- Page 1 ENGLISH KD-R616 CD RECEIVER / For canceling the display demonstration, see page 4. / For installation and connections, refer to the separate manual. INSTRUCTIONS GET0639-001A [U/UH]...
-
Page 2: How To Read This Manual
Thank you for purchasing a JVC product. Please read all instructions carefully before operation, to ensure your complete understanding and to obtain the best possible performance from the unit. IMPORTANT FOR LASER PRODUCTS 1. CLASS 1 LASER PRODUCT 2. CAUTION: Do not open the top cover. There are no user serviceable parts inside the unit; leave all servicing to qualified service personnel. -
Page 3: Table Of Contents
How to attach/detach the control CONTENTS panel How to read this manual How to attach/detach the control panel How to reset your unit How to forcibly eject a disc Canceling the display demonstration How to reset your unit Setting the clock Preparing the remote controller Your preset adjustments (RM-RK50) -
Page 4: Canceling The Display Demonstration
Canceling the display demonstration Turn on the power. Select <DEMO OFF>. [Hold] (Initial setting) Finish the procedure. Setting the clock Turn on the power. [Hold] (Initial setting) Select <CLOCK>. Select <CLOCK SET>. Adjust the hour. Adjust the minute. Finish the procedure. ENGLISH... -
Page 5: Preparing The Remote Controller (Rm-Rk50)
Preparing the remote controller (RM-RK50) Warning (to prevent accidents and When you use the remote controller for the first time, pull out the insulation sheet. damage): • Do not install any battery other than CR2025 or its equivalent. • Do not leave the remote controller in a place (such as dashboards) exposed to direct sunlight for a long time. -
Page 6: Basic Operations
Basic operations Ejects the disc Display window Loading slot USB (Universal Serial Bus) input jack Control dial Auxiliary input jack Detaches the panel Remote sensor • DO NOT expose to bright sunlight. When you press or hold the following button(s)... Remote Main unit General operation... -
Page 7: Listening To The Radio
Remote Main unit General operation controller • Enters <COLOR> setting directly ( 24). — • Enters <COLOR SETUP> setting directly ( 25) if pressed and held. — Returns to the previous menu. Power off : Checks the current clock time. —... -
Page 8: Selecting A Preset Station
Manual presetting (FM/AM) Title assignment You can preset up to 18 stations for FM and 6 You can assign titles up to 30 station stations for AM. frequencies (FM and AM) using 8 characters (maximum) for each title. Ex.: Storing FM station of 92.50 MHz into preset •... -
Page 9: Listening To A Disc
Listening to a disc Ÿ ] Turn on the power. All tracks will be played repeatedly until you change the source or eject the disc. Stopping playback and ejecting Caution on volume setting: Discs produce very little noise compared the disc with other sources. -
Page 10: Listening To The Usb Device
Changing the display information Using the remote controller 5 U / D ∞ : Selects folder of the MP3/WMA Disc title/Album name/performer (folder 2 R / F 3 : Selects track name)* = Track title (file name)* = Current 2 R / F 3 : Fast-forwards or track number with the elapsed playing time [Hold]... -
Page 11: Using Bluetooth ® Devices
Cautions: • You cannot connect a computer to the USB input terminal of the unit. • Avoid using the USB device if it might hinder • Make sure all important data has been backed your safety driving. up to avoid losing the data. •... -
Page 12: Deleting A Registered Device
Repeat step 3 on page 11 until you have finished entering the PIN code. ] Select a device you want to connect. For available devices... “OPEN..” flashes. ] Enter the specific PIN code of the Use the Bluetooth device to search and device to the unit. -
Page 13: Using A Bluetooth Mobile Phone
When a text message comes in..If the mobile phone is compatible with text message (notified through JVC Bluetooth adapter) and “MSG INFO” (message info) is set to “AUTOMATIC” ( 15), the unit rings to inform you of the message arrival. -
Page 14: Using A Bluetooth Audio Player
For REDIAL, RECEIVED, MISSED Reverse skips/forward ] Repeat step 4 on page 13 to select skips a name (if it is acquired) or a phone Pauses/starts playback* number. * Operation may be different For PHONE BOOK according to the connected ] Repeat step 4 on page 13 to select a Bluetooth audio player. - Page 15 Bluetooth Information: and displaying “RCV MESSAGE” If you wish to receive more information (receiving message). about Bluetooth, visit the following JVC web • The display illuminate in blue. site: <http://www.jvc.co.jp/english/car/> (<RING COLOR>, (English website only)
-
Page 16: Listening To The Ipod/Iphone
Listening to the iPod/iPhone You can connect the iPod/iPhone using the USB 2.0 cable (accessory of the iPod/iPhone) to the USB input jack on the control panel. Apple iPod/iPhone USB input jack USB 2.0 cable (accessory of the iPod/iPhone) • Disconnecting the iPod/iPhone will stop The operations explained below are under playback. -
Page 17: Selecting The Playback Modes
: Fast-forwards or [Hold] reverses the track ] “REPEAT” j “RANDOM” Notice: When operating an iPod, some operations may not be performed correctly or as intended. In this case, visit the following JVC web site: <http://www.jvc.co.jp/english/car/> (English website only) ENGLISH... -
Page 18: Listening To The Other External Components
Listening to the other external components You can connect an external component to: • EXT INPUT: Expansion port on the rear of this unit using the following adapters (not ] “EXT INPUT” or “AUX IN” supplied): Ÿ Turn on the connected –... -
Page 19: Selecting A Preset Sound Mode
Selecting a preset sound mode You can select a preset sound mode suitable Storing your own sound mode for the music genre. You can store your own adjustments in memory. FLAT = NATURAL = DYNAMIC = VOCAL [Hold] BOOST = BASS BOOST = USER = (back to the beginning) While listening, you can adjust the tone level of ] <PRO EQ>... -
Page 20: Menu Operations
Menu operations Repeat step 2 if necessary. [Hold] • To return to the previous menu, press BACK. • To exit from the menu, press DISP or MENU. Category Menu item Selectable setting, [ Initial: Underlined DEMO • DEMO ON : Display demonstration will be activated Display automatically if no operation is done for about demonstration... - Page 21 Category Menu item Selectable setting, [ Initial: Underlined SSM * • SSM 01 – 06 : For settings, Strong-station • SSM 07 – 12 Sequential • SSM 13 – 18 Memory MONO * • MONO ON : Activate monaural mode to improve FM Monaural mode reception, but stereo effect will be lost.
