display the chemical symbol Hg, Cd, or Pb, then it means that the battery has a heavy metal content of more than 0.0005% Mercury, or more than 0.002% Cadmium, or more than 0.004% Lead.
-
Page 5: Declaration Of Rohs Compliance
Declaration of RoHS Compliance This product has been designed and manufactured in compliance with Directive 2002/ 95/EC of the European Parliament and the Council on restriction of the use of certain hazardous substances in electrical and electronic equipment (RoHS Directive) and is deemed to comply with the maximum concentration values issued by the European Technical Adaptation Committee (TAC) as shown below: Substance... -
Page 6: Important Safety Instructions
Important Safety Instructions 1. DO NOT place objects on top of the ViewPad, as objects may scratch the screen. 2. DO NOT expose the ViewPad to dirty or dusty environments. 3. DO NOT place the ViewPad on an uneven or unstable surface. 4. -
Page 7: Copyright Information
® trademarks or registered trademarks of DataViz, Inc. All rights reserved. Disclaimer: ViewSonic Corporation shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages resulting from furnishing this material, or the performance or use of this product. -
Page 8: Product Registration
Purchase Date: _________________________________________ Product disposal at end of product life ViewSonic respects the environment and is committed to working and living green. Thank you for being part of Smarter, Greener Computing. Please visit ViewSonic website to learn more. USA & Canada: http://www.viewsonic.com/company/green/recycle-program/ Europe: http://www.viewsoniceurope.com/uk/kbase/article.php?id=639... -
Page 9: Table Of Contents
Chapter 1: Getting Started..............1 1.1 Your Device....................1 Front ......................1 Back ......................1 Top ......................2 Down ......................2 Left & Right ....................2 1.2 Accessories ....................2 1.3 Installing Memory/SIM Card ............... 3 1.4 Charging Battery ..................3 1.5 Using Headsets ................... - Page 10 Chapter 6: Google Apps ........... 21 ( Select Model) 6.1 Gmail ......................21 Signing in to Gmail ..................21 Refreshing Gmail ..................21 Creating and sending emails..............21 Reading and replying to emails ..............22 Forwarding emails ..................22 Managing emails ..................22 Viewing folder labels .................
- Page 11 Playing videos ................... 35 Viewing photos ..................35 8.3 Playing music .................... 35 Playing music .................... 35 Managing playlists..................36 Chapter 9: Programs ............37 ( Select Model) 9.1 Books ......................39 Browsing an ebook..................39 Downloading an ebook................39 9.2 Browser ......................
- Page 12 10.3 Device Display ..................46 10.4 Device Storage ..................47 10.5 Device battery..................47 10.6 Device Apps..................... 47 10.7 Accounts and Sync ................. 47 10.8 Location Services..................47 10.9 Security ....................48 10.10 Language & Input .................. 48 10.11 Backup & reset ..................48 10.12 Date and Time..................
-
Page 13: Chapter 1: Getting Started
FEDERAL COMMUNICATIONS COMMISSION:This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause und esired operation. ** For ViewPad G70 model. -
Page 14: Top
2. Micro USB port is only for device mode link to computer and power charging. Left & Right Volume( Up/ Down) SIM Card Slot (Select Model)** ** For ViewPad G70 models. 1.2 Accessories Your package comes with the following items. If any of them is missing, please contact your retailer. • ViewPad 7”... -
Page 15: Installing Memory/Sim Card
• AC adapter and plugs • Quick Start Guide • Compliance information 1.3 Installing microSD/SIM Card ® You need a microSD card to store photos, music, videos, and other data. To install the microSD card 1. Open the card cover. 2. -
Page 16: Using Headsets
1. Connect one end of the AC adaptor to the Micro USB port of the device. 2. Plug the other end of the AC adaptor to the wall outlet to start charging. When the battery is charging and the device is turned on, icon is displayed on the status bar. -
Page 17: Unlocking The Screen
1.7 Unlocking the Screen By default, the screen automatically locks after a period of inactivity. You can set the length of time until the screen locks. To unlock the screen 1. Press the Power button to turn on the display from Sleep mode. 2. -
Page 18: Chapter 2: The Basics
Chapter 2: The Basics 2.1 Home Screen From the Home screen, you can quickly access common features and view notifications of received messages, battery and connection status. Extended Home screen Swipe your finger to the left or right across the Home screen. The two extensions to the left and to the right of the Home screen provide more space for icons, widgets, shortcuts, and other items. -
Page 19: Shortcut Menu
Shortcut menu The shortcut menu allows you to easily access an application from the Home screen. To open an application, tap an icon. Customizing shortcut menu Home screen: Tap You can add apps and widgets to your home screen. Touch & hold to move icon. - Page 20 From this screen, you can add items to all home screen panels.Use panels to organize your Widgets and Apps. To move or delete something, touch and hold on the icon, then drag it to another panel or to the trash at of the screen.
