Page 1
T O Y O T A N A V I G A T I O N S Y S T E M INSTALLATION INSTRUCTIONS PART NUMBER 08545-00803 NAVIGATION KIT PART N° Manual Ref. Nr.N1RT23-0-00 TOYOTA MOTOR CORPORATION...
Celica TNS 500 PRECAUTIONS PLEASE READ THOROUGHLY THESE PRECAUTIONS BEFORE THE INSTALLATION • Be sure to disconnect the negative • Protect your car with fender covers, seat (-) lead from the battery terminals. and so on. • Do not pinch the rear wiring or har- •...
Page 6
Celica TNS 500 1: NAVIGATION DISC (CD-ROM) is not included in the navigation kit. Note : In cases where the CD-Changer is installed together with the navigation system, the wire harness n° 08695-00260 is needed (See page 7). The wire harness is not included in the navigation kit.
Celica TNS 500 HOW TO CONNECT GENERAL OUTLINE (Audio with AVC-LAN) Refer to the repair manual for information on removal of vehicle parts, installation methods, torque and so forth. DIN-13P GPS Antenna Monitor Computer Wire Harness Sub-Assy - Speed Line (violet/white)
Celica TNS 500 AUDIO UNITS WITH 13PIN CONNECTOR (WITHOUT AVC-LAN) DETAILED CONNECTION OUTLINE Audio Assy CD-Changer MOP Radio without AVC TM0461 • Audio Unit Application AUDIO ASSY + NAVIGATION SYSTEM Audio Assy DIN 13P (No use) DIN 13P Antenna No use...
Yaris Celica TNS 500 TNS 500 VEHICLE DISASSEMBLY FOR A/T MODELS Remove the console panel Figure 1 FOR M/T MODELS Remove the shift knob and console panel Figure 2 FOR VEHICLES WITH AUTO AIR CONDITIONER Remove the center cluster : Screws (2x)
Page 14
Celica TNS 500 FOR VEHICLES WITH MANUAL AIR CONDITIONER Remove the heater control knobs and center cluster : Screws (2x) Figure 4 Remove the covers : Bolts (4x) Figure 5 Remove the front pillar garnish RH Figure 6 09-99 Celica (RHD) - 14...
Page 15
Celica TNS 500 Remove the cowl side panel (RH) and front door scuff plate (RH) : Nut Figure 7 Remove the deck floor box (RH) : Hook : Bolts (2x) Figure 8 Remove the luggage front box : Clips (2x)
Page 16
Celica TNS 500 Remove the rear seat back : Bolts (4x) Figure 10 Remove the rear seat cushion : Hooks (2x) Figure 11 09-99 Celica (RHD) - 16...
Celica TNS 500 INSTALLATION OF THE GPS-ANTENNA Affix the earth plate at the location shown in the diagram and mount the antenna earth plate CAUTION: When affixing the earth plate make sure to carefully wipe off any dirt, moisture or oil...
Celica TNS 500 WIRE HARNESS INSTALLATION SPEED (SPD) SENSOR WIRE (TO MONITOR ) INSTALLATION red/white Take the wire harness sub assy and cut and tape the red/white wire. violet/white Tape Figure 15 2. Make a splicing connector as shown in the left figure.
Page 19
Celica TNS 500 Turn the 20P connector so the wires face you and the connector’s tab is on J/B 20P (white) top. Locate the wire in the top row, fifth posi- tion from the right. Using a splicing connector, attach the...
Page 20
Celica TNS 500 Turn the 8P connector so the wires 8P (black) face you and the tab is on top. Locate the wire in the bottom row, first position from the left. Using a splicing connector, attach the reverse sensor wire (red/blue) to the vehicle wire.
Page 21
Celica TNS 500 WIRE HARNESS AND WIRE HARNESS SUB-ASSEMBLY INSTALLATION Tape Route the wire harness and the wire harness sub-assembly shown in the left figure. Secure the speed sensor wire (vio- let/white) of the wire harness sub- assembly with the tape...
Page 22
Celica TNS 500 Route the antenna cord securely in between the trim to the computer connection location. CAUTION: Route the antenna cord securely in between the trim, so that Antenna Cord and it does not show. Wire Harness Figure 27...
Celica TNS 500 INSTALLATION OF THE COMPUTER Temporarily place the brackets the computer Attach the adhesive tapes to the under part of the brackets CAUTION: Do not remove the re- lease paper on the under side of the adhesive tapes yet.
Page 24
Celica TNS 500 FOR MODELS WITHOUT DECK FLOOR BOX 210mm Slit the luggage carpet at the computer installation position. Computer installing part 20mm Figure 31 Install the computer at the left rear position of the luggage room. Asphalt Seat (Right Side)
Celica TNS 500 MONITOR INSTALLATION Connect the splicing connector of wire harness to the speed sensor wire Vehicle Wire Harness (violet/white) of the wire harness sub- assy of the monitor 8P Connector Connect the wire harness radio con- nector to the audio assy, and 8P con-...
Page 26
Celica TNS 500 Remove the brackets and panels. Bracket (L) : Screws (8x) Cover Bracket (R) Panel (L) Cover Figure 34 Panel (R) Mount the bracket onto the monitor Bracket (L) and audio assembly. : Bolts (8x) NOTE: Before moving to 5, see Chapter “Wire Harness”...
Celica TNS 500 WIRE HARNESS CONNECTION AUDIO ASSEMBLY + NAVIGATION SYSTEM For details of the wire harness connection, refer to pages 9-12. FOR FUJITSU TEN AUDIO UNITS Wrap the DIN 13P connector in the foam to the DIN 13P connector.
Page 28
Celica TNS 500 AUDIO ASSY + NAVIGATION SYSTEM + CD AND MD CHANGER *NOTE : In case a CD Changer is installed in conjunction with a navigation system, wire harness 08695-00260 is necessary. 08695-00260 is not included in the navigation kit but to be ordered separately.
Page 29
Celica TNS 500 Secure the 1P connectors with wire To Audio assy * 08695-00260 To monitor To Changer wire Figure 43 Celica (RHD) - 29 09-99...
Celica TNS 500 STORAGE OF THE REMOTE CONTROL Stick the “soft” part of the Velcro to the rear of the remote control Figure 44 NORMAL STORAGE Attach the “hard” part of the Velcro the mid console. Figure 45 HIDE AWAY STORAGE Attach the “hard”...
Celica TNS 500 SYSTEM START UP POST-INSTALLATION INSPECTION Inspect wether the installation, the wiring and the connectors are well fitted. Especially verify whether no wire harness is pushed, pulled or pinched with excessive force. Use additional foam tape wherever necessary to prevent any damage.
Page 32
Celica TNS 500 The display will slide out. Figure 49 Raise the display by hand. Figure 50 An image will appear on the screen. TOYOTA NAVIGATION SYSTEM Figure 51 09-99 Celica (RHD) - 32...
Page 33
6. Set the system to the customers language by following the section on “language setting” in the Navigation System Owner’s Manual. NOTE : In case of any abnormality, please refer to the “TOYOTA Navigation System Troubleshooting Guide”. 7. Take the vehicle for a test drive and confirm that the map scrolls automatically.
