Cordless Driver Drill
Equipped with Electric Brake
MODEL 6313D
I N S T R U C T I O N
M A N U A L
WARNING:
For your personal safety, READ and UNDERSTAND before using.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
w w w . m a k i t a t o o l s . c o m

Advertisement

Table of Contents
loading

Related Manuals for Makita 6313D

Summary of Contents for Makita 6313D

  • Page 1 Cordless Driver Drill Equipped with Electric Brake MODEL 6313D I N S T R U C T I O N M A N U A L WARNING: For your personal safety, READ and UNDERSTAND before using. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.

  • Page 2: Specifications

    SPECIFICATIONS Model 6313D Steel 13 mm (1/2”) Wood 25 mm (1”) Capacities Wood screw 6.4 x 76 mm (1/4” x 3”) Machine screw 6 mm (1/4”) High 0 - 1,400/min. No load speed (RPM) 0 - 450/min. 243 mm x 94 mm x 241 mm Dimensions (L x W x H) (9-9/16”...
  • Page 3 SAVE THESE INSTRUCTIONS Work Area tery pack into a tool with the switch on invites accidents. 1. Keep your work area clean and well lit. 9. Remove adjusting keys or wrenches Cluttered benches and dark areas invite acci- before turning the tool on. A wrench or a dents.

  • Page 4: Specific Safety Rules

    small metal objects that can make a con- model. Accessories that may be suitable for nection from one terminal to another. one tool may create a risk of injury when Shorting the battery terminals together may used on another tool. cause sparks, burns, or a fire.
  • Page 5 8. An extension cord should not be used 3. CAUTION - To reduce risk of injury, charge unless absolutely necessary. Use of only MAKITA rechargeable batteries improper extension cord could result in a marked on the charger label. Other types risk of fire and electric shock.
  • Page 6 c. That wire size is at least as large as the one specified in the table below. Table 1: RECOMMENDED MINIMUM AWG SIZE FOR EXTENSION CORDS FOR BATTERY CHARGERS Length of Cord (Feet) AWG Size of Cord 9. Do not operate charger with damaged 13.
  • Page 7 7. Do not incinerate the Battery Cartridge 8. Be careful not to drop, shake or strike bat- even if it is severely damaged or is com- tery. pletely worn out. The battery cartridge can 9. Do not charge inside a box or container of explode in a fire.

  • Page 8: Functional Description

    FUNCTIONAL CAUTION: DESCRIPTION • Always be sure that the tool is switched off and the battery cartridge is removed before adjusting or checking function on the tool. Installing or removing battery cartridge 002048 • Always switch off the tool before insertion or removal of the battery cartridge.
  • Page 9 NOTE: • The battery charger is for charging Makita battery cartridge. Never use it for other purposes or for other manufacturer’s batteries. • When you charge a new battery cartridge or a battery cartridge which has not been used for a long period of time, it may not accept a full charge.

  • Page 10: Switch Action

    Electric brake This tool is equipped with an electric brake. If the tool consis- tently fails to quickly stop after switch trigger release, have tool serviced at a Makita service center. Reversing switch action 002086 This tool has a reversing switch to change the direction of rotation.

  • Page 11: Adjusting The Fastening Torque

    CAUTION: • Always set the speed change lever fully to the correct position. If you operate the tool with the speed change lever positioned halfway between the “I” side and “II” side, the tool may be damaged. • Do not use the speed change lever while the tool is running.

  • Page 12: Screwdriving Operation

    When not using the driver bit, keep it in the bit holders. Bits 002114 45 mm (1-3/4”) long can be kept there. 1. Bit 2. Bit holder OPERATION Screwdriving operation 002868 Place the point of the driver bit in the screw head and apply pressure to the tool.

  • Page 13: Maintenance

    Drilling operation First, turn the adjusting ring so that the pointer points to the marking. Then proceed as follows. Drilling in wood When drilling in wood, the best results are obtained with wood drills equipped with a guide screw. The guide screw makes drilling easier by pulling the bit into the workpiece.

  • Page 14: Replacing Carbon Brushes

    Makita Authorized or Factory Service Centers, always using Makita replacement parts. EN0001-1 Recycling the Battery The only way to dispose of a Makita battery is to recycle it. The law prohibits any other method of disposal. To recycle the battery: 1. Remove the battery from the tool.
  • Page 15 CAUTION: • These accessories or attachments are recommended for use with your Makita tool specified in this manual. The use of any other accessories or attachments might present a risk of injury to persons. Only use accessory or attachment for its stated purpose.
  • Page 16 Memo...
  • Page 17 First-Class Postage Required Post Office will not deliver without proper postage. Makita U.S.A., Inc. 14930 Northam Street La Mirada, CA 90638-5753 Fold...
  • Page 18 Design Repair Service Industrial Maintenance Features Durability Home Maintenance Size Power Hobby Price Other ( Other ( Makita Brand 5. Any comments: DATE PURCHASED MODEL NO. MONTH YEAR SERIAL NO. STATUS INTL. LAST NAME / COMPANY NAME Married Single STREET ADRESS...

  • Page 19: Factory Service Centers

    Date Purchased When you need service: Send complete tool (prepaid) to one Dealer’s Name & Address of the Makita Factory Service Centers listed, or to an Authorized Makita Service Center. Be sure to attach a letter to the outside of Model No.

  • Page 20: Warranty Policy

    MAKITA LIMITED ONE YEAR WARRANTY Warranty Policy Every Makita tool is thoroughly inspected and tested before leaving the factory. It is warranted to be free of defects from workmanship and materials for the period of ONE YEAR from the date of original purchase.