-
Page 21: Using Widgets
Using widgets Save time with live updates right on the Home screen and get all your personalized updates in one place. You may add and customize the Widgets on the Home screen as you like. 1. From the Home screen, tap All available widgets are displayed. -
Page 22: Application Drawer
Application drawer The Application Drawer contains all applications and settings. Tap to open the menu. • Tap an icon to access the application. Setting wallpaper Wallpapers : Long press on empty space on desktop or tap [Menu / Wallpaper] to change your wallpaper. -
Page 23: Adjusting Volume
2.2 Adjusting Volume This device features three types of volume which can be adjusted separately: • Ringer volume: Set the volume for notifications. • Media volume: Set the volume for music and videos. • Alarm volume: Set the volume for alarms. To adjust the volume 1. -
Page 24: Setting Up Wi-Fi
2.3 Setting up Wi-Fi You need to connect to a wireless network before surfing the Internet or using the related applications that require internet connection. To turn Wi-Fi on or off 1. From the Home screen, tap > Settings > Wi-Fi. 2. -
Page 25: Chapter 3: Entering Information
Chapter 3: Entering Information 3.1 On-Screen Keyboard The on-screen keyboard appears when an application requires text input, such as messaging and writing emails. The keyboard input method is activated by default. Using the on-screen keyboard Tap the screen to display the on-screen keyboard. Lowercase keyboard Uppercase keyboard •... -
Page 26: Using User Dictionary
• Auto-capitalization: Select to automatically capitalize the first letter of a sentence. • Vibrate on keypress: Select to activate vibration when a key is touched. • Sound on keypress: Select to activate a clicking sound when a key is touched. •... -
Page 27: Chapter 4: Email
Chapter 4: Email Use Email to send and receive email messages via your internet email accounts. 4.1 Email Accounts Your device can send and receive emails just as you do with a computer. Your device supports email accounts provided by an Internet Service Provider (ISP) or web-based email, such as Hotmail, Yahoo! Mail, etc. -
Page 28: Viewing Email Accounts
Viewing email accounts 1. From the Home screen, tap > Email. 2. Tap the account picker box at the top left of the screen. 3. Tap the account you want to access from the available email accounts. Customizing email settings Configure message settings using the Account settings menu. -
Page 29: Sending An Email From Contacts
4. In the To field, enter the recipient’s email address. 5. Enter a Subject. 6. Compose your email. 7. Tap Sending an email from Contacts You can send an email to a contact with an email address stored in Contacts. 1. -
Page 30: To Reply Or Forward An Email
To reply or forward an email 1. From the Home screen, tap > Email. 2. Tap an email account. 3. Tap a message to open. 4. Do any of the following: • Tap (Reply) or (Reply all) to reply the email. -
Page 31: Chapter 5: Using Internet
Chapter 5: Using Internet 5.1 Browsing Web Pages 1. From the Home screen, tap > Browser. 2. Tap the address bar. 3. Type the URL. As you type, a list of URL suggestions appears on the screen. 4. Tap a match item in the list. Address bar Tap to update the... -
Page 32: Managing Web Pages
Managing web pages While viewing a web page, tap to configure the browser settings: • General: Select to set home page, and configure sync data and autofill settings. • Privacy & Security: Select to configure privacy and security settings including cache, history, cookies, form data, location, and etc. -
Page 33: Chapter 6: Google Apps
Chapter 6: Google Apps ( Select Model) The following sections cover Android and Google applications that come pre-installed on your device depends on models. NOTE: ViewPad E70 is not available for these Android/ Google applications. 6.1 Gmail Gmail is the email service provided by Google. Signing in to Gmail 1. -
Page 34: Reading And Replying To Emails
Reading and replying to emails 1. From the Home screen, tap > Gmail. 2. Tap an email to read. 3. To reply, tap (Reply) or (Reply all). 4. Compose your message. 5. Tap to send the email. To preview and download attachments 1. -
Page 35: Viewing Folder Labels
To place emails in archive 1. From the Home screen, tap > Gmail. 2. Tap and hold an email, then tap Archive. To mute emails 1. From the Home screen, tap > Gmail. 2. Tap and hold an email, then tap Mute. To change labels of emails 1. -
Page 36: Talk
6.2 Talk Use Google Talk to chat with your friends who also have Google accounts. Signing in to Google Talk 1. From the Home screen, tap > Talk. 2. Select an account and tap Sign in. If you log in for the first time, enter your username and password, then tap Sign in. Google Talk options Once logged in, you can begin using Google Talk and do any of the following:... - Page 37 2. Tap > Settings. 3. Tap one of the following settings: • Sign in automatically: Enable to automatically sign in when Google Talk is opened. • Mobile indicator: Enable to show mobile indicator to your friends. • Set status to away when screen is turned off: Enable to set status to away when the screen is turned off.
