Instruction Manual
Underwater Case
PT-033
For the digital camera
Stylus 720 SW, µ 720 SW
■ Thank you for buying the Underwater Case PT-033.
■ Please read this instruction manual carefully and use the product safely
and correctly.
■ Please keep this instruction manual for reference after reading it.
■ Wrong use may cause damage to the camera on the inside from water
leakage, and repair may not be possible.
■ Before use, perform an advance check as described in this manual.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PT-033 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Olympus PT-033

Summary of Contents for Olympus PT-033

  • Page 1 PT-033 For the digital camera Stylus 720 SW, µ 720 SW ■ Thank you for buying the Underwater Case PT-033. ■ Please read this instruction manual carefully and use the product safely and correctly. ■ Please keep this instruction manual for reference after reading it.

  • Page 2: Please Read The Following Items Before Use

    Unauthorized reproduction is strictly prohibited. ● OLYMPUS IMAGING CORP. shall not be responsible in any way for lost profits or any claims by third parties in case of any damage occurring from unsuitable use of this product.
  • Page 3 1. Do not disassemble or modify this product. This may cause water leakage or trouble. In case of disassembly or modification by persons other than those appointed by OLYMPUS IMAGING CORP. the guarantee shall not apply. 2. Do not place this product at locations with abnormally high or abnormally low temperatures or at locations with extreme temperature changes.

  • Page 4: Batteries

    9. When sealing this product, take sufficient care that no foreign matter gets caught at the O-ring and the contact surfaces. Batteries ● Use only an Olympus lithium-ion rechargeable battery (LI-42B) with the camera. ● Take care that the battery electrodes do not become wet. This may cause trouble or accidents.

  • Page 5: For Prevention Of Water Leakage Accidents

    For Prevention of Water Leakage Accidents When water leakage occurs while this product is being used, repair of the camera housed in this product may become impossible. Please observe the following cautions for use. 1. When sealing this product, make sure that no hairs, fibers, sand particles or other foreign matter stick not only to the O-ring, but also to the contact surface (flat part of the front cover).
  • Page 6 8. When the O-ring contact surface is pressed strongly from the outside of the Case, or when the Case is twisted, the waterproof function may be lost. Take care not to exert excessive force. 9. Please use the Case after performing the advance test and the final check.
  • Page 7 Any troubles in taking pictures or with the equipment resulting from the above actions shall be outside the guarantee. ● OLYMPUS IMAGING CORP. shall be in no way responsible for accidents involving immersion of a digital camera in water. ● OLYMPUS IMAGING CORP. shall not pay any compensation for...

  • Page 8: Table Of Contents

    Contents Introduction ................E-1 Please read the following items before use ......E-1 For safe use ................E-1 Batteries ..................E-3 Setting the underwater shooting scene mode......E-3 For Prevention of Water Leakage Accidents......E-4 Handling the Product..............E-5 E-7-8 Contents ................1.Preparations ............Check the contents of the package...........E-9 Names of the parts ..............E-10 Install the strap.
  • Page 9 Remove the O-ring..............E-30 Remove any sand, dirt, etc.............E-30 Install the O-ring..............E-32 How to Apply Grease to the O-ring ..........E-32 Replace consumable products..........E-33 E-34 8.Appendix ................Q & A on the use of the PT-033 ..........E-34 Specifications ................E-39...

  • Page 10: Preparations

    O-ring remover (Check that the O-ring is normal.) Instruction manual Authorised distributors list/ (this manual) Authorised service centres list PT-033 取扱説明書 防水プロテクタ  デジタルカメラμ720 SW 用  Instruction Manual Underwater Case For the digital camera Stylus 720 SW, µ 720 SW Mode d'emploi Caisson étanche Pour l'appareil photo numérique Stylus 720 SW, µ 720 SW Bedienungsanleitung Unterwassergehäuse...

  • Page 11: Names Of The Parts

    Names of the parts ❈ Palm grip Loading guide rails (Note 1)/ Diffuser plate and LCD inner hood cross-cursor button diffuser plate cover O-ring (Note 1) The Down cross-cursor button functions as the AF lock button ❈ Shutter lever Tripod seat in Underwater Wide 1 or Underwater ❈...

  • Page 12: Install The Strap

    Hand strap ring Hand strap CAUTION : Please install the strap correctly as shown above. OLYMPUS IMAGING CORP. shall bear no responsibility for damage etc. caused by dropping the Case because of incorrect installation of the strap. Master the basic operation.

