- Page 1 LAVATRICE LAVE-LINGE WASCHAUTOMAT WASHING MACHINE ZWF 1220 - ZWF 1420 ZWF 1620 LIBRETTO ISTRUZIONI NOTICE D’UTILISATION GEBRAUCHSANWEISUNG USER MANUAL G G B B 132975770...
-
Page 2: Table Of Contents
Dear customer, Transport damages Please read these operating instructions carefully When unpacking the appliance, check that it is not and pay particular attention to the safety notes damaged. If in doubt, do not use it and contact the indicated in the first pages. We recommend that you Service Centre. -
Page 3: Warnings
Warnings The following warnings are provided in the interests of overall safety. You must read them carefully before installing or using the appliance. Installation General safety • All internal packing must be removed before using • Repairs to the machine must be carried out only by the appliance. -
Page 4: Disposal
MAXIMUM LOAD Cotton Synthetics 2.5 kg Delicates 2.5 kg Woollens/Handwash SPIN SPEED 1200 rpm max. (ZWF 1220) 1400 rpm max. (ZWF 1420) 1600 rpm max. (ZWF 1620) POWER SUPPLY VOLTAGE/FREQUENCY 220-230 V/50 Hz TOTAL POWER ABSORBED 2200 W MINIMUM FUSE PROTECTION... -
Page 5: Installation
Installation 7. Fill the smaller upper hole and the two large ones Unpacking with the corresponding plastic plug caps supplied in the bag containing the instruction booklet. All transit bolts and packing must be removed before using the appliance. You are advised to keep all transit devices so that they can be refitted if the machine ever has to be transported again. -
Page 6: Water Drainage
In a sink drain pipe branch. This branch must be above the trap so that the bend is at least 60 cm above the ground. Directly into a drain pipe at a height of not less than 60 cm and not more than 90 cm. The end of the drain hose must always be ventilated, i.e. -
Page 7: Description Of The Appliance
Description of the appliance 1 Detergent dispenser drawer 2 Control panel 3 Door handle 4 Drain pump 5 Adjustable feet Detergent dispenser drawer Prewash Main wash Fabric softener, starch... -
Page 8: Use
Control panel 1 ON/OFF button 4 TEMPERATURE button Press this button to switch the washing machine on. Press this button repeatedly to increase or decrease Press the button again to switch the machine off. the temperature, if you want your laundry to be washed at a temperature different from the one 2 MAINS-ON light proposed by the washing machine. -
Page 9: Option Buttons
(not available for wool and hand wash programmes). Maximum speeds are: • for cotton: 1200 rpm (ZWF 1220), 1400 rpm (ZWF The prewash ends with a short spin at 650 rpm in 14200, 1600 rpm (ZWF 1620); programmes for cotton and synthetic fabrics, •... - Page 10 7 Display Important! The first time you use the washing machine, The following pieces of information are shown on the when you switch it on, it may display a blinking zero and display: give an audible warning signal. This is due to the fact •...
-
Page 11: Skip/Reset Button
• If the machine is already switched on because it 8 START/PAUSE button has just performed a washing programme, proceed This button has two functions: as follows: • Start: after you have selected the desired - depress RESET once or repeatidly to cancel the programme and options, press this button to start previously performed programme (three blinking the washing machine. -
Page 12: Washing Hints
10 DELAY START button Washing hints This button makes it possible to delay the starting of the programme from 30 min-60 min-90 min, 2 hours Sorting the laundry and then by 1 hour up to maximum of 23 hours. The delay you have selected is shown on the display for Follow the wash code symbols on each garment about 3 seconds;... -
Page 13: Laundry Weights
Ink: depending on the type of ink, moisten the fabric Laundry weights first with acetone (*), then with acetic acid; treat any The following weights are indicative: residual marks on white fabrics with bleach and then bathrobe 1200 g rinse thoroughly. napkin 100 g Tar stains: first treat with stain remover, methylated... -
Page 14: International Wash Code Symbols
Quantity of detergent to be used The type and quantity of detergent will depend on the type of fabric, load size, degree of soiling and hardness of the water used. Water hardness is classified in so-called “degrees” of hardness. Information on hardness of the water in your area can be obtained from the relevant water supply company, or from your local authority. -
Page 15: Operating Sequence
4. Switch the machine on Operating sequence Press the ON/OFF button to switch the machine on. The display will show three blinking dashes or a Before the first wash we recommend that you pour 2 blinking zero. The light above the button will light up. litres of water into the main wash compartment of the detergent drawer in order to activate the ECO valve. - Page 16 If you select the RINSE HOLD option, the machine will stop at the end of the programme with the water still in the tub. ZWF 1220 ZWF 1420 9. Select the DELAY TIME Before you start the programme, if you wish the...
- Page 17 11. How to change a programme during When you close the door and press the ON/OFF button again, the washing machine will resume the its cycle programme from the point where it had been Before you make any change, you must pause the interrupted.
-
Page 18: Washing Programmes
Washing programmes Type of Consumption* Programme/ Description of laundry and Available options temperature programme Water load symbols on Energy kWh litres labels Main wash at 60°-95°C White cotton: 5 kg 3 rinses e.g. sheets, 60°-95°C Long spin tablecloths, household linen Main wash at 60°-40°-30°C Coloured... -
Page 19: Maintenance
Maintenance 1. Door seal Detergent can also accumulate inside the drawer recess: clean it with an old toothbrush. Refit the Check from time to time the door seal and eliminate drawer after cleaning. eventual possible objects that could be trapped in the fold. -
Page 20: Water Inlet Filter
• Remove any objects from the pump impeller by Emergency emptying out rotating it. If the water is not discharged, proceed as follows to empty out the machine: • pull out the plug from the power socket; • close the water tap; •... -
Page 21: Something Not Working
Something not working? Problems which you can resolve yourself. During machine operation it is possible that one of the following alarm codes appears on the display and an acoustic signal is given: - E10: problem with the water supply - E20: problem with water draining - E40: door open Once the problem has been eliminated, press the START/PAUSE button to restart the programme. - Page 22 Problem Possible cause • The door will not open: • The water level is above the bottom edge of the door. • The machine is heating the water. • The drum is turning. • Spinning starts late or the • The electronic unbalance detection device has cut in because the laundry is not evenly distributed in laundry is not spun enough: the drum.
-
Page 23: Service Centre List
