Summary of Contents for Yamaha SX230

  • Page 1 SX230 Owner’s / Operator’s Manual...
  • Page 2 Sport Boat, please consult a Failure to follow WARNING instruc- Yamaha dealer. tions could result in severe injury or Because Yamaha has a policy of con- death to the machine operator, a tinuing product improvement, this prod- bystander, or a person inspecting or uct may not be exactly as described in repairing the Sport Boat.
  • Page 3 SX230 PORT AFETY NFORMATION & F EATURES UNCTIONS PERATION & C AINTENANCE & S ROUBLESHOOTING PECIAL ROCEDURES ONSUMER NFORMATION...
  • Page 4: Table Of Contents

    Chapter 1 SAFETY INFORMATION IDENTIFICATION NUMBER RECORDS ......1-1 Primary I.D. Number ........1-1 Hull Identification Number (H.I.N.) .
  • Page 5: Identification Number Records

    Record your Primary I.D., H.I.N., and engine numbers in the spaces provided to assist you in ordering spare parts from your Yamaha Sport Boat dealer. Also record and keep these I.D. num- bers in a separate place in case your Sport Boat is stolen.
  • Page 6: Star Labels

    AFETY NFORMATION STAR LABELS TWO STARS - VERY LOW EMISSION The two-star label identifies engines This watercraft is labeled in California that meet the Air Resources Board’s with a California Air Resources Board 2004 exhaust emission standards. (CARB) star label 1. See below for a Engines meeting these standards have desciption of your particular label.
  • Page 7: Emission Control Information

    ENGINE FAMILY : THIS ENGINE CONFORMS TO U.S. EPA REGULATIONS FOR MARINE S1 ENGINES FELs g/low - hr SPARK PLUG GAP (mm) : TROLLING SPEED : YAMAHA MOTOR CO., CO, LTD. MANUFACTURED DATE LABEL 2 Manufactured date label YAMAHA Manufactured:...
  • Page 8: Important Labels

    AFETY NFORMATION IMPORTANT LABELS...
  • Page 9 AFETY NFORMATION...
  • Page 10 AFETY NFORMATION...
  • Page 11 AFETY NFORMATION Do not touch or remove electrical parts when starting or running engine. YAMAHA 6R7-83623-40...
  • Page 12: Safety Information

    Basic Orientation Video. Showing them the video may help reinforce the information contained in these materials. LIMITATIONS ON WHO MAY OPERATE THE SPORT BOAT Yamaha recommends a minimum operator age of 16 years old. Adults must supervise use by minors.
  • Page 13: Required Equipment

    A mirror can sizes), and electrical tape also be used as an emergency sig- Oar or paddle (look for one with a nal. Contact your Yamaha dealer or boat hook on the other end) the Coast Guard for more informa- tion.
  • Page 14: Cruising Limitations

    AFETY NFORMATION CRUISING LIMITATIONS risk of back/spinal injury (paralysis), facial injuries, and broken legs, Scan constantly for people, objects, ankles, and other bones. Do not and other watercraft. Be alert for jump waves or wakes. conditions that limit your visibility or Do not operate the boat in rough block your vision of others.
  • Page 15: Operational Requirements

    AFETY NFORMATION OPERATIONAL REQUIREMENTS For reasons of safety and proper care of the Sport Boat, always per- All riders must wear a Coast Guard form the pre-operation checks listed approved personal flotation device on page 3-4 before operating. (PFD). Passengers must always sit in a designated seating area, place feet on the deck, and hold on to the hand grips when the boat is in motion.
  • Page 16: Hazard Information

    AFETY NFORMATION Attach the engine shut-off cord (lan- Maintain a safe distance from other yard) to PFD and keep it free from boats or watercraft, and also watch steering wheel or other controls so for boats’ ski ropes or fishing lines. that the engine stops if the operator Obey the “Rules of the Road”...
  • Page 17: Night Operation