  • Page 13: How To Press The Shutter

    How to Press the Shutter When pressing the shutter lever, press it gently, so that there will be no movement of the camera. Note: • For detailed operation of the shutter, refer to the instruction manual for the digital camera. How to Switch Between the and SCN Modes You can switch between the...

  • Page 14: Advance Check Of The Case

    Do not feel that this is troublesome, but perform this test. • If a leak is detected in normal handling during testing, do not use the Case and contact Olympus. E-13...

  • Page 15: Install The Digital Camera

    Case lids and may cause water leakage. • When removing the strap, handle the digital camera with sufficient care. OLYMPUS IMAGING CORP. shall not be responsible for damage caused by dropping the camera etc.

  • Page 16: Prepare The Camera

    Prepare the camera. Applicable Digital Cameras This product (PT-033) is designed exclusively for use with the Stylus 720 SW and µ 720 SW digital cameras. Turn the digital camera ON. The digital camera can be switched ON by pressing the camera’s POWER button once.

  • Page 17: Load The Digital Camera

    Load the digital camera. Confirm that the digital camera is OFF and insert the digital camera gently into the Case. CAUTION : • If the digital camera is not inserted properly, it may not be possible to seal the case so that it is airtight. Alternatively, some controls may become inoperable.

  • Page 18: Insertion Of Silica Gel

    Insertion of silica gel Before sealing the Case, insert the accessory silica gel bag for prevention of fogging between the bottom of the camera and the Case. Pay attention to the orientation. CAUTION : • Insert the silica gel all the way at the specified location and with the specified orientation.

  • Page 19: Make Sure The Camera Is Loaded Properly

    Make sure the camera is loaded properly. Check the following points before sealing the Case. Is the digital camera loaded properly? Is silica gel inserted deep in the specified location? Is the O-ring attached properly to the opening on the Case? Is there any dirt or foreign matter on the O-ring or the O-ring contact surface on the front lid? Seal the Case.

  • Page 20: Check The Operation Of The Loaded Camera

    Check the operation of the loaded camera. After sealing the Case, make sure the camera is functioning properly. 1. Press the POWER button on the Case and confirm that the camera turns ON/OFF. 2. Press the /SCN button on the Case and confirm that the camera modes switch properly.

  • Page 21: Confirm The Shooting Scene And Shooting Mode

    Confirm the shooting scene and shooting mode When using the Case, current shooting scene and shooting mode information should be confirmed by checking the shooting scene/shooting mode indicators displayed on the camera’s LCD monitor. Shooting scene/shooting mode indicators E-20...

  • Page 22: Installation And Removal Of The Lcd Hood

    Installation and Removal of the LCD Hood Installation Strongly push the mounting projections of the LCD hood as shown in the figure into the guides above and below the LCD monitor window. Removal Remove the mounting projections of the LCD hood from the guides above and below the LCD monitor window by widening the LCD hood.

  • Page 23: Mounting And Removing The Lens Cap

    Mounting and Removing the Lens Cap Fit the lens cap onto the lens ring as shown in the figure. Be sure to remove the lens cap before shooting. Perform the final checks. Visual Inspection After sealing the Case, check the sealing part of front and rear lid visually to confirm that the O-ring is not twisted or out of the groove and that no foreign matter has been caught.

  • Page 24: Final Test

    As the inside can be seen, the inspection for become moist? entry of water also can be made securely! Now everything is Now everything is all right! all right. Have a nice dive! Note : The PT-033 is not provided with a balance weight. E-23...

  • Page 25: Taking Pictures Under Water

    4. Taking Pictures Under Water How to Use the Hand Strap Pass your hand through the accessory hand strap and adjust the length with the stop button. Take pictures carefully. Confirm the picture on the LCD monitor. This Case uses the LCD monitor to confirm the picture. Quietly press the shutter lever.

  • Page 26: Underwater Shooting According To The Scene Type

    5. Underwater Shooting According to the Scene Type The camera incorporates the following shooting scene modes. Select the one best suited to the underwater scene you are shooting. Underwater shooting modes (Examples) Underwater Wide-Angle 1 Suitable for shooting a scene that extends across a wide range such as a school of fish swimming through the water.

  • Page 27: How To Select The Shooting Scene

    How to select the shooting scene Press the /SCN button on the Case to set the camera mode to the SCN (Scene) mode. When the selection display Set to appears, press the Up/Down cross-cursor “SCENE.”. buttons to select Underwater Wide- angle 1, Underwater Wide-angle 2 or Underwater Macro.

