- Page 1 REFRIGERADOR- CONGELADOR FRIDGE-FREEZER FRIGORÍFICO- CONGELADOR ZIC 722/9 LIBRO DE INSTRUCCIONES INSTRUCTION BOOKLET MANUAL DE INSTRUÇÕES 2222 284-11...
-
Page 2: General Safety
WARNINGS It is most important that this instruction book should be retained with the appliance for future reference. Should the appliance be sold or transferred to another owner, or should you move house and leave the appliance, always ensure that the book is supplied with the appliance in order that the new owner can be acquainted with the functioning of the appliance and the relevant warnings. -
Page 3: Table Of Contents
CONTENTS Fresh food refrigeration Installation Movable shelves Positioning Positioning the door shelves Cleaning the interior Air circulation Instructions for totally built-in appliances Defrosting Electrical connection Maintenance Technical specification Periodic cleaning Periods of non use Starting Replacing the interior light bulb Quick-freezing Defective operation Warning light... -
Page 4: Instructions For Totally Built-In
I nstructions for totally built-in appliances Door reversibility (Fig. 1) D337 Right opening Left opening Remove the pins (P) and (P1) Remove (P) from both sides and the door. Remove (A) from the left side and (B-C-D) from the right side. Refit (B-C-D)on the left side and (A) on the right side. - Page 5 If after having carried out the previously Fig. 4 described operation there is still some space left between the appliance and the kitchen unit, fit the trimming provided together with the appliance on the stop strip (A). D265 Fig. 5 Open the door and push the appliance against the side of the kitchen unit opposite to that of appliance hinges.
-
Page 6: Electrical Connection
Open both the appliance door and that of the Fig. 9 kitchen unit to approx. 90°. Place the little plates over the runners. Hold the doors of the appli- ance and the unit together and mark the holes. PR34 Remove the little plates and make the holes with a diam. -
Page 7: Use
This freezer has been marked with the symbol, which means that it is suited to the freezing of fresh foods, the conservation of frozen foods and the production of ice-cubes. The control panel A. Pilot light thermostat knob with respect to the normal running position. -
Page 8: Storage Of Frozen Food
Storage of frozen food on the evaporator. If this happens, turn the knob to a warmer setting (lower numbers) to allow To obtain the best performance from this automatic defrosting and so a saving in appliance, we strongly recommend that you electricity consumption. -
Page 9: Positioning The Door Shelves
Positioning the door shelves Fig. 13 To permit storage of food packages of various sizes, the door shelves can be adjusted in height. To make these adjustments proceed as follows: Gradually pull the shelf in the direction of the arrows until it comes off, then reposition as required. -
Page 10: Defrosting
Defrosting Frost is automatically eliminated from the evaporator of the refrigerator compartment every time the motor compressor stops, during normal use. The defrost water drains out through a trough into a special container at the back of the appliance, over the motor compressor, where it evaporates. -
Page 11: Maintenance
MAINTENANCE Interior light Unplug the appliance before carrying out any maintenance operation. The light bulb inside the refrigerator compartment can be reached as follows: Internal cleaning Never use metal objects for clearing your unscrew the light cover securing screws; appliance as it may get damaged. unhook the moving part by pressing it as shown in the figure.