    JET THRUST NOZZLES obstructions until you have a good feel for the maneuver. Yamaha Sport Boats are water-jet propelled. The pumps are directly INTAKE GRATE connected to the engines. This means that the jet thrust will pro- duce some movement whenever the engines are running.
  • Page 18: Water-Skiing

    AFETY NFORMATION woven, sturdy and snug fitting WATER-SKIING apparel such as denim, but does not You can use the Sport Boat to tow a include spandex or similar fabrics water skier, using the tow cleat provid- like those used in bicycle shorts. A second person should be on It is the boat operator’s responsibility to board as a spotter to watch the...
  • Page 19: Rules Of The Road

    RULES OF THE ROAD Stand-On Vessel The vessel with the right-of-way has the duty to continue its course and Your Yamaha Sport Boat is legally con- speed, except to avoid an immediate sidered a powerboat. Operation of the collision. When you maintain your...
  • Page 20: Rules When Encountering Vessels

    AFETY NFORMATION RULES WHEN ENCOUNTERING Meeting If you are meeting another power ves- VESSELS sel head on, and are close enough to There are three main situations that run the risk of collision, neither of you you may encounter with other vessels has the right-of-way! Both of you which could lead to a collision unless should alter course to avoid an acci-...
  • Page 21: Other Special Situations

    AFETY NFORMATION Narrow Channels and Bends When navigating in narrow channels, you should keep to the right when it is safe and practical to do so. If the oper- ator of a power-driven vessel is prepar- ing to go around a bend that may obstruct the view of other water ves- sels, the operator should sound a pro- longed blast of four to six seconds on...
  • Page 22 AFETY NFORMATION “1” “3” “5” “7” C “1” “6” N “2” LIGHTED BUOY (Port Hand) Odd number, increasing toward head “7” RB “L” of navigation. Leave to port (left) pro- ceeding RG “L” White Light Green Light “5” “4” “2” “4” “6” LIGHTED BUOY (Starboard Hand) Even number, increasing toward head “3”...
  • Page 23: Reading Buoys And Other Markers

    The Online Boating Safety Course, particular state. The Uniform State available through the watercraft section Waterway Marking System has been of the yamaha-motor.com website, is a devised for these waters. free, 50-question learning course avail- This system uses buoys and signs with able to the public.
  • Page 24: Accident Reporting

    AFETY NFORMATION ACCIDENT ENJOY YOUR SPORT REPORTING BOAT RESPONSIBLY Boat operators are required by law to You share the areas you enjoy when file a Boating Accident Report with their operating your boat with others and state boating law enforcement agency with nature.
  • Page 25 Chapter 2 FEATURES & FUNCTIONS LOCATION OF MAIN COMPONENTS ......2-1 OPERATION OF CONTROLS AND OTHER FUNCTIONS ... . . 2-5 Steering .
  • Page 26 & F EATURES UNCTIONS LOCATION OF MAIN COMPONENTS Main Features: Air Filter Cases Hood Supports Fuel Tank Engine Compartment Vent Outlets Battery Engine Compartment Vent Inlets Blower Motor Fuel Tank Compartment Air Ventilation Port/Starboard Features: Fuel Tank Compartment Drain Plug Flush Attachments Jet Pumps Electrical Boxes...
  • Page 27 & F EATURES UNCTIONS...
  • Page 28 & F EATURES UNCTIONS LOCATION OF MAIN COMPONENTS: Bow Light Bow Eye Storage Compartments Bow Anchor Locker Grab Handles Cleats Courtesy Lights Fuel Pump Access Hatch Throttle/Shift Levers Ski Locker Stern Light Storage Stern Light Socket Ski Tow Hook Jet Pump Clean-out Access Panel Pump Clean-out Interlock Switches Rear Boarding Step Accessory Pedestal Table Mounts...
  • Page 29: Location Of Main Components

