Using with the Rechargeable Battery
Do not force the
battery cover
open too far.
AC 230V,
50/60Hz
To the DC IN
5V socket
Using with the Alkaline Battery
Use one commercially available alkaline battery (LR6,
"AA" size).
Open
2
Press
1
Back of the
portable MD
RELEASE
LOCK
OPERATION MANUAL
Charging the rechargeable battery
When the rechargeable battery is used for the first time
Insert the
or when you want to use it after a long period of disuse,
– side first.
be sure to charge it fully.
1
Insert the rechargeable battery.
A rechargeable battery other than the AD-N55BT
cannot be charged.
2
Plug the AC adaptor into the wall socket, and
then insert the plug on the other end into the DC
IN 5V socket.
3
Press the MENU/CHRG button.
The battery indicator will scroll, and battery will be-
gin charging.
After the rechargeable battery is charged or used, it
will get slightly warm. This is normal.
When the portable MD is turned on or operating, the
battery will not be charged.
When using the alkaline battery, be sure to insert the
rechargeable battery also.
1
Open the case cover.
2
Insert an alkaline battery into the battery case.
3
Attach the battery case to the portable MD.
Caution:
Whilst you are using the rechargeable battery and the
alkaline battery at the same time, do not remove either
of them. If you do, when the unit is in the play mode,
playback will stop. When in the recording mode, the
recorded contents will be erased, and the power may
be disconnected.
Do not replace the battery or the rechargeable battery
during operation.
Do not use a rechargeable battery (nickel-cad-
mium battery etc.) in the battery case.
If the unit is not used for a long period of time, remove
the battery. (Even if the power is turned off, the battery
will be drained slowly but continuously.)
– 5 –