-
Page 38: Maps
6.3 Maps Use Google Maps to find places, view traffic and direction information, and find your friends’ location. Before starting Maps , do the following: 1. From the Home screen, tap > Settings > Location & security. 2. Tap to enable Use wireless networks. 3. -
Page 39: Finding Places
Finding places 1. From the Home screen, tap > Maps. 2. Tap the Search Maps box. 3. Type the place to search on the text field. 4. Tap A callout appears to indicate the location of the searched place. 6.4 Navigation Google Maps Navigation allows you to say the destination and get voice directions. -
Page 40: Getting Directions
Getting directions 1. From the Home screen, tap > Navigation. 2. Enter the starting point and the ending point, or tap the corresponding and select an option. 3. Select a direction icon. • : Driving directions • : Transit directions •... -
Page 41: Latitude
6.5 Latitude With Latitude, you can view your friends’ location and share your location to them on Google Maps Starting Latitude 1. From the Home screen, tap > Latitude. 2. Do any of the following: • To add friends, tap •... -
Page 42: Market
6.6 Market Android Market allows you to purchase and download games and other applications to your device. When opening Android Market for the first time, the Terms of Service is displayed on screen. Tap Accept to accept the terms and continue. NOTE: Android Market may not be supported on all models or in all countries. -
Page 43: Places
6.7 Places Places is a location-based application that helps you find the places and things around you. Local information available includes restaurants, coffee shops, bars, hotels, attractions, ATMs, gas stations, and more. This application also helps you get where you are going with maps and directions. From the Home screen, tap >... -
Page 44: Voice Search
6.9 Voice Search Speak your query to search item on Google, or for applications or contacts on your device. 1. From the Home screen, tap > Voice Search or in the Quick Search box. 2. A dialog opens, prompting you to speak the words that you want to search for. -
Page 45: Chapter 7: Using Bluetooth
Chapter 7: Using Bluetooth ( Select Model) Bluetooth modes • On: Bluetooth is turned on. Your device detects other Bluetooth devices, but your device is not visible to others. • Discoverable: Bluetooth is turned on and your device is visible to other Bluetooth devices. -
Page 46: Chapter 8: Multimedia Applications
Chapter 8: Multimedia Applications 8.1 Videos and Photos Your device is equipped with a front camera and a main camera for you to take photos and record videos. NOTE: ViewPad E70 with front camera only. Taking a Photo 1. On the Home screen, tap >... -
Page 47: Viewing Videos & Photos
Tap to view and adjust the general settings of your camera: Mode Setting Available options White balance Auto, Incandescent, Daylight, Fluorescent Photo mode Exposure +4, +3, +2, +1, 0, -1, -2, -3, -4 Camera settings Restore defaults, Store location (Off/ On) White balance Auto, Incandescent, Daylight, Fluorescent Video mode... -
Page 48: Managing Playlists
During playing, you can press Menu to add it to the desired playing list or delete Item Description To play the track To pause the track Play the previous track Play the next track Process bar Play forward or backward To view the playing list Turn on or off shuffle Repeat the current song or all songs, or turn off repeat... -
Page 49: Chapter 9: Programs
Chapter 9: Programs ( Select Model) Your device comes with the following pre-installed programs. Programs Description Books Download ebooks from online catalog for viewing on your device. Browser Browse the web and download files from the Internet. Calculator Perform basic arithmetic functions, such as addition, subtraction, multiplication, and division. - Page 50 Programs Description Maps View the map and get directions to your destination. Market Purchase games and other applications from Android Market and download them to your device. Music Play and manage music and audio files on your device. Navigation Use to track your location, find places, and get driving directions to your destination.