    & F EATURES UNCTIONS LOCATION OF MAIN COMPONENTS 40 45 x 1000 x 1000 PORT STARBOARD Control Features: Ignition Switch Keys Speedometer Steering Wheel Tachometer Tilt Adjustment Lever Depth Sounder Switches and Breakers Fuel Gauge Control Features: Pump Gates Deck Drain Ladder Clean-out Compartment Drain Trailer Strap Eyes...
  • Page 30: Operation Of Controls And Other Functions

    & F EATURES UNCTIONS OPERATION OF TILT LEVER CONTROLS AND OTHER FUNCTIONS STEERING 40 45 x 1000 x 1000 FUEL The tilt lever 1 is located under the steering wheel and is used to adjust the tilt of the steering wheel. There are three positions.
  • Page 31: Engine Shut-Off Switch

    & F EATURES UNCTIONS WARNING ENGINE SHUT-OFF SWITCH The clip on the end of the engine shut- Always attach the engine shut-off off cord must be attached to the engine cord to your personal flotation shut-off switch for the engines to run. device (PFD) BEFORE starting The cord must be attached to a secure the engines.
  • Page 32: Throttle/Shift Levers

    & F EATURES UNCTIONS OFF: WARNING Ignition circuits are switched off. The Before starting the engine, check engine cannot be started but other the operation of each engine’s throt- switches will operate. (The key can be tle/ shift lever. It should move removed.) smoothly through the full range of operation.
  • Page 33 & F EATURES UNCTIONS Do not shift into Reverse while traveling at planing speeds. Loss of control, boat swamping, or damage to the boat could occur. NOTE: This Sport Boat is equipped with “start-in-gear” protection. The engines will not start unless the levers are in the Neutral position.
  • Page 34: Fuel Tank Filler Cap

    & F EATURES UNCTIONS Reverse GAUGES The jet pump gates are dropped all the 1. Speedometer way down over the jet nozzles. Jet thrust The speedometer 1 shows the boat is redirected toward the bow of the boat, speed in miles per hour (mph). which moves the boat backward.
  • Page 35 & F EATURES UNCTIONS 3. Fuel Level Gauge 4. Depth Sounder The fuel level gauge 1 shows the amount of fuel in the fuel tank. The ignition switch must be in the “ON” position to activate the gauge. 40 45 x 1000 x 1000 Warning LED...
  • Page 36 AFETY NFORMATION miliar water, or if you suspect shallow water or submerged objects, as water depth may change too quickly to allow time for you to react. • Extremely dirty water, very soft bottom, high speeds, deep water, Setting the Shallow Alarm or a combination of the above The Shallow Alarm function can be set may result in incomplete or inac-...
  • Page 37 At the same time, engine speed reduc- tion control is activated, limiting maximum speed to 3000 rpm. If this occurs, reduce engine speed and return to shore. Have a Yamaha 2-12...
  • Page 38: Overheat Warning System

    & F EATURES UNCTIONS dealer check the engine oil pres- sure. 40 45 x 1000 x 1000 If water is not circulating, something may be clogging the jet intake grate. OVERHEAT WARNING SYSTEM Refer to the Jet Pump Clean-Out pro- cedures on page 5-5 for further infor- The engine has an overheat warning mation.
  • Page 39: Switches

    The electrical circuit for each switch is protected by a circuit breaker. If the button below a switch pops out, push it back in with your finger. If it pops out again, ask your Yamaha dealer to inspect the electrical system. 2-14...
  • Page 40: Swivel Seat Operation

    & F EATURES UNCTIONS NOTE: There is also an accessory fuse at the battery (see page 4-15). STEREO SYSTEM SWIVEL SEAT OPERATION A stereo CD player/receiver is stan- dard. The system consists of the CD The driver’s and mid-ship passenger’s player/receiver, four speakers, and a seats are two-way adjustable.
  • Page 41: Engine Hood