- Page 22 Category Menu item Selectable setting, [ Initial: Underlined FADER * R06 – F06 : Adjust the front and rear speaker output [00] balance. BALANCE * L06 – R06 : Adjust the left and right speaker output [00] balance. LOUD • LOUD ON : Boost low and high frequencies to produce a Loudness well-balanced sound at a low volume level.
- Page 23 Category Menu item Selectable setting, [ Initial: Underlined BEEP • BEEP ON : Activates the keypress tone. Keytouch tone • BEEP OFF : Deactivates the keypress tone. AMP GAIN * • LOW POWER : VOLUME 00 – VOLUME 30 (Select if the Amplifier gain maximum power of each speaker is less than control...
- Page 24 Selecting the variable buttons and display color illumination You can select your preferred color for buttons illumination (except for EQ/BASS-TRE / DISP) and display color separately. Button zone Display zone All zone Repeat steps 2 and 3 to select a [Hold] different zone and your preferred color.
- Page 25 Creating your own day and night colors—USER You can create your own colors for <DAY COLOR> and <NIGHT COLOR> to apply to button zone and display zone. • <DAY COLOR> Displayed when <DIMMER> is set to <DIMMER OFF>. • <NIGHT COLOR> Displayed when <DIMMER> is set to <DIMMER ON>. Menu hierarchy Operation •...
-
Page 26: More About This Unit
More about this unit Basic operations • When a disc is inserted upside down, “PLEASE” and “EJECT” appear alternately on the display. General Press 0 to eject the disc. • If you turn off the power while listening to • If the ejected disc is not removed within a track, playback will start from where it had 15 seconds, it is automatically inserted into been stopped previously next time you turn... - Page 27 – Discs on which labels can be directly printed • This unit cannot play back the following files: by an ink jet printer. – MP3 files encoded in MP3i and MP3 PRO Using these discs under high temperature format. or high humidity may cause malfunctions or –...
-
Page 28: Bluetooth Operations
• The maximum number of characters for: • This unit may not work for some Bluetooth – Folder names : 32 characters devices. – File names : 32 characters • Connecting condition may vary depending – MP3 Tag : 64 characters on the circumstances around you. -
Page 29: Maintenance
Maintenance How to clean the connectors To keep discs clean Frequent detachment will deteriorate the A dirty disc may not play connectors. correctly. If a disc does become dirty, wipe it with a soft cloth To minimize this possibility, periodically wipe the connectors with a cotton swab or cloth in a straight line from center to moistened with alcohol, being careful not to... -
Page 30: Troubleshooting
( If “PROTECT” does not disappear, consult your JVC car audio dealer or a company supplying kits. The unit does not work at all. - Page 31 Symptom Remedy/Cause Disc cannot be played back. • Use a disc with MP3/WMA tracks recorded in a format compliant with ISO 9660 Level 1, Level 2, Romeo, or Joliet. • Add the extension code <.mp3> or <.wma> to the file names.
- Page 32 Symptom Remedy/Cause • “CANNOT PLAY” flashes on • Attach a USB device that contains tracks encoded in the display. an appropriate format. • “NO USB” appears on the • Reattach the USB device again. display. • The unit cannot detect the USB device.
- Page 33 ( 28). JVC bears no responsibility for any loss of data in an iPod/iPhone and/or USB mass storage class device while using this System. • Microsoft and Windows Media are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.
-
Page 34: Specifications
Specifications Maximum Power Output: Front/ 50 W per channel Rear: Continuous Power Output (RMS): Front/ 20 W per channel into 4 Ω, 40 Hz to Rear: 20 000 Hz at no more than 1% total harmonic distortion. Load Impedance: 4 Ω (4 Ω to 8 Ω allowance) Tone Control Range: Bass: ±12 dB (60 Hz, 80 Hz, 100 Hz, 200 Hz) - Page 35 Type: Compact disc player Signal Detection System: Non-contact optical pickup (semiconductor laser) Number of Channels: 2 channels (stereo) Frequency Response: 5 Hz to 20 000 Hz Dynamic Range: 96 dB Signal-to-Noise Ratio: 98 dB Wow and Flutter: Less than measurable limit MP3 Decoding Format: (MPEG1/2 Audio Layer 3) Max.