-
Page 51: Books
9.1 Books The Books program allows you to download ebooks from online catalog for viewing on your device. Browsing an ebook 1. From the Home screen, tap > Books. 2. Select an ebook and tap the book cover to start reading. -
Page 52: Calendar
9.4 Calendar The Calendar lets you schedule and sound alarms for appointments, meetings and other events. Scheduled appointments for the day can be displayed on the Home screen. To schedule an event 1. From the Home screen, tap > Calendar. 2. -
Page 53: Downloads
9.8 Downloads Use Downloads to view or delete what you have downloaded in Browser, Gmail, or Email. NOTE: The downloaded files are stored in the “Download” folder in your memory card. 1. From the Home screen, tap > Download. 2. Tap an image to view it. Managing files •... -
Page 54: Fm Radio
• To sort items, tap > Sort, then tap a sorting option. • To mark a file or folder, tap > Mark. • To copy all files and folders, tap > Copy all. • To delete all files and folders, tap >... -
Page 55: Gallery
9.12 Gallery You can view your captured images, recorded video clips, and downloaded images in Gallery. 1. From the Home screen, tap > Gallery. 2. Tap the desired folder to view the camera pictures or camera videos. The images or videos are displayed in thumbnails. 9.13 Gmail Use Gmail to send and receive emails using your Google email account. -
Page 56: Navigation
9.19 Navigation Use Navigation to locate your location and provide a real time turn by turn direction to your chosen destination. 9.20 Places Places is a location-based application that helps you find the places and things around you. 9.21 Settings In the Settings menu, you can view and make adjustments for wireless &... -
Page 57: Note Everything
9.27 Note Everything This full-featured note taking app makes it easy to create, view and manage text notes, as well as hand-drawn notes and voice recordings. 9.28 Sketcher Create beautiful drawings with the sketchpad app, featuring a variety of textured brushes and colors. -
Page 58: Chapter 10: Managing Your Device
Chapter 10: Managing Your Device 10.1 Wireless & networks From the Home screen, tap > Settings to view and adjust the settings of your device. Application Description WiFi Manage Wi-Fi connections, scan and connect to available Wi- Finetworks. Bluetooth settings Manage connections, set device name, and discoverability of the device. -
Page 59: Device Storage
Application Description Sleep Adjust display enter sleep inactivity time. Font size Set up Font size from small, normal, Large and Huge. 10.4 Device Storage Application Description Internal storage Show available device storage on total space. Unmount SD card Unmount the SD card so you can safety remove it. Erase SD cad Erases all data on the SD card, such as music and photos. -
Page 60: Security
Application Description GPS satellites Let apps use GPS to pinpoint your location. 10.9 Security Application Description Screen lock Set up screen lock with none, Slide, Pattern, PIN or Password. Owner Information Show owner info on lock screen. Set up SIM card Set up SIM card lock info. -
Page 61: Date And Time
10.12 Date and Time Application Description Automatic date Check to use network provided time. and time Automatic time Check to use network provided time zone. zone Set date Set the date. Set time Set the time. Select time zone Select the time zone of your current location. Use 24-hour Set the clock to 24-hour format. -
Page 62: Specifications
Specifications Connectivity GPS / AGPS ( select models) Wi-Fi 802.11 b/g/n Bluetooth 2.1 with EDR ( select models) USB 2.0 High-Speed client (micro-B type) Power Battery 2 cell battery pack (3300mAH, in series), unremovable AC Adapter AC input voltage: 100-240Vac, 50/60Hz AC input current: 300mAac max. -
Page 63: Customer Support
Renta y Datos, 29 SUR 721, COL. LA PAZ, 72160 PUEBLA, PUE. Tel: 01.222.891.55.77 CON 10 LINEAS Electroser, Av Reforma No. 403Gx39 y 41, 97000 Mérida, Yucatán. Tel: 01.999.925.19.16 Other places please refer to http://www.viewsonic.com/la/soporte/index.htm#Mexico Latin America (Peru) www.viewsonic.com/la/ T= 0800-54565 soporte@viewsonic.com... -
Page 64: Limited Warranty
Replacement product or parts may include remanufactured or refurbished parts or components. How long the warranty is effective: ViewSonic ViewPad are warranted for at least 1 year for labor from the date of the first customer purchase. Who the warranty protects: This warranty is valid only for the first consumer purchaser. - Page 65 Exclusion of damages: ViewSonic’s liability is limited to the cost of repair or replacement of the product. ViewSonic shall not be liable for: 1. Damage to other property caused by any defects in the product, damages based...
