INCLUDED IN YOUR PACKAGE

Handset
Line Cord
CONNECTING THE OPAL 1010S
1. Located on the left side of the Opal 1010S (as the phone is facing you) is
a modular jack. Insert one end of the coiled handset cord into this jack (you
should hear the coil cord click when properly inserted).
2. Insert the other end of the coiled handset cord into the modular jack on
the handset.
3. Turn the telephone so the back panel is facing you. Insert either end of
the line cord into the jack on the back of the telephone labeled LINE.
4. Insert the other end of the line cord into a telephone wall outlet jack.
5. Once your telephone is connected, remove the plastic overlay and place
the paper faceplate over the keys. Replace the plastic overlay by hooking the
tabs on the overlay into the recessed slots located on both sides. The overlay
is easiest to insert when; the left or right side tabs are inserted first, and the
middle of the overlay is slightly bowed to allow for insertion of the other
tabs.

PLACING A CALL

USING THE HANDSET

1. Lift the handset.
2. Listen for dial tone. Dial the desired number, or press an AUTO DIAL key
to automatically dial a number.
3. To end the call, hang up by placing the handset back in the cradle.
USING THE SPEAKERPHONE
1. With the handset in the cradle, press the SPEAKER key. The Opal will
engage the open line.
NOTE: The red SPEAKER LED will indicate that the speakerphone is active.
2. Listen for dial tone, dial the desired number, or press an AUTO DIAL key
to automatically dial a number.
3. To end call the call press the SPEAKER key again.

RECEIVING A CALL

An audible ring and flickering red LED indicate an inbound call.
USING THE HANDSET
1. Lift the handset. The Opal will select the ringing line.
2. To end the call hang up the handset.
Base Unit
Clear Plastic Overlay
Coiled Handset Cord
User Guide
1