    & F EATURES UNCTIONS ENGINE HOOD STORAGE COMPARTMENTS Your boat has 12 convenient on-board There are two hood latches located storage compartments. under the front of the rear seat. To open the engine hood, lift both latch Bow Anchor Storage hooks upward and lift the hood.
  • Page 42 & F EATURES UNCTIONS Glove Box Under Rear Side Seats Pull up the seat cushions to access the storage compartments. Port-Side Console Starboard Side Rear Compartment Port Gunwale Battery Compartment Driver’s Side Console WARNING Do not carry any flammable sub- stances in the battery compartment or any heavy or metal items that can damage the battery or cause a short...
  • Page 43: Front Walk-Through

    & F EATURES UNCTIONS FRONT WALK-THROUGH Windshield If desired, the Walk-Through to the bow of the boat can be closed. Doorway Unlatch the folding door from the port side console by pulling the rubber latch. Unfold the door and guide the edge of it into the channel on the dri- ver’s side helm console.
  • Page 44: Swim Platform

    & F EATURES UNCTIONS SWIM PLATFORM The swim platform area provides a place to stand or sit while putting on skis or a wakeboard, and includes a ladder to make boarding from the water easier. To use the ladder, pull it out from underneath the swim platform until it can drop down.
  • Page 45 Chapter 3 OPERATION FUEL AND OIL ..........3-1 Gasoline .
  • Page 46: Operation

    Sport Boat is in the water, be Gasohol containing methanol is not sure it is securely moored to the recommended by Yamaha because it fueling dock. All passengers can cause fuel system damage or must be out of the boat during engine performance problems.
  • Page 47: Engine Oil

    Ring Free Fuel Additive, Do not “top off” the tank, because available from your Yamaha dealer. gasoline could spill out. Be sure to Ring Free has repeatedly proven its tighten the cap securely.
  • Page 48 If the level is above the “F” mark, the engine is overfilled. Consult a 2) If the level is at least at the minimum Yamaha dealer to have oil extracted level “L” mark 2 on the dipstick, but from the engine to avoid damage.
  • Page 49: Pre-Operation Checks

    PERATION PRE-OPERATION WARNING CHECKS If any item in the Pre-Operation check is not working properly, have CHECK LIST it inspected and repaired before operating the Sport Boat. Otherwise Before Operating this Sport Boat, per- an accident could occur. form the following checks: PAGE ITEM CHECK...
  • Page 50: Check Points

    PERATION NOTE: Pre-operation checks should be Throttle/Shifters made each time the boat is used. This procedure can be accomplished thor- oughly in a short time. The added safe- ty and reliability the checks assure is worth the time involved. CHECK POINTS Steering Move the control levers several times 40 45...
  • Page 51: Operation

    A fire extinguisher is not standard equipment with this boat. If you do not have one, contact your local Yamaha Sport Boat dealer or a fire extinguisher dealer to obtain one meeting the prop- er specifications.
  • Page 52 PERATION Jet Intakes Fuel System Refer to page 4-11, “FUEL SYSTEM INSPECTION,” for correct procedure. Fuel and Engine Oil Levels 1) Turn the main switch key to ON. Wait for the fuel gauge needle to stop moving, then note the fuel level.
  • Page 53 PERATION through the large drain hole in the A drain plug is located at the center of the stern to allow more complete drain- deck. A one-way check valve in the ing when the boat is removed from the drain prevents water from traveling water.
  • Page 54 PERATION Engine Compartment Lights Check for proper operation of the bow, Operate the bilge blower switch 1 for stern, and instrument lights by pressing at least 4 minutes before starting the the switch 3 on the control panel. engines. Open engine hood and check to be sure no gasoline vapors are pre- sent.
  • Page 55 PERATION Horn Cooling-Water Pilot Outlets Check that water comes out from the Press the horn switch 1 to be sure the pilot outlets while engine is running in horn operates. the water. Refer to page 2-10 for cor- rect operation of the device. Engine Shut-Off Switch NOTE: It may take up to 20 seconds for water to reach the pilot outlets when...
  • Page 56 PERATION BIMINI TOP 4) Attach the snap hooks to the strap eyes. Raising from the fully collapsed stor- age position. 1) With an assistant, raise the top and secure the rear support poles to the rear support pole mounts with the lock pins.
  • Page 57 The Bimini top must be secured to the 1) Raise the rear support poles. boat when it is being trailered. When trailered with a Genuine Yamaha 2) Unhook the front straps and pull the Cover, simply store the Bimini top in top to the back.
  • Page 58: Starting The Engines

