Summary of Contents for Zanussi ZI 418
- Page 1 KÜHL-GEFRIER- SCHRANK REFRIGERATEUR- CONGELATEUR TWEEDEURS- KOELKAST FRIDGE-FREEZER ZI 418/9 BEDIENUNGSANLEITUNG MODE D’EMPLOI GEBRUIKSAANWIJZING INSTRUCTION BOOKLET 2222 124-32...
-
Page 2: Table Of Contents
CONTENTS ....... .page Warnings Installation ....... .page Positioning . -
Page 3: Warnings
WARNINGS It is most important that this instruction book should be The inner lining of the appliance consists of retained with the appliance for future reference. Should the channels through which the refrigerant passes. If appliance be sold or transferred to another owner, or should these should be punctured this would damage the appliance beyond repair and cause food loss. -
Page 4: Installation
INSTALLATION If this appliance featuring magnetic door seals is to Electrical connection replace an older appliance having a spring lock (latch) on Before plugging in, ensure that the voltage and the door or lid, be sure to make that spring lock frequency shown on the serial number plate unusable before you discard the old appliance. -
Page 5: Instructions For Totally Built-In Appliances
Instructions for totally built-in appliances Door reversibility (Fig. 1) D114 Fig. 1 Right-hand opening Recess dimensions Remove pins (P) and (P1). Height 1580 mm Depth 550 mm Left-hand opening Width 560 mm Remove (P) from both sides and also remove the To ensure adequate ventilation, allow the clearances door. - Page 6 Push appliance into housing until stop strip (A) Press in the joint covers between the appliance and touches the kitchen unit. the kitchen unit. Fig. 3 Fig. 6 D098 D023 If after having carried out the previously described Apply covers (B) on joint cover lugs and into hinge operation there is still some space left between the holes.
- Page 7 Open both the appliance door and that of the If the appliance is fixed to the side of the kitchen kitchen unit to approx. 90 . unit, simply slacken the screws in fixing brackets (F), move the brackets as shown in the figure and Place the little plates over the runners.
-
Page 8: Operation
OPERATION Refrigerator/Freezer - Starting-up and Storage of foods in refrigerator compartment Temperature Regulation To achieve the best results with the refrigerator compartment, you should follow some very simple Insert the plug into the wall socket. rules: Open the refrigerator door and turn the thermostat knob, to be found on the upper right side of the Do not put warm foods or evaporating liquids in the inner liner, clockwise, beyond the «O»... -
Page 9: Positioning The Door Shelves
Positioning the door shelves Freezing fresh food To permit storage of food packages of various sizes, Place the food to be frozen in the upper the door shelves can be adjusted in height. compartment of the freezer as this is the coldest To make these adjustments proceed as follows: part. -
Page 10: Storage Of Frozen Food
Storage of frozen food Thawing If the freezer has been out of use for some time, Deep-frozen or frozen food, prior to being used, can before putting the products in the compartment let be thawed in the refrigerator compartment or at the freezer run for at least two hours on the coldest room temperature, depending on the time available setting. -
Page 11: Defrosting
Defrosting The freezer compartment, however, will become progressively covered with frost. This should be Frost is automatically eliminated from the removed with the special plastic scraper provided, evaporator of the refrigerator compartment every whenever the thickness of the frost exceeds 4 mm. time the motor compressor stops, during normal Do not use metal tools to remove the frost –... -
Page 12: Maintenance
MAINTENANCE Before all operations, disconnect the appliance from Interior light bulb the mains. The light inside the refrigerator compartment is easy to get at through the opening in the light Cleaning holder. If the light does not come on when the door is open, Clean the inside and accessories of the refrigerator check that it is screwed into place properly.
