10. Set-up mode

Your VDO CYTEC C 08 features the following set-up procedures
wheelsize = WS
clock = CLK
odometers = ODO
No matter which set-up mode is used for your VDO CYTEC , the procedure is the same.
You can start the set-up mode for a certain display by pressing the MODE 1 button for 5 sec. With this MODE button you may also
exit the set-up mode at any time.
Once the set-up mode is activated, MODE 1 and MODE 2 buttons are covered with following instructions:
MODE1 changing from one enter display to the next enter display
MODE2 selection of figure to be entered, changing from KMH to MPH mode

11. Entering your wheelsize

Your VDO CYTEC identifies wheelsize as WS = wheelsize.
following default is entered
wheelsize = WS = 2155 mm
Watch out: Above default is automatically applied after a battery change.
After a battery change, the correct wheelsize for your bike has to be re-entered

How is the wheelsize precisely determined?

Place the front wheel of your bike with the valve at the bottom, mark this position with a line and push your bike ahead until exactly
one rotation of the front wheel is completed. Draw another line where the valve now is. Take a ruler and measure the distance between
marks 1 and 2 which reflects the wheelsize = wheel-circumference. The figure measured (inches or mm) is the wheelsize to be entered
into your computer
set-up starts out of TRP in display
set-up starts out of CLK in display
set-up starts out of ODO in display