    RESULT IF YOU IGNORE ANY OF THE FOLLOWING: Before operating your Sport Boat, become familiar with all controls. Consult your Yamaha 1) Always make sure the boat is dealer about any control or func- launched and used in waters that tion you do not fully understand.
  • Page 59 PERATION NOTE: Before the first start-up, re- move the fuel tank filler cap to release Engine shut-off switch any built-up pressure in the tank Clip with cord because of fuel expansion. NOTE: It is not possible to start the engine with the clip removed from the engine shut-off switch.
  • Page 60: Stopping The Engines

    PERATION STOPPING THE ENGINES CAUTION: Never turn the ignition key to “Start” while the engine is running. Do not keep the starter motor running for more than 5 seconds. If the engine does not start after 5 seconds of cranking, release the starter button. Wait at least 15 seconds before try- ing to start the engine again.
  • Page 61: Break-In Procedure

    PERATION BREAK-IN PROCEDURE The engine break-in period is essential to allow the various components of the engine to wear and polish themselves to the correct operating clearances. This ensures proper performance and promotes longer component life. 1) Launch the boat and start the engine.
  • Page 62: Driving Your Sport Boat

    PERATION DRIVING YOUR Know and follow U.S. Coast Guard, state, and local laws when operating SPORT BOAT your Sport Boat. Select a wide area to learn in, where GETTING TO KNOW YOUR visibility is good and other boat traffic is SPORT BOAT light.
  • Page 63: Turning The Sport Boat

    PERATION TURNING THE SPORT BOAT D. If the engines are stopped, there is no thrust. The Sport Boat will go Steering control depends on the com- straight even though the steering bination of steering wheel position and wheel is turned. the amount of throttle.
  • Page 64: Boating With Passengers

    PERATION TURNING LEFT BOATING WITH PASSENGERS When one or more passengers are on board, the boat may handle differently, 40 45 so operating it requires a higher degree x 1000 x 1000 FUEL of skill. Remember: Your Sport Boat designed for one operator and up to nine passengers only.
  • Page 65: Boarding From A Dock Or Landing Jetty

    PERATION WARNING Stay away from the swim step while the engines are running. Exhaust gases coming from underneath it contain carbon monoxide, a color- less, odorless gas which may cause brain damage death when inhaled. Symptoms include nausea, dizziness, and drowsiness. 2) Climb up onto the swim platform, then sit in one of the seats provided.
  • Page 66: Stopping

    PERATION STOPPING 2) Notice how wind and water currents are affecting boat movement as you attach your mooring lines and fenders. 3) Approach the dock at idle speed. Use reverse as necessary during 345 ft (105 m) slow speed maneuvering to help control speed direction.
  • Page 67: Leaving A Dock

    PERATION Wind or current pushing boat 2) When the stern is out a few feet, toward dock: release the bow mooring then steer in the direction you want the bow to move. Open the throttle slightly and WIND OR CURRENT begin to move away from the dock.
  • Page 68: Anchoring

    PERATION ANCHORING 4) Pull on the line to be sure the anchor is holding. Also, periodically check your boat’s position against WARNING the shoreline to make sure it is not Always anchor from the bow. drifting and dragging the anchor. Anchoring from the stern will make Reset it if necessary.
  • Page 69: Crossing Wakes And Swells