  • Page 28: Handling After Shooting

    6. Handling After Shooting Wipe off any waterdrop. After completing the shooting and returning to land, wipe off any waterdrop sticking to the Case. Use air or a soft cloth not leaving any fibers to thoroughly wipe any waterdrop etc. from the joint between the front and rear lid, the shutter lever, the palm grips, and the buckles.

  • Page 29: Take Out The Digital Camera

    Take out the digital camera. Open the Case carefully and take the digital camera out. CAUTION : • Always place the opened Case with the O-ring side facing up. If the Case is placed with the O-ring side facing down, dirt or other foreign matter may get on the O-ring or the O-ring contact surface and may allow water penetration during the next dive.

  • Page 30: Wash The Case With Pure Water

    Wash the Case with pure water. After use, seal the Case again after taking out the camera and wash it sufficiently in pure water as soon as possible. After use in sea water, it is effective to immerse it for a fixed time in pure water to remove any salt. CAUTION : •...

  • Page 31: Maintaining The Waterproof Function

    7. Maintaining the Waterproof Function Whenever you open the rear lid of the Case, always be sure to perform the O-ring maintenance operation as described below. Remove the O-ring. Open the Case and remove the O-ring from the Case. Removal of the O-ring Insert the O-ring remover between the O-ring and the O-ring groove.
  • Page 32 Remove any foreign matter attached to the O-ring groove using a lint- free clean cloth or cotton swab. Also remove any sand or dirt attached to the O-ring contact surface on the front lid of the case. CAUTION : • Maintenance of the waterproof functions is required even before using this product underwater for the first time.

  • Page 33: Install The O-Ring

    Install the O-ring. Confirm that no foreign matter is attached, apply a thin coat of the accessory grease to the O-ring, and fit the O-ring into the groove. At this time, confirm that the O-ring does not stick out from the groove. How to Apply Grease to the O-ring Apply the Make sure that your fingers and the O-...

  • Page 34: Replace Consumable Products

    Replace the O-ring even before a year has passed if it shows signs of damage, cracking or loss of elasticity. Note: • Please use original Olympus products for the silicone O-ring grease, the silica gel, and the O-ring. These consumable products also can be purchased at an Olympus service station.

  • Page 35: Appendix

    Q & A on the use of the PT-033 Q1 : What digital camera models can be used with this product? A1 : This product (PT-033) is designed exclusively for use with the Stylus 720 SW and µ 720 SW digital cameras.
  • Page 36 (c) Places with volatile substances (d) Places with vibrations (3) In case of the following handling with a camera loaded into the Case, trouble or breakage may be caused for the Case and/or the loaded camera. Always avoid such handling. (a) Hitting other objects (b) Dropping (c) Placing heavy objects on top of the Case...
  • Page 37 Case under direct sunlight. Exposure to high temperatures or direct sunlight may cause deformation, discoloration or breakage of the Case and deterioration of the O-ring. Wipe the inside of the Case with a soft cloth not causing any fibers. Remove the O-ring, wipe off any salt, sand, dust, etc., and also clean the O-ring groove and the O-ring contact surface in the same way and then dry them.
  • Page 38 O-ring will be damaged or that its deterioration will be accelerated. (2) Use the original Olympus silicone O-ring grease (white cap). The grease attached to Cases up to PT-008 (red cap) and the grease of...
  • Page 39 Case yourself. Repair, disassembly or modification by you or third parties not authorized by Olympus invalidates the guarantee. Q12: What are the model names of the accessories for the PT-033? A12: The following accessories are being sold. (1) O-ring for the PT-033 body (POL-033): This is a silicone rubber O-ring packing to be installed in the PT-033 body to make it waterproof.

  • Page 40: Specifications

    Specifications Available models Olympus digital camera Stylus 720 SW, µ 720 SW Pressure Depth of up to 40 m resistance Main materials Body: Transparent polycarbonate Buckles: Stainless steel Grip/Shutter lever: Red polycarbonate Lens window: FL glass Operation buttons: Stainless steel Nickel-plated brass Dimensions Width 131.5 mm x height 106.5 mm x thickness 72.0 mm...
  • Page 41 MEMO E-40...
  • Page 42 MEMO E-41...
  • Page 43 MEMO E-42...
