Summary of Contents for Olympus PER-E01
- Page 1 PER-E01 Instruction Manual Underwater Extension Ring for PT-E Series Mode d’emploi Bague d’extension sous-marine pour la série PT-E Bedienungsanleitung Unterwasser-Zwischenring für PT-E Serie Manual de instrucciones Aro de extensión para usar debajo del agua para la serie PT-E...
-
Page 2: For Safe Use
I Unauthorized copying of this manual in part or in full, except for personal use, is prohibited. Unauthorized reproduction is strictly prohibited. I Olympus shall not be responsible for damages, loss of profit or any claims by third parties in case of any damage occurring from incorrect use of this product. -
Page 3: Name Of Parts
* This product has been designed for exclusive use with the following rear converter. It cannot be used in combination with any other rear converter. Corresponding rear converter ZUIKO DIGITAL 1.4X TELECONVERTER EC-14 Mounting the PER-E01 between the Waterproof Case and the Waterproof Lens Port Threaded section Grease applying surface on O-rings O-ring... - Page 4 Align the threaded section of the PER-E01 with the port mount thread on the PT-E series case. Hold the PT-E series case firmly with one hand, hold the main body of the PER-E01 with your other hand and screw it into the PT-E series by turning the PER-E01 clockwise.
- Page 5 Be careful not to drop the PER-E01 or PT-E. CAUTION: When removing the PPO-E series lens port and PER-E01 from the case, water drops on the O-rings may splash on the lens or camera. If this happens, wipe the water drops away from the lens and camera with a dry cloth.
-
Page 6: Loading The Camera And Lens
Loading the Camera and Lens After installing the EC-14 ZUIKO DIGITAL 1.4X TELECONVERTER rear converter between the camera and lens, insert the camera and lens into the PT-E series case on which the PER-E01 and the PPO-E series lens port are mounted. - Page 7 CAUTION: When this product is used in combination with a zoom lens, zooming of cannot be controlled after the camera has been loaded in the case. Be sure to set the zoom ring of the lens to the desired focal distance before loading the camera in the case. Pull out the zoom dial further.
-
Page 8: Maintenance
Maintenance For safe use of this product, always perform maintenance after each diving session. For details, refer to “Handling After Shooting” and “Maintaining the Waterproof Function” in the PT-E series case instruction manual. Apply the same procedures to this product. After shooting, remove the inserted cam- After making sure that the PT-E series era and lens, then re-seal the empty... -
Page 9: Specifications
(Monday to Friday) ET numbers. E-Mail: distec@olympus.com For all not listed European Countries and in case that you Olympus software updates can be obtained at: can’t get connected to the above mentioned number please http://www.olympus.com/digital/ make use of the following... - Page 10 © 2005 OLYMPUS IMAGING CORP. Printed in Japan PER-E01_01...
