- Page 1 PPO-E03 Instruction Manual Underwater Lens Port for the PT-E Series Mode d’emploi Port d’objectif étanche pour la série PT-E Bedienungsanleitung Unterwasser-Objektiv-Port für PT-E Serie Manual de instrucciones Puerto de objetivo hermético para la serie PT-E...
-
Page 2: For Safe Use
■ Unauthorized copying of this manual in part or in full, except for personal use, is prohibited. Unauthorized reproduction is strictly prohibited. ■ Olympus shall not be responsible for damages, loss of profit or any claims by third parties in case of any damage occurring from incorrect use of this product. -
Page 3: Name Of Parts
Align the threaded section of the PPO-E03 with the port mount thread on the PT-E series case. Hold the PT-E series case firmly with one hand, hold the main body of the PPO-E03 with your other hand and screw it into the PT-E series by turning the PPO-E03 clockwise. - Page 4 PT-E series case. Be careful not to drop the PPO-E03 or PT-E series case. CAUTION: While dismounting the PPO-E03 from the case, water remaining on the PPO-E03 may splat- ter on the lens or camera. If this happens, wipe the water off the lens and camera with a dry cloth.
- Page 5 Attaching the Gear to the Lens To control the camera lens’s manual focus (MF) operation, the provided gear must be attached to the MF ring on the lens. * Note that this will restrict the rotation range of the MF ring to within 180°. Confirm the position of the gear’s lock dial and hinge.
-
Page 6: Loading The Camera And Lens
Loading the Camera and Lens After attaching the gear to the camera’s lens, insert the camera and lens into the PT-E series case on which the PPO-E03 is mounted. Screw the camera table provided with the PT-E Remove the eyecup from the camera’s viewfind- series case firmly into the bottom of the cam- er. - Page 7 After inserting the camera, turn the PT-E series Push in the PT-E series case’s power switch case’s camera table lock lever all the way clock- dial and mode dial knob. Turn the power switch wise to lock the camera table. Then, push in the dial and mode dial knob and confirm that they zoom/MF dial on the PT-E series case and can control the camera power ON-OFF and...
-
Page 8: Maintenance
Maintenance For safe use of this product, always perform maintenance after each diving session. For details, refer to “Handling After Shooting” and “Maintaining the Waterproof Function” in the PT-E series case instruction manual. Apply the same procedures to this product. After shooting, remove the inserted cam- After making sure that the PT-E series era and lens, then re-seal the empty... -
Page 9: Specifications
(Monday to Friday) ET numbers. E-Mail: distec@olympus.com For all not listed European Countries and in case that you Olympus software updates can be obtained at: can’t get connected to the above mentioned number please http://www.olympus.com/digital/ make use of the following... - Page 10 © 2005 OLYMPUS IMAGING CORP. Printed in Japan PPO-E03_01...
