Instruction Manual
CWPC-01
Water Resistant Case For
µ-mini DIGITAL/Stylus Verve

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CWPC-01 and is the answer not in the manual?

Questions and answers

Related Manuals for Olympus CWPC-01

Summary of Contents for Olympus CWPC-01

  • Page 1 Instruction Manual CWPC-01 Water Resistant Case For µ-mini DIGITAL/Stylus Verve...
  • Page 2 Thank you for buying the CWPC-01 Water Resistant Case. To ensure safe and correct operation of this product, please read this instruction manual carefully. Keep this instruction manual handy for future reference. Improper use may result in internal to the camera from water leakage.
  • Page 3 For safe use This instruction manual uses various symbols to warn of danger to the user or other persons, as well as property damage. These symbols and their meanings are shown below. Death or severe injury may result if this warning is WARNING disregarded.
  • Page 4 4. This product has been designed and manufactured for use at a water depth up to 3 meters. Please note that using this product at depths exceeding 3 meters could result in water leakage and may cause permanent deformation or damage to this product, as well as to the camera inside.

  • Page 5: For Prevention Of Water Leakage Accidents

    For Prevention of Water Leakage Accidents When water leakage occurs while this product is being used, the camera inside may be irreparably damaged. To avoid this, please take the following precautions. 1. When sealing this product, make sure that there are no hairs, fibers, sand particles or other foreign matter adhering to the waterproof packing or the surface that comes in contact with the packing.

  • Page 6: Handling The Product

    Do not use anticorrosion agents. The metal parts Anticorrosion agent use stainless steel or brass, and washing with pure water is sufficient. Do not use adhesive for repairs or other purposes. Adhesive When repair is required, please contact your dealer or nearest Olympus Service Station.
  • Page 7 OLYMPUS IMAGING CORP. shall be in no way responsible for accidents involving immersion of a digital camera in water. OLYMPUS IMAGING CORP. shall not pay any compensation for accidents (injury or material damage) that may occur during use of this product.

  • Page 8: Check The Contents Of The Package

    1. Preparations Check the contents of the package. Check that all accessories are in the box. Contact your dealer if accessories should be missing or damaged. Instruction manual Water Resistant Case (this manual) Authorized distributors list/ Authorized service centres list...

  • Page 9: Names Of The Parts

    Names of the parts Hand strap Buckle opener/closer Cross button Hand strap rings levers (grip) OK/Menu button Mode dial knob Buckle hooks LCD monitor window Shutter button Quick View button Waterproof packing Lens window Power switch button Shade hood Buckle lock levers Zoom button Note : The controls on the water-resistant case marked “...

  • Page 10: How To Press The Shutter Button

    Master the basics. Before taking any pictures, make sure you have mastered the basics of using the case. How to press the shutter button Press the shutter button gently, so that there is no movement of the camera. Also take care not to cover the lens with your hand.

  • Page 11: Preliminary Check Of The Case

    • If the preliminary test should show water leakage with normal handling, stop using the case and contact your dealer or nearest Olympus Service Station (listed on the rear page of this instruction manual). E-11...

  • Page 12: Installing The Digital Camera

    Loading the camera in the case Which digital cameras can be loaded? This case (CWPC-01) is exclusively for the µ-mini DIGITAL/Stylus Verve. Turn on the camera. Press the power button on the digital camera once to switch it on.

  • Page 13: Check Camera Operation

    Check camera operation. Make sure that the camera operates according to the digital camera’s instruction manual. Open the water resistant case. While sliding the buckle lock levers on the left grip of the case downward, hold the upper and lower sections of the left grip and pull it toward the front to open the case.

  • Page 14: Seal The Case

    Seal the case. Close the rear lid of the case, engage the buckles with the edge of the rear lid, and tilt the left grip in the direction of the arrow to seal the case airtight. Perform the final checks. Visual inspection After sealing the case, check around the sealed section on the front and rear lid to make sure that there are no particles caught in the...

  • Page 15: Final Test

    Final test The final test after loading the camera is explained below. This is the only way to eliminate worry about possible entry of water! Always perform this test. It can be performed easily in a water tank or a bathtub. The required time is about five minutes.

  • Page 16: Shooting Precautions

    4. Shooting Precautions Take pictures carefully. Cautions when using the flash When taking wide-angle macro pictures, flash coverage may not be complete or the amount of light may not be uniform. Wide-angle : Approx. 0.2 to 2.8 meters Flash range (Land shooting) Telescopic : Approx.

  • Page 17: Handling After Shooting

    5. Handling After Shooting Wipe off any water drops. Once you’re back on dry land, wipe any water off the case. Use air or a soft fiber-free cloth to thoroughly wipe water or dirt from between the front and rear lids, buttons, etc.

  • Page 18: Dry The Case

    Wash the case with fresh water. After removing the camera, seal the case and wash it thoroughly in fresh water as soon as possible. After use in or near sea water, it is important to immerse the case in fresh water long enough to remove any salt.
  • Page 19 6. Maintaining Water Resistance Remove any foreign matter from the waterproof packing. Visually check that the waterproof packing is free of sand, dust and other foreign matter. Also make sure that it is not damaged or cracked. If any foreign matter is attached, use a clean, lint-free cloth or similar material to remove the foreign matter.

  • Page 20: Specifications

    Control button/dial: Silicon rubber Strap mount: Brass nickel plating Dimensions Width 120.2 mm x height 74.0 mm x thickness 52.4 mm Weight 120 g OLYMPUS IMAGING CORP. reserves the right to change the design and the specifications without notice. E-20...
  • Page 21 MEMO E-21...
  • Page 22 Our phone customer support is available from 8 am to 10 pm (Monday to Friday) ET E-Mail: distec@olympus.com Olympus software updates can be obtained at: http://www.olympus.com/digital/ Premises : Wendenstrasse 14-18, 20097 Hamburg, Germany Tel: +49 40-23 77 3-0 Fax: +49 40-23 07 61...