    PERATION CROSSING WAKES AND SWELLS You will not always have flat, smooth water. There will be swells, wakes from other boats, etc. SHARP WAKES The best way to cross wakes and swells is with the least jolt to you and the boat.
  • Page 70: Post-Operation Checks

    PERATION POST-OPERATION 1) After putting the Sport Boat on the trailer, flush cooling system on each CHECKS engine to prevent the cooling sys- tem from clogging up with salt, POST-OPERATION CHECKS sand, or dirt. Refer to page 4-1 for the cooling system flushing proce- These post-operation procedures are dure.
  • Page 71 Sport Boat. Clean any foreign material, such as dirt or sand, from the threads before installing the drain plug. 6) Spray a rust inhibitor, such as Yamaha Silicone Protectant and Lubricant, on metallic parts to mini- mize corrosion. 3-26...
  • Page 72: Trailering

    PERATION TRAILERING HITCH The trailer hitch ball must match the size of the socket on the trailer hitch WARNING coupler. Hitches are divided into class- es that specify the gross trailer weight Avoid accident and injury from (GTW) and the maximum tongue improper trailering: weight.
  • Page 73: Backing Your Trailer

    PERATION it is a good idea to carry a set of Check wheel bearings and wheel spare wheel bearings, seals, and lug nuts before each trip. races. Check tail, brake, and turn signal When making a turn, do not cut cor- lights for proper operation.
  • Page 74: Launching

    PERATION LAUNCHING 5) Remove the bow line from the bow eye. 6) Back the trailer farther into the water until just the tops of the fend- ers show, then reset the parking brake. Board the boat and start it. If possible, remain on the trailer until the engines are warm and are responding to throttle.
  • Page 75: Lifting

    4) Make sure the boat is centered on LIFTING the support rails and is headed CAUTION: straight for the bow stop (bumper board). Ease the boat forward until Do not attach lifting cables to the the bow rests against the bow stop. bow eye, cleats, water-ski tow eye, or grab handles.
  • Page 76 Chapter 4 MAINTENANCE AND CARE STORAGE ..........4-1 Fuel System .
  • Page 77: Storage

    It is advis- able to have the Sport Boat serviced by an authorized Yamaha Sport Boat deal- er before storage. However, the follow- ing procedures can be performed by the owner with a minimum of tools.
  • Page 78: Lubrication

    6) Replace the cap securely. 7) Repeat the flushing procedure for the other engine. LUBRICATION WARNING 4) Spray a rust inhibitor such as Yamaha Store-Rite Fogging Oil into spray flammable rust each intake opening 3 for 3 sec- inhibitor on engine surfaces while onds.
  • Page 79: Battery

    & C AINTENANCE 7) Grease the areas of the Sport Boat 3) If the battery will be stored for a specified in “Grease Points” in the longer period, check the specific Adjustment and Maintenance sec- gravity of the fluid at least once a tion.
  • Page 80: Cleaning

    4) Spray the exterior of the engines with Yamaha Silicone Protectant and Lubricant or an equivalent. 5) Wax the hull with a non-abrasive wax such as Yamaha Ultra Gloss Cleaner Wax or other wax designed for marine gelcoat. WARNING Slippery surfaces can cause falls WARNING and injury.
  • Page 81: Adjustment And Maintenance

    If the owner is not familiar with machine servicing, this work should be done by a Yamaha dealer or other qualified mechan- ic. Improperly serviced compo- nents could fail or stop operating correctly, which could result in an accident.
  • Page 82: Periodic Inspection Chart

    Frequency of maintenance operations may be adjusted according to the operating conditions, but the following table gives general guidelines. ● Indicates the checkups which you may do yourself. ■ Indicates work to be done by your Yamaha dealer. Maintenance interval Initial Thereafter Page...
  • Page 83: Spark Plug Cleaning And Adjustment

    Do not attempt to diagnose any prob- the spark plug cap down until it clicks. lems yourself. Instead, take the Sport Boat to a Yamaha Sport Boat dealer. You should periodically remove and NOTE: If a torque-wrench is not avail-...
  • Page 84: Grease Points

