  • Page 1 BUILT-IN OVEN ZOB 899 INSTRUCTION BOOKLET 35687-6901...
  • Page 3: Important Safety Information

    English Important Safety Information These warnings are provided in the interest of safety. You read them carefully before installing or using the appliance. MUST Installation • Never use steam or high pressure steam cleaners to clean the appliance. • It is mandatory that all operations required for the •...
  • Page 4: Table Of Contents

    Contents For the User For the Installer Important Safety Information Technical Data Description of the Oven Installation Controls Electrical connection When the oven is first installed It is most important that this instruction book Electronic programmer is be retained with the appliance for future reference.
  • Page 5: Controls

    Controls Push-Pull control knobs The oven is provided with push-pull control knobs (Fig. 1). These knobs can be completely sunken inside the control panel when the oven is not working. Oven function control knob (Fig. 2) The oven function control knob can have the following symbols and functions: Fig.
  • Page 6: When The Oven Is First Installed

    This oven is provided with a safety thermostat. In case of malfunctioning of the main thermostat, and consequent over-heating, the safety device will stop the power supply to the appliance. If this happens, call your local Zanussi Service Centre. Under no circumstances should you attempt to repair the appliance yourself.
  • Page 7: Thermostat Control Knob

    Electronic programmer 1. Push button for selecting a function 2. Decreasing control button “ ” 3. Increasing control button “ ” 4. Display 5. “Cooking Duration” pilot lamp 6. “End of cooking” pilot lamp 7. “Minute minder” pilot lamp FO 2571 8.
  • Page 8 “End of cooking” function Thanks to this function, you can set the oven to switch off automatically when a programmed end of cooking time is over. Place food in the oven, select a cooking function and adjust the cooking temperature. Press button repeatedly to select the “End of cooking”...
  • Page 9: Using The Oven

    Using the Oven Always cook with the oven door closed. • Stand clear when opening the drop down oven door. Do not allow it to fall open - support the door using the door handle, until it is fully open. •...
  • Page 10: Conventional Cooking

    Using the Oven Always cook with the oven door closed. • The temperatures inside the oven can reach 230°C. Always ensure that you are using oven proof baking Conventional cooking trays, oven dishes, etc. • Do not place pans, biscuit pans or aluminium foil Turn the oven function control knob to the relevant symbol directly on the base of the oven.
  • Page 11: Cooking Tables

    Cooking Tables Cooking times do not include pre-heating time. We reccomend a short oven pre-heating (about 10 minutes) before cooking. Shelf positions are counted from bottom of the oven. Conventional and fan cooking Traditional Cooking Cooking Fan Oven time TYPE OF DISH NOTES Level Level...
  • Page 12: Cooking With The Turnspit

    Cooking Tables Cooking times do not include pre-heating time. We reccomend a short oven pre-heating (about 10 minutes) before cooking. Shelf positions are counted from bottom of the oven. Cooking chart - Grilling Cooking time Quantity Grilling (minutes) TYPE OF DISH Upper Lower °C...
  • Page 13: Cleaning And Maintenance

    Cleaning and Maintenance General Cleaning Before carrying out any cleaning or manteinance work, always disconnect the appliance from the electrical supply, and allow it to cool down. • When using spray cleaning products, be careful not to spread them on the heating elements or on the thermostat sensor.
  • Page 14: Cleaning The Oven Door

    Cleaning the oven door The following instructions explain how to disassemble the oven door as it is supplied by the Manufacturer. If you the oven door has been reversed, please note that the references to the right or left side have to be switched. Figure 11.
  • Page 15 Figure 15. Tightly hold with both hands the second innner glass “E” and remove it from its original position too by making it slipping off. After removing the inner glass, clean the oven door and the glasses. We recommend to clean the oven door using only a wet sponge and dry it up after cleaning with a soft cloth.
  • Page 16 Oven Shelves Shelf Supports To clean the oven shelves, soak in warm soapy water and remove stubborn marks with a well wetted soap impregnated pad. Rinse well and dry with a soft cloth. The shelf supports can be removed for easy cleaning. Proceed as follows: 1) remove the front screw while keeping the shelf support in position with the other hand (Fig.
  • Page 17 The Hinged Grill Some models are fitted with a hinged grill element, to enable you to clean the roof of the oven easily. Before proceeding ensure the oven is cool and is isolated from the electricity supply. Undo the screws which hold the grill in place (see Fig.
  • Page 18: Something Not Working

    Something not working... If the appliance is not working correctly, please carry out the following checks, before contacting your local Service Centre. SYMPTOM SOLUTION The oven does not come on Check that both a cooking function and a temperature have been selected Check the appliance is wired in properly, and the socket switch or the switch from the mains supply to the oven are...
  • Page 19: Technical Assistance

    Technical Assistance If after the checks listed in the previous chapter, the appliance still does not work correctly, contact your local Service Centre, specifying the type of malfunctioning, the appliance model (Mod.), the product number (Prod. No.) and the serial number (Ser. No.) marked on the identification plate.
  • Page 20: Installation

    Installation The following instructions are meant to a qualified technician, in order to allow him carry out the installation in compliance with the rules in force. The building-in and the electrical connection fo the appliance must be carried out by a qualified and authorized technician only.
  • Page 21: Electrical Connection

    Electrical connection Before the appliance is connected: 1) check that the main fuse and the domestic installation can support the load; 2) check that the power supply is properly earthed in compliance with the current rules; 3) check the socket or the double pole switch used for the electrical connection can be easily reached with the appliance built in the forniture unit.
  • Page 22 ZOB 899 0,79 kWh 0,78 kWh 43 min. 41 min. 1130 cm² From the Electrolux Group. The world’s No.1 choice. The Electrolux Group is the world’s largest producer of powered appliances for kitchen, cleaning and outdoor use. More than 55 million Electrolux Group products (such as refrigerators, cookers, washing machines, vacuum cleaners, chain saws and...
