Transcend SSD18M User Manual

1.8" solid state drive
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
1.8" Solid State Drive
User's Manual
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SSD18M and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Transcend SSD18M

Summary of Contents for Transcend SSD18M

  • Page 1 1.8" Solid State Drive User’s Manual...

  • Page 2: Table Of Contents

    OS 9.0, or Later (USB & eSATA) ..................14 ® Linux Kernel 2.4, or Later (USB) ....................14 Formatting the SSD︱ ......................15 ® Windows 2000/XP ........................15 Windows Vista® ...........................16 ® OS ............................18 ® Linux ............................20 Troubleshooting︱ .......................22 Specifications︱ ........................23 Ordering Information︱ ......................23 Transcend Limited Warranty︱ ...................24...

  • Page 3: Introduction

    With both eSATA and USB 2.0 connection options, the SSD18M gives you the ultimate in flexibility. The USB interface provides maximum compatibility with all types of notebooks and PCs, while the new high-speed eSATA interface gives you the maximum performance possible from your SSD with transfer speeds up to 90MB/s.

  • Page 4: Features

    SATA connector. • Whether connecting via eSATA or USB, the SSD requires power from an extra USB port on your computer. Backing Up Data • Transcend does NOT take any responsibility for data loss or damage during operation. If you...

  • Page 5: Reminders

    decide to store data on your SSD we strongly advise that you regularly backup the data to a computer, or other storage medium. • To ensure eSATA / High-Speed USB 2.0 data transfer rates when using your SSD with a computer, please check the computer has the relevant eSATA / USB drivers.

  • Page 6: Product Overview

    Product Overview︱ USB Port eSATA Port LED Indicator Light...

  • Page 7: Connecting To A Computer

    Connecting to a Computer︱ The SSD can be connected to your computer in two ways: USB 2.0 or eSATA. To get the best performance results from your SSD, we strongly recommend using the eSATA interface. If your computer does not have an eSATA port, you may need to purchase an SATA to eSATA adapter bracket (often included in PC motherboard packaging) or a PCI / PCI-X / PCI-Express eSATA card to connect your SSD using eSATA.
  • Page 8 When connecting with eSATA, use the Device Manager to scan for the SSD if Windows does not auoto-detect it. 3. A new Local Disk with a newly assigned drive letter representing the SSD will automatically appear in the My Computer window under “Hard Disk Drives.” Note: the drive name and letter in your "My Computer"...

  • Page 9: Windows Vista

    Windows Vista® 1. Connect the SSD to your computer: – eSATA – A. Plug both the eSATA and mini USB ends of the eSATA cable into the SSD. B. Connect the large USB connector on the other end of the cable to a working USB port on your desktop computer.

  • Page 10: Mac ® Os

    Note: the drive name and letter in your "AutoPlay" window may differ ® 1. Connect the SSD to your computer: – eSATA – A. Plug both the eSATA and mini USB ends of the eSATA cable into the SSD. B. Connect the large USB connector on the other end of the cable to a working USB port on your desktop computer.

  • Page 11: Linux

    ® the Formatting the SSD section to prepare your drive for use with your Linux system. 3. Create a directory for the SSD. Example: mkdir /mnt/SSD18M 4. Then, mount the SSD. Example: mount –a –t msdos /dev/sda1 /mnt/SSD18M...

  • Page 12: Disconnecting From A Computer

    Disconnecting from a Computer︱ WARNING! To prevent data loss, ALWAYS follow these removal procedures. NEVER disconnect or turn off the SSD when its LED is flashing. ® Windows 2000, XP and Vista (USB) 1. Select the Removable Hardware icon on the system tray. 2.
  • Page 13 4. In the Policies tab, ensure that the “Enable write caching” option is not checked.

  • Page 14: Mac ® Os 9.0, Or Later (Usb & Esata)

    ® OS (USB & eSATA) Drag and drop the Disk icon that represents your SSD into the trashcan. Then unplug your SSD from the eSATA and/or USB port. ® Linux Kernel 2.4, or Later (USB) Execute umount/mnt/SSD to un-mount the device. Then unplug your SSD from the USB port.

  • Page 15: Formatting The Ssd

    Windows 2000/XP Download StoreJet Format Utility from Transcend’s online Download Center http://www.transcendusa.com/Support/DLCenter/index.asp (the software can be located by selecting “Storage Devices -> StoreJet Drives -> any StoreJet product -> any StoreJet model) When the download is complete, extract the downloaded ZIP file to your computer’s hard drive (not the SSD) and run the StoreJetFormatter.exe application.

  • Page 16: Windows Vista

    Windows Vista® Download StoreJet Format Utility from Transcend’s online Download Center http://www.transcendusa.com/Support/DLCenter/index.asp (the software can be located by selecting “Storage Devices -> StoreJet Drives -> any StoreJet product -> any StoreJet model) When the download is complete, extract the downloaded ZIP file to your computer’s hard drive (not the SSD).
  • Page 17 Plug the SSD into an available USB port on your Windows Vista® computer. Unplug all other USB storage devices from your computer. This is to prevent accidental format of a different USB drive. In the StoreJet Format Utility window, click the “Refresh” button. The program will automatically detect the SSD drive.

  • Page 18: Mac ® Os

    11. The format process may take a few minutes. When complete, an “O.K.” message will appear in the bottom right hand corner of the window. 12. Click the “Close” button to finish and exit. ® Plug the SSD into an available USB port on your MAC computer. Unplug all other external storage devices from your computer.
  • Page 19 Input a name for your new drive (otherwise, your drive will be named “Untitled”) Click the “Erase” button in the bottom right corner of the window...

  • Page 20: Linux

    Click “Erase” again to confirm. 10. Click the “Close” button to finish and exit. ® Linux Plug the SSD into an available USB port on your Linux computer. Unplug all other USB storage devices from your computer. This is to prevent accidental format of a different USB drive.
  • Page 21 Type mkdir /mnt/SSD Type mount /mnt/SSD...

  • Page 22: Troubleshooting

    If a problem occurs with your SSD, please first check the information listed below before taking your SSD in for repair. If you are unable to remedy a problem from the following hints, please consult your dealer, service center, or local Transcend branch office. We also have FAQ and Support services on our website at www.transcendusa.com...

  • Page 23: Specifications

    Linux® kernel 2.4.2 or later Windows® 2000 / XP / Vista Supported Operating Systems (eSATA) Mac® OS 10.4 or later CE, FCC ClassB, BSMI Certificates: 2-years Warranty: Ordering Information︱ Device Description Transcend P/N SSD18M (32GB) TS32GSSD18M-M SSD18M (64GB) TS64GSSD18M-M SSD18M (128GB) TS128GSSD18M-M...

  • Page 24: Transcend Limited Warranty

    Transcend is not responsible for recovering any data lost due to the failure of a hard drive device. Transcend’s SSD18M must be used with devices that conform to the recommended industry standards. Transcend will not be liable for damages resulting from a third party device that causes the Transcend SSD18M to fail.