    AINTENANCE GREASE POINTS To keep moving parts sliding or rotating smoothly, coat them with water resis- tant grease such as Yamaha Marine Grease, Yamaha Grease A, or an equiv- alent. Throttle Cable Grease the throttle-cable inner wires at the carburetors.
  • Page 85 Recommended water-resistant grease: Yamaha Marine Grease, or Yamaha Grease A The first service should be done after 10 hours or 1 month by your Yamaha dealer. Fill the bearing housing with water resistant grease through the grease nipple. Grease capacity: 33.0~35.0 cc (1.11~1.18 oz)
  • Page 86: Fuel System Inspection

    2 the port- Check the fuel system for leaks, cracks, or malfunctions. If any problem side storage compartment. Remove is found, consult a Yamaha dealer. the seat cushion then look up inside the compartment to see the fuel filler hose Checking points: and clamp.
  • Page 87: Engine Oil

    & C AINTENANCE FUEL TANK It is recommended to have a Yamaha dealer change the engine oil. However, If the fuel tank needs to be cleaned or if you choose to change the oil on your when any water is found in the fuel sys-...
  • Page 88: Air Filter Element

    & C AINTENANCE AIR FILTER The air filter element should be checked every 12 months or every 100 hours of operation. To check the air filter: 1) Open the hood (see page 2-14). 2) Remove the air filter case cover screws 1, slide the locks 2 to open, and then remove the case cover.
  • Page 89: Steering Cable Inspection

    1) Check for smooth operation of the wheel and steering nozzles. 2) Check for proper steering adjust- ment. The nozzles should both point straight back when the steering wheel is centered. If steering is stiff or misadjusted, ask your Yamaha dealer to service it. 4-13...
  • Page 90: Reverse Gate Mechanism Inspection

    Reverse position. Check that the shift gates drop down over the noz- zles to the stops. If the controls do not operate smoothly or correctly, ask your authorized Yamaha Sport Boat dealer for service. 4) Pull the shift lever back from Forward through Neutral Reverse.
  • Page 91: Fuse Replacement

    & C AINTENANCE FUSE REPLACEMENT WARNING Do not use fuses of higher amper- that those recommended. Substitution of a fuse of improper rating can cause extensive electrical system damage and possible fire. BATTERY The fuse is in the ignition coil holder. To NOTE: These general guidelines apply replace the fuse, unscrew the cap to many commonly used battery types...
  • Page 92 & C AINTENANCE Recharging WARNING WARNING Battery electrolyte is poisonous and dangerous, causing severe burns, ● When charging the battery, keep etc. It contains sulfuric acid. Avoid it well away from sparks and contact with skin, eyes or clothing. open flames, as it gives off explo- sive gases.
  • Page 93 & C AINTENANCE Battery Switch This model includes a battery discon- nect switch. Turn this switch to the Off position when you want to be sure no battery power is available, such as dur- ing storage to prevent accidental dis- charge of the battery or during service work.
  • Page 94: Specifications

    & C AINTENANCE SPECIFICATIONS MODEL ITEM UNIT SRT1000-B/C-B VEHICLE CAPACITY Maximum people on board Number of people Maximum load capacity 1800 DIMENSIONS Length feet / inches 23' / 2761" Beam feet / inches 8.53' /102.4" Draft inches 18" Dry weight 3025 Height on trailer feet / inches...
  • Page 95 Chapter 5 TROUBLESHOOTING & SPECIAL PROCEDURES TROUBLESHOOTING ........5-1 Troubleshooting Chart .
  • Page 96: Troubleshooting

    If any trouble happens on your Sport Boat, use this section to check for possible cause. If you cannot find the cause or if the procedure for replacement or repair is not described in this owner's manual, ask your Yamaha Sport Boat dealer or qualified mechanic for the proper ser- vice.
  • Page 97 • Refill as soon as possible Engine runs irregularly or Stale or • Have serviced at stalls • Fuel contaminated Yamaha dealer Water or dust • Have serviced at • Fuel filter collected Yamaha dealer Fouled or defective • Replace •...
  • Page 98: Special Procedures

