XL-3500H
COMPACT AUDIO SYSTEM
1
1
Accessories
AC power lead
FM aerial
2
2
Battery installation of remote control
Use 2 "AAA" size batteries (UM-4, R03, HP-16 or similar).
Batteries are not included.
Remove the
1
battery cover.
*XL-3500H(E)_QG
This Quick Guide will help you to correctly
install and operate your system.
If you require any advice or assistance
regarding your Sharp product, please
visit our web-site www.sharp.co.uk/
support.
Customers without internet access may
telephone 08705 274277 during office
hours (or (01) 676 0648 if telephoning
from Ireland).
1
Remote control
1
Insert the batteries
2
as shown.
– 1 –
1
1
AM loop aerial
Speaker wire 2
Replace the cover.
3
TINSE0087SJZZ
02.1.16, 11:18 AM
1
A0201.TO