    & S ROUBLESHOOTING PECIAL ROCEDURES EMERGENCY WARNING PROCEDURES The operator of the towing boat must keep speed to a minimum and TOWING THE SPORT BOAT avoid traffic or obstacles which could be a hazard to the driver on the Sport Boat. RUNNING ON ONE ENGINE If one engine becomes inoperative, the properly running engine can be used to...
  • Page 99: Jump Starting

    & S ROUBLESHOOTING PECIAL ROCEDURES JUMP STARTING 2) Connect one end of the negative (–) jumper cable to the negative (–) ter- minal of the booster battery. 3) Connect the other end of the nega- tive (–) cable to an engine hanger on either side of the engine oil tank.
  • Page 100: Jet Pump Clean-Out Procedure

    Yamaha Sport Boat Dealer. 2) Lift the hatch on the rear platform. 5) To reinstall the access port cap, first clean off any sand or other foreign matter from the cap or port surfaces.
  • Page 101 & S ROUBLESHOOTING PECIAL ROCEDURES 6) Press the T-handle down firmly to CAUTION: lock the cap in place. Pull up force- ● Be sure the caps are locked fully on the handle to be sure it is securely in place. Otherwise the locked.
  • Page 102 LIMITED WARRANTY ........6-1 YAMAHA EXTENDED SERVICE (Y.E.S) ......6-4 BOATING TERMS .
  • Page 103 Owner’s Manual. The owner of the Sport Boat shall give notice to an authorized Yamaha Sport Boat dealer of any and all apparent defects within ten (10) days of discovery and make the boat available at that time for inspection and repairs at the dealer’s place of business.
  • Page 104 Charges for transporting the Sport Boat to and from an authorized Yamaha Sport Boat dealer are excluded from warranty coverage.
  • Page 105 2. Explain the operation, maintenance, and warranty requirements to your satisfaction at the time of sale, and upon your request at any later date. In addition, each Yamaha Sport Boat dealer is held responsible for his setup, service and warranty repair work.
  • Page 106 This excellent Y.E.S. plan coverage is only tection on the hull. available to Yamaha owners like you, and only while your Yamaha is still within the first year ● Y.E.S. is designed and administered by of the Yamaha Limited Warranty period. So...
  • Page 107 & I ONSUMER NFORMATION NDEX BOATING TERMS TERM DEFINITION The front part of the boat. Deck The “floor” or upper structure which covers the hull. Give-Way The vessel which must yield the right-of-way when two boats meet. Gunwale The meeting junction of the deck and hull; the upper edge around the boat.
  • Page 108: Float Plan

    SAMPLE FLOAT PLAN Leave a float plan with a responsible person on shore before boating. The exam- ple below can be copied and used. FLOAT PLAN VESSEL INFORMATION BOAT MAKE: Yamaha MOTOR TYPE: Jet MODEL: LENGTH.: REGISTRATION NO: DECK COLOR:...
  • Page 109 & I ONSUMER NFORMATION NDEX Checks: Access port caps ..3-6, 5-5 Accident Reporting ... . . 1-20 Battery condition ..3-7, 4-3, 4-15 Access Port Caps .
  • Page 110 & I ONSUMER NFORMATION NDEX Docking ..... . 3-21 Drain plugs ... . 3-8, 3-26, 4-4 Garden hose adapter .
  • Page 111 & I ONSUMER NFORMATION NDEX Limit on starter motor Pre-operation checks ... . 3-5 running period ....3-15 Primary Identification number .
  • Page 112 Tachometers ....2-9 Yamaha Extended Service (Y.E.S.) . . 6-4 Throttle/shift ..1-12, 2-7, 3-5, 3-18 Throttle cable inspection .
